IDEA CAMERA BIP-VI1A-2M Manuel utilisateur

SHENZHEN RISE ELECTRONIC CO., LTD.
Website: http://www.ideacamera.com Email:cctv@ideacamera.com
Global Sources HomepageAddress: http://www.globalsources.com/ideacamera.co
2Mp wireless smart battery camera, two-way speech intercom, HD H.265, Waterproof
IP65
Model: BIP-VI1A-2M
Product features:
◆to install, convenient to use, all wireless, no cable.
◆clear, smooth, intelligent transmission play the network limits.
◆online firmware upgrade, synchronous update function and checkup.
◆Standard H.265 video compression algorithms for high-definition video transmission
over a narrow bandwidth network. High picture quality, low code stream, local HD video,
more smooth viewing, no drag. Compared with H.264 video compression algorithm,the bit
rate is lower and the recording space is less.
◆Support two-way speech intercom, echo elimination, noise suppression.
◆SupportAndroid and IOS intelligent terminal remote real-time monitoring.
◆200W hd pixel (1920X1080), clear picture quality.
◆Red light night vision lighting (night vision distance of 7 meters), 24-hour monitoring,
IR-cut switch, no color during the day, night vision more clear.
◆Built-in rechargeable lithium battery, long battery life, normal operation as long as 6
months, 12 months standby time.
◆supports 2.4G Wi-Fi(IEEE802.11b/g/n).
◆SDcard(supportcloudstoragetechnology,microsupportup to128GB)storage,mobile
video recording.
◆Support qr code intelligent connection and distribution network.

SHENZHEN RISE ELECTRONIC CO., LTD.
Website: http://www.ideacamera.com Email:cctv@ideacamera.com
Global Sources HomepageAddress: http://www.globalsources.com/ideacamera.co
◆Support human shape detection, electronic fence, intelligent push, pet snapshot.
◆Easy to install, support 1/4 universal screw support and magnetic suction support.
◆minimum order quantity: 100pcs
Product parameters:
camera items parameters
main processor
SOC 3518E V300 :900MHz main
frequency
DDR 512M
Image sensor
sensor 1/3"colours CMOS sensor
lens M12, f: 3.3mm, F2.0, 200mp
visual angle H(level)95 degree; V(vertical)55
degree; D(opposite)110 degree
minimum illumination 0.01Lux
audio
input/output two-way voice intercom (with built-in
microphone and speaker)
audio compression
mode AAC
video
video compression
mode H.265
lighting frequency 50Hz, 60Hz
image frame rate 15fps
maximum image size 1920*1080P
night light IRCUT Double filter switch
automatically,10pcs ir leds

SHENZHEN RISE ELECTRONIC CO., LTD.
Website: http://www.ideacamera.com Email:cctv@ideacamera.com
Global Sources HomepageAddress: http://www.globalsources.com/ideacamera.co
(850nm wave length), irradiation
distance:7meters
network
wireless network 2.4G WIFI(IEEE802.11b/g/n), built-in
aerial
support agreement TCP/IP、UDP/IP、DHCP、RTMP、
MUTP
support IP address dynamic IP address
AI smart function human shape detection, electronic
fence, intelligent push, pet snapshot
type of alarm Warning notice mobile phone APP alarm push,
alarm song
rouse wake up the way PIR body induction and remote
active awakening
recording
Video mode alarm trigger, manual recording
video storage cloud storage,local Micro SD
card,mobile phone storage
indicator light LED indicate RGB trichromatic light,
power/network signal/function
indicator
battery
capacity 5200mAh/6700mAh(optional)
detachability no
hours of use 6 months(Record 20 10s videos
per day)
stand-by time 12months
charging voltage DV 5V+-5%/1.5A

SHENZHEN RISE ELECTRONIC CO., LTD.
Website: http://www.ideacamera.com Email:cctv@ideacamera.com
Global Sources HomepageAddress: http://www.globalsources.com/ideacamera.co
charging time 8 hours
protected mod over current/over discharge/over
charge/short circuit/high and low
temperature charge protection
power dissipation
stand-by power
consumption 1.68mW(4V 0.42mA)
daytime power
consumption 1W((3.8V 264mA)
power consumption at
night 2.17W((3.8V 571mA)
interface
power 1个Micro USB port
sd card 1个Micro SD card(max support
128GB)
key 1 reset,1 power on
installation installation 1/4 universal screw hole and
magnetic suction
environment
dustproof and
waterproof IP65
working environment -10° ~ 45°C /10% ~ 80% (no
condensation)
storage environment -20°C ~ 60° /0% ~ 90% (no
condensation)
specification
size (LxWxH) 70mm*50mm*90mm(excluding
stents)
weight(bare)240g
finished weight 500g
material & process ABS+PC

SHENZHEN RISE ELECTRONIC CO., LTD.
Website: http://www.ideacamera.com Email:cctv@ideacamera.com
Global Sources HomepageAddress: http://www.globalsources.com/ideacamera.co
color white highlights
authentication certificate CE, FCC, RoHS, WEEE, MSDS,
UN38.3
Packing list:
1. Camera*1
2. Bracket*1
3. 3MAdhesive tape*1
4. Mounting kit*1
5. USB charging cable *1
6. Operation instruction*1
Quick start:
The wireless smart battery camera supports battery- powered supply and AC-powered
supply.
1. Download and install theApp
The wireless smart battery camera supports Android and iOS App. For your best
experience, please scan the QR code below, or search Vicoo in theApp store to download
and install theApp, and follow the instruction to complete the user registration.
Download:Android/App Store
2. Add the device
Signin toVicooApp,connect toWi-Fiandadd thedeviceaccording totheprompts(please
bring the device close to the router when configuring).

SHENZHEN RISE ELECTRONIC CO., LTD.
Website: http://www.ideacamera.com Email:cctv@ideacamera.com
Global Sources HomepageAddress: http://www.globalsources.com/ideacamera.co
Install the camera:
You can place the camera on a shelf or other surfaces to use, or you can install it on a wall
to use.
(1) Select a good spot for your camera
Please install the camera in a position where its view is not blocked and ensure that it is
within the coverage of the Wi-Fi network.
(2) Install the bracket
1) 3M adhesive fixing:
Remove the protective film on one side of the 3M adhesive and stick it to the mounting
surface of the bracket.Then remove the protective film on the other side to fix the mounting
bracket in the installation position. (Theinstallation surface must be clean, smooth anddry.
It is not suitable for uneven wood, leather and stucco walls. Please press and hold the
bracket on the installation position for 3 minutes to achieve the best gluing performance)
2) Screw fixing:
Use the drilling tool to punch holes on the wall according to the hole distance of the base.
It is recommended to mark the holes on the wall with a pencil before drilling. Screw the

SHENZHEN RISE ELECTRONIC CO., LTD.
Website: http://www.ideacamera.com Email:cctv@ideacamera.com
Global Sources HomepageAddress: http://www.globalsources.com/ideacamera.co
expansion nut into the holes on the wall, and then connect the bracket to the expansion
nut with screws to complete the fixing.
(3) Fix the camera
Insert the ball-type connection shaft into the rear of the camera.
(4) Adjust the angle
Adjust the camera to an appropriate angle, and then tighten the base by rotating it in
clockwise direction to fix the angle.
Power on/off and network configuration:
Long press the power button for 2s to power on/off the device.

SHENZHEN RISE ELECTRONIC CO., LTD.
Website: http://www.ideacamera.com Email:cctv@ideacamera.com
Global Sources HomepageAddress: http://www.globalsources.com/ideacamera.co
Double click the power button to enter the network configuration mode after the prompt
tone.
When connecting the camera for the first time, use the VicooApp and follow theinstruction
to configure the camera network.
Set up the camera:
1) Click the “Add Device” in the App and enter the Wi-Fi network name and password
that you want the camera to connect.
To ensure a longer distance connection, the camera only supports the 2.4Ghz Wi-Fi with
stronger wall penetration capability and does not support Wi-Fi for enterprise- level
authentication currently. Please ensure that the entered Wi-Fi meets the requirements.
After completion, click “Continue” to generate the QR code for pairing the camera.

SHENZHEN RISE ELECTRONIC CO., LTD.
Website: http://www.ideacamera.com Email:cctv@ideacamera.com
Global Sources HomepageAddress: http://www.globalsources.com/ideacamera.co
2) After pressing the camera switch for 3 seconds, the camera will turn on. At this
moment, target the camera at the QR code of the mobile App, with a distance of
about 20cm (about 7 inches) until the camera emits a “Di” sound, which represents
the scanning is succeeded and the pairing is started.
Power button

SHENZHEN RISE ELECTRONIC CO., LTD.
Website: http://www.ideacamera.com Email:cctv@ideacamera.com
Global Sources HomepageAddress: http://www.globalsources.com/ideacamera.co
3) After a while, the camera will give out a prompt sound of successful connection.At
this moment, please set the name for the device on the App and select the location
you want to place the device. Click “Continue” to complete the pairing.
about 7 inchs (20cm)
