Huawei U7519 Manuel utilisateur
Notice
Copyright © Huawei Technologies Co., Ltd. 2010. All rights reserved.
Trademarks and Permissions
, HUAWEI and are trademarks or registered trademarks of Huawei
Technologies Co., Ltd.
Other trademarks, products, services and company names mentioned are
the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT
AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION
TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO
CASE SHALL HUAWEI TECHNOLOGIES CO., LTD. BE LIABLE FOR
ANY SPECIAL, INCIDENTAL, INDIRECT OR CONSEQUENTIAL
DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOOD-
WILL OR ANTICIPATED SAVINGS.
1
Introduction
1 Introduction
About This Guide
This guide describes how to use your phone.
All the images in this guide are provided as a reference. The actual appear-
ance and display depends on the phone that has been delivered.
Frequency Band
Your phone can operate where cellular coverage exists, automatically
switching between WCDMA/HSDPA 1700/2100 MHz AWS (Band IV),
2100 MHz (Band I), and GSM/GPRS/EDGE 850/900/1800/1900 MHz
networks.
Packing List
The product package includes the following items.
• One HUAWEI U7519 mobile phone
• One Lithium Ion(Li-Ion) battery
• One battery charger
• One USB cable
• One Quick Start Guide
• One headset (Optional)
Introduction
2
SIM Card and Memory Card
Insert your SIM card before using your phone. Remove the SIM card and
the battery only after turning off your phone. To use the SIM card properly,
please read the following instructions carefully.
NOTE:
•Keep the SIM card out of the reach of children.
•The SIM card and its metal contacts can be easily damaged by
scratching or bending. Be careful when you carry, insert or remove the
SIM card.
•Always disconnect the charger from the phone before inserting or
removing the SIM card.
Your phone supports a memory card (microSD) with a capacity of up to 8
GB.
To insert or remove the memory card, you must remove the battery cover.
3
Introduction
Follow these steps to install of the SIM card and memory card.
Charging the Battery
NOTE:
•The battery loses its charge even when it is not being used. If you
have not used your phone for a long time, you should recharge it first.
•The battery can be recharged but eventually it will wear out again. If
the battery lasts for a shorter time period than usual after being
charged normally, replace it with a battery of the same type.
1 Remove the battery cover. 2 Insert the SIM card.
3 (Optional) Insert the memory card. 4 Insert the battery.
Introduction
4
•The time it takes to charge your phone depends on the environmental
temperature and the age of the battery.
•When the battery charge is very low, the phone sounds a warning tone
and a prompt will appear on the display screen. When the battery
charge is too low, the phone will turn off automatically.
Before charging the battery, ensure that the battery has been properly
inserted into your phone. To charge the battery, first plug in the charger
connector to a power socket, and then insert the plug of the cable into the
connector of the phone as shown in the following figure. The figure is for
reference only. The actual appearance is subject to your mobile phone and
accessories delivered.
1. Plug in the phone charger into a power outlet.
2. Plug the charger into your phone’s charger jack. When the battery is
being charged, the battery icon blinks continuously.
3. When the battery icon stops blinking, it means that the battery is full.
Disconnect the charger from the power outlet.
4. Unplug the charger from the phone.
1
2
5
Introduction
Appearance of Your Phone
1 Earpiece 2 Touchscreen 3 Microphone
4 SEND Key 5 OK Key 6 END Key
7 Navigation
Key
8 Camera Key 9 Lock Key
10 Volume
Up/Down
Key
11 Battery Cover 12 Speaker
13 Camera 14 Charger/USB/
Headset Port
15 POWER Key
1
2
3
45
6
7
11
12
13
14 15
8
9
10
Introduction
6
Home Screen
SEND Key • Place or answer calls.
• Access the Calls Screen in standby mode.
OK Key Confirm a selection.
END Key • End a call or reject an incoming call.
• Return to the idle screen.
Camera
Key
Activate the camera in standby mode when the
screen is not locked.
Lock Key Press to lock/unlock the phone.
POWER
Key
Press and hold to turn phone on or off.
Icon Bar
Access Widget Bar
Access the Browser
Desktop
Access Contact List
Access Dial touch keys Access Main Menu
7
Introduction
The phone is currently
in the HSDPA network.
The phone is currently in
the GSM network. When
“E” is in red, it indicates
in EDGE/GPRS network.
The phone is currently
in the WCDMA
network.
Handset is roaming.
A call is in progress. An alarm is set.
Bluetooth is enabled. Bluetooth is connected.
You have a new text
message waiting.
You have a new
multimedia message
waiting.
The headset is
connected.
Memory card is inserted.
Displays current
battery strength.
You have a new voice
message waiting.
Introduction
8
Using the Touchscreen
You can select an item or enter text by tapping the touchscreen with your
finger.
NOTE:
•Tap properly on the icon to select it.
• To protect your touchscreen, tap gently.
• When the screen is locked, press the lock key to unlock the touch-
screen.
•When the screen is locked, press the send key, the OK key or the end
key to activate the screen. To unlock the screen, press and hold the
icon according to the instructions on the screen.
Calibrating the Touchscreen
If your phone does not respond to your touch requests correctly, calibrate
the screen as follows.
1. Select Settings> Touch settings> Calibrate to access the screen for
calibration.
2. To calibrate the screen, tap the centre of the calibration frame on the
screen according to the instructions.
NOTE: During the calibration, tap the center of the calibration frame prop-
erly to ensure that the phone responds correctly to your tapping and text
entry after the calibration.
9
Introduction
Dragging and Flicking
You can perform the following operations by dragging your finger on the
touchscreen.
• On the home screen, tap and drag the profile to change its position on
the screen.
• On the home screen, tap and drag the widgets to change their position
on the screen.
• In the menu list, drag up or down to scroll. To select a submenu, tap it.
• When viewing pictures, flick right or left to change the order of the
pictures.
Accessing the Widget Bar
The widget bar provides quick access to the most frequently used items.
1. Tap the widget bar tab located on the left side of the home screen to
open it.
2. To open an item on the widget bar, tap it.
3. Tap the widget bar tab to close it again.
NOTE: You can drag a widget to the screen or drag it back to the widget
bar.
