Iceco GO20 Manuel utilisateur
Please email us at: official@icecofreezer.com
GO20 White/Grey
Catalogue
1 1
-----------------------
What's Inside
2 2
---------------------------
Operation
3 10
--------------
Care And Maintenance
4 11
- - - - - - - - - - -
Error Codes & Solutions
5 13
- - - - - - - - - -
Warranty & Return Policy
6 14
- - - - - - - - - - -
Troubleshooting (Q & A)
7 19
-----------------------
APP Control
8 21
- - - - - - - - - - - - - - - -
Safety Instructions
What's Inside
Refrigerator x1
7 Feet 80W
Universal
AC Adapter x1
8 Feet 12/24V
DC Cigarette
Lighter Plug Cable x1
01
1
MODEL GO20 Series
External dimensions(LxWxH)
Net weight
Storage volume
Supply voltage
Temperature setting
Insulation
Shell material
10.8 Kg (23.8 lbs)
20 liters (21 quarts)
DC 12V/24V
C-pentane
ABS
570x320x315 mm
(22.4x12.6x12.4 inch)
-18°C to + 10°C (0°F to 50°F)
Operation
2
: "Locked" or
"Unlock" Button
: Left-Compt Temperature
Adjustment
: Power ON / OFF Button
: Function Button
(Fast Cooling Mode)
: Right-Compt Temperature
Adjustment
02
L
R
Power On
With your fridge plugged in, press and hold the
A (Power) Button for 3 seconds.
Power Off
Press and hold the A (Power) Button for 3
seconds.
03
2.1 Switched-on/off
NOTICE: If the partition is removed from
your fridge, it will function as a single zone
unit, and only one temperature setting will
become available.
04
2.2 Fast Cooling Mode
With the fridge turned on, you can press the
Button B to toggle between Fast and Normal
cooling modes.
Under the fast cooling mode, the left bin will
receive all of the fridge’s cooling power for the
1 15 minutes, and the right bin will maintain
its current temperature during this period. Then
when you switch back to the normal cooling
mode, the right bin will go back to its set
temperature.
st
With the fridge powered on, press and hold the
Button C to unlock the fridge’s control interface.
05
The fridge will lock its control interface after
90 seconds of no control inputs, to prevent
accidental changes from being made.
You can press and hold the Button C (Unlock)
for 3 seconds to unlock the control interface.
2.3 Unlock Button
06
NOTICE: When the temperature is set,
the display will return to show the current
temperature inside the refrigerator.
2.4 Switch Between °C to °F
In standby mode (fridge
turned off but plugged into
power), press and hold the
Temp.
Up and Down Buttons
on display E (Right Compt.)
at the same time for 3 seconds,
and you should be able to
toggle between Battery
Protection Levels and C/F
settings using the Button A.
Once you see either a C or F,
you can use UP/DOWN Button
switch between this two scales.
07
In standby mode (fridge turned
off but plugged into power),
press and hold the Temp. Up
and Down Buttons on display
E (Right Compt.) at the same
time for 3 seconds, and you
should be able to toggle
between Battery Protection
Levels and C/F settings using
the Button A.
The Battery Protection Levels
are represented by 3 dashes
on the display. There are 3
protection levels available and
you can select it using the
UP/DOWN Button on display.
NOTICE: Details of Battery Protection
Mode could be found in Page 16.
2.5 Battery Protection Mode
08
In standby mode (fridge turned
off but plugged into power),
press and hold the Temp. Up
and Down buttons on display
D (Left Compt.) at the same
time for 3 seconds, and you
should be able to switch
between F1/F2/F3 off-set
values for both compartments
by pressing the Button A.
NOTICE: We do not recommend our
customer to adjust the temperature off-set
value unless necessary or there is an
obvious temperature measurement deviation
from actual temperature.
2.6 Off-Set Value
