Huawei Vodafone R207 Caractéristiques techniques

Product Description

R207 Mobile WiFi Product Description

V100R001

Issue 02

Date 2014-04-21

HUAWEI TECHNOLOGIES CO., LTD.

R207 Mobile WiFi V100R001

Product Description

Issue 02 (2014-04-21) Commercial in Confidence Page 2 of 19

Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service.

Please feel free to contact our local office or company headquarters.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://consumer.huawei.com/en/

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

R207 Mobile WiFi V100R001

Product Description

Issue 02 (2014-04-21) Commercial in Confidence Page 3 of 19

About This Document

Summary

This document provides information about the major functions, supported services

and system architecture.

The following table lists the contents of this document.

Chapter Details

1 Overview The supported network modes, basic services and functions, and

the appearance of the product.

2 Features The supported features and technical specifications of the

product.

3 Services and

Applications The services and applications of the product.

4 System

Architecture The architecture of the product.

5 Packing List The items contained in the package of the product.

R207 Mobile WiFi V100R001

Product Description

Issue 02 (2014-04-21) Commercial in Confidence Page 4 of 19

History

Issue Details Date

01 First release. 2014-04-02

02 recension 2014-04-21

R207 Mobile WiFi V100R001

Product Description

Issue 02 (2014-04-21) Commercial in Confidence Page 5 of 19

Contents

1 Overview..........................................................................................................................6

1.1 Brief Introduction.............................................................................................................................. 6

2 Features...........................................................................................................................8

2.1 Main Features .................................................................................................................................. 8

2.2 Technical Specifications................................................................................................................... 9

2.2.1 Hardware................................................................................................................................. 9

2.2.2 Software .................................................................................................................................11

3 Services and Applications ...........................................................................................13

3.1 Data Service................................................................................................................................... 13

3.1.1 Wireless Modem.................................................................................................................... 13

3.1.2 USB Modem.......................................................................................................................... 14

3.2 SMS................................................................................................................................................ 14

4 System Architecture.....................................................................................................15

4.1 System Architecture ....................................................................................................................... 15

4.2 Functional Modules........................................................................................................................ 16

5 Packing List...................................................................................................................17

R207 Mobile WiFi V100R001

Product Description

Issue 02 (2014-04-21) Commercial in Confidence Page 6 of 19

1 Overview

1.1 Brief Introduction

R207 Mobile WiFi (hereinafter referred to as the R207) is a high-speed packet access

mobile hotspot. It is a multi-mode wireless terminal for SOHO (Small Office and Home

Office) and business professionals.

The R207 supports the following standards:

zHigh Speed Packet Access Plus (HSPA+)

zHigh Speed Uplink PacketAccess (HSUPA)

zHigh Speed Downlink PacketAccess (HSDPA)

zUniversal Mobile Telecommunications System (UMTS)

zEnhanced Data rates for Global Evolution (EDGE)

zGeneral Packet Radio Service (GPRS)

zGlobal System for Mobile communications (GSM)

The R207 provides the following services:

zHSPA+ packet data service of up to 21.6 Mbit/s

zHSPA (HSUPA/HSDPA)/UMTS packet data service of up to 14.4 Mbit/s

zEDGE/GPRS packet data service of up to 236.8 kbit/s

zUMTS/GSM Short Message Service (SMS)

You can connect the R207 with the USB interface of a computer, or connect the R207

with the Wi-Fi. In the service area of the HSPA+/HSPA/UMTS/EDGE/GPRS/GSM

network, you can surf the Internet and send/receive messages/emails cordlessly. The

R207 is fast, reliable, and easy to operate. Thus, mobile users can experience many

new features and services with the R207. These features and services will enable a

large number of users to use the R207 and the average revenue per user (ARPU) of

operators will increase substantially.

Issue 02 (

014-04-21)

Sho

s the app

Com

arance of t

ercial in Co

e R207.

fidence

R207 Mobile WiFi

Product

V100R001

Description

ge 7 of 19

R207 Mobile WiFi V100R001

Product Description

Issue 02 (2014-04-21) Commercial in Confidence Page 8 of 19

2 Features

2.1 Main Features

The R207 mainly supports the following features:

zHSPA+ (DL) data service of up to 21.6 Mbit/s

zHSDPA(DL) data service of up to 14.4 Mbit/s

zHSUPA(UL) data service of up to 5.76 Mbit/s

zUMTS data service of up to 384 kbit/s

zEDGE data service of up to 236.8 kbit/s

zGPRS data service of up to 85.6 kbit/s

zPS domain data service based on UMTS and GSM

zSMS based on CS/PS domain of GSM and UMTS

zWi-Fi

zPress and Play

zIPv6 /IPv4 dual stack (optional)

zBuilt-in DHCP Server, DNS RELAY and NAT

zTraffic statistic

zStandard Micro USB interface

zHiLink features (Driverless, Zero installation)

zLED indicators

zBuilt-in UMTS and WLAN high gain antenna

zWindows Vista SP1/SP2, Windows 7, Windows 8 (32 and 64 Bit) (does not

support Windows RT), MAC OS X 10.6, 10.7 and 10.8 with latest upgrades

R207 Mobile WiFi V100R001

Product Description

Issue 02 (2014-04-21) Commercial in Confidence Page 9 of 19

2.2 Technical Specifications

2.2.1 Hardware

Table 2-1 lists the hardware specifications.

Table 2-1 Hardware specifications

Item Specifications

Technical

standard WAN: HSPA+/HSPA/UMTS/EDGE/GPRS/GSM

WLAN: IEEE 802.11b/g/n

Operating

frequency HSPA+/HSPA/UMTS：2100/900MHz

EDGE/GPRS/GSM：1900/1800/900/850MHz

WLAN：2400MHz～2483.5MHz

Internal memory 128 MB Flash, 64 MB Memory

Maximum

transmitter

power

UMTS: 24 (+1/-3) dBm

WLAN 802.11b: 14 (+/-3) dBm

802.11g: 11 (+/-3) dBm

802.11n: 9 (+/-3) dBm

Receiver

sensitivity UMTS: Confirm to 3GPP Requirements

WLAN 802.11b -76 dBm@11 Mbit/s

-82 dBm@1 Mbit/s

WLAN 802.11g: -65 dBm@54 Mbit/s

WLAN 802.11n: -64 dBm@65 Mbit/s

WLAN speed 802.11b: Up to 11 Mbit/s

802.11g: Up to 54 Mbit/s

802.11n: Support MCS0–MCS7; Up to 72.2 Mbit/s.

Maximum power

consumption 3.5 W

Power supply AC: 100–240 V

DC: 5 V, 1 A

Battery Type: Li (rechargeable)

Capacity: 3.7 V, 1500 mAh

R207 Mobile WiFi V100R001

Product Description

Issue 02 (2014-04-21) Commercial in Confidence Page 10 of 19

Item Specifications

Maximum working time: 5–6 hours (depending on the network)

Maximum standby time: 300 hours (depending on the network)

External

interfaces USB interface: Micro USB

SIM card interface: standard 6-pin SIM card interface

Indicators Signal Green: Strong signal

Orange: Weak signal

Red: No signal

Wi-Fi Green: Wi-Fi turned on

Battery Green: Sufficient battery

Blinking green: Charging the battery

Red: Low battery

SMS Green: New message

Blinking green: Inbox full

Power Blinks slowly: The Mobile WiFi enters the standby

mode

Button Power switch, Reset switch

Antenna zBuilt-in GSM/UMTS main diversity antenna

zBuilt-in UMTS diversity antenna

zBuilt-in WLAN antenna

Dimensions

(D × W × H) 60.0 mm×92.8 mm×14.0 mm

Weight about 74 g (including the battery)

Temperature Operating: 0℃to +35℃

Storage: -20℃to +60℃

Humidity 5% to 95% ( non-condensing)
