Huawei Display 23.8 Manuel utilisateur

User Guide

Contents

About this guide

Appearance

Installing the display

Connects the display to the tower

Conguring the display

FAQs

Safety information

Legal Notice

About this guide

This document only applies to associated devices. Read this document carefully before using

the device.

The components listed in this document may not be included in the device. In this case, you

will need to purchase them separately. The functions described in this document can only be

used when they are used together with other components. The gures and UIs in this

document may be dierent from the actual ones. All gures are for reference only.

Symbols and denitions

Highlights important information and tips, and provides additional information.

Indicates potential problems that may arise, such as damage to the device or

data loss.

Appearance

7 86

1 Panel

2 Support

3 Base

4 Function buttons

Adjusts the display settings. For details, see the Conguring the display section.

5 Power button/Power indicator

Turns the display on and o.

•The indicator is steady white when the device is powered on.

•The indicator turns o when the device is powered o.

•The indicator ashes white in sleep mode.

6 Power port

Connects the power adapter for turning on the display.

7 HDMI port

Connects to an HDMI input device, such as a tower.

8 VGA port

Connects to a VGA input device, such as a tower.

Installing the display

To avoid damaging the screen, do not press on the screen when taking the display panel

out of the packaging.

1 3

1Place the display panel on a clean and at surface, with the front side facing down. (You

can view device information including the S/N code on the nameplate on the rear side of

the display panel.)

2Use screws to connect the base to the support.

3Tilt and insert the upper end of the base support into the slot at the rear of the display,

and then press the base support downwards until you hear a clicking sound, which

indicates that the base support has been installed correctly.

To remove the base, nd the button above the port at the rear of the display, push the

button upwards, lift the bottom of the base support, and remove the base.

Connects the display to the tower

0°

22°(±2°)

5°(±2°)

HDMI/VGA

1Gently lift the assembled display and place it on a at surface.

2Use an HDMI or VGA cable to connect the display to the computer.

3Connect the power cable to the display and connect the power supply.

4Power on the tower and display. If images are displayed on the display, it indicates that

the installation is successful. If no image is displayed on the display, see the FAQs chapter.

5Adjust the pitch angle of the display as required.

To ensure the optimal performance of the display, you are advised to turn o the display

when it is not used for a long time.

Conguring the display

1234

After the display and the tower are assembled and powered on, the system automatically

congures and optimises the settings of the display. If you need to congure the display

settings, you can also open the settings menu of the display to adjust the settings.

1Press any button from 1 to 4 to access the display settings menu.

2On the settings menu screen, press buttons 1 to 4 to set the parameters.

1Exit/Back

2Downward/Leftward adjustment

3Upward/Rightward adjustment

4Conrm

The default language of the display is English. You can change the language in More

settings > Language, as well as congure other settings.

If you do not perform any operation within a period of time, the Settings menu is

automatically closed.

Functions in the Settings menu

Adjusts specications such as screen brightness and contrast.

Selects a video input signal.

Switches between dierent colour temperature modes including low blue light

mode or cool mode.

When reading for a long time, we recommend that you set the screen

colour temperature to low blue light mode to prevent eye fatigue and make

it easier on your eyes. Once Blue light mode is enabled, the screen will take

on a mild yellow tint.

Adjusts the display settings such as the display mode.

Selects the display scenario.

More settings, such as language, menu transparency, and reset settings.

Conguring the display

FAQs

Unable to power on the display

•Check whether the display is powered on.

•Check whether the power adapter is correctly connected to the display and the power

supply.

There are no images on the display

•Check whether all of the cables are correctly connected.

•Check whether the display and the tower are powered on.

•Check whether the VGA or HDMI signal cable is damaged.

•If the preceding issues do not occur, restart the display and the tower, then check whether

the images can be properly displayed on the screen.

The screen is too dark or too bright

•Open the settings menu on the display and adjust the screen brightness and contrast.

•If the keyboard comes with the and keys, you can use them to adjust the screen

brightness.

The screen colour is abnormal

•Check whether the VGA or HDMI signal cable is damaged. For example, the pins may be

bent.

•Open the settings menu on the display and adjust the colour temperature.
