Huawei ESpace IAD104H Manuel utilisateur

eSpace IAD104H

Quick Start

Issue

Date

2019-04-09

HUAWEI TECHNOLOGIES CO., LTD.

eSpace IAD104H

Quick Start

Contents

Issue 10 (2019-04-09)

Huawei Proprietary and Confidential

Contents

1 Packing List.........................................................................................1

2 Safety Precautions .............................................................................2

3 Installation ..........................................................................................6

4 Manual Configuration (CLI) ...........................................................7

4.1 Logging In Through Telnet....................................................................................... 7

4.2 Connecting to NGN/IP PBX (SIP)...........................................................................11

4.3 Accessing NGN/IP PBX (MGCP) .......................................................................... 20

4.4 Connecting to the IMS (SIP) .................................................................................. 27

4.5 Accessing Network Through the IAD..................................................................... 38

5 Configuration (EMS).......................................................................40

6 FAQs...................................................................................................43

7 Technical Specifications and Environment Requirements .....46

eSpace IAD104H

Quick Start

1 Packing List

Issue 10 (2019-04-09)

Huawei Proprietary and Confidential

1 Packing List

After you unpack the product package, check the items in the

following table. If the items in the package are different from

those in the table, contact the sales person.

Item

Quantity

eSpace 104H

Power supply adapter

Network cable

CD-ROM

Quick Start

Certificate

eSpace IAD104H

Quick Start

2 Safety Precautions

Issue 10 (2019-04-09)

Huawei Proprietary and Confidential

2 Safety Precautions

Pay attention to the following precautions when installing and

using the device.

Basic Requirements

Follow the requirements of the manufacturer to install the

device.

Do not disassemble the device. Contact the specified

maintenance station if the faults occur on the device.

Any company or person cannot change the design of the

structure, security, or performance without permission.

Comply with the related laws and regulations, and respect

the legal rights of others when using this device.

Usage Notice

Use the accessories shipped with the product and the

recommended accessories, such as the power supply

adapters and batteries. The power supply voltage must

meet the requirement on the input voltage of the device.

Keep the power plug clean and dry to avoid the electric

shock and other potential risks.

eSpace IAD104H

Quick Start

2 Safety Precautions

Issue 10 (2019-04-09)

Huawei Proprietary and Confidential

Keep your hands dry when plugging in or out the device

cable.

Stop the device and turn off the power before plugging in

or out the device cable.

In the lightning weather, turn off the power and remove

all the cables from the device, such as the power cable,

network cable, and phone cable. Otherwise, the device

may be damaged by the lightning.

If you do not need to use the device for a long time, turn

off the power and remove the power plug.

Keep the water and other liquids away from the device. If

the liquid accidentally flows into the device, turn off the

power immediately and remove all the cables from the

device, such as the power cables and network cables.

Contact the specified maintenance station if faults occur.

Do not use the damaged or aged cables.

If exceptions occur, for example, the device is smoking,

the sound is abnormal, or the device turns smelly, stop

using the device and turn off the power immediately.

Remove all the cables connected to the device, such as the

power cables and network cables. Contact the specified

maintenance station when faults occur.

Prevent the objects (such as the metal) getting into the

device from the heat dissipation hole.

Avoid scratch or wear and tear on the device shell.

Otherwise, the dropped paint may cause allergy or device

exceptions. For example, short circuit may be caused if

the paint drops into the host.

Keep children away from the device and accessories to

avoid the dangerous behaviors such as swallowing.

Cleaning Notice

Before you clean the device, stop the device and turn off

the power. Remove all the cables connected to the device,

such as the power cables and network cables.

eSpace IAD104H

Quick Start

2 Safety Precautions

Issue 10 (2019-04-09)

Huawei Proprietary and Confidential

When you clean the device, do not use the liquid cleaner

or spray cleaner to clean the device shell. Use the soft

cloth to wipe and clean the shell.

Environment Requirements

Keep the device dry when storing, transporting, and using

the device.

Avoid the collision when storing, transporting, and using

the device.

Place the device in the indoor environment with good

ventilation and without direct and strong sunlight.

Keep the device clean to avoid dust.

Do not place any object on the device to avoid the

overheating of the device or damage caused by extrusion.

Clear the space with the radius of over 10 cm around the

device for heat dissipation.

Keep the device away from the heat sources or exposed

fire, such as the electrical heater or candle.

Keep the device away from the appliance with the strong

magnetic field or intensive electric field, such as the

microwave oven, fridge, or mobile phone.

Environment Protection

Do not discard the obsolete devices or batteries randomly.

Discard them at the specified recycle station.

Comply with the local laws and regulations on processing

the device package materials, consumed batteries, and

obsolete devices, and support the recycling.

Class A Products

eSpace IAD104H

Quick Start

2 Safety Precautions

Issue 10 (2019-04-09)

Huawei Proprietary and Confidential

This product is of class A and may cause radio interference in a

living environment. If radio interference exists, take some

measures to eliminate the interference.

eSpace IAD104H

Quick Start

3 Installation

Issue 10 (2019-04-09)

Huawei Proprietary and Confidential

3 Installation

The eSpace Integrated Access Device 104H (eSpace IAD104H)

is the case-shaped device. You only need to connect cables.

eSpace IAD104H

Quick Start

4 Manual Configuration (CLI)

Issue 10 (2019-04-09)

Huawei Proprietary and Confidential

4 Manual Configuration (CLI)

About This Chapter

You can use the CLI to configure all eSpace Integrated Access

Device 104H (IAD104H) functions. The chapter describes how

to configure about typical scenes and advanced parameters by

using the command line (CLI).In addition, some titles are

marked with (SIP) or (MGCP) to indicate that these service

configurations can be implemented over SIP or MGCP.

4.1 Logging In Through Telnet

The IAD104H supports data configuration and maintenance

management in Web mode.

Context

You can log in to the web management system of the

IAD104H in either of the following modes:

HTTPS

The web browser interacts with IAD104H through

HTTPS, which ensures user information security.

eSpace IAD104H

Quick Start

4 Manual Configuration (CLI)

Issue 10 (2019-04-09)

Huawei Proprietary and Confidential

HTTP

The web browser interacts with IAD104H through HTTP.

You are advised to log in to the web management system

through HTTPS to ensure data security.

HTTP is disabled on the IAD by default. You can run the

system soft-parameter command to enable HTTP.

Before logging in to the web management system through

HTTPS, you have to load the web_rootcert, web_servercert,

and web_serverkey certificates and restart the IAD. For

details about how to load the certificates and restart the IAD,

see the load and reboot commands under Command

Reference > Config Commands in the eSpace IAD104H

Product Documentation.

Establishing the Web Configuration Environment

The IAD hardware connections are set up and the IAD is

powered on.

Use the network cable to connect the network port of the PC to

any network port of the IAD104H. If the PC network port does

not support self-adaptation, you need to use the crossover cable.

Set IP addresses of the PC and IAD (the default IP address of

the IAD is 192.168.100.1) in the same network segment to

ensure that the PC can ping the IAD successfully.

Before the delivery, the same IP address 192.168.100.1 is configured

on all IADs. Do not connect multiple IADs to the network at the

same time to prevent IP address conflict.
