HyperX Cloud Revolver Series Manuel utilisateur

HyperX Cloud Revolver Headset

Document No. 480HX-HSCR001.A01 HyperX Cloud Revolver Headset Page 1 of 10

Part Numbers: HX-HSCR-BK/AS HX-HSCR-

BK/EE

HX-HSCR-BK/EM

HX-HSCR-BK/LA

HX-HSCR-BK/NA

Introduction

HyperX Cloud Revolver™ has a wider audio range that creates depth and width for improved

audio precision. Get the competitive edge by hearing your opponents’ location more

accurately, even when they’re further away. Re-engineered audio profiles create a larger

sound stage that’s ideal for FPS and open-environment gameplay and for a concert-hall-like

experience when listening to music. Next-generation 50mm drivers direct sound into the ear for

precise audio positioning, making HyperX Cloud Revolver the only headset you need for both

PC and console gaming.

Document No. 480HX-HSCR001.A01 HyperX Cloud Revolver Headset Page 2 of 10

What’s included:

HyperX Cloud R

evolver Headset

Detachable

icrophone

Audio

ontrol box

Document No. 480HX-HSCR001.A01 HyperX Cloud Revolver Headset Page 3 of 10

Features:

•Studio-grade sound stage

•Signature HyperX memory foam with premium leatherette

•Durable steel frame

•Detachable noise-cancellation microphone

•Next-generation directional 50mm drivers Multi-platform compatibility

Technical specifications:

Headphone

•Driver: Dynamic, 50mm with neodymium magnets

•Type: Circumaural, closed back

•Frequency response: 12Hz–28,000 Hz

•Impedance: 30 Ω

•Sound pressure level: 104.5dBSPL/mW at 1kHz

•THD: < 2%

•Input power: Rated 30mW, maximum 500mW

•Weight: 360g

•Weight w/ mic: 376g

•Cable length and type: Headset (1m) + audio control Box (2m)

•Connection: Headset - 3.5mm plug (4 pole) + Audio Control Box - 3.5mm stereo and

mic plugs

Microphone

•Element: Electret condenser microphone

•Polar pattern: Uni-directional, Noise-cancelling

•Frequency response: 50Hz-18,000 Hz

•Sensitivity: -40dBV (0dB=1V/Pa,1kHz)

Overview

Document No. 480HX-HSCR001.A01 HyperX Cloud Revolver Headset Page 4 of 10

mic D.

urable

teel F

rame

Suspension headband

Detachable noise cancellation

Attached cable w/ 4 pole

3.5

mm plug

Audio control box with 3.5mm

stereo and mic plugs (2m)

Document No. 480HX-HSCR001.A01 HyperX Cloud Revolver Headset Page 5 of 10

Audio control box operation

The audio control box contains a volume dial to adjust the headphone output volume and

a microphone mute slider to mute the microphone output.

To increase the volume of the headset, rotate the volume wheel towards the + sign

(anticlockwise). To reduce the volume, rotate the volume wheel towards the –sign (clockwise).

To mute the microphone output, slide the microphone mute button to the down position. To

activate the microphone output, slide the microphone mute button to the up position.

Document No. 480HX-HSCR001.A01 HyperX Cloud Revolver Headset Page 6 of 10

Microphone

Active

Headphone

Volume

Microphone

Mute

Document No. 480HX-HSCR001.A01 HyperX Cloud Revolver Headset Page 7 of 10

Usage (PC)

To connect the headset to your computer (or other device) that has both a headphone jack

and a microphone jack, connect the headset’s 3.5mm plug to the female jack on the audio

control box. The audio control box has two 3.5mm jacks. The audio plug, which has green

stripes, plugs into the port signified by a green input or headphone symbol . The extension

cable microphone plug, which has pink stripes, plugs into the port signified by a pink input or a

microphone symbol .

Using with PC extension cable

Usage (Xbox One)

To use the headset with Xbox One™, connect the 3.5mm plug on the headset directly to the

3.5mm jack on the Xbox One controller

Document No. 480HX-HSCR001.A01 HyperX Cloud Revolver Headset Page 8 of 10

*If your Xbox One controller does not have a 3.5mm jack you will need the Xbox One Stereo Headset

adapter (sold separately) that plugs into the Xbox One controller (pictured below).

Using with Xbox One™

Usage (PlayStation4)

To use the headset with PlayStation®4 (PS4™), connect the 3.5mm plug on the headset

directly to the PS4 game controller and follow these steps:

Document No. 480HX-HSCR001.A01 HyperX Cloud Revolver Headset Page 9 of 10

1. Turn on your PS4 game console.

2. Navigate to the Settings menu and select it.

3. Highlight the ‘Devices’ menu option and select it.

4. Scroll down to ‘Audio Devices’ and select it.

5. Choose ‘Output to Headphones’ and select ‘All Audio’.

Using with PS4™

Usage (Wii U)

To use the headset with Wii U™, connect the 3.5mm plug on the headset directly to the Wii

U gamepad controller.
