IBM ThinkPad 390X Manuel utilisateur
IBM
Part Number: 08K8871
ThinkPad 390X Quick
Reference and Service
Information
Your Name:
_______________________________
Company Name:
_______________________________
Model Number:
_______________________________
Serial Number:
_______________________________
Company or Reseller Service:
_______________________________
IBM Service Website:
_______________________________
IBM Service Number:
_______________________________
Copyright IBM Corp. 1999
Location
Battery status
Numeric lock
Drive in use
Scroll lock
Power on
Caps lock
TrackPoint
Headphone jack
Modem connector
Line-in jack
Microphone jack
PC Card slots
Volume control
Suspend mode
Battery status lamp
Suspend mode lamp
PS/2 mouse
and keyboard
connector
Parallel
connector
Security
keyhole Serial
connector External-
monitor
connectorPower jack
Universal serial bus(USB)
connector
Infrared port
Power switch
S-video jack
Note: The modem feature is available only on
select models.
Function Keys
You can change operational features instantly using
the following Fn key and function key combinations:
Function
Keys
Fn key
Fn + Result
F2 The window for the battery power status
appears or disappears. (The Fuel-Gauge
program must first be activated.)
F3 The computer enters standby mode.
F4 The computer enters suspend mode.
F7 The display output location changes.
F11 During battery-power operation, the power
mode changes.
F12 The computer enters hibernation mode.
Getting Service
Always read the Solving Computer Problems
chapter of your
User's Reference
before calling
IBM.
During the warranty period, you can get help and
information from the International Warranty Service
(IWS) in your country. Before you call, fill out the
front of this card. Also have:
Exact wording of any error messages
Hardware and software configuration informa-
tion
Description of the problem
Information and serial numbers of any options
installed on your system
International Warranty Service
This IBM product is eligible for service interna-
tionally wherever your machine type is sold by IBM.
Your computer must be registered to receive inter-
national service. To register, call one of the fol-
lowing IWS offices:
Help through a ThinkPad Web Site
The latest information about ThinkPad
computers:
http://www.ibm.com/thinkpad
Technical support information:
http://www.ibm.com/support
Southeast Asia, Australia, New
Zealand, and Hong Kong: 61-2-9354-4171
Canada, Latin America, and the U.S.: 1-800-497-7426
or
248-740-1215
Europe, Middle East, and Africa: 44-1475-893638
Japan, Korea, China (except Hong
Kong), and Taiwan: 81-462-73-7598
ThinkPad Configuration Program
You can manipulate your hardware system settings
with the ThinkPad Configuration program. Click
Start, move the cursor to Programs, ThinkPad,
then click ThinkPad Configuration.
For more information, click the Help button (
).
TrackPoint Setting
You can customize such TrackPoint function as
Press-to Select, Sensitivity, and Scrolling. Click
Start, move the cursor to Settings, Control Panel,
then double-click the TrackPoint icon.
Battery Status
You can see the battery status by using the Fuel
Gauge program. Click Start, move the cursor to
Programs, ThinkPad, then click Fuel-Gauge.
For Further Information
You can find the following information in your
ThinkPad user's manuals:
User's Reference
Getting familiar with your computer
Extending the features of your computer
Protecting your computer
Solving computer problems
Getting service
Features and specifications
Product warranties and notices
Online User's Guide
Using your computer outside your home country
Using audio, modem and DVD features
Protecting your computer
Using your computer with a battery pack
Using your computer with a PC Card
Resolving system resource conflicts
Solving computer problems
Installing software
Using system management
Handling the ThinkPad
Getting service
Note: To see the Online User's Guide , click Start,
move the cursor to Programs, ThinkPad
390X, then click ThinkPad 390X User's
Guide.
