Hydac MM-KKE-M-C-U Manuel
MM-KKE-M-C-U
Measuring
microscope
Operating and Maintenance Instructions
English (translation of original instructions)
Document no.: 3239239b
MM-KKE-M-C-U Trademarks
Trademarks
The trademarks of other companies are exclusively used for the products of those
companies.
Copyright © 2011 by
HYDAC Filter Systems GmbH
all rights reserved
All rights reserved. This manual may not be reproduced in part or whole without the
express written consent of HYDAC FILTER SYSTEMS GMBH. Contraventions are
liable to compensation.
Exclusion of Liability
We have made every endeavor to ensure the accuracy of the contents of this
document. However, errors cannot be ruled out. Consequently, we accept no
liability for such errors as may exist nor for any damage or loss whatsoever which
may arise as a result of such errors. The content of the manual is checked regularly.
Any corrections required will be incorporated in future editions. We welcome any
suggestions for improvements.
All details are subject to technical modifications.
Technical specifications are subject to change without notice.
HYDAC FILTER SYSTEMS GMBH
Postfach 12 51
66273 Sulzbach / Saa
r
Germany
Documentation Representative
Mr. Günter Harge
c/o HYDAC International GmbH, Industriegebiet, 66280 Sulzbach / Saar
Telephone: ++49 (0)6897 509 1511
Telefax: ++49 (0)6897 509 1394
HYDAC FILTER SYSTEMS GMBH en Page 2/32
BeWa MM-KKE-M-C-U 3239239b en-us 2011-10-10.doc 2011-09-27
MM-KKE-M-C-U Content
HYDAC FILTER SYSTEMS GMBH en Page 3/32
BeWa MM-KKE-M-C-U 3239239b en-us 2011-10-10.doc 2011-09-27
Content
Trademarks ...............................................................................................................2
Documentation Representative...............................................................................2
Content......................................................................................................................3
Preface ...................................................................................................................... 4
Technical Support...................................................................................................5
Modifications to the Product ...................................................................................5
Warranty .................................................................................................................5
Using the Documentation .......................................................................................6
Safety information and instructions....................................................................... 7
Obligations and liability ........................................................................................... 7
Explanation of Symbols and Warnings, etc. ...........................................................8
Proper/Designated Use .......................................................................................... 8
Improper Use .......................................................................................................... 8
Transporting the microscope..................................................................................9
Storing the microscope ........................................................................................... 9
Checking the Scope of Delivery............................................................................ 10
Microscope features .............................................................................................. 11
System requirements............................................................................................ 11
Components on the microscope...........................................................................12
Installing the microscope ...................................................................................... 16
Assembling the illuminator (cold light source) ................................................... 17
Installing and setting the camera .........................................................................19
Installing the image processing software.............................................................. 20
Operating the microscope..................................................................................... 21
Performing a measurement................................................................................... 22
Evaluating a filter membrane / sample.................................................................23
Performing Maintenance ....................................................................................... 24
Cleaning / maintaining the microscope................................................................. 24
Replacing the bulb on the microscope.................................................................. 25
Replacing the illuminator bulb............................................................................... 27
Disposing of your microscope..............................................................................28
Model Code ............................................................................................................. 29
Technical Data ........................................................................................................30
MM-KKE-M-C-U Preface
Preface
For you, as the owner of a product manufactured by us, we have produced this
manual, comprising the most important instructions for its operation and
maintenance.
It will acquaint you with the product and assist you in using it as intended in an
optimal manner.
Keep it in the vicinity of the product so it is always available.
Note that the information on the unit's engineering contained in the documentation
was that available at the time of publication.There may be deviations in technical
details, figures, and dimensions as a result.
If you discover errors while reading the documentation or have additional comments
or suggestions, contact us at:
HYDAC FILTER SYSTEMS GMBH
Technische Dokumentation
Postfach 12 51
66273 Sulzbach / Saar
Germany
We look forward to receiving your input.
“Putting experience into practice”
HYDAC FILTER SYSTEMS GMBH en Page 4/32
BeWa MM-KKE-M-C-U 3239239b en-us 2011-10-10.doc 2011-09-27
MM-KKE-M-C-U Preface
HYDAC FILTER SYSTEMS GMBH en Page 5/32
BeWa MM-KKE-M-C-U 3239239b en-us 2011-10-10.doc 2011-09-27
Technical Support
If you have any questions, suggestions, or encounter any problems of a technical
nature, please don't hesitate to contact us. When contacting us, please always
include the model/type designation, serial no. and part-no. of the product:
Fax: ++49 (0) 6897 / 509 - 846
Modifications to the Product
We would like to point out that changes to the product (e.g. purchasing options, etc.)
may result in the information in the operating instructions no longer being completely
accurate or sufficient.
After modification or repair work that affects the safety of the product has been
carried out on components, the product may not be returned to operation until it has
been checked and released by a HYDAC technician.
Please notify us immediately of any modifications made to the product whether by
you or a third party.
Warranty
For the warranty provided by us, please refer to the General Terms of Sale and
Delivery of HYDAC FILTER SYSTEMS GmbH.
They are available at: www.hydac.com -> Legal information.
MM-KKE-M-C-U Preface
Using the Documentation
Note that the method described for locating specific information does
not release you from your responsibility of carefully reading these
instructions prior to starting the unit up for the first time and at regular
intervals in the future.
What do I want to know?
I determine which topic I am looking for.
Where can I find the information I’m looking for?
The documentation has a table of contents at the beginning. There, I select
the chapter I'm looking for and the corresponding page number.
de
HYDACFiltertechnikGmbH
BeWa12
34
56a
d
e
Seit e x
Produkt/Kapitel
200x-xx- xx
Chapter description
Page number
Edition date
Document language
Documentation no.
with index/
file name
The documentation number with its index enables you to order another copy of the
operating and maintenance instructions.
The index is incremented every time the manual is revised or changed.
HYDAC FILTER SYSTEMS GMBH en Page 6/32
BeWa MM-KKE-M-C-U 3239239b en-us 2011-10-10.doc 2011-09-27
MM-KKE-M-C-U Safety information and instructions
HYDAC FILTER SYSTEMS GMBH en Page 7/32
BeWa MM-KKE-M-C-U 3239239b en-us 2011-10-10.doc 2011-09-27
Safety information and instructions
These operating instructions contain the key instructions for properly and safely
operating the measuring microscope.
Obligations and liability
The basic prerequisite for the safe and proper handling and operation of the
measuring microscope is knowledge of the safety instructions and warnings.
When handling the measuring microscope, please observe in particular these
operating and maintenance instructions, in particular the rules and regulations on
accident prevention applicable for the place of operation.
The measuring microscope has been designed and constructed in accordance with
current state of the art technology and recognized safety regulations. Nevertheless,
hazards may be posed to the life and limb of the individual using the unit, or the
ROCS or other material assets may be damaged.
Only use the measuring microscope as follows:
Only for proper or designated use.
Only when in safe, perfect condition.
Immediately remedy any malfunctions that might impair safety.
Our General Terms and Conditions apply. Any and all warranty and liability claims
for personal injuries and damage to property shall be excluded in the event they are
attributable to one or more of the following causes.
MM-KKE-M-C-U Safety information and instructions
Explanation of Symbols and Warnings, etc.
The following designations and symbols are used in this manual to designate
hazards, etc.:
DANGER
DANGER denotes situations
which can lead to death if
safety precautions are not
observed.
WARNING
WARNING denotes situations
which can lead to death if
safety precautions are not
observed.
CAUTION
CAUTION denotes situations
which can lead to severe
injuries if safety precautions
are not observed.
NOTICE
NOTICE denotes situations
which can lead to property
damage if instructions are not
followed.
Proper/Designated Use
Use the measuring microscope for optical evaluation of filter membranes and for the
enlargement / visualization of particles etc.
Analyzing the type, size and quantity of contamination enables quality standards to
be verified and documented, and the requisite optimization measures to be
implemented.
Improper Use
Never look into the sun /sunlight using the microscope. This may damage your
eyesight.
HYDAC FILTER SYSTEMS GMBH en Page 8/32
BeWa MM-KKE-M-C-U 3239239b en-us 2011-10-10.doc 2011-09-27
MM-KKE-M-C-U Transporting the microscope
HYDAC FILTER SYSTEMS GMBH en Page 9/32
BeWa MM-KKE-M-C-U 3239239b en-us 2011-10-10.doc 2011-09-27
Transporting the microscope
NOTICE
Transporting the microscope without a transport container
The measuring microscope will be damaged.
►Transport the measuring microscope only in a closed transport container;
carry it in vertical position or by the handle.
Storing the microscope
NOTICE
Storing the microscope without a transport container
The measuring microscope will be damaged.
►Store the microscope in a clean and dry location in its closed transport case
and in a horizontal or vertical position. The microscope must not be exposed
to any shaking or vibration.
MM-KKE-M-C-U Checking the Scope of Delivery
Checking the Scope of Delivery
The measuring microscope comes packed and partially factory-assembled. Before
commissioning, check the contents of the package to make sure it has not been
damaged during transport and that it is complete.
The following items are supplied:
Item Qty Description
1 1 Microscope stand with trinocular optical head, specimen stage,
objective lens turret and illuminator
2 2 Eyepiece
3 1 Objective lens 4:1 (already mounted on the objective lens turret)
4 1 Objective lens 10:1 (already mounted on the objective lens turret)
5 1 Objective lens 20:1 (already mounted on the objective lens turret)
6 2 Connection cable, L=1.5 m
7 1 Camera with micrometer eyepiece
8 1 Power supply for camera
9 1 S-VHS connection cable, L = 5 m
10 1 Cold light illuminator, 100 W
11 1 Fiber optic gooseneck, dual-arm
12 1 WinTV USB (external TV card) including
USB connection cable, L=1.8 m
13 1 CD-ROM containing the software for on-screen image viewing
14 1 Transport case
- 1 Replacement bulb, replacement fuse, ground glass plate (transparent /
blue-tinted)
1
11
10
6
6
14
8
9
12
13 7
2
HYDAC FILTER SYSTEMS GMBH en Page 10/32
BeWa MM-KKE-M-C-U 3239239b en-us 2011-10-10.doc 2011-09-27
Table des matières
Manuels Microscope populaires d'autres marques
VWR
VWR VisiScope 384 Series Manuel utilisateur
Nikon
Nikon ECLIPSE E200 POL Manuel utilisateur
Leica
Leica DI C800 Manuel
ThermoFisher Scientific
ThermoFisher Scientific Continuµm Manuel utilisateur
ThermoFisher Scientific
ThermoFisher Scientific Continuµm Manuel utilisateur
Olympus
Olympus SZ61 Manuel utilisateur
