SERVICE MANUAL HPS-300/600/1100/1600

for authourized technicians only

For Your Safety

Read and understand this service manual before use.

Keep this manual for future reference.

We are still constantly improving this power station, therefore, some parts of this power station may be

changed in order to achieve the better quality, but the main functions and operations will not be alternated

and changed. Your understanding would be greatly appreciated.

HPS-300/600/1100/1600

HYUNDAI 01

Table of Contents

SAFETY ..............................................................................................................................................................

PARTS AND FUNCTIONS .............................................................................................................................. ....

TROUBLESHOOTING GUIDE AND SOLUTION ...............................................................................................

1) PROBLEM WITH LCD SCREEN ............................................................... ................

2) PROBLEM WITH POWER ON . ..... .... ............................ ...............................

3) PROBLEM WITH CHARGING .............................................................................

4) PROBLEM WITH AC/DC OUTPUT ..................................................................................

EXPLODED DRAWING ........................................................................................................................................

...................

............................

.........................................

. .

...............

. .

................................................

HPS-300/600/1100/1600

1. SAFETY

Rechargeable Lithium-iron-phosphate (LifePO4) battery is equipped with this product so take particular

attention on operation, storage and delivery.

Recharge only with the charger specified by the manufacturer. A non-specified charger may create a risk of

fire.

3) Charge it in a ventilated location; do not put this product in water and do not throw or beat this product.

Keep this product and related accessories in a safe place, which is not accessible to children. Do not

expose it to sources of ignition or other heat sources to avoid danger.

Avoid touching the charging/discharging socket with the metal objects. Otherwise will cause a short circuit

and injured.

6) Inadequate ventilation may cause damage to the unit. Do not put anything on top of the unit.

7) Do not disassemble the appliance and do not use it when the temperature is above 40 degrees.

8) Keep the unit from dirt, dust, or moisture.

9) Do not insert any objects into output port or ventilation holes.

10)

Any repair must be carried out by the manufacturer or an authorized repair agent in order to avoid danger.

Do not attempt to replace the internal battery. It shall be done by a qualified service center.

11) Do not insert any conductors into output port deliberately.

To ensure safe operation and service of the meter, follow these instructions. Failure to observe these

warnings can result in severe injury or death.

HYUNDAI 03

2. MAIN PARTS AND FUNCTIONS

PCB board-A : main control board used to display the current power

AC &DC status and control the output

when

abnormal

PCB board-B : control of USB-A & TYPE-C output

PCB board-C : control of DC 12V output

PCB board-D BMS : for detecting battery status and control battery

output when abnormal

PCB board-H : control DC charging and MPPT charging

Inverter : converting DC power from a battery to AC current

The image above is a representative model's part, and the shape of the parts may vary by model.

AC & DC

HPS-300/600/1100/1600

3. TROUBLESHOOTING GUIDE

It is only for the authourized technicians when testing and repairing. Non-authorized person should

never disassemble or repair the power station and contact the supplier or customer center.

)

PROBLEM

WITH

LCD

SCREEN

Situation 1

The blue LED light is on, the button and the AC and DC output work normally,

Incomplete display information such as white screen, white dots, white lines, and color

cast appear on the display

Blue Indicator Light

LCD Display

Reason

Solution

Damage caused by strong impact, falling from height, or exposure to high temperatures for a

long time, etc

Power on and off the power station again to confirm whether the abnormality is eliminated;

check whether all external devices of the power station and the charging input terminal are all

unplugged, disassemble the PCB board-A where the display screen is located, and replace

the display screen with a new one. When replacing, pay attention to whether the

corresponding display driver chip is consistent.

HYUNDAI 05

Situation 2

Reason

Solution

The

blue

indicator

light

but

the

button

has

response.

the

AC/

has

output

and

the

display

screen

white

black.

Most

the

reasons

for

this

phenomenon

are

caused

damage

the

microcontroller

abnormal

power

supply.

Check

whether

all

external

devices

the

power

station

and

the

charging

input

terminal

are

all

unplugged,

and

replace

the

PCB

board-A

main

control

board.

When

replacing,

pay

attention

whether

the

serial

number

the

main

control

board

corresponds

the

serial

number

the

main

control

board

replaced.

The

serial

number

can

found

the

secondary

menu.

HPS-300/600/1100/1600

PROBLEM

WITH

POWER

Situation 1

Reason

Most of the reasons for this phenomenon are that the power switch reaches the service

lifetimes, and the BMS triggers the shutdown command after the battery is stored with zero

power for a long time.

Main Power Switch

Solution

he blue indicator light is off, and the display screen is black.

Switch the main power switch in the "O" position and plug in the charger. Then check

whether the display screen shows normal. If the battery charge level rises normally, the

power on/off switch may be faulty.

In this case, unplug the charger first, and check whether all external devices of the power

station and the charging input are unplugged then proceed replacement of the power

switch.

If the battery power is always below 1%, there may be a problem with BMS or battery pack.

Check whether all external devices of the power station and the charging input are all

unplugged first, and check whether the battery voltage of each string is normal. If the

battery voltage is below 1 V, replace the battery pack. If not, replace the PCB board D.

HYUNDAI 07

PROBLEM

WITH

CHARGING

Situation 1

Reason

Solution

Situation

Reason

Solution

No charging icon on the display

Most of the reasons for this phenomenon are caused by damage to the charger or poor

contact with the charging port.

Check

whether

the

output

voltage

the

charger

within

the

limited

charging

voltage

range.

exceeds

the

maximum

input

voltage,

the

charger

needs

replaced.

Input Connector

Check the charging port whether have foreign objects, oxidation, looseness. If no

abnormality is found, replace the charger of the same specification

The display shows the charging icon , but the battery charge level does not

change . When the charging voltage is higher than the maximum input voltage ,

the charging overvoltage protection function is triggered.

HPS-300/600/1100/1600

PROBLEM

WITH

AC/DC

OUTPUT

Situation 1

Reason

Solution

output

and

the

display

is off.

The

inverter

the

board-C which is reponsible for DC output

short-circuited.

Switch the main power switch in the "o" position first and check whether all the external devices

of the power station and the charging input terminal are all unplugged. Then check that the AC

or DC button is pressed to cause the display to be black, and replace the corresponding PCB-A

board after confirmation.
