Installer and User Guide

LCM

NetBAY Advanced Connectivity Technology

Local Console Manager

For 32P1635, 1735-L04 and 32P1644

INSTRUCTIONS

This symbol is intended to alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature accompanying the appliance.

DANGEROUS VOLTAGE

This symbol is intended to alert the user to the presence of uninsulated

dangerous voltage within the product’s enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to persons.

POWER OFF

This symbol indicates the principal on/off switch is in the off position.

POWER ON

This symbol indicates the principal on/off switch is in the on position.

PROTECTIVE GROUNDING TERMINAL

This symbol indicates a terminal which must be connected to earth ground

prior to making any other connections to the equipment.

Statement 4:

DANGER

To Connect: To Disconnect:

1. Turn everything OFF.

2. First, attach all cables to devices.

3. Attach signal cables to connectors.

4. Attach power cords to outlet.

5. Turn device ON.

1. Turn everything OFF.

2. First, remove power cords from outlet.

3. Remove signal cables from connectors.

4. Remove all cables from devices.

Electrical current from power, telephone, and communication cables is

hazardous.

To avoid a shock hazard:

•Do not connect or disconnect any cables or perform installation,

maintenance, or reconfiguration of this product during an electrical

storm.

•Connect all power cords to a properly wired and grounded electrical

outlet.

•Connect to properly wired outlets any equipment that will be attached

to this product.

•When possible, use one hand only to connect or disconnect signal

cables.

•Never turn on any equipment when there is evidence of fire, water, or

structural damage.

•Disconnect the attached power cords, telecommunications systems,

networks, and modems before you open the device covers, unless

instructed otherwise in the installation and configuration procedures.

•Connect and disconnect cables as described in the following table

when installing, moving, or opening covers on this product or

attached devices.

LCM

Installer and User Guide

Table of Contents

Chapter 1: Product Overview

Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Chapter 2: Installation

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Installing Your LCM . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Cabling the LCM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Chapter 3: Basic Operations

Controlling Your System . . . . . . . . . . . . . . . . . . . . . . . . .21

Viewing and Selecting Ports and Servers . . . . . . . . . . . .21

Configuring OSCAR . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Resetting Your Keyboard and Mouse . . . . . . . . . . . . . .32

Displaying Version Information . . . . . . . . . . . . . . . . . . . 33

Scanning Your System . . . . . . . . . . . . . . . . . . . . . . . . . .34

Broadcasting to Servers . . . . . . . . . . . . . . . . . . . . . . . . . .36

Appendices

Appendix A: FLASH Upgrades . . . . . . . . . . . . . . . . . . . .41

Appendix B: Technical Specifications . . . . . . . . . . . . . .45

Appendix C: Hardware Maintenance Information . . . .46

Appendix D: Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Contents

Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

1

Product Overview
