KNX Module IC-USB-S.1 Manuel utilisateur

module-electronic.ru

KNX USB INTERFACE

IC-USB-S.1

Application Program: ver. 1.0

User Manual: ver. 1.0

User Manual

CONTENT

Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1 Basic information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.1 Speciﬁcation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.2 Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.3 Installation and conection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2 Operational description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.1 KNX programming interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.2 Individual address assignment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.3 Project individual address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.4 Group associations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

page 2

module-electronic.ru

The KNX USB interface provides data transfer between the PC and the KNX bus via USB. Used to

conﬁgure, monitor, visualize and manage devices on the KNX network.

• Protocol cEMI (Common EMI)

• Supports «RAW Frame» operation mode

• Interface USB 2.0 type B

• LED status indication

• Long telegrams with up to 220 bytes APDU length are supported

• USB and KNX TP galvanic isolation

• Power supply via USB

• Low power consumption

• DIN rail 35mm mounting

IC-USB-S.1

1 BASIC INFORMATION

page 3

module-electronic.ru

1.1 SPECIFICATION

Device model

IC-USB-S.1

Inputs

USB connector

USB 2.0 type B, female

KNX interface

Speciﬁcation

TP-256

Available application soware

ETS 4 and later

KNX connector

4-wire EIB connector (PUSH WIRE spring clips) for standard cable TP1 0,8мм Ø

Supported protocols

cEMI (Common EMI)

KNX physical address by default

0.2.255

Power supply

via USB: 5V DC

Consumption on the KNX bus (29V DC)

< 5mA

< 150mW

Consumption on the USB (5V DC)

< 20mA

< 100mW

Operation temperature

-5°C ... + 45°C

Operation humidity

5 ... 95% (no condensation)

Degree of protection

IP 20, clean environment

Mounting type

DIN rail 35mm

Dimensions

36 х 90 х 71mm (2TE)

Weight

62g

page 4

module-electronic.ru

90mm

36mm 71mm

1.2 APPEARANCE

A. USB connector B. KNX TP connector

1. LED state USB 2. LED bus state KNX TP

1. State USB

Green: USB connection OK / No telegram traﬀic

Green (blinking): Telegram traﬀic

Red: USB Suspend Mode

OFF: No USB connection

2. Bus state KNX TP

Green: KNX TP connection OK / No telegram traﬀic

Green (blinking): Telegram traﬀic

OFF: KNX TP line not connected (or no USB connection)

page 5

module-electronic.ru

Шина KNX

USB

ETS

It is recommended to use USB cables that do not exceed 5 meters

Without connection to USB device is not powered!

1.3 INSTALLATION AND CONNECTION

INSTALLATION

WIRING DIAGRAMS

Attaching to DIN rail

Removing from DIN rail

ATTENTION! Installation and connection of the device to the mains must only be carried

out by qualiﬁed personnel! Be sure to turn oﬀ the power before installing or removing the

device! Even when the device is turned oﬀ, the output terminals can be live! Do not

connect to the outputs a load that exceeds the recommended values! The design of the

device meets the requirements of electrical safety according to GOST 12.2.007.0-75.

page 6

module-electronic.ru

2 OPERATIONAL DESCRIPTION

In KNX network installations the IC-USB-S.1 can be used as KNX USB interface. Aer establishing the USB

connection, IC-USB-S.1 operates with its default settings. Setting the correct Individual Address is

necessary to include IC-USB-S.1 in the KNX bus system.

Both LEDs lighting green show proper working of KNX bus connection and USB connection. Lightning

green means the connection is established. Blinking green indicates the telegram traﬀic extent. In

Microso Windows the IC-USB-S.1 is recognized as HID (Human Interface Device). So, no extra drivers

have to be installed or downloaded.

The IC-USB-S.1's ETS (dummy) database entry, e.g. for connecting a visualization device, is available for

ETS4 and upward. The database without parameters and without communication objects can be added

to an ETS project as usual.

It is recommended to use USB cables that do not exceed 5 m.

All screen shots are related to the IC-USB-S.1 database ﬁle R1-4 in ETS5.

page 7

module-electronic.ru

To use IC-USB-S.1 for ETS programming it has to be chosen as the Current Interface in the ETS Bus

Connections window or alternatively during editing a project, at the bottom line («Name and state of

current connection») of the ETS window.

2.1 KNX PROGRAMMING INTERFACE

Figure 1. ETS bus connection interface windows

page 8

module-electronic.ru

2.2 INDIVIDUAL ADDRESS ASSIGNMENT

The device is supplied with the Individual Address 0.2.255. With the ETS the Individual Address can be

assigned to the device by setting the desired address in the Individual Address ﬁeld of the Bus

Connections window of the ETS. To download the desired Individual Address the IC-USB-S.1 has to be

chosen as the Current Interface. Then type in the Individual Address and press the Test button.

Figure 2. Individual addres assignment

page 9

module-electronic.ru

2.3 PROJECT INDIVIDUAL ADDRESS

For i.e. connecting a visualization device to KNX, the IC-USB-S.1 must be contained in the ETS project. The

necessary product database entry can be downloaded from the website and from the KNX Online

Catalog.

With the ETS, the project Individual Address can be assigned by setting the desired address in the

properties window of the ETS.

Figure 3. USB interface in the ETS catalog

Figure 4. ETS properties window

page 10
