Huawei R230D Caractéristiques techniques

R230D&R240D

Product Description

Issue 02

Date 2015-10-31

HUAWEI TECHNOLOGIES CO., LTD.

Issue 02 (2015-10-31) Huawei Proprietary and Confidential

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and

the customer. All or part of the products, services and features described in this document may not be

within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,

information, and recommendations in this document are provided "AS IS" without warranties, guarantees or

representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://e.huawei.com

R230D&R240D

Product Description About This Document

Issue 02 (2015-10-31) Huawei Proprietary and Confidential

About This Document

Intended Audience

This document describes the positioning, characteristics, hardware structure, product features,

and technical specifications of the RRU.

This document helps you understand the characteristics and features of the RRU.

This document is intended for:

Network planning engineers

Hardware installation engineers

Commissioning engineer

Data configuration engineers

On-site maintenance engineers

Network monitoring engineers

System maintenance engineers

Symbol Conventions

The symbols that may be found in this document are defined as follows.

Symbol Description

Indicates an imminently hazardous situation

which, if not avoided, will result in death or

serious injury.

Indicates a potentially hazardous situation

which, if not avoided, could result in death

or serious injury.

Indicates a potentially hazardous situation

which, if not avoided, may result in minor

or moderate injury.

Indicates a potentially hazardous situation

which, if not avoided, could result in

equipment damage, data loss, performance

deterioration, or unanticipated results.

NOTICE is used to address practices not

R230D&R240D

Product Description About This Document

Issue 02 (2015-10-31) Huawei Proprietary and Confidential

iii

Symbol Description

related to personal injury.

Calls attention to important information,

best practices and tips.

NOTE is used to address information not

related to personal injury, equipment

damage, and environment deterioration.

Change History

Changes between document issues are cumulative. The latest document issue contains all the

changes made in previous issues.

Changes in Issue 02 (2015-10-31)

This version has the following updates:

Added the R230D.

Changes in Issue 01 (2015-08-31)

This is the initial commercial release.

R230D&R240D

Product Description Contents

Issue 02 (2015-10-31) Huawei Proprietary and Confidential

Contents

About This Document.................................................................................................................... ii

1 Product Positioning and Characteristics...................................................................................1

1.1 Product Positioning....................................................................................................................................................... 1

1.2 Product Characteristics ................................................................................................................................................. 2

2 Hardware Structure.......................................................................................................................4

2.1 R230D........................................................................................................................................................................... 4

2.2 R240D........................................................................................................................................................................... 8

3 Product Features ..........................................................................................................................12

3.1 WLAN Features.......................................................................................................................................................... 12

3.2 Network Features........................................................................................................................................................ 13

3.3 QoS Features............................................................................................................................................................... 13

3.4 Security Features ........................................................................................................................................................ 13

3.5 Maintenance Features ................................................................................................................................................. 14

3.6 BYOD......................................................................................................................................................................... 14

3.7 Spectrum Analysis ...................................................................................................................................................... 14

4 Technical Specifications ............................................................................................................15

4.1 Basic Specifications.................................................................................................................................................... 15

4.2 Radio Specifications (R230D) .................................................................................................................................... 16

4.3 Radio Specifications (R240D) .................................................................................................................................... 20

4.4 Standards Compliance ................................................................................................................................................ 24

R230D&R240D

Product Description 1 Product Positioning and Characteristics

Issue 02 (2015-10-31) Huawei Proprietary and Confidential

1 Product Positioning and Characteristics

1.1 Product Positioning

Product Overview

The R230D and R240D are remote radio units (RRUs) used in Huawei agile distributed Wi-Fi

solution. They support PoE power supply, and are deployed indoors and connected to the

central AP. The central AP and RRUs are connected through network cables, which greatly

extends the coverage range, enhances flexibility in AP deployment and planning, and reduces

the engineering construction costs. The central AP manages the RRUs and processes services

in a centralized manner. The RRUs process radio signals independently. Such distributed

architecture further improves the wireless access capability, creating optimal service

experience for users.

The RRU uses an 86 mm plate in compliance with international standards and can be easily

installed into a junction box in a room. It is equipped with a built-in antenna and a hidden

indicator; therefore, installation of the RRU does not affect indoor decorations and designs. It

also has an IEEE 802.11a/b/g/n/ac wireless module and can work on both 5 GHz and 2.4 GHz

frequency bands.

The RRU is recommended for environments with complex wall structures and high-density

rooms, such as schools, hotels, hospitals, and office meeting rooms. Signals are transmitted

through network cables without attenuation. The RRUs are deployed indoors and provide

comprehensive signal coverage.

The RRUs are managed by the central AP. The central AP and RRUs are plug-and-play and

can be managed and maintained in real time. Compared with traditional distributed AP

solutions, the AC in Huawei agile distributed Wi-Fi solution needs to manage a smaller

number of APs. A large number of RRUs can be deployed, which improves the overall

performance and reduces network deployment costs.

R230D&R240D

Product Description 1 Product Positioning and Characteristics

Issue 02 (2015-10-31) Huawei Proprietary and Confidential

Usage Scenario

Figure 1-1 Distributed wireless access

As shown in the figure, the downlink GE interfaces of the central AP support PoE power

supply and can be directly connected to RRUs. The central AP can connect to more RRUs

through a PoE switch. RRUs are deployed indoors and communicate with the central AP

through network cables.

1.2 Product Characteristics

Long-Distance Network Coverage

Unlike the traditional distributed AP which allows for a maximum feeder length of 15 m, the

central AP uses network cables to replace feeder cables and supports up to 100 m distance

from the RRUs. The network coverage range is therefore expanded by several times.

No Wall Penetration Loss, No Coverage Hole

Restricted by feeder length or installation requirements, signals have to pass through walls in

some scenarios, resulting in large signal attenuation. If rooms to be covered have complex

structures, coverage holes may occur. To prevent these problems, lots of calculation and

verification work needs to be carried out. Huawei distributed solution solves these problems.

In this solution, RRUs are placed in rooms, and signals are transmitted over wired cables,

without wall penetration loss, delivering high-quality wireless access services.

R230D&R240D

Product Description 1 Product Positioning and Characteristics

Issue 02 (2015-10-31) Huawei Proprietary and Confidential

802.11ac Gigabit Wireless Rate

The RRU complies with IEEE 802.11a/b/g/n/ac, supports 2x2 MIMO, works on both 2.4 and

5 GHz frequency bands, and provides strong signals and gigabit wireless rate.

Unique, Graceful Plate Design

The RRU is white in appearance and has heat emission holes and interfaces at the side and

bottom. The mounting screws are hidden under the slide panel. The overall design is simple

but graceful and blends well with the layout of hotels and apartments.

Easy to Install in a Standard 86-type Box

The RRU uses an 86 mm plate in compliance with international standards and can be easily

installed into a junction box in a room, requiring no drilling or cabling.

Flexible Installation Modes

The R230D can be embedded into an 86-type box or mounted to a ceiling or wall. Its

installation positions can be flexibly planned.

Hidden Indicator, Zero Impact on Sleep

The RRU uses a hidden indicator design. When being turned on, the indicator has soft light.

The AC controls the switch of the indicator and turns off the indicator at nights to prevent

blinking lights from affecting sleep of guests.

Four Downlink Ethernet Interfaces, Supporting Wired Access from Multiple

Users

The R240D has four downlink 100M Ethernet interfaces that can process data concurrently.

The interfaces can be connected to multiple terminals through network cables, such as the

IPTV, desktop computer, and laptop, meeting requirements of hotels and apartments.

Low Engineering Cost

Compared with traditional distributed APs, the central AP cuts down the following expenses:

Construction: Network cables replace expensive feeder cables. The central AP can

directly use the network cables originally routed in the rooms, without the need of

deploying new cables.

License: The maximum number of central APs in Fit AP mode allowed by the AC is

controlled by licenses, but RRUs do not require licenses. Therefore, one central AP can

use RRUs to cover dozens of rooms.

Hierarchical Processing Technology, High Wireless Forwarding Capability

Huawei distributed solution uses innovative hierarchical processing technology. The central

AP manages RRUs in a centralized manner and concurrently forwards service traffic, while

the RRUs only process radio signals. The hierarchical design makes the network structure

clearer and reduces the processing burden on the central AP and RRUs, improving efficiency

and optimizing the overall wireless forwarding performance.

R230D&R240D

Product Description 2 Hardware Structure

Issue 02 (2015-10-31) Huawei Proprietary and Confidential

2 Hardware Structure

2.1 R230D

Appearance

Figure 2-1 shows the appearance of the R230D.

The actual device appearance may be different from the following device appearance; these differences

will not affect device functions.

Figure 2-1 R230D appearance

Port

The following figure shows ports on the R230D.

R230D&R240D

Product Description 2 Hardware Structure

Issue 02 (2015-10-31) Huawei Proprietary and Confidential

Figure 2-2 R230D ports

As shown in Figure 2-2, each port can be described as follows:

1. ETH/PoE: 10/100M port used to connect to the wired Ethernet. The port can connect to a

PoE power supply to provide power for the RRU.

2. Default: Reset button used to restore factory settings if you hold down the button more

than 3 seconds.

LED Indicator

The R230D provides only one indicator, as shown in Figure 2-3.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Huawei Point d'accès sans fil

Huawei

Huawei E5573S Manuel utilisateur

Huawei

Huawei U-SYS IAD208E Manuel utilisateur

Huawei

Huawei LTE E8372 Caractéristiques techniques

Huawei

Huawei AP7050DE Caractéristiques techniques

Huawei

Huawei E5730 Manuel utilisateur

Huawei

Huawei WA8021V5 Manuel utilisateur

Huawei

Huawei R250D-E Manuel d'utilisation

Huawei

Huawei MA5833 Manuel utilisateur

Huawei

Huawei AP4050DN Manuel d'utilisation

Huawei

Huawei OptiXstar P812E Manuel utilisateur

Huawei

Huawei Quidway WA1003A Manuel utilisateur

Huawei

Huawei WA635SN-GN Manuel utilisateur

Huawei

Huawei PT530 Manuel utilisateur

Huawei

Huawei E5776 Manuel utilisateur

Huawei

Huawei eLTE2.2 eA660 Series Caractéristiques techniques

Huawei

Huawei AP6510DN-AGN Manuel utilisateur

Huawei

Huawei 5G CPE WiN Manuel utilisateur

Huawei

Huawei AP6050DN Caractéristiques techniques

Huawei

Huawei UA5000 Manuel utilisateur

Huawei

Huawei AP6010DN-AGN Manuel utilisateur

Huawei

Huawei Quidway W1000 Series Manuel utilisateur

Huawei

Huawei Mobile WiFi E5878 Manuel utilisateur

Huawei

Huawei AP8030DN Manuel du produit

Huawei

Huawei OptiX RTN 310 Manuel utilisateur

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur
