Read Before Installing

HP A7789A Fire GL™-UX Graphics Card And Software

System Prerequisites

Your HP workstation must meet the following prerequisites to support the Fire GL-UX graphics

option:

1. Hardware requirements - The A7789A Fire GL-UX card is supported only on hp j6000 and HP

PA-RISC workstations with the PA-8700 or later processors. At this time, the only supported mod-

els are the HP c3650, c3700, j6000 and j6700 Workstations. (HP has not tested other host systems

and does not provide technical support for conﬁgurations other than these.)

2. O.S. requirements - The prerequisite OS software must be installed before the Fire GL-UX card

will function as a console device. If the workstation was ordered with the Fire GL-UX card inte-

grated at the factory and HP-UX ignited, the prerequisite software should already be installed.

OS requirements for HP-UX 11.0: On Media:

* General Release Patch Bundle, Nov. 1999 (ACE) 11.0 (Core) Install/Update

* Hardware Enablement Patch Bundle, Mar. 2002 or later 11.0 Support Plus (Mar. 2002)

OS requirements for HP-UX 11i:

* Hardware Enablement Patch Bundle 11i, Mar. 2002 or later 11i Support Plus (Mar. 2002)

You can conﬁrm that you have the necessary O.S. revision and appropriate patch bundles by exe-

cuting the following commands:

$/usr/sbin/swlist -l bundle | grep ACE (for General Release patches)

A7789- 90001

$/usr/sbin/swlist -l bundle | grep HWE (for Hardware Enablement patches)

The output should contain information similar to this:

XSWGR1100... General Release Patches, November 1999 (ACE) or

HWE1100... Hardware Enablement Patches for HP-UX 11.00, March 2002 (HWE)

If you do not see lines like this in the output, you should install the appropriate patch bundles

(November 1999 or later ACE and March 2002 or later HWE) before attempting to install the Fire

GL-UX software.

Multi-display conﬁgurations - The j6000 and j6700 Workstations can be conﬁgured to run multiple

Fire GL-UX cards in a multi-display environment. At this time, HP does not support the Single Logi-

cal Screen functionality with the Fire GL-UX card. You cannot use multiple Fire GL-UX cards in the

c3650 or c3700 Workstations. You also cannot use the Fire GL-UX card concurrently with any other

type of graphics card.

Monitor Support

An HP-supported, full multimode color monitor is required for the Fire GL-UX card.

The following list of monitors, plus all other monitors that HP supports in the future, are supported

with the Fire GL-UX card

NOTE The Fire GL-UX card does not support all timings and resolutions that each display

device will accept. Use the HP System Administration Manager (SAM) utility to select

alternative settings.

See your workstation Owner's Guide for information on using the /opt/graphics/common/bin/

setmon command to produce a list of supported timings and screen resolutions for your workstation.

Table 0-1. Fire GL-UX Supported Monitors

Product

Name Product Number Description

A4490A 17-inch color CRT monitor

P920 D8912W 19-inch color CRT monitor

P910 D8910W 19-inch color CRT monitor

A4575A 19-inch color CRT monitor

P1130 P4819W 21-inch color CRT monitor

P1120 D8915W 21-inch color CRT monitor

P1110 D2847W 21-inch color CRT monitor

A4576A 21-inch color CRT monitor

A7217A 24-inch color CRT monitor

A1295A 24-inch color CRT monitor

L1820 P4829W 18-inch color LCD ﬂat panel (quartz gray bezel)

L1820 P4829X 18-inch color LCD ﬂat panel (dark gray bezel)

L1810 D5069W 18-inch color LCD ﬂat panel

L1800 D5065W 18-inch color LCD ﬂat panel

Software Installation Instructions

NOTE The Fire GL-UX Software CD-ROM must be installed prior to using the workstation

when a Fire GL-UX graphics card is installed. Basic drivers for the Fire GL-UX are

included in the Hardware Enablement Bundle (March 2002) and on factory-ignited

workstations. These drivers are supported only for installing the full drivers from the

Fire GL-UX Software CD-ROM. If you are upgrading a workstation that already has a

video card, the Fire GL-UX Software CD-ROM must be installed prior to installing the

Fire GL-UX graphics card.

1. Insert the Fire GL-UX Software CD-ROM (HP Part No. A7789-91001) into your CD-ROM Drive.

2. As root, mount the CD to a directory. For example:

$mount /dev/dsk/c0t0d0 <directory_name>

3. Change directories (cd) to the <directory_name>

4. Execute the “install” script by typing: #./install

This script is included on the CD and contains the appropriate swinstall command and options to

install the software.

5. Your Fire GL-UX software is now ready for use

NOTE For Ignite-UX: The March 2002 (or later) release of Ignite-UX must be used on an

ignite server to boot target workstations having a Fire GL-UX console. All of the

prerequisite OS software and all patches on the Fire GL-UX Software CD-ROM must

be ignited on the target workstation in order to generate a functioning and supported

conﬁguration.

Making Software And Device-speciﬁc Changes

For important information on re-conﬁguring an existing graphics card (for example, creating the

proper device ﬁles), refer to your workstation Owner's Guide, Technical Reference or the Graphics

Administration Guide which is found on the http://www.hp.com/go/workstationsupport web page.

Removing/Replacing Cards

NOTE Please read your workstation documentation for important system conﬁguration

information.

CAUTION Graphics boards are susceptible to electrostatic shock. When handling your

graphics board, always wear a properly grounded wrist strap and handle the

board carefully. Always unplug the AC power cord from the workstation before

opening the cabinet and performing any installation inside the workstation

j6700/j6000 Graphics Cards

Your j-Class Workstation’s PCI (Peripheral Connect Interface) assembly cage has three 64-bit, 4x,

3.3v, 66 MHz card slots, providing I/O expansion capabilities. See Figure 0-1.

Use the Primary Graphics Slot for the highest performance graphics card. Use the Secondary

Graphics Slot for the second graphics card and the remaining slot for any additional supported card.

Figure 0-1 j6700 PCI Card Slot Numbering

NOTE: You will need a T-15 Torx driver or ﬂathead screwdriver to remove the I/O slot bulkhead

screws.

Here are the steps required to remove a graphics card from your j6700 or j6000 computer.

1. Power down the system, and unplug the power cord from the electrical outlet.

2. Open the side panel of the system unit. See your workstation’s User’s Guide for detailed instruc-

Primary Graphics Card Slot

Secondary Graphics Card Slot

tions. Follow the instructions below to install cards in the j6000 PCI Cage Assembly.

3. Slide the card into the appropriate slot (see #3 above), ensuring that you align Bulkhead Pin(s),

Board Connector(s) and Board Guide(s). Make sure cards are fully seated in their connectors

before replacing the PCI Cage Assembly.

4. Plug the AC power cord into the workstation and power on the workstation.

5. Refer to your workstation documentation for instructions on using the HP-UX System Adminis-

tration Manager (SAM) utility to verify your graphics conﬁguration

CAUTION The j-Class workstations supply about 75 Watts of power to the PCI slots. Do not insert

cards that together draw more than 75 Watts, or damage to the workstation may result.

Please look at the speciﬁcations that come with your individual cards for power

requirements. Note that each j-Class PCI slot can provide up to 25 watts.

c3650 and c3700 I/O Cards

Your HP c3650 and c3700 computer’s PCI assembly has six slots. Slots 1 through 4 are full-size PCI

1. Slide PCI retainer back

2. Lift off cage

- Lift PCI handle to remove cage from workstation

- Insert I/O card in PCI slot as shown

- Insert bulkhead screw

PCI CARD

RETAINER

Bulkhead

screw

slots. Slots 5 and 6 are half-size slots. See below for a brief description of slot capabilities.

Figure 0-2 c37xx PCI Card Slot Numbering and Capabilities

To ensure optimum graphics performance, you should always use slot 2 (SL2) as your primary graph-

ics card slot.

If you connect your monitor to a different graphics card slot, you will need to change the graphics path

for that monitor. Note that the six I/O slots as seen from the back of the computer are labeled from top

to bottom starting with one. See below.

Figure 0-3 c3650/c3700 I/O Slot Numbering

You will need a T-15 Torx driver or ﬂathead screwdriver to remove the I/O slot bulkhead screws.

Here are the steps required for remove an I/O card from the system unit.

1. Power off the system, and unplug the system unit power cord from the electrical outlet. Note that

when you press the system power switch, the system automatically performs a shutdown -q.

2. Open the side panel of the system unit. See your User’s Guide for access instructions. Pull evenly

in the direction of the arrow on both PULL tabs of the card retainer to remove it. See below.

Use this slot for your

Fire GL-UX card

I/O Slot 1

I/O Slot 6

Figure 0-4 Removing the I/O Card Retainer

3. Locate the card you want to remove and, using the T-15 Torx driver, remove the I/O card’s

bulkhead screw as shown below:.

Figure 0-5 Removing the I/O Card

4. Pull evenly on the outside edges of the I/O card to remove it.

To install a card into your system unit, follow these steps.

1. Locate the appropriate slot for the I/O card that is to be installed.

2. Insert the card into the slot you have chosen with the bulkhead appropriately positioned. See

above. The non-bulkhead end of the card should be placed in the card guide. Press ﬁrmly and

evenly on the card until it is seated in the connector. Screw the T-15 Torx screw into the card’s

bulkhead (using 6 inch-pounds of torque) to secure the card.

3. Replace the card retainer by placing the bottom retainer hook in the slot on the air divider and

the clips on the PULL tabs into their slots on the chassis wall.

4. Close the left side panel of the system unit by following the procedure in the User’s Guide. Also

refer to your workstation documentation for instructions on using the HP-UX System Administra-

tion Manager (SAM) utility to verify your graphics conﬁguration

I/O Card Retainer

I/O Card

Air Divider

I/O Card

Bulkhead

Screw

I/O Card

Bulkhead

I/O Card Being Removed

HP Hardware Warranty

This HP accessory is covered by a limited hardware warranty for a period of one year from the date of

purchase by the original end-user. The type of service provided is return to an HP or repair-autho-

rized reseller service-center. At Hewlett-Packard’s discretion, a defective accessory will be repaired or

replaced by a new unit, either of the same type or of an equivalent model.

If this accessory is purchased and used together with an HP workstation, it will be covered by the

warranty of this computer or workstation, under the same conditions of service and duration. Please

refer to the warranty statement provided with your HP workstation for warranty limitations, cus-

tomer responsibilities, and other terms and conditions.

FOR CONSUMER TRANSACTIONS IN AUSTRALIA AND NEW ZEALAND: The warranty terms

contained in this statement, except to the extent lawfully permitted, do not exclude, restrict or modify

and are in addition to the mandatory statutory rights applicable to the sale of this product to you.

Software Support

If you encounter problems with displayed images when using third party application software, contact

the application software vendor, not Hewlett-Packard, to report problems and/or obtain ﬁxes.

Regulatory Information

NOTE: This graphics card is a Class A device. Systems will perform at FCC Class A /CISPR 22/

EN55022 Class A / VCCI Class A levels when this device is integrated.

Federal Communications Commission Radio Frequency Interference

Statement (for USA only)

This equipment has been tested and found to comply with the limits for a Class A digital device, pur-

suant to Part 15 of the FCC Rules and the Canadian Department of Communications. These limits

are designed to provide reasonable protection against harmful interference when the equipment is

operated in a commercial installation. This equipment generates, uses, and can radiate radio fre-

quency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the interference at this

own expense.

Hewlett-Packard’s system certiﬁcation tests were conducted with HP supported peripheral devices

and HP-shielded cables. Changes or modiﬁcations no expressly approved by Hewlett-Packard could

void the user’s authority to operate the equipment.

Notice For Canada

This Class A digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulations.

Cet appareil numérique de la Class A respecte toutes les exigences du Règlement sur le matériel

brouilleur du Canada.

Notice For Japan (Class A)

Declaration of Conformity

according to ISO/IEC Guide 22 and EN 45014

Manufacturer: Hewlett-Packard Company

3404 East Harmony Rd.

Fort Collins, CO 80528

USA

Declares that the:

Product Name: Fire GL-UX Graphics Board

Model Number: A7789A

Product Options: All

conforms to the following speciﬁcations:

Safety EN 60950: 1992+A1+A2+A3+A4+A11

UL 1950/CSA 22.2 No. 950

AS/NS 3260

EMC CISPR 22: 1993+A1+A2 /EN 55022: 1998 Class A

EN 50024:1998 / EN 61000-4-2

EN 50024:1998 / EN61000-4-3

EN 50024:1998 / EN 61000-4-4

EN 50024:1998 / EN 61000-4-5

EN 50024:1998 / EN 61000-4-6

EN 50024:1998 / EN61000-4-11.

AS/NS 3548:1995, Class A

U.S. FCC Part 15, Class A

Japan VCCI Class A

and is certiﬁed by:

EMV Testhaus GmbH - DAR accredited Nr: TTI-P-G 101/95-20

Australia/New Zealand AS/NZS 3548:1995

Fort Collins CCQD HTC

Supplementary information:

The product herewith complies with the requirements of the following Directives and carries the CE marking

accordingly:

- the EMC directive 89/336/EEC and 92/31/EEC and 93/68/EEC

- the Low Voltage Directive 73/23/EEC and 93/68/EEC

This product was tested in a typical Hewlett-Packard workstation conﬁguration.

Original signed by Douglas K. Howell, TCD Regulatory Manager, Fort Collins, CO, USA

For Compliance Information ONLY, contact:

European Contact: Your local Hewlett-Packard Sales and Service Ofﬁce or Hewlett-Packard GmbH,

Department Standards Europe, Herrenberger Strasse 130, D-71034 Boeblingen (FAX: +49-7031-14-3143)

Americas Contact: Hewlett-Packard, TCD Regulatory Mgr.,3404 E. Harmony Road, Fort Collins, CO 80528,

U.S.A.(FAX: (970) 898-4556

Autres manuels pour j6700

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HP Carte vidéo

HP GP529AA Guide d'installation

HP NVIDIA Quadro FX 570 Instructions d'utilisation

HP Workstation x1000 Manuel utilisateur

HP A4979A Mode d’emploi

HP Workstation x1000 Manuel utilisateur

HP P Class 733/800/866MHz / 1GHz Manuel utilisateur

HP p2289a Manuel utilisateur

HP 8886 - Photosmart Camera Dock Digital Docking... Manuel utilisateur

HP P Class 733/800/866MHz / 1GHz Manuel

HP NVIDIA Quadro FX 3400 Instructions d'utilisation

HP Xw4550 - Workstation - 2 GB RAM Manuel utilisateur

HP NVIDIA Quadro FX 1400 Instructions d'utilisation

HP Xw460c - ProLiant - Blade Workstation Manuel utilisateur

HP NVIDIA Quadro FX 3450 Guide d'installation

HP Intel HD Graphics 2500 Manuel utilisateur

HP ATI FireGL V3100 Manuel utilisateur

HP AMD Radeon 7000 Manuel utilisateur

HP ATI Radeon X300SE (128MB) PCIe Manuel utilisateur

HP Xw460c - ProLiant - Blade Workstation Manuel utilisateur

HP Visualize b1000 Manuel utilisateur

HP ATI FireGL V5100 Instructions d'utilisation

HP Xw9400 - Workstation - 16 GB RAM Manuel utilisateur

HP c3700 - Workstation Manuel utilisateur

HP Visualize b1000 Instructions d'installation

Manuels Carte vidéo populaires d'autres marques

Gainward

Gainward GeForce GTX 690 4GB Manuel utilisateur

ATI Technologies

ATI Technologies RADEON 137-40225-20 Manuel utilisateur

MSI

MSI N220GT series Manuel utilisateur

ATI Technologies

ATI Technologies RADEON 7000 MAC EDITION Manuel utilisateur

SIIG

SIIG aurora Manuel utilisateur

ClearSpeed

ClearSpeed ClearSpeed Advance e720 Manuel utilisateur

MSI

MSI R7850 series Manuel utilisateur

DVS

DVS Atomix HDMI Manuel utilisateur

Aztech

Aztech VGS3D-AGP Manuel utilisateur

Advoli

Advoli TB4 Standard Manuel utilisateur

ELSA

ELSA ERAZOR III LT Manuel utilisateur

Gigabyte

Gigabyte GV-R7500L Manuel utilisateur

Themis

Themis TGA-7000 PMC Manuel utilisateur

EMS

EMS XtremeRGB-Ex1 Manuel utilisateur

Nvidia

Nvidia Quadro Workstation Manuel utilisateur

Pioneer

Pioneer PDA-5003 Manuel utilisateur

QDI

QDI N2 Manuel utilisateur

NEC

NEC N8116-48 Manuel utilisateur

HP j6700 Manuel utilisateur

Manuels Carte vidéo populaires d'autres marques
