ICON Cube 4nano Manuel utilisateur
User manual
4-In / 4-Out Recording USB Interface with Smart Device connecting I/O
(Digital & Analog) for live streaming applications
Important Safety Instructions
1. Read this manual thoroughly before using this unit.
2. Keep this manual for future reference.
3. Take notice of and comply with all warnings included in the user's manual or indicated on the
appliance.
4. Follow all instructions included in this manual.
5. Do not expose this unit to rain or moisture. Avoid having water or other liquids spilled on this
unit.
6. When cleaning the cabinet or other parts of this appliance, use only a dry or slightly damp soft
cloth.
7. Do not block any ventilation openings or interfere with the proper ventilation of this unit. Install
in accordance with the manufacturer's instructions.
8. Do not use or store near any heat sources such as radiators, heat registers, stoves, or other heat-
producing appliances.
9. Do not interfere with the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding-type plug has two blades and a third
grounding prong. These are designated for your safety. If the provided plug does not fit into your
outlet, consult an electrician.
10. Protect the power cord from being walked on or otherwise damaged by items placed on or
against them. Particular attention should be given to the plugs, receptacles, and the point where
the cord exits the appliance.
11. To avoid the risk of electrical shock, do not touch any exposed wiring while the unit is in
operation.
12. Only use attachments/accessories specified by the manufacturer.
13. Unplug this unit and all connected electrical equipment during lightning storms or when left
unused a long period of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the appliance has
been damaged in any way or fails to operate normally.
WARNING: To reduce the risk of fire or electric shock, do not expose this unit to rain or moisture
Introductions.............................................................................................4
What’s in the package? ............................................................................4
Register your ICON ProAudio product to your personal account ...........5
Features ...................................................................................................6
Front Panel ..............................................................................................8
Rear Panel................................................................................................9
Top Panel................................................................................................10
Mac driver installation............................................................................. 11
Install ProDriver 4 with LoopBack function............................................. 11
Mixer control panel(Mac)........................................................................15
Windows driver installation.....................................................................17
ProDriver4(Windows) .............................................................................20
Mixer control panel(Windows) ................................................................21
Settings (Sample rate and latency settings)...........................................24
ProDriver hosting rack (Mac/Windows) ..................................................28
Hardware Connections (Use with Mac/PC and
mobile device simultaneously)................................................................36
Different types of microphone connection ..............................................37
method diagram......................................................................................37
Specications .........................................................................................38
Services..................................................................................................39
Contents
4
Introductions
What’s in the package?
●Cube4Nano Dyna USB Recording Interface
●Quick Start Guide x 1
●USB 2.0 cable (Type C) x 1
●3.5mm TRS audio cable x 1
Firstly, congratulations on your purchase of the ICON Pro Audio Cube4Nano Dyna
digital audio Interface! In these pages, you'll nd a detailed description of the features
of the Cube4Nano Dyna digital audio Interface, as well as a guided tour through its
front and rear panels, step-by-step instructions for their setup and use and a full list
of specications. As you read through the ma- nual, you will spot orange boxes -
these denote actions for you to complete which will help you get underway.
As with most electronic devices, we strongly recommend you retain the original
packaging. In the unlikely event that the product is returned for servicing, the original
packaging (or reasonable equivalent) is required. With proper care and adequate air
circulation, your Cube4Nano Dyna digital audio interfacewill operate awlessly for
many years to come.
We trust that this product will provide years of excellent service and in the unlikely
event that your product does not perform to the highest standard, every effort will be
made to address the issue.
5
Register your ICON ProAudio product to your
personal account
1. Check serial number of your device
Please go to http:// iconproaudio.com/registration or scan the QR code
below.
Input your device’s serial number and the other information on the screen. Click
“Submit”.
A message will pop up showing your device information such as model name
and its serial number - Click “Register this device to my account” or if you see
any other message, please contact our after-sales service team
2. Log in to your personal account page for existing user or
sign up for new user
Existing user: Please log into your personal user page by inputing your
user name and password.
New user: Please click “Sign Up” and ll in all the information.
3. Download all useful materials
All your registered devices under your account will show on the page. Each
product will be listed along with all its available les such as drivers, rmware,
user manual in different languages and bundled software etc. for download.
Please make sure you have download the necessary les such as driver before
you begin device installation.
6
Features
●24-Bit 192KHz 2 mic-In/2 inst-In, 2-Out USB Recording Interface
●Hi-end studio grade DAC/ADC provides super high dynamic range
DAC: Dynamic Range: 127dB
●Supporting Mac/PC connectivity simultaneously with SmartDevice
●Live session possible with audio signal processing via ProDriver4 virtual plug-in rack
●4x4 analog I/O full duplex simultaneous recording and playback
●Compatible with iOS and Android Digital I/O jack (Type C) & Analog I/O jack (3.5mm
stereo TRRS) for direct connection with SmartPhone, tablet or other device
●Mic/Instrument preamps with individual gain control and phantom power switch
●2 analog outputs on 1/4” TRS jacks
●Monitor volume control knob on the top panel
●Direct monitor button control on the top panel
●1 headphone output with assignable source and individual volume control
●Flexible channel routing via the ProDriver4 software software control panel
●ICON ProAudio developed ultra low latency ProDriver4™driver is provided
●ICON ProAudio innovative and user friendly plug-in hosting rack software is built-in
with ProDriver4™(Windows and Mac)
●ARM-M7/500MHz processing power and technology for super fast and stable signal
processing
●USB2.0 High Speed equipped and USB bus-powered
●2xType C “OTG” ports for direct connection with 2 mobile devices
●Supports DirectSound, WDM and ASIO2.0
The ICON ProAudio Cube4Nano Dyna USB recording interface provides an audio
input and output module as well as analog & digital connectivity with any Smart
mobile device for live streaming applications. Main features include:
7
●LoopBack function is equipped with ProDriver 4™ for both Mac and Windows
platforms
●Compatible with Mac OS (M1/ Intel-Mac) 10.11 and later, iOS 9 or above, Andriod
and Windows 7, 8 & 10 (32-bit/64-bit)
●+5VDC power supply connector is equipped for external power supply when using
with iOS
●Rugged aluminum construction
●Bitwig 8Track included
●Dotec audio plugins included
8
Front Panel
1. “Mic/Inst” Inputs 1/2
Unbalanced instrument and mic level inputs. These hybrid connectors will accept
a standard 3-pin XLR plug or a 1/4” TS connector.
2. 48V phantom power switch
Press to supply +48V phantom power to the associated XLR input. This phantom
power circuit is suitable for most condenser microphones.
3. Input gain level controls 1/2
These potentiometers control the input level of their associated analog Mic/Inst
input.
4. Master level control
This potentiometer controls the master output level of the analog outputs.
5. Headphone level control
This potentiometer controls the output level of the headphone output.
6. Headphone output
This output jack accepts a standard 1/4″ stereo TRS headphone connector.
2 61
3 4 5
9
Rear Panel
1. USB 2.0 connector (Type C)
Connect it with the provided USB cable Type C to your Mac/PC/iOS device
camera kit’s USB connector. Your Mac/PC must have a USB2.0 connector in
order to run the full speed of Cube4Nano Dyna.
2. Line outputs 1/2
These are unbalanced analog outputs on standard 1/4″ TS connectors at +6dBU
line level.
3. Smart Device I/O (Digital - Type C & Analog - 3.5mm TRRS)
These ports allow you to connect your smart device and your Mac/PC
simultaneously so you may process the audio signal with your Mac/PC before
delivering signal to the smart device for live streaming application.
Digital - Type C jack for connecting directly to the digital jack of the smart
device (OTG adapter raquired)
Analog - TRRS stereo jack for connecting directly to smart device’s audio I/O
4. MIDI I/O connectors
MIDI input and output on standard 5-pin DIN connectors.
5. Power supply connector (USB Type C)
Cube4Nano Dyna is USB-bus powered. If your computer does not supply
sufcient power, connect an ICON 5VDC power supply adapter to this jack. Or
you may try to use your smart phone power adapter with the correct cable type
(USB Type C). Normally it should work and provide enough power to the device.
(Note: You can get the power adapter from ICON distributors/dealers near you)
(Note: External power adapter is needed if the Cube4Nano Dyna is use as a
standalone unit without a Mac or PC)
1
53
42
10
Top Panel
1. “Direct monitor ” knob
Hardware direct monitoring (clockwise “Direct out”) eliminates the latency or
delay inherent in even the best internal circuitry while listening to your input
and existing tracks. Alternatively listen to your input complete with effects (anti-
clockwise “Computer”) while recording by using the extremely low-latency ASIO
monitoring.
1
