TECHNICAL MANUAL

MODEL: 61-700

MODEL: 61-701

MODEL: 61-702

MODEL: 61-704

The Service Information provides the following information:

•Precautions and safety information

• Specifications

• Performance test procedure

• Calibration and calibration adjustment procedure

• Basic maintenance (replacing the battery)

Form number: TM61700-1-2-4

Revision: 4. Date: Sept 2004

Form number TM61700-1-2-4 Rev 4 September 2004

TABLE OF CONTENTS

Title Page

Introduction 1

Precautions and Safety Information 1

Symbol Table 1

Safety Information 2

Indicator Functions 2

Certifications and compliance 2

Specifications 3

General Specification 3

Voltage Specifications 4

Current Specifications 4

Resistance Specifications 4

Frequency Specification 4

Capacitance Specifications 4

Diode / Continuity Specifications 4

Performance Verification 5/6

Calibration 6/7

Calibration Reference Points 8

Replacing the Battery 9

Form number TM61700-1-2-4 Rev 4 September 2004

Page 1

Introduction Warning

To avoid shock or injury, do not perform the verification

tests or calibration procedures described in this manual

unless you are qualified to do so.

The information provided in this document is for the use

of qualified personnel only.

Caution

The 61-700 series contains parts that can be damaged by static

discharge. Follow the standard practices for handling static sensitive

devices.

For additional information about IDEAL INDUSTRIES, INC. and its products,

and services, visit IDEAL INDUSTRIES, INC. web site at:

www.idealindustries.com

Precautions and Safety Information

Use the meter only as described in the Users Manual. If you do not

do so, the protection provided by the meter may be impaired.

Read the “Safety Information” page before servicing this product.

In this manual, a Warning identifies conditions and actions that

pose hazard (s) to the user; a Caution identifies conditions and

actions that may damage the meter or the test instruments.

The Symbols

The symbols used on the Meter and in this manual are explained

in Table A.

Table A Symbols

Symbol Description Symbol Indicator Lights

Battery HI-V High Voltage Indicator

>30 V indicator is on

Cautionary or important

information in manual NCV Non-Contact indicator

Danger- Risk of electrical

shock Continuity indicator

Double Insulation- Protection

Class II CP Clean power indicator

On if power is Clean

Off if power has > 5% THD

CAT III IEC Over-voltage Category III

Form number TM61700-1-2-4 Rev 4 September 2004

Page 2

SAFETY

Review the following safety precautions to avoid injury and prevent damage to this product or any

products connected to it. To avoid potential hazards, use the product only as specified.

CAUTION.

These statements identify conditions or practices that could result in damage to the equipment or other

property.

WARNING.

These statements identify conditions or practices that could result in personal injury or loss of life.

Specific precautions:

Do not operate without covers. To avoid personal injury, do not apply any voltage or current to the

product without the covers in place.

Electric overload. Never apply a voltage to a connector on the product that is outside the range specified

for that connector.

Avoid electric shock. To avoid injury or loss of life, do not connect or disconnect probes or test leads

while they are connected to a voltage source.

Do not operate in wet/damp conditions. To avoid electric shock, do not operate this product in wet or

damp conditions.

Indicator Functions:

• Hi-V: In ACV, DCV, Resistance, and Continuity/Diode test, the end user will get an audible

warning and the Hi-V light will blink if there is Voltage Greater that 30V present at the input

terminals.

o In addition to the LED and audible beep, the 61-702 and 61-704 has a tactile vibration

when voltage is present.

• NCV: When the NCV button is pressed, the analog to digital circuit is turned off and the NCV

circuit is activated. Sensing for the NCV is at the tip of the Clamp Jaw or by the Red Test Lead in

the red (+) input terminal. Follow the operation instructions giving in the operator’s manual for

proper use of this function. The NCV function is on Ideal Models 61-701,61-702, and 61-704.

• CP: When the 60Hz AC power is clean, with less than 5% Total Harmonics Distortion (THD) on

AC voltage, the green CP light will be energized. If there is greater that 5% THD on the line, the

green CP light will be de-energized.

Certifications and compliances

Safety Designed to IEC 1010-1, UL3111-1 and CSA specifications

1000V DC Category III {61-702, 61-704}

600V DC Category III {61-700, 61-701}

750V AC Category III {61-702, 61-704}

Input rating

600V AC Category III {61-700, 61-701}

CAT III: Distribution level mains, fixed installation.

CAT II: Local level mains, appliances, and portable equipment.

Over voltage category CAT I: Signal level, special equipment or parts of

equipment, telecommunication, electronics.

Form number TM61700-1-2-4 Rev 4 September 2004

Page 3

General specifications

Characteristics Description

Display 3½ Digit LCD display

Display Count 2000 count, maximum reading 1999

Over range Indication “OL” is displayed

Sampling Rate 2.5 time/second

Operating Environment:

Relative Humidity 0°C to 50°C (32°F to 122°F)

0 ~ 75% RH

Storage Environment: -20°C to 60°C (-4°F to 140°F) at <80 relative humidity

Power source: 9V Battery (NEDA 1604)

Battery Live: 300 hours typical (alkaline) {61-700 and 61-701}

150 hours typical (alkaline) {61-702 and 61-704}

Low Battery Indicator: symbol indicates low battery voltage

Auto power off Approximately 60 minutes

Dimensions 9.7” H X 3.7” W X 1.8” D

247mm H X 94mm W X 46mm D

Maximum Cable Size ACA 1¼” (32mm)

Weight: Approximately 13.4 oz. or 430g including battery

RANGES and ACCURACY SPECIFICATION

Accuracy: Accuracy specifications at 23°C ±5°C (73.4°F ±9°F) less than 75% RH.

Temperature Coefficient: 0.1 times the applicable accuracy specification per degree C

from 0°C to 18°C and 28°C to 50°C (32°F to 64°F and 82°F to 122°F)

Electrical Specification: Accuracy are ±(reading plus number of digits) at 23°C ±5°C <75% RH

Form number TM61700-1-2-4 Rev 4 September 2004

Page 4

61-700

Function /

Range Ranges Accuracy

200V, 50Hz - 500Hz 1.2% + 3digits

AC Voltage 200V, 50Hz - 1KHz 2.0% + 5 digits

600V, 50Hz - 500Hz 2.0% + 5 digits

DC Voltage 200mV/2000mV/200V/600V 0.5% + 1 digit

AC Current 200A, 50Hz - 60Hz 3.0% + 5 digit

200A, 60Hz - 400Hz 5.0% + 5 digit

Frequency 2K ~ 40KHz (Auto-ranging only) 0.1% + 3 digits

Resistance 200Ω/200KΩ1.0% + 3digit

Diode Check 1mA ±0.6mA Not specified

Continuity <100Ωon Diode, Continuity Not Specified

61-701

Function /

Range Ranges Accuracy

200V, 50Hz - 500Hz 1.2% + 3 digits

AC Voltage 200V, 50Hz - 1KHz 2.0% + 5 digits

600V, 50Hz - 500Hz 2.0% + 5 digits

DC Voltage 2000mV/20V/ 600V 0.5% + 1 digit

AC Current 200A, 50Hz - 60Hz 3.0% + 5 digit

200A, 60Hz - 400Hz 5.0% + 5 digit

Capacitance 200MFD 3.0% + 5 digits

Frequency 2K ~ 40KHz (Auto-ranging only) 0.1% + 3 digits

Resistance 200Ω/200KΩ1.0% + 3digit

Diode Check 1mA ±0.6mA Not specified

Continuity <100Ωon Diode, Continuity Not specified

61-702, 61-704

Function /

Range Ranges Accuracy

2000mV/200V, 50Hz - 500Hz 1.2% + 3digits

AC Voltage 2000mV/200V, 500Hz - 1KHz 2.0% + 5 digits

750V, 50Hz - 500Hz 2.0% + 5 digits

DC Voltage 2000mV/200V/1000V 0.5% + 1 digit

AC Current 200A, 50Hz - 60Hz 3.0% + 5 digit

200A, 60Hz - 400Hz 5.0% + 5 digit

Capacitance 200MFD 3.0% + 5 digits

Frequency 2K ~ 40KHz (Auto-ranging only) 0.1% + 3 digits

Resistance 200Ω/200KΩ1.0% + 3digit

Diode Check 1mA ±0.6mA Not specified

Continuity <300Ωon Diode, Continuity Not specified

AC Converter: Average responding, RMS Calibrated to Sine Wave

Overload Protection:

AC and DC Voltage: not to exceed 600V DC or VAC RMS for the model 61-700 and 61-701,

and 1000V DC or 750V AC for the 61-702 and 61-704

Resistance: Not to exceed 500V DC or AC RMS

Capacitance, Frequency, Diode Check, Continuity: not to exceed 500V DC or VAC RMS

Form number TM61700-1-2-4 Rev 4 September 2004

Page 5

PERFORMANCE VERIFICATIONS

Perform the following analysis; if the meter conforms to the limits listed in Table 1 through 5 the meter is

functioning correctly. If the meter does not conform to any of the listed limits the calibration procedure

must be performed.

Performance Verification Preparation

1. Turn on the calibrator, allow calibrator to warm up. Temperature stabilization

should be reached after 30 minutes.

2. Remove battery cover and using a calibrated meter to ensure the battery measures a minimum of 7.5V

DC. If the battery measures under 7.5V DC, replace the battery before beginning the performance test.

3. Input the values listed in Table 1 through 5

Table 1 AC Voltage Test

Function

/Range Input Low

Limit High

Limit Model number

V AC 2000mV 1900mV AC @ 50Hz 1874 1926 61-702, 61-704

V AC 2000mV 1900mV AC @ 500Hz 1874 1926 61-702, 61-704

V AC 2000mV 1900mV AC @ 1kHz 1857 1943 61-702, 61-704

V AC 200V 190V AC @ 50Hz 187.4 192.6 61-700, 61-701, 61-702, 61-704

V AC 200V 190V AC @ 500Hz 187.4 192.6 61-700, 61-701, 61-702, 61-704

V AC 200V 190V AC @ 1kHz 185.7 194.3 61-700, 61-701, 61-702, 61-704

V AC 600V 500V AC @ 50Hz 485 515 61-700, 61-701

V AC 600V 500V AC @ 500Hz 485 515 61-700, 61-701

V AC 750V 700V AC @ 50Hz 681 719 61-702, 61-704

V AC 750V 700V AC @ 500Hz 681 719 61-702, 61-704

Table 2 DC Voltage Test

Function

/Range Input Low

Limit High

Limit Model number

V DC 200mV 190mV 188.9 191.1 61-700

V DC 2000mV 1900mV 1889 1911 61-700, 61-702, 61-704

V DC 20V 19V 18.89 19.11 61-701

V DC 200V 190V 188.9 191.1 61-700, 61-701, 61-702, 61-704

V DC 600V 500V 496 504 61-700, 61-701

V DC 1000V 900V 894 906 61-702, 61-704

Table 3 AC Current Test

Function

/Range Input Low

Limit High

Limit Model number

A AC 200A 100A AC @ 50Hz 96.5 103.5 61-700, 61-701, 61-702, 61-704

A AC 200A 100A AC @ 400Hz 94.5 105.5 61-700, 61-701, 61-702, 61-704

Form number TM61700-1-2-4 Rev 4 September 2004

Page 6

Table 4 Capacitance, Frequency, and Resistance Test

Function

/Range Input Low

Limit High

Limit Model number

Hz {auto} 1KHz @ 10V .996 1.004 61-700, 61-701

Hz {auto} 10KHz @ 10V 9.96 10.04 61-700, 61-701

MFD 200 100µF 96.5 103.5 61-701, 61-702, 61-704

Ω200 100Ω98.7 101.3 61-700, 61-701, 61-702, 61-704

Ω200K 100KΩ98.7 101.3 61-700, 61-701, 61-702, 61-704

Table 5 Diode and Continuity Check

Function

/Range Test Value Low

limits High

Limit Model number

Diode 500mV DC 485 515 61-700, 61-701, 61-702, 61-704

Continuity 40Ωbeep on,

150Ωbeep off 61-700, 61-701

Continuity 50Ωbeep on,

300Ωbeep off 61-702, 61-704

CALIBRATION

Calibration Preparation

1. Turn on the calibrator, allow calibrator to warm up. Perform calibration at

23±2°C at relative humidity of < 70%. Temperature stabilization should be

reached after 30 minutes.

2. Disconnect the test leads and turn the range switch to “OFF”.

3. Remove the screws holding the battery cover and one at the jaw.

4. Remove the case bottom using care not to damage the battery connector and leads

to the continuity beeper. (Beeper is attached to the bottom case cover.)

5. Using a calibrated meter ensure the battery measures a minimum of 7.5V DC.

If the battery measures under 7.5V DC, replace the battery.

Calibration Procedure

It is recommended that all IDEAL meters undergo the following calibration procedure on

an annual basis.

The class of calibrator or equipment should have an accuracy that exceeds, by an expectable ratio the

accuracy of this instrument.

Form number TM61700-1-2-4 Rev 4 September 2004

Page 7

V DC Calibration

61-700 (Refer to Figure 1)

1. Set the function / range to 200mV DC.

2. Connect the calibrator to the Vand COM inputs on the meter.

3. Output 190.0mV DC.

Adjust VR1 (VR 200Ω) until unit display reads 190.0

De-energize source and remove test leads

61-701 (Refer to Figure 2A)

1. Set the function / range to 20V DC.

2. Connect the calibrator to the Vand COM inputs on the meter.

3. Output 19.00V DC.

Adjust VR1 (VR 200Ω) until unit display reads 19.00

De-energize source and remove test leads

61-702 (Refer to Figure 3A)

61-704 (Refer to Figure 4A)

1. Set the function / range to 2000mV DC.

2. Connect the calibrator to the Vand COM inputs on the meter.

3. Output 1.900 VDC.

Adjust VR1 (VR 200Ω) until unit display reads 1900.

De-energize source and remove test leads

V AC Calibration:

61-704 only (Refer to Figure 4A)

1. Set the function/range to the 2000mV AC.

2. Connect the calibrator to the Vand COM inputs on the meter.

3. Output 1.900 VAC/50Hz

Adjust VR5 (VR 100Ω) until unit display reads 1900V± 1 digit.

De-energize source and remove test leads

A AC Calibration:

61-700 (Refer to Figure 1)

61-701 (Refer to Figure 2B; peel front label back to access calibration hole)

61-702 (Refer to Figure 3B; peel front label back to access calibration hole)

61-704 (Refer to Figure 4B; peel front label back to access calibration hole)

1. Set the function / range to the 200A AC

2. Set output of the AC calibrator for 10.00A/60Hz +/- 0.01% and connect it to Coil = 10N = 100.0A

AC.

3. Clamp the jaws to the coil = 10N.

4. Adjust VR2 (VR 2KΩ) for a display reading of 100.0 ±1 digit

Calibration of the 61-700 series is complete.

Remove all leads from the calibrator and equipment.

Return unit to proper operating condition.

Form number TM61700-1-2-4 Rev 4 September 2004

Page 8

Figure 1 Figure 2A Figure 2B

Figure 3A Figure 3B Figure 4A Figure 4B

Form number TM61700-1-2-4 Rev 4 September 2004

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels IDEAL Multimètre

IDEAL

IDEAL 61-340 Manuel utilisateur

IDEAL

IDEAL SecuriTEST Manuel utilisateur

IDEAL

IDEAL 61-357 Manuel d'utilisation et d'entretien

IDEAL

IDEAL 61-494 Manuel utilisateur

IDEAL

IDEAL ND 3405-1 Manuel utilisateur

IDEAL

IDEAL 61-340 Manuel utilisateur

IDEAL

IDEAL 61-497 Manuel utilisateur

IDEAL

IDEAL 61-310 Manuel utilisateur

IDEAL

IDEAL 61-354 (TRMS) Manuel utilisateur

IDEAL

IDEAL ND 2350-1 Manuel utilisateur

IDEAL

IDEAL Resi-Pro 310 Series Manuel utilisateur

IDEAL

IDEAL 61-764 Manuel utilisateur

IDEAL

IDEAL ND 2365-1 Manuel utilisateur

IDEAL

IDEAL 480 Series Manuel utilisateur

IDEAL

IDEAL 61-681 Manuel utilisateur

IDEAL

IDEAL ND 2351-1 Manuel utilisateur

IDEAL

IDEAL 61-497 Manuel utilisateur

IDEAL

IDEAL 61-312 Manuel utilisateur

IDEAL

IDEAL 602 Manuel utilisateur

IDEAL

IDEAL 61-340 Manuel utilisateur

IDEAL

IDEAL 61-603 Manuel utilisateur

IDEAL

IDEAL ND 2385-1 Manuel utilisateur

IDEAL

IDEAL 61-327 Manuel d'utilisation et d'entretien

IDEAL

IDEAL 61-605 Manuel utilisateur

Manuels Multimètre populaires d'autres marques

Agilent Technologies

Agilent Technologies 34420A Manuel utilisateur

Fluke

Fluke 83 Manuel utilisateur

Hameg

Hameg HM 8012 Manuel utilisateur

Mastech

Mastech MY70 Manuel utilisateur

Steren

Steren MUL-300 Manuel utilisateur

Somogyi Elektronic

Somogyi Elektronic home SMA 92 Manuel utilisateur

Gossen MetraWatt

Gossen MetraWatt METRAmax 6 Manuel utilisateur

PeakTech

PeakTech 4000 Manuel d'utilisation et d'entretien

YOKOGAWA

YOKOGAWA 90050B Manuel utilisateur

Gossen MetraWatt

Gossen MetraWatt METRALINE DMM16 Manuel utilisateur

Fluke

Fluke 8846A Manuel d'utilisation et d'entretien

Tempo Communications

Tempo Communications MM200 Manuel utilisateur

Elenco Electronics

Elenco Electronics CM-1555 Manuel utilisateur

Mastech

Mastech MS8238C Manuel utilisateur

SDAR

SDAR 830A, 830B, 830D, 830C Manuel utilisateur

RS PRO

RS PRO RS-9519BT Manuel utilisateur

BGS technic

BGS technic 8890 Manuel utilisateur

Amprobe

Amprobe Hexagon 60 Manuel utilisateur
