HSM Classic 70.2 Manuel utilisateur

PAPER SHREDDER

INSTRUCTION MANUAL

STANDARD PRODUCT WARRANTY

Quality is part of the company philosophy and all products are manufactured to the highest quality standards. All

technical data and measurements are approximate values and based upon single shift operations. All products are

subject to different limits and specifications due to operation length, paper size, grain, weight, misuse/abuse and power

configurations.

Prior to operation read the Manufacturer’s Operating Instructions included with this product. This will help ensure all

precautions are taken to avoid cancellation of the manufacturer’s warranty.

The manufacturer warrants that any new products sold will be free from defects in material and workmanship

when used under specified and normal operating conditions. This warranty is void if repairs are necessitated by

accidents, misuse, abuse, water damage or fire.

The capabilities of all products are in each specification flier. Exceeding model specifications causing product failure

is not covered by this warranty. Modifications, alterations and repairs must be performed by an authorized technician.

Lubrication for cross-cut shredders is required every fifteen to thirty minutes of operation, to maintain top working

condition and this warranty.

Compact Shredders

Parts to repair any failure caused by defect is limited to one (1) year from date of invoice. Labor to repair any failure

caused by defect is limited to 180 days from date of invoice or warranty registration date.

NOTES:

• Freight or transportation damage is not classified as a warranty repair in any case.

• Proof of purchase invoice is required from the end-user for warranty validation or warranty registration date.

• All parts under warranty will be shipped and invoiced using standard costs and will be credited for the full amount only

when the defective part is returned.

• IT IS RECOMMENDED THAT A MAINTENANCE AGREEMENT BE UTILIZED TO SUPPLEMENT ALL WARRANTIES.

1. Proper use, warranty

The shredder is designed exclusively for destroying paper. Its sturdy drive

mechanism is not damaged by paper clips and staples.

We provide a warranty for the device in accordance with our general sales and

delivery terms. This warranty excludes wear, damage due to improper handling,

natural depreciation, and actions taken by third parties.

2. Machine components / Technical Data

OPERATING INSTRUCTIONS

1 2 3 4 5

1. Cut material

container

2. Cutting head

3. Paper feeding opening

4. Automatic start stop control

5. Rocker switch

Cutting type Strip cut

Shred size 1/8" 1/4"

Safety rating DIN 32757 – 1 2 2

Cutting capacity (sheet) DIN A4 70 g/m

5 7

Loading width 8.9"

Cutting speed 16 ft./min.

Voltage 115 V, 60 Hz

Power max. 80 W

Dimensions W x D x H 11.7" x 7" x 15.1"

Weight 8 lbs.

Volume of shred. mat. container 4.5 gallons

Noise level (idle running) 59 - 62 dB (A)

Technical and optical modications reserved.

OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS

3. Safety instructions

• Keep paper shredder out of the reach of children. If the shredder is damaged

or does not function properly, switch the device off, pull out the power plug and

inform our service engineers.

• This paper shredder should never be placed near or over a radiator or heat

source. The ventilation slots must not be blocked or covered.

• Make sure the power plug is easily accessible. Before plugging in the

power plug, check that the voltage and frequency of your local main supply

correspond to those stated on the type plate.

• Before changing the location or cleaning turn off and unplug the paper

shredder!

Risk of injury!

Do not reach into the paper feed slot.

Risk of injury by pulling in!

Keep long hair, loose articles of clothing, ties, scarves, jewelry

etc. away from feed opening. Material with the tendency to

form loops, e.g. tapes, strapping material, etc. must not be

shredded.

4. Putting into operation

Switching the paper shredder on

Press rocker switch pos. 1.

èRocker switch locks in.

Feed paper

See “Technical data” for sheet capacity.

• Automatic start stop control starts the cutting system automatically

èPaper is pulled into cutting system and cut. When the paper

feeding opening is free again, the cutting system automatically

switches off.

Switching paper shredder off

• Tap rocker switch pos. 2.

èSwitch resets to zero position.

5. Troubleshooting

Paper jam You have fed in too much paper.

Caution!

Do not press rocker switch alternately forwards/backwards (pos. 1 /

pos. 2):

Cutting unit can be damaged.

• Press and hold down rocker switch pos. 2. Paper is pushed out.

• Separate paper stack.

• Press rocker switch pos. 1.

• Feed paper successively.

Shredded material container full

Empty the cut material container, because if it is too full, malfunctions

can occur in the cutting system.

• Press Automatic start stop control (4) 2 seconds.

• Switch equipment off; tap rocker switch pos. 2.

• Move cutting head away.

• Empty cut material container.

• Remove cutting head.

If other faults occur, please check the following before calling our customer

service:

• Is power plug inserted? èInsert

• Is rocker switch turned on? èpress rocker switch pos. 1

• Is the motor overloaded? èAllow motor to cool down for approx. 15-20

minutes

6. Cleaning

Switch off the shredder, pull out the power plug.

When cleaning only use a soft cloth and a mild soap-water solution.
