HP 54710A Instructions de montage

User’s Reference

Publication number 54720-97005

First edition, October 1995

This book applies directly to firmware revision 4.XX.

For Safety information, Warranties, and Regulatory

information, see the pages behind the index

Copyright Hewlett-Packard Company 1992-1995

HP 54710A, 54710D, 54720A

and 54720D Oscilloscopes

Advanced Test Equipment Rentals

www.atecorp.com 800-404-ATEC (2832)

Printed in USA July 2004

Notice

Hewlett-Packard to Agilent Technologies Transition

This manual may contain references to HP or Hewlett-Packard. Please note that Hewlett-

Packard’s former test and measurement, semiconductor products and chemical analysis

businesses are now part of Agilent Technologies. To reduce potential confusion, the only

change to product numbers and names has been in the company name prefix: where a

product name/number was HP XXXX the current name/number is now Agilent XXXX. For

example, model number HP8648 is now model number Agilent 8648.

Contacting Agilent Sales and Service Offices

The sales and service contact information in this manual may be out of date. The latest

service and contact information for your location can be found on the Web at:

http://www.agilent.com/find/assist

If you do not have access to the Internet, contact your field engineer or the nearest sales

and service office listed below. In any correspondence or telephone conversation, refer to

your instrument by its model number and full serial number.

United States

(tel) 1 800 452 4844

(fax) 1 800 829 4433

Latin America

(tel) (305) 269 7500

(fax) (305) 269 7599

New Zealand

(tel) 0 800 738 378

(fax) 64 4 495 8950

Canada

(tel) +1 877 894 4414

(fax) +1 888 900 8921

Japan

(tel) (81) 426 56 7832

(fax) (81) 426 56 7840

Asia Pacific

(tel) (852) 3197 7777

(fax) (852) 2506 9284

Europe

(tel) (31 20) 547 2323

(fax) (31 20) 547 2390

Australia

(tel) 1 800 629 485

(fax) (61 3) 9210 5947

HP 54710A, 54710D, 54720A, and 54720D

Oscilloscopes

The HP 54720 is a modular, high-performance oscilloscope that

contains four data acquisition systems behind each of four plug-in

slots. Each plug-in slot provides 8 bits, 2-GSa/s maximum sample

rate, 16K maximum acquisition memory on the A models and 64K

maximum acquistion memory on the D models, and up to 1.5-GHz

bandwidth (depending on the plug-in you are using). A two-wide

plug-in, like the HP 54721A, uses two slots which allows a maximum

sample rate of 4 GSa/s and a maximum acquisition memory of 32K in

the A models and 128K in the D models. A four-wide plug-in, like the

HP 54722A, uses four slots which allows a maximum sample rate of 8

GSa/s and a maximum acquisition memory of 64K in the 54720A and

256K in the 54720D.

The HP 54720 also has firmware modularity by having a 3-1/2 inch

disk drive and flash ROMs, which allows for upgrades of the system

firmware features in the oscilloscope.

The plug-ins provide analog signal conditioning for the A/D converters

that are inside the mainframe.

This performance and flexibility provide you with the most accurate

analysis of single-shot phenomena found in any laboratory

oscilloscope.

The HP 54710 gives you the same performance as the HP 54720,

except that it has two acquisition systems.

This oscilloscope has many powerful features, and each of them is

described in this book. Your key to unlocking the power of the

oscilloscope depends how you combine its features for your

application, and your knowledge of how each feature effects the

operation of the oscilloscope.

All calibration and repair information is contained in the Service

Guide, and all programming information is contained in the

Programmer’s Reference.

Accessories Supplied

The following accessories are supplied with the oscilloscope.

•This User’s Reference

•One Programmer’s Reference

•One Service Guide

•One 2.3 meter (7.5 feet) power cord

See Also The Service Guide for available power cords.

Accessories Available

The following accessories are available for use with the oscilloscope.

CAUTION Make sure you use the correct length screw to rackmount the oscilloscope.

If you use a screw that is too short, it may not hold the oscilloscope safely in

the rack. If you use a screw that is too long, it can damage the oscilloscope.

•HP 54710-68703 (Opt 907) Rackmount kit, handles only. Includes

M4 X 0.7 X 12 mm flat-head screws, HP part number 0515-2227

•HP 54710-68704 (Opt 908) Rackmount kit, ears only. Includes M4

X 0.7 X 14 mm flat-head screws, HP part number 0515-0435

•HP 54710-68705 (Opt 909) Rackmount kit with ears and handles.

Includes M4 X 0.7 X 20 mm flat-head screws, HP part number

0515-0456

•HP 54720-68701 (Opt 002) Training kit including a PC board,

training guide, and power supply

•HP 10087A HP 54710A to HP 54720A upgrade service

•HP 54701A 2.5-GHz active probe

•HP 54006A 6-GHz passive probe

•HP 10430A 500-MHz 6.5-pF passive probe

•HP 10441A 500-MHz 9-pF passive probe

•HP 1141A 200-MHz differential probe

•HP 1142A Power supply for HP 1141A Probe

iii

In This Book

This book consists of 24 chapters, a glossary, and an index. Most of

the chapters describe the various menus in the oscilloscope. These

chapters contain the word "Menu" as part of their title. For example,

"Acquisition Menu" discusses the various softkey menus that come up

on the display when you press the Acquisition hardkey on the front

panel. The remaining chapters contain additional information about

the oscilloscope. For example, "Measurements" discusses how the

oscilloscope calculates the measurement results when you select an

automatic measurement.

You will find it easier to use this reference book if you are at least a

little familiar with how to use the front panel. The best way to learn

how to use the front panel is by reading the User’s Quick Start Guide

that is supplied with the oscilloscope.

How the Oscilloscope Works

Front Panel Features

Acquisition Menu

Applications

Calibration Overview

Channel Menu

Define Measure Menu

Disk Menu

Display Menu

Messages

Marker Menu

Math Menu

Measurements

Setup

Setup Print Menu

Specifications and

Characteristics

Time Base Menu

Trigger Menu

Utility Menu

Waveform Menu

FFT Menu

Limit Test Menu

Mask Menu

Histogram Menu

Glossary

Index

vii

viii

Contents

1 How the Oscilloscope Works

Hardware Architecture 1–10

Data Flow 1–15

Sampling Overview 1–18

Choosing Plug-ins 1–24

Choosing Probes 1–27

System Bandwidth 1–32

2 Front-Panel Features

Autoscale Key 2–3

Clear Display Key 2–3

Display 2–4

Entry Devices 2–7

Fine Mode 2–8

Help Menu 2–9

Indicator Lights 2–10

Local Key 2–12

Run Key 2–13

Stop/Single Key 2–14

3 Acquisition Menu

Sampling Mode 3–4

Digital BW Limit 3–6

Interpolate 3–6

Sampling Rate 3–12

Record Length 3–14

Averaging 3–19

Completion 3–20

4 Applications

Contents – 1
