HUSKY LINERS 6582 Manuel

6582 Front_Back.doc

12/08/2004

THANK YOU FOR SELECTING A HUSKY FLOOR LINER

FROM WINFIELD CONSUMER PRODUCTS

CARE AND USE INSTRUCTIONS

Your new floor liner is custom molded to fit your particular vehicle. The liner is made to take the place of

your factory floor mats. For correct fit, it is necessary to remove the factory floor mats before installing your

new floor liner. However, do not remove the factory-installed carpeting.

Your liner is made from an engineering resin that is lightweight and extremely tough and durable. The

easiest way to clean your liner is with a damp cloth or sponge. If using a cleaner, 409®or Glass Plus®work

well. Use of Armor All®, Son-of-a-Gun®or similar items is discouraged as these products make the liner slick.

INSTALLATION INSTRUCTIONS FOR YOUR LEXUS

RX-330 SECOND SEAT FLOOR LINER

YOUR LEXUS RX 330 COMES STANDARD WITH AN ADJUSTABLE LENGTH CONSOLE. BY MOVING THE

CONSOLE, YOU CAN INCREASE/DECREASE THE SECOND SEAT PASSENGERS’ FLOOR SPACE AS WELL

AS FRONT PASSENGERS’ STORAGE SPACE. YOUR HUSKY LINER IS DESIGNED TO ACCOMMODATE THE

MOVEMENT OF THE CONSOLE SHOULD YOU DECIDE TO ADJUST IT.

IN ITS ORIGINAL (OUT OF THE BOX) CONFIGURATION, YOUR HUSKY LINER FITS WITH THE CONSOLE

ADJUSTED TO THE MOST FORWARD POSITION. THIS POSITION ALLOWS THE MAXIMUM SECOND SEAT

PASSENGER’S FLOOR SPACE; HOWEVER, THE CONSOLE CANNOT BE ADJUSTED TO THE REAR TO

ALLOW FOR MORE FRONT PASSENGER STORAGE. TO ALLOW FOR REARWARD MOVEMENT OF THE

CONSOLE, YOUR HUSKY LINER MUST BE TRIMMED. THE NECESSARY TRIMMING IS EASILY DONE;

DETAILED PHOTOS OF THE NECESSARY TRIMMING ARE INCLUDED ON THE REVERSE SIDE OF THIS

INSTRUCTION SHEET.

FRONT OF VEHICLE

6582 Front_Back.doc

12/08/2004

PHOTO 1

PART #6582 SHOWN “UNTRIMMED” IN PHOTO 1 AND “TRIMMED” IN PHOTO 2. TRIM BY FOLLOWING THE

EDGE FORMED BY THE LOWERED AREA IN THE PART THEN (SEE INSET PHOTOS) CONTINUING ALONG

THE INTERSECTION OF THE WALL AS SHOWN BELOW. ONCE THE WALL IS TRIMMED AWAY, THE

CONSOLE WILL SLIDE OVER THE REMAINING TREAD PLATED AREA.

PHOTO 2
