Product Instruction Manual

Microboil Smart

Wall Mounted Boiling Water Heater

MS3W, MS3SS

MS6W, MS6SS

MS10W, MS10SS

v23.11.1

Overview

Thank you for purchasing a Microboil Smart wall mounted boiling water heater. Available

in 3, 6 and 10 litre capacities, it will provide hot water for making tea and coee in the work

place.

Please read and follow these instructions to ensure that installation and operation are as

simple and safe as possible.

This appliance is intended to be used in household and similar applications such as:

– sta kitchen areas in shops, oces and other working environments;

– farm houses;

– by clients in hotels, motels and other residential type environments;

– bed and breakfast type environments.

This appliance can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Parts of this appliance – especially the vent pipe and tap– can become very hot in

use and can also generate steam. Consider and avoid the risk of injury to people or

damage to property when installing the appliance.

The appliance should only be installed and maintained by a competent person in

accordance with any local electrical and plumbing regulations.

Do not install the appliance if there is any sign of damage to the supply cable.

Do not locate the appliance where the consequences of a water leak could be

unusually serious.

If the supply cord is damaged, it must be replaced by the manufacturer, its service

agent or similarly qualied persons in order to avoid a hazard.

The appliance must be permanently connected to the electrical supply through an

appropriately rated isolating switch with a contact separation in all poles.

Only connect the appliance to an electrical supply that meets the specication

detailed on the rating label.

Important Safety Points

This appliance must be earthed.

This appliance is intended to be permanently connected to the water mains and

should not be connected by a detachable hose-set.

Only connect this appliance to a water supply that meets the min/max pressures

specied in the specications section of this manual.

Do not confuse the vent and the inlet pipes – serious damage may result.

Any plastic pipework or ttings connected to the vent pipe must be rated to 100°C

minimum.

Failure to comply with the venting requirements detailed in these instructions may

cause permanent damage to the appliance and will invalidate the warranty.

Cleaning and user maintenance shall not be made by children without supervision.

Children shall not play with the appliance.

Isolate the appliance from the electrical supply before performing any maintenance

task.

Ensure the appliance has cooled down before performing any maintenance task.

The appliance should be drained if it will be switched o and unattended for any

length of time, particularly during the colder months of the year where a possibility

of freezing temperatures exists.

For installations in areas with hard water, consider scale reduction lters to

minimise the need for future descaling.

1. Installation

1(a) Remove the Cover

• The cover is attached to the back frame by means of two screws at the base and top

of the appliance (see Diagram 1).

1(b) Select Mounting Position

Ensure the mounting surface is suitable for the weight of the appliance when full.

Parts of this appliance – especially the vent pipe and tap – can become very hot

and also could generate steam. Consider and avoid the risk of injury to people or

damage to property when installing the appliance.

Do not locate the appliance where the consequences of a water leak would be

unusually serious.

Diagram 1

• The appliance must be installed in a frost free environment. Frost damage is not

covered by the warranty.

• Ensure there is a wholesome water supply connection to the appliance with isolating

valve to facilitate future maintenance.

• Position the appliance bearing in mind it will contain scalding water.

• Units are typically mounted above a draining board or drip tray in a kitchen or similar

setting. The tap height should be convenient for both the operator and such that

visual contact is maintained with the liquid level of any vessel being lled.

• Ensure adequate clearance is left above the appliance to access the cover screws

using a screwdriver in order to remove the cover for servicing. Ensure there is

sucient clearence under the drain for a bucket or similar container.

Ensure there are no hidden cables or pipework before commencing any drilling.

1(c) Secure to Wall

• Mark positions of the keyhole slots, drill and plug the holes (see Diagram 2).

• Hang the appliance on the two screws and mark the two mounting holes in the

bottom of the appliance. Remove the appliance from the wall, drill and plug the two

holes. Rehang the appliance on the top two screws and screw the appliance to the

wall.

Diagram 2

2. Plumbing Connection

This appliance is intended to be permanently connected to the water mains and

should not be connected by a detachable hose-set.

Only connect this appliance to a water supply that meets the min/max pressures

specied in the specications section of this manual.

Any plastic pipework or ttings connected to the vent pipe must be rated to 100°C

minimum.

The appliance should only be used with the tap provided. Do not attempt to

change or modify in any way.

Do not confuse the vent and the inlet pipes – serious damage may result.

The appliance will malfunction if steam cannot easily escape via the vent pipe.

Failure to comply with the venting requirements detailed in these instructions may

cause permanent damage to the appliance and will invalidate the warranty.

• If incoming water pressure is above 1MPa (10 bar), a pressure reducing valve (not

supplied) must be tted.

• The appliance has movable inlet and vent connections. This allows the appliance

to be retrotted to previously installed pipe work. The height from the mounting

surface and the distance between the pipes can be adjusted by loosening the screws

and moving to the required position (see Diagram 3).

• The appliance can be installed with concealed or exposed plumbing connections.

Cold water pipes must be ushed before connection to the inlet.

26 - 42 mm

36 - 48 mm

WALL

Diagram 3

• All models will take 15mm pipe by means of compression ttings.

• Connect the cold water supply to the inlet connection below the solenoid valve (see

Diagram 4).

Diagram 4

Solenoid valve

• For the vent connection it is important that the vent pipe installation adheres to the

following specication;

- Falls continuously.

- Has a maximum total length of 400mm before any air gap.

- Is open to the atmosphere (no blockages).

- All ttings must be rated for continuous operation at a minimum of 100°C.

• The vent pipe can be more than 400mm long but if it is, a tundish or other air gap

device must be tted within the 400mm distance to the appliance (see Diagram 5).

3. Retting the Cover and Installing the Tap

• Slide the cover back over the appliance, taking care not to trap the vent tube at the

side of the appliance. Then secure with the 4 cover screws (see Diagram 1).

• Press the tap stem into the tank outlet, whilst holding the tap vertically so the tap

outlet points downward (see Diagram 6). Tighten the securing nut using a spanner

(see Diagram 7). Take care to not scratch the chrome.

• Ensure the tap is tight and correctly orientated. The stem and outlet of the tap are hot

when in use.

Diagram 6 Diagram 7

Diagram 5

4. Electrical Connection

The appliance must be permanently connected to the electrical supply through an

appropriately rated isolating switch with a contact separation in all poles

Only connect the appliance to an electrical supply that meets the specication

detailed on the rating label.

This appliance must be earthed.

The appliance should only be installed and maintained by a competent person in

accordance with any local electrical and plumbing regulations.

Ensure a water supply is present prior to turning on the electrical supply.

• Electrical connection should be made via a 13A switched fuse spur.

• Make connections as below;

- Green/Yellow earth wire to terminal marked

- Brown live wire to the terminal marked‘L’

- Blue neutral wire to the terminal marked ‘N’

5. Commissioning (rst power on)

• Ensure water supply is on.

• Switch power on.

• Automatic commissioning will then commence under the control of the electronic

circuit board. The (automatic) stages in commissioning are as follows:

• At rst power on, the water tank will completely ll with cold water through the

solenoid valve. This will take approximately 5 - 20 minutes depending on capacity of

the appliance.

• When the electronic level sensor detects that the tank is full of water, the heating

element is switched on.

• The status ring on the base of the tap stem will indicate the appliance is heating (red).

• When the water has reached operating temperature the commissioning phase ends

and the appliance switches to normal operating mode. The heating phase will take

approximately 5 - 20 minutes depending on capacity of the appliance.

• The status ring will now indicate the appliance is ready to use (green).

• In operating mode, the electronic circuit board optimises boiling water availability.

The circuit board prioritises heating over lling, adding cold water only when the

contents of the tank are already at operating temperature.

6. Operation

Parts of this appliance – especially the vent pipe and tap– can become very hot in

use and can also generate steam. Consider and avoid the risk of injury to people or

damage to property when installing the appliance.

This appliance can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance.
