Icar IK703 Manuel utilisateur
IK703 User Manual V1.0
1
IK703 GPS Tracker
User Manual V1.0
Preface
Congratulations on choosing the icar GPS IK703 4G GPS tracker. This manual shows
how to easily program and setup the tracker for best results. Make sure to read this manual
carefully before using this product, so as to avoid delays or confusion with it’s operation.
Please note that specifications and instructions are subject to change without notice to
facilitate product improvement. Updates and changes will be integrated into the latest release.
The manufacturer assumes no responsibility for any errors or omissions in outdated
documents.
IK703 User Manual V1.0
2
1. Overview
IK703 is 4G Asset GPS tracker.
2. Features
Real-timing tracking
GPS Positioning
History record check
Geo-Fence alarm
Low battery alarm
Power saving mode
PC & Mobile App tracking
Mini Hidden
IP65 Water resistant
3. Applications
Vehicle tracking
Container tracking
Asset tracking
4. Specifications
Item
Specifications
Dimension
41*69*67.7 mm
Weight
40g
Charging mode
CAR Charger DC 12V/24V
Backup battery
3.7 V 350mAh
Power consumption
40mA standby current
Working temperature
-20°C to 65°C
Item
Specifications
Cellular Bands
GSM 850/900/1800/1900 MHz
Positioning
GPS, AGPS, LBS
Tracking Sensitivity
-162 dBm
Sensor
Accelerometer
LED
RED/GREEN/BLUE
IK703 User Manual V1.0
3
SIM Card interface
Nano SIM
Waterproof
IP65
5. IK703 interface
6. In the box
1* IK703 GPS Tracker
1* Quick Start Guide
7. Installation
7.1 SIM Card installation
Get ready a Micro Sim Card that support LTE with 30MB data per month
Open the top housing
Insert Sim card to sim card slot correctly
Devices would turn on autoly (green led will blinking).
After that the device will be ready.
7.2 LED Indications
Flash
Fix
Off
Green Light
GSM/GPRS conversation start
No GPRS signal
Power off or in sleep mode
Blue Light
GPS location successful
No GPRS signal
Power off or in sleep mode
Red Light
charging
Full battery or charged full
8. SMS Commands List
Function
Command Format
explain
IK703 User Manual V1.0
4
APN
SL APNapn contecnt,apn user,apn pas
sword
SL APNcmnet,,
Check locatio
n
SL LC
admin123456 186********
Domain
SL DPa.icargps.com#7700#
IP&port also ok
upload
frequency(ti
me)
SL SC0,50
Upload location every 50s
upload
frequency(dis
tance)
SL SC1,500
Upload location every 500
m
Real time tra
ck
SL GZ5,60
Track 60s
Delete real tr
ack
SL GZ0,60
Delete real track
Restart Devic
e
SL RT
Restart the device
Admin numb
er
SL CP18948742396#
18948742396 is the admin
phone number
Back to facto
ry
SL FT
Back to factory settings
9. App & PC Tracking platform
9.1 App install & Login
Search “ICAR GPS” in Google Play or iOS store(or scan the following QR code) to
download the Mobile APP;
Choose the” Login by Device No.,
IK703 User Manual V1.0
5
Input your device’s ID number and password(default is 123456) to login.
Choose the” Login by User name.,
Input your user name and password(default is 123456) to login.
9.2 PC login
Web: www.icargps.net, Choose “ID No.”
Input your device’s ID number and password(default is 123456) to log in
IK703 User Manual V1.0
7
Q：The device can not obtain location information?
A：Place the unit at the open area to test.
Q：How to choose SIM card?
A: the SIM card must support GSM&GPRS，and ensure t
hat the card has enough currency and credit.
Q: How to use in the foreign countries?
A：please set the APN before use，please edit the text “SL
APNcmnet,, “ and send it to the SIM card of the device，
CMNET is Chinese operator’s APN, Replace the correspon
ding APN when use in other countries, APN details, please
consult your local SIM card carrier.
