I-Data 50 Manuel utilisateur
Contents
1 Introduction...................................................................................................................................1
1.1 Appearance of iData 50........................................................................................................................... 1
1.2 Installing the Battery................................................................................................................................ 2
1.3 Removing the Battery.............................................................................................................................. 2
1.4 Inserting a SIM Card................................................................................................................................ 2
1.5 Inserting a TF Card.................................................................................................................................. 3
1.6 Charging.................................................................................................................................................... 4
2.1 Powering On/Off the iData 50 ................................................................................................................ 5
2.2 Locking and Unlocking the iData 50...................................................................................................... 5
2.3 Keys ........................................................................................................................................................... 5
2.4 Home Screen............................................................................................................................................ 6
2.5 Status Icons and Indicators..................................................................................................................... 6
2.6 Basic Settings........................................................................................................................................... 7
3 Call Function...............................................................................................................................12
3.1 Making a Call.......................................................................................................................................... 12
3.2 Contacts................................................................................................................................................... 12
3.3 SMS and MMS........................................................................................................................................ 13
3.4 Email ........................................................................................................................................................ 14
4 Network Connection and Connection Synchronization..................................................16
4.1 GPRS Data Connection........................................................................................................................ 16
4.2 Wi-Fi Network Connection.................................................................................................................... 17
4.3 Bluetooth.................................................................................................................................................. 17
4.4 GPS.......................................................................................................................................................... 19
4.5 Connecting the iData 50 to a PC......................................................................................................... 19
4.6 Synchronization...................................................................................................................................... 20
5 Enabling the Scan Function....................................................................................................21
5.1 To start the iScan program and enable scanning, do as follows: ................................................... 21
6 Enabling the NFC Function.....................................................................................................22
6.1 To enable the NFC function, do as follows......................................................................................... 22
7 Managing the iData 50..............................................................................................................23
7.1 Installing Applications............................................................................................................................ 23
7.2 Uninstalling Applications ....................................................................................................................... 23
7.3 Managing Applications .......................................................................................................................... 24
8 Precautions and Troubleshooting.........................................................................................25
8.1 Precautions............................................................................................................................................. 25
8.2 Troubleshooting...................................................................................................................................... 26
Appendix .........................................................................................................................................29
iData 50 User Manual
- 1 -
1 Introduction
1.1 Appearance of iData 50
Figure 1-1 Front view of iData 50
Figure 1-2 Rear view of iData 50
iData 50 User Manual
- 2 -
1.2 Installing the Battery
1. Push the battery to the bottom of the battery compartment and press it downwards.
2. Push the battery cover lock to the right to lock the battery cover.
1.3 Removing the Battery
1. Push the battery cover lock to the left.
2. Pull up the battery cover from the groove at the upper end of the battery cover.
(Note: The iData 50 adapts integrated design for the battery and battery cover.)
1.4 Inserting a SIM Card
1. Insert a SIM card by following the direction in the figure below.
(Note: Micro SIM cards are applicable to the iData 50. After replacing a SIM card, restart
the iData 50.)
iData 50 User Manual
- 3 -
1.5 Inserting a TF Card
1. Push the card cover by following the OPEN direction marked on the card cover.
2. Open the card cover upwards and insert a TF card, as shown in the figure below.
3. Close the card cover, as shown in the figure below.
4. Pull back the card cover by following the LOCK direction marked on the card cover.
(Note: TF cads, namely Micro SD cards, are applicable to the iData 50. After replacing a TF card,
restart the iData 50.)
iData 50 User Manual
- 4 -
1.6 Charging
You can charge a battery in the following ways:
1. Bottom charging cable;
2. 1-slot charging & communication stand (to be purchased separately).
Description of charging indicator:
When the battery is in the charging status, the charging indicator is in red.
When the battery is fully charged, the charging indicator is in green.
When the battery volume is low,
(1) a message indicating that the battery volume is less than 20% is displayed on the
screen.
(2) the iData 50 gives out a low battery prompt tone.
(3) the charging indicator blinks in red.
★Tips
The following operations help obtain a longer standby duration of the iData 50.
Shorten the time to sleep by selecting Settings > Display > Sleep.
Set the screen brightness to a small value by selecting Settings > Display > Brightness.
Disable functions that are not frequently used, for example, GPS, Bluetooh, Wi-Fi and 3G
communication.
iData 50 User Manual
- 5 -
2 Using the iData 50
2.1 Powering On/Off the iData 50
After installing a SIM card and a battery and charging the iData 50 completely, you can use
the iData 50.
1. To power on the iData 50, press the On/Off key on the right for some time. The
iData 50 vibrates, displays the startup screen and enters the Android OS after the guide
progress is complete. It takes some time for the iData 50 to initialize. Please wait
patiently.
2. To power off the iData 50, press the On/Off key on the right for some time. A dialog
box that provides shutdown options is displayed. Click Power Off.
2.2 Locking and Unlocking the iData 50
Locking the iData 50
Press the On/Off key momentarily to lock the iData 50. If you do not perform any
operation for the iData 50 within the default locking time, the iData 50 is automatically
locked.
Unlocking the iData 50
Press the On/Off key momentarily and slide the unlock
key to the right on the screen.
2.3 Keys
The iData 50 provides a physical keypad that consists of four keys, as shown in the figure
below.
On the physical keypad of the iData 50, keys are respectively home key, menu key, scan
key, and back key from left to right.
Home key: used to go back to the home screen.
Menu key: used to show menus.
Scan key: used to scan.
Return key: used to return to the previous operation screen.
iData 50 User Manual
- 6 -
2.4 Home Screen
By default, the iData 50 has one home screen. You can add home screens by placing
applications to the home screen and slide to the left or right to switch to another home
screen. On the home screen, click the icon of any application to open the application.
★Tips
You can freely add or delete the icon of an application in the blank of the home screen.
If you click the application tray, all applications can be viewed.
2.5 Status Icons and Indicators
Status icons and indicators are in the status bar at the upper part of the screen and show
device status and notifications.
Return key
Scan key
Application tray
Home key
Menu key
iData 50 User Manual
- 7 -
Table 2-1 Status icons
Icon
Description
Icon
Description
WLAN
Signal strength
Bluetooth
Flight mode
USB connection
Network access restricted
Missed calls
USB debugging
New messages
Charging
Modem logs
Battery full
Silent mode
Multiple notification icons,
which are beyond the scope
of display
Application permission
EDGE
Connection between USB
and PC pea pod
★Note
As software is upgraded continuously, status indicators may be different from those
displayed on the iData 50. The actual status indicators prevail.
2.6 Basic Settings
2.6.1 Date and Time Settings
To change the date and time in the iData 50, do as follows:
1. Find the following icon.
iData 50 User Manual
- 8 -
2. Select Settings > Date & time > Set date or Set time.
2.6.2 Display Setting
1. Find the following icon.
2. Select Settings > Display > Lock screen
notification/Wallpaper/Brightness/Auto-rotate screen/Sleep/Interactive
screensaver/Font size/Cast screen.
