Total Air PurificationTotal Air PurificationTotal Air Purification

Form# 44069-01

20100618

Permanent HEPA

Air Purifier

Owner’s Manual

Model

30849

English

TABLE OF CONTENTS

Introduction ............................................................. 3

Safety Instructions ..................................................... 3

Setting Up Your Air Purifier ....................................... 5

How The System Works ............................................ 6

Operating Your Air Purifier ....................................... 7

Remote Operation .................................................... 7

Air Purifier Maintenance ........................................... 7

Check or Clean Your Pre-Filter 8

Check or Clean Your Filter 8

Replace The UVC Bulb 8

Clean the Unit 9

Troubleshooting ...................................................... 10

Technical Support ................................................... 10

Filter Ordering ....................................................... 11

Warranty ............................................................... 11

Products ................................................................ 11

Filter and UVC Calendar ........................................ 14

Notes .................................................................... 14

SPEED

ON / OFF

SPEED

3High Particulate Efficiency: The permanent

HEPA filter will remove up to 99.9% of particles as

small as 0.3 micron particles from the air that passes

through the filter.

3Washable Pre-Filter: The washable pre-filter is

permanent and can be cleaned and reused.

3UVC Lamp: This Hunter Air Purifier is equipped

with a UVC germicidal lamp. UVC technology is a

proven germicide that is accepted by the FDA and

EPA as having the ability to kill pathogens in air that

are exposed to UVC light.

3Photocatalitic Oxidation: Reduces the amount

of toxic VOCs in the air caused by household cleaners

and products.

3Oxygenating Catalyst: Converts ozone and

smog into oxygen for cleaner air and peace of mind.

3Remote Operation: Convenient remote allows

operation of UVC and speed settings.

SAFETY INSTRUCTIONS

1. WARNING: This Air Purifier emits UVC radiation that

may cause eye and/or skin irritation. RG-3. Avoid

exposing eyes and skin to unshielded UVC Lamp.

2. CAUTION: The UVC Lamp may shatter and cause

injury if it is dropped or sustains impact. Wear safety

glasses and gloves when handling the UVC Lamp.

IMPORTANT!

READ ALL INSTRUCTIONS BEFORE USING THIS AIR

PURIFIER.

INTRODUCTION

Thank you for purchasing the Total Air Purification System

from Hunter Fan Company. You have purchased our

latest development in Portable Air Purification Systems.

This system has been developed to improve the quality of

the air you breathe.

Our Permanent HEPA Air Purification System out

performs other air purification systems by quickly and

effectively removing dust, smoke, and pollen particles as

small as 0.3 microns in size. The following innovative

features are included in your Hunter Air Purifier.

Do not use excessive force when handling the UVC

Lamp. Dispose of the UVC bulb in accordance with

local or State guidelines as trace amounts of Mercury

are present.

3. This Air Purifier is designed for use on a level floor and

may not work properly on an uneven floor. ALWAYS

place the Air Purifier on a firm, level floor. ALWAYS

place the Air Purifier at least six (6) inches away from

walls and heat sources such as stoves, radiators, or

heaters.

4. Place the Air Purifier in an area that is out of the reach

of children.

5. Before using the Air Purifier, extend the cord and

inspect for any signs of damage. DO NOT use the

product if the cord has been damaged.

6. To reduce the risk of electric shock, this product has

a polarized plug (one blade is wider than the other)

as a safety feature. This plug will fit into a polarized

outlet only one way. If the plug does not fit fully into

the outlet, reverse the plug. If it still does not fit, contact

a qualified electrician. DO NOT attempt to defeat or

override this safety feature.

7. ALWAYS UNPLUG the Air Purifier while it is being

cleaned.

8. DO NOT move or tilt the Air Purifier while it is in

operation. Turn off and unplug before moving.

9. DO NOT immerse the Air Purifier in water at any time

because permanent damage will occur. To properly

clean your Air Purifier, follow the instructions in the

Maintenance section of this manual “Air Purifier

Maintenance” on page 7.

10. This equipment should be inspected frequently and

collected dirt removed from it regularly to prevent

excessive accumulation that could result in flashover

or risk of fire.

Figure 1.

SETTING UP YOUR AIR PURIFIER

1. Take the Air Purifier out of the box and remove the

clear plastic protective bag and place the unit on a

firm, level surface.

2. Before turning on the Air Purifier, you need to confirm

that the filters are firmly in place and have not become

loose during shipping. To check the filters, push down

on the tab under the handle. Figure 1.

3. Gently pull the rear grill away from the unit and lift

away. Figure 2.

4. The washable Pre-Filter is mounted inside the back

grill of the unit. Confirm that it properly covers the

grill vents.

5. The Permanent HEPA Filter will be resting inside the

unit. If present, remove the plastic bag surrounding

the filter and place the filter back into the Air Purifier.

The filter should have arrows on the side to indicate

air flow and the direction the filter should be placed

back into the unit. Figure 3.

6. Set the tab on the bottom of the rear grill into the slot

in the base of the unit and rock the grill up until the

top tab snaps into place. Figure 4.

7. Plug the unit into a 120V electrical outlet.

Figure 2.

Figure 4.

Figure 3.

Permanent

HEPA Filter

Tab

HOW THE SYSTEM WORKS

Dust and other irritants are pulled into the Air Purifier by the fan. The Washable Pre-Filter

attracts larger particles like pet dander and hair and traps them on the Pre-Filter. Smaller

particles such as dust, mold, and pollen pass through the Pre-Filter and are captured by the

Permanent HEPA filter. Up to 99.9% of particles can be captured.

The UVC Light helps kill particles not trapped on the Permanent HEPA Filter and the

Photocatalytic Oxidation screen removes harmful VOC’s. Clean, purified air is then released

into the room through the front grill as the Oxygenating Catalyst converts smog and ozone

back into oxygen. Figure 5.

Figure 5.

Grill

Permanent

HEPA Filter

Washable

Pre-Filter

Unit

UVC

Light

Photocatalytic

Oxidizer

Oxygenating Catalyst

AIR PURIFIER MAINTENANCE

It is necessary to periodically check your Air Purifier for

performance. If the Pre-Filter and/or Permanent HEPA

Filter are covered in dust and other captured particles, it

will be necessary to clean one and or both. The Pre-Filter

and Filter should be checked at least every 6 months. The

UVC Light should be replaced every year.

NOTE: Some environments may require more frequent

cleaning of each filter. In these situations, adjust the time

you check your filters to ensure the filters stay clog free to

optimize performance.

Figure 8.

Press

Down

OPERATING YOUR AIR PURIFIER

Figure 6.

SPEED

ON / OFF

SPEED

UVC

on/off

Speed

Ultra Low - No background noise.

Low speed - Recommended for use when soft

background noise is unwanted.

Medium speed - Typical usage setting. Soft

background noise is not an issue.

High speed - Use when quick, efficient results

to a room’s air quality are desired.

The fan speed can be adjusted at any time by pressing

the Speed button until the desired speed is selected.

Press the UVC Light Button to turn on and off the

UVC function of your Air Purifier.

NOTE: The ON/OFF Indicator and the UVC Indicator

will stay lit while the fan and/or UVC is running.

OFF

Figure 7.

REMOTE OPERATION

See Figure 7.

OFF Turns the unit on or off.

UV Turns the UVC light on or off.

Adjusts the speed of the air purifier between

high, medium, or low.

Figure 11.

Replace The UVC Bulb

The UVC light should be replaced once yearly. Follow

these instructions to remove and replace the UVC bulb.

1. Unplug the unit from the wall outlet and remove the

back grill by pressing down on the top tab. Figure 12.

Check or Clean Your Filter

1. Turn the Air Purifier off and disconnect from the wall.

2. Remove the rear grill on the back of the unit by

pressing the tab at the top of the unit, under the

handle and pull the rear grill outward. Figure 8.

3. Remove the Permanent HEPA Filter from the unit.

4. Check the Filter for particle build-up.

5. To clean, use a vacuum cleaner with an upholstery

brush attachment, gently run the upholstery brush

over the cleanable filter until all particles are removed

from the filter. An arrow indicating which side to clean

is present on the top of the filter. Figure 9.

Note: Filter discoloration is normal and will not be

removed by vacuuming. Do not attempt to wash the filter

as damage to the filter or Air Purifier may occur.

Figure 9.

Figure 10.

Screws

Check or Clean Your Pre-Filter

1. Turn the Air Purifier off and disconnect from the wall.

2. Remove the rear grill on the back of the unit by

pressing the tab at the top of the unit, under the

handle and pull the rear grill outward. Figure 8.

3. Turn the Rear grill over and gently remove the Pre-

Filter from the grill.

4. Check the Pre-Filter side facing the grill for particle

coverage.

5. If the Pre-Filter needs to be cleaned, It may be

submerged in warm soapy water to clean. Gently lift

and submerge the filter several times to clean.

6. When complete, rinse the filter with warm water and

allow to dry completely.

Note: Wet parts placed into the unit can cause damage

to the filters and or the motor of the Air Purifier.

Figure 15.

2. Remove the 2 screws holding the Photcatalytic Screen

in place and remove the screen. Figure 10.

3. Remove the 3 screws holding the UVC Guard in place

and remove it from the unit. Figure 11. & 12.

4. Grasp the bulb with your thumbs and forefingers at

the plastic top and bottom and gently roll the bulb to

the left. Figure 13.

5. When the bulb releases, slide the top of the bulb out

of the bracket and remove.

6. Partially remove the new UVC Bulb from it’s packaging

being careful not to let the bulb come in contact with

your skin.

Note: Oils from your skin can cause damage to the bulb

and will prevent it from working.

7. Using the bag the bulb came in to prevent skin contact

with the bulb, insert the base of the bulb into the lower

UVC socket in the unit, with the flat side of the base

facing the opening of the unit. Figure 14.

8. Insert the top part of the UVC bulb into the top socket

and roll the bulb to the right util it locks into place.

Note: If the UVC Bulb Guard is not re-installed correctly,

the unit will not run.

9. Reattach the UVC Guard by inserting the back tabs

into the Air Purifier and secure the 3 screws holding it

back in place. Figure 15.

10. Align the Photocatalytic Screen over the 2 holes in

the unit and screw it back into place.

11. Set the tab on the bottom of the rear grill into the slot

in the base of the unit and rock the grill up until the

top tab snaps into place.

Figure 16.

Clean the Unit

Clean the outside of the unit with a soft, damp cloth.

The rear grill can be cleaned in soapy water after it has

been removed from the unit and the pre-filter has been

removed.

NOTE: Ensure the grill is completely dry before

reinstalling it on the unit. Failure to do so could cause

damage to the filters or motor.

Figure 14.

Figure 13.

TROUBLESHOOTING

Problem:

No Operation.

Solution:

3Confirm that the unit is plugged in.

3Check the installation of the Rear grill.

3Check the installation of the UVC Lamp Cover.

Problem:

Unit has reduced air flow or increased noise.

Solution:

3 The filter may be clogged and needs to be

cleaned. See “Check or Clean Your Filter” on

page 10.

Problem:

The UVC Lamp is not operating.

Solution:

3Check the installation of the UVC Bulb.

3Replace the UVC Bulb. See “Replace The UVC Bulb”

on page 8.

If you have any additional questions or problems with

your Hunter Air Purifier, please call:

USA: 1-888-830-1326

Canada: 1-866-268-1936

Hours of operation are from 7:00 am to 7:00 pm

Monday - Friday and 8:00 am to 5:00 pm on Saturday,

Central Time. You may also contact us over the Internet at

www.hunterfan.com.

TECHNICAL SUPPORT

Table des matières

Autres manuels Hunter Purificateur d'air

Hunter

Hunter Permalife 30748 Manuel utilisateur

Hunter

Hunter 30836 Manuel utilisateur

Hunter

Hunter HEPAtech 30078 Manuel utilisateur

Hunter

Hunter HEPAtech 30057 Manuel utilisateur

Hunter

Hunter HEPATECH 30378 Manuel utilisateur

Hunter

Hunter 30993 Manuel utilisateur

Hunter

Hunter 30703 Manuel utilisateur

Hunter

Hunter 37711 Manuel utilisateur

Hunter

Hunter permalife 30023 Manuel utilisateur

Hunter

Hunter HEPATECH 30700 Manuel utilisateur

Hunter

Hunter 30903 Manuel utilisateur

Hunter

Hunter HEPAtech 30124 Manuel utilisateur

Hunter

Hunter PermaLife 30706 Manuel utilisateur

Hunter

Hunter QuietFlo 30145 Fiche technique

Hunter

Hunter HEPAtech 30057 Manuel utilisateur

Hunter

Hunter QuietFlo 30210 Manuel utilisateur

Hunter

Hunter 30300 Manuel utilisateur

Hunter

Hunter HEPATECH 30378 Manuel utilisateur

Hunter

Hunter QuietFLO 30525 Manuel utilisateur

Hunter

Hunter Argenius 30580 Manuel utilisateur

Hunter

Hunter 30300 Manuel utilisateur

Hunter

Hunter Ceiling Fan Light Kits Manuel utilisateur

Hunter

Hunter HEPATECH 30378 Manuel utilisateur

Hunter

Hunter Quietflo 30085 Manuel utilisateur

Manuels Purificateur d'air populaires d'autres marques

IKEA

IKEA UPPÅTVIND Manuel utilisateur

Nash

Nash AP-1 PureSmart Manuel utilisateur

LG PH-U450 Series Manuel utilisateur

DeLonghi

DeLonghi DDSX 220WFA Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manuel utilisateur

Sharp

Sharp FU-40SE Manuel utilisateur

Philips

Philips AC2721 Manuel utilisateur

Hitachi

Hitachi EP-A3000 Manuel utilisateur

TruSens

TruSens Z-2000 Manuel utilisateur

Motorola

Motorola MBP87SN Manuel utilisateur

Beko

Beko ATP 7100I Manuel utilisateur

Carrier

Carrier INFINITY 1620 Manuel utilisateur

AtmosAir

AtmosAir P2002 Manuel utilisateur

Winix

Winix NK300 Manuel utilisateur

Friedrich

Friedrich C-90A Instructions d'utilisation et d'installation

Surgically Clean Air

Surgically Clean Air JADE2.0 Manuel utilisateur

Base aire

Base aire 555 Pro Manuel utilisateur

Champion

Champion CP25 Manuel utilisateur
