HuddleCamHD RS-232 Manuel utilisateur
HuddleCamHD RS-232 Joystick Controller
Supports VISCA, Pelco-D & Pelco-P Protocols
3D Joystick for Variable Speed Control, PTZ and more
Only $300!
Providing RS-232 Control for Video
Conferencing Solutions in the 21st Century
www.HuddleCamHD.com
Product Features:
· Metal Housing, computer keyboard design
· Support PELCO-D, PELCO-P and VISCA protocols
· Chinese/English LCD, key-pressing prompting voice available
· With three dimensional joystick, can variable speed control the camera or Pan/tilt
· Two dimensional keyboard control, can get accurate step speed
· Can control the camera or pan/ tilt rotation, zoom, iris, focus and camera parameter
setting
· Can control the camera or pan/ tilt preset tour, pattern, absolute position, zoom
operation, AUX operation and so on
· Real time display the decoder and matrix’s working status
· Short circuit and overcurrent protection, automatic recovery program design for
communication port
· Multi interface control signals: RS485, RS422, RS232, can control max. 256 unit of
camera.
· Max. Communication distance: 1200M (0.5MM twisted pairs).
Technical Specs:
· Communcation Mode RS-485 semiduplex,
· RS-422 full-duplex, RS232 full-duplex
· Baud Rate 1200/2400/4800/9600BIT/S
· Interface RJ45 net network interface,
· RS232 standard jack, terminal
· Voltage: DC12V
· Power: 5W
· Display: LCD
· Working Temperature: -10° ~ +50° C
· Working Humidity: 10~90%(non-condensation)
· Weight
· Dimension: 271MM(L)X 181MM(W)X 54MM(H)
Easy Pan Tilt Zoom Controls for
any RS-232 VISCA protocol
camera! Control Pan Tilt controls
with variable speeds of slow/
medium/fast. Use 2 & 3
Dimensional Joy stick with “Twist”
Controls for Focus and Zoom.
