Iceco JP60P Manuel utilisateur
JP60P
official@icecofreezer.com
official@icecofreezer.com
Any questions please contact us:
Catalogue
Catalogue
1 1
- - - - - - - - - - - - - - - - -
Supply Details
2 2
---------------------
Operation
3 6
- - - - - - - -
Cleaning And Maintenance
4 7
- - - - - - - - - -
Error Codes & Solutions
5 9
- - - - - - - - -
Warranty & Return Policy
6 10
- - - - - - - - -
Troubleshooting (Q & A)
7 15
-------------
Safety Instructions
Supply Details
JP60P refrigerator x1 Basket x1
DC CONNECTION
CABLE x1
80W AC ADAPTER
(FOR HOME USE)
01
1
MODEL JP60P Series
External dimensions
(LxWxH)
28.9*19.3*18.8(inch)
735 x 490 x 477(mm)
Net weight 51.9lbs/23.5kg
Installed power 60W
Supply voltage DC 12V/24V
Supply current 7.0A/3.5A
Temperature setting -18°C to +10°C (0°F to 50°F)
Insulation C-pentane
Shell material LLDPE
Operation
2(Using in Vehicles)
02
BFunction Button
(MAX mode & ECO mode)
CTemperature Down Button
(Changing setting temperature down)
DTemperature UP Button
(change setting temperature up)
APower ON / OFF Button
2.1 MAX & MIN Mode
With power on (long press A)→ press B
(MAX/ECO light turns on)
03
Tip: Press the C or D button to adjust the
temperature according to your needs. In
order to save energy, the compressor will
stop running automatically after reaching
the setting temperature, and restart again
when the inside temperature goes up
04
2.2 Switch Between °C to °F
In the standby mode, long press B and D at 3S,
→ press C or D to switch °C or °F.
TIP: When the temperature is adjusted, the
screen will show the temperature inside the
refrigerator.
2.3 Triple Battery Protection Operation
In the standby status(connecting the power
without pressing A), long press A and B at the
same time for 3S to enter the battery protection
setting menu. Press D and C to adjust the level.
Display : “- - -” → low mode; “= = =” →
middle mode; “≡ ≡ ≡” → high mode.
This is an electronic device which has the function of
piloting the motor of the compressor and carrying out all
the controls and electrical protection of the system.
TIP: It can be adjusted according to the
actual situation. When the refrigerator
connection voltage is lower than the cut off
value, the refrigerator will automatically
disconnect the power supply. The
refrigerator will restart only if the voltage is
higher than or equal to the cut in value.
05
06
Cleaning And Maintenance
3
3.1 Cleaning
Cleaning the freezer with a wet cloth and warm
water mixed with gentle non-abrasive
detergents.
3.2 Maintenance
Don't forget to power off and disconnect the
plug before cleaing the unit.
Don't use pointed objects or abrasive
detergents. to clean the fridge.
Don't use pointed or sharp objects, such as
knife, to punch through the ice when
defrosting.
Don't cleaning the fridge with running water
or using a high pressure washer.
07
Error Codes & Solutions
4
Error Code
Battery protection cut-out
※ The voltage can not reach the cut-out
value, the battery protection is activated.
E1
Fan over-current cut-out
※ The fan overloads with more than 1 A
current.
E2
Motor start error
※ The motor of compressor is blocked or
the pressure difference in the refrigeration
system is too high.
E3
Minimum motor speed error
※ The compressor overloads and the
motor can not maintain its minimun speed
1850 rpms.
E4
Thermal cut-out of electronic unit
※ Thermal cut-out error If the refrigeration
system overloads, or the ambient
temperature is too high, the thermal sensor
is overheated.
E5
NTC fault (NTC open circuit or short circuit)
E6
