Hyundai PD421 Manuel utilisateur
FCC ID : PJIP4200S001
ATTACHMENT E.
- USER’S MANUAL -
REPORTNO.:HCT-F03-0701 HYUNDAIC–TECH
Hyundai
Plasma Display
PD421
User’s Guide
1UIOM:M\MV\QWVMNNMK\ӧ
Image retention effect could be seen if still picture is continuously displayed for a
certain period of time as a feature of Plasma display panel.
To avoid this effect, use the product with reduced brightness and contrast especially
when a still image is displayed for long time. (example:contrast 75, brightness 50)
Once Image retention is created, change the mode into Video mode which displays
more motions. This can help to reduce Image retention effect but cannot completely
eliminate once it occurs. Especially, when a fixed pattern is frequently used, screen’s
brightness may be worsened. (For more details, see the page 25)
8Q`MT,MNMK\ӧ
Plasma panel is made of a group of refined pixels (cells). When the Panel has 99.9%
of pixels approved, that is normal product. Therefore, please do not think it is a
faulty product if some pixels of a panel flickers or off all the time.
U.S.A.
U.S.FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
INFORMATION TO THE USER
NOTE : This equipment has been tested and found to comply with the limits for a
Class B digital device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet of a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for assistance.
Changes or modification not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Connecting of peripherals requires the use of grounded shielded signal cables.
BACK
NEXT
Safety Precautions ................................................... 1
Contents of the Package........................................... 3
Parts Names and Functions .................................... 5
Remote Control ........................................................ 7
Connecting VCR, Cable/Satellite Receiver ............. 11
Connecting a DVD player ....................................... 12
Connecting DTV(Digital Broadcast) Receiver ........ 13
Connecting to a PC(DVI, D-SUB) .......................... 14
Resolutions Supported in PC ................................ 15
How To Select Picture Mode ................................. 17
How To Set the User Picture ................................ 18
How To Select Sound Mode .................................. 19
How To Set the User Sound ................................. 20
How To Select the Aspect Ratio ........................... 21
How To Select Color Temperature ........................ 23
How To Know the Picture Information .................. 24
How To Adjust Image ............................................25
How To Adjust Image(Under PC Input Mode) ...... 26
How To Set Key-Lock ............................................27
How To Set Multi-Screen ...................................... 28
Still Function .......................................................... 31
How To Set OSD(On Screen Display) .................. 32
How To Set the Clock ...........................................33
How To Set On Time/Off Time ............................. 34
How to Set Sleep/Run Time .................................. 35
Cleaning and Caring .............................................. 37
Troubleshooting ...................................................... 38
Product Specifications ............................................ 39
1
*);1+;
<PMKWV\MV\[WN\PQ[[MK\QWVIZMXZW^QLMLNWZ\PM[INM\aWN][MZ[IVL\PMQZXZWXMZ\a
8TMI[MZMIL\PMKWV\MV\[JMNWZM][QVO
Safety instructions are divided into “warning”and “alert”. Their meanings are as follows.
This pictorial sign is used when a caution is needed on a potentially dangerous items and operations.
Warning
:When there is a possibility of serious injury or death upon violation of the displayed instruction.
Alert
:When there is a possibility of slight injury or product damage upon violation of the displayed instruction.
Firmly plus the power cord so
that it does not pull out.
- Unstable connection may cause fire.
Do not use damaged power cord
or plug, or loose outlet.
- They may cause electric shock or fire.
Never touch power plug with wet
hand.
- They may cause electrocution.
Do not put water bowl, vase,
candle, bug repellant smoke,
cigarette, small metal palette, or
heavy thing on a PDP.
- It may cause electric shock or fire and
also heavy things may cause injury when
it falls.
Do not install in a place where
there are oil, smoke, or humidity,
or where water is sprinkled or in
a car.
- They may cause electric shock or fire.
Do not install on an unstable place
or small support.
- If a child touch a PDP on such place while
playing, PDP may fall and injury the child.
?IZVQVO
HYUNDAI Plasma Display PD421
2
*);1+;
Do not use or store flammable
spray or inflammables in a place
near a PDP.
- They may cause explosion or fire.
Do not install a PDP in a
bookshelf, closet, or a place
where air is not well circulated.
- Fire may be caused due to the rise of
internal temperature.
Bend an antenna line downward on
a point where the line pass through
from outdoor to indoor so that
rainwater may not penetrate indoor.
- If raindrop gets into a PDP, fire or electric
shock may be caused.
Never separate, fix, or modify at
user’s discretion.
- When there is a need for fixing, call a
service center. Fire or electric shock
may be caused.
Do not put a metallic object like
chopstick, wire, or puncher or
inflammables like paper or a
match in a vent, headphone
jack, or AV jacks of PDP.
- Electric shock or fire may be caused.
When a PDP produces abnormal
noise, burning smell, or smoke,
unplug the PDP immediately and
call a service center.
- Electric shock or fire may be caused.
Unplug when you do not use your
PDP for long time.
- If dust is stacked on a PDP, electric shock
or fire may be caused from heat, fire, or
deterioration of insulation.
When moving a PDP, 2 or more
people are advised to carry it.
- Injury or damage may be caused when a
PDP falls.
Consult a service center or
customer service for inside cleaning
about once a year.
- When dust is collected inside a PDP for long
time, fire or malfunction may be caused.
?IZVQVO
3
*);1+;
<WX]ZKPI[MILLQ\QWVITXIZ\[KWV[]T\ILQ[\ZQJ]\WZWZ[MTTQVOIOMV\
1NaW]_IV\\WX]ZKPI[M[MXIZI\MTa[WTLXZWL]K\[KWV[]T\I[MZ^QKMKMV\MZMTMK\ZWVQK[[PWX[WZXIZ\[[MTTMZ
:MUW\M+WV\ZWT*I\\MZQM[
>))
8+[QOVITKIJTM8W_MZKWZL
+WUXW[Q\M>QLMW)]LQWKIJTM+WUXWVMV\A8J8Z+IJTM
,M[S\aXM[XMISMZ,M[S\aXM[\IVL ,M[S\aXM[XMISMZ[\IVL
=[MZœ[/]QLM
HYUNDAI Plasma Display PD421
4
*);1+;
.Q`ML_ITTUW]V\NZIUM )LR][\IJTM_ITTUW]V\NZIUM
+MQTQVOUW]V\NZIUM ;^QLMWKIJTM
,>18+^QLMWLQOQ\ITKIJTM
5
*);1+;
.ZWV\>QM_
Remote
sensor
and
power
LED.
Point the remote control toward here. It
displays standby or operation status.
Menu
button
Use this button to display or exit from
menus.
Source
button(Page
11~14)
Use this button to switch among inputs
connected to PDP.
PC, DVI, DTV, DVD, S-VIDEO, VIDEO,
SCART are sequentially chosen.
▲▼◀▶buttons
Use these buttons to select menu items
and to make adjustments.
When no menu is displayed, you can use
the ◀▶buttons to adjust the volume level.
Power
button:
Use this button to turn on or off a PDP
