IDTECK iTDC Mode d'emploi
2011 Jan IDTECK. © All rights reserved
1
2014 IDTECK. © All rights reserved
IDTECK TROUBLE SHOOTING
2011 Jan IDTECK. © All rights reserved
2
1) How to set up in/output configuration according to number of doors. l 4
2) Error occurs when installing SQL Database. l 9
3) All the software have been installed, but error message appears and can’t log-in to the software. l 13
1) Door does not open. l 16
2) Communication does not work. l 24
3) Response speed of Event has slowed. l 32
4) I would like to print T&A report, but I can’t find the report. l 33
5) I don’t know how to do a database backup. l 34
6) Can I recover a database backup file? l 37
7) How can I have a backup database automatically with arranged schedule? l 40
8) I have used the software for long time. The software has slowed down and “Database Insert Error”
message appears. l 47
1. Installation
2. Management
Contents
3. Technical Training (Communication & System Integration)
2011 Jan IDTECK. © All rights reserved
3
1. Installation (iTDC / iTDC PRO)
1) How to set up in/output configuration according to number of doors.
2) Error occurs when installing SQL Database.
3) All the software have been installed, but error message appears
and can’t log-in to the software.
2011 Jan IDTECK. © All rights reserved
4
1) How to set up in/output configuration according to number of doors.
Solution
①IN/OUTPUT Configuration for 1~2 Door Control (Basic Configuration)
※ 2 Doors / Using In Reader Only (2 Readers) : Connect to iTDC Main Board
2 Doors / Using In-Out Reader (4 Readers) : Same with Configuration of Door 1 & 2 for 3 Door Control
(Refer to Next Page)
Input Ports #1
Exit Button for Door 1
Output to Output Port #1
Input Ports #2
Door Contact for Door 1
Output to Output Port #2
Input Ports #3
Exit Button for Door 2
Output to Output Port #3
Input Ports #4
Door Contact for Door 2
Output to Output Port #4
Output Ports #1
Door Lock for Door 1
Input Port #1,
Output for Reader #1
Output Ports #4
Alarm for Door 2
Input Port #4,
Output for Reader #2
Output Ports #3
Door Lock for Door 2
Input Port #3,
Output for Reader #2
Output Ports #2
Alarm for Door 1
Input Port #2,
Output for Reader #1
iTDC Main Board
2011 Jan IDTECK. © All rights reserved
5
②IN/OUTPUT Configuration for 3 Door Control (Basic Configuration)
※ 1 Door / Using In-Out Reader : Connect to iTDC Main Board
2~3 Door / Using In Reader Only : Connect to EIO88 Board
iTDC Main Board
Output Ports #2 (MAIN)
Alarm for Door 1
Input Port #2,
Output for Reader #1 & 2
Input Ports #1 (MAIN)
Exit Button for Door 1
Output to Output Port #1
Output Ports #1 (MAIN)
Door Lock for Door 1
Input Port #1,
Output for Reader #1 & 2
Input Ports #2 (MAIN)
Door Contact for Door 1
Output to Output Port #2
1) How to set up in/output configuration according to number of doors.
2011 Jan IDTECK. © All rights reserved
6
EIO88 Expansion Board
Output Ports #4 (EIO88)
Alarm for Door 3
Input Port #4,
Output for Reader #4
Output Ports #3 (EIO88)
Door Lock for Door 3
Input Port #3,
Output for Reader #4
Output Ports #2 (EIO88)
Alarm for Door 2
Input Port #2,
Output for Reader #3
Output Ports #1 (EIO88)
Door Lock for Door 2
Input Port #1,
Output for Reader #3
Input Ports #1 (EIO88)
Exit Button for Door 2
Output to Output Port #1 (EIO88)
Input Ports #2 (EIO88)
Door Contact for Door 2
Output to Output Port #2 (EIO88)
Input Ports #3 (EIO88)
Exit Button for Door 3
Output to Output Port #3 (EIO88)
Input Ports #4 (EIO88)
Door Contact for Door 3
Output to Output Port #4 (EIO88)
※ 1 Door / Using In-Out Reader : Connect to iTDC Main Board
2, 3 Door / Using In Reader Only : Connect to EIO88 Board
1) How to set up in/output configuration according to number of doors.
2011 Jan IDTECK. © All rights reserved
7
※Door 1, 2: Connect to iTDC Main Board
Door 3, 4: Connect to EIO88 Board (Refer to Next Page)
③IN/OUTPUT Configuration for 4 Door Control (Basic Configuration)
Input Ports #1
Exit Button for Door 1
Output to Output Port #1
Input Ports #2
Door Contact for Door 1
Output to Output Port #2
Input Ports #3
Exit Button for Door 2
Output to Output Port #3
Input Ports #4
Door Contact for Door 2
Output to Output Port #4
Output Ports #1
Door Lock for Door 1
Input Port #1, Output for Reader #1
Output Ports #4
Alarm for Door 2
Input Port #4, Output for Reader #2
Output Ports #3
Door Lock for Door 2
Input Port #3, Output for Reader #2
Output Ports #2
Alarm for Door 1
Input Port #2, Output for Reader #1
iTDC Main Board
1) How to set up in/output configuration according to number of doors.
2011 Jan IDTECK. © All rights reserved
8
Solution
Input Ports #1 (EIO88)
Exit Button for Door 3
Output to Output Port #1 (EIO88)
Output Ports #1 (EIO88)
Door Lock for Door 3
Input Port #1(EIO88), Output for Reader #3
Output Ports #4 (EIO88)
Alarm for Door 4
Input Port #4(EIO88), Output for Reader #4
Output Ports #3 (EIO88)
Door Lock for Door 4
Input Port #3(EIO88), Output for Reader #4
Input Ports #3 (EIO88)
Exit Button for Door 4
Output to Output Port #3 (EIO88)
Input Ports #4 (EIO88)
Door Contact for Door 4
Output to Output Port #4 (EIO88)
Input Ports #2 (EIO88)
Door Contact for Door 3
Output to Output Port #2 (EIO88)
Output Ports #2 (EIO88)
Alarm for Door 3
Input Port #2(EIO88), Output for Reader #3
EIO88 Expansion Board
※Door 1, 2: Connect to iTDC Main Board
Door 3, 4: Connect to EIO88 Board
1) How to set up in/output configuration according to number of doors.
2011 Jan IDTECK. © All rights reserved
9
2) Error occurs when installing SQL Database.
Solution
①Did You Install SQL Server 2005 Express Edition as Indicated Below?
※ Following products must be installed to the computer prior to installing SQL Server 2005
Express Edition
ㆍMicrosoft .NET Framework 2.0
ㆍMS-XML6
ㆍCheck ” I accept the licensing terms
and conditions”, Click Next
ㆍClick Install ㆍInitial Installation Complete,
Click Next
2011 Jan IDTECK. © All rights reserved
10
ㆍBegin Installation of SQL Server,
Click Next
ㆍConfirm the SQL Server System
Configuration Check, Click Next
ㆍInsert ”Name / Company “
ㆍUn-check “Hide advanced configuration
options”, Click Next
ㆍSelect “Entire feature will be installed
on local hard drive” for Database Service
and Client Components, Click Next
ㆍClick Next ㆍSelect ”Default Instance”,
Click Next
2) Error occurs when installing SQL Database.
