HP 1405-5 Manuel utilisateur

HP 1405 Switch Series

Installation and Getting Started Guide

HP 1405-5 Switch (J9791A)

HP 1405-5G Switch (J9792A)

HP 1405-8 Switch (J9793A)

HP 1405-8G Switch (J9794A)

HP 1405 Switch Series

Installation and Getting Started Guide

Hewlett-Packard Company

8000 Foothills Boulevard, m/s 5551

Roseville, California 95747-5551

www.hp.com/networking

Company, L.P.

Manual Part Number

5998-3081

May 2012

Applicable Products

Disclaimer

HEWLETT-PACKARD COMPANY MAKES NO WARRANTY

OF ANY KIND WITH REGARD TO THIS MATERIAL,

INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not

be liable for errors contained herein or for incidental or

consequential damages in connection with the furnishing,

performance, or use of this material.

The information contained herein is subject to change

without notice. The only warranties for HP products and

services are set forth in the express warranty statements

accompanying such products and services. Nothing herein

should be construed as constituting an additional warranty.

HP shall not be liable for technical or editorial errors or

omissions contained herein.

Hewlett-Packard assumes no responsibility for the use or

reliability of its software on equipment that is not furnished

by Hewlett-Packard.

Warranty

For the latest license and warranty information, visit

www.hp.com/networking/support.

A copy of the specific warranty terms applicable to your

Hewlett-Packard products and replacement parts can be

obtained from your HP Sales and Service Office or

authorized dealer.

Safety

Before installing and operating these products, please read

the “Installation Precautions” in chapter 2, “Installing the

Switch”, and the safety statements in the General Safety and

Regulatory Information booklet included with the product.

HP 1405-5 Switch (J9791A)

HP 1405-5G Switch (J9792A)

HP 1405-8 Switch (J9793A)

HP 1405-8G Switch (J9794A)

iii

1 Introducing the Switch

Front of the Switch .............................................. 1-2

Network Ports ..............................................1-3

LEDs ......................................................1-3

Back of the Switch ..............................................1-4

Power Connector ...........................................1-4

Switch Features ................................................1-5

2 Installing the Switch

Included Parts ..................................................2-1

Installation Precautions ......................................2-3

Installation Procedures .......................................... 2-4

1. Prepare the Installation Site ................................2-5

2. Verify the Switch Passes Self Test ...........................2-6

LED Behavior ........................................... 2-8

3. Mount the Switch .........................................2-8

Wall Mounting ........................................... 2-8

Horizontal Surface Mounting ..............................2-9

4. Connect the Switch to a Power Source ......................2-11

5. Connect the Network Cables ...............................2-12

Using the RJ-45 Connectors ..............................2-12

Sample Network Topologies .....................................2-13

3 Troubleshooting

Basic Troubleshooting Tips ...................................... 3-1

Diagnosing with the LEDs ........................................3-3

LED patterns for General Switch Troubleshooting ...............3-3

Hardware Diagnostic Tests .......................................3-5

Testing the Switch by Resetting It .............................3-5

Testing Twisted-Pair Cabling ..................................3-5

Contents

Testing End-to-End Network Communications ..................3-5

HP Customer Support Services ................................... 3-6

Before Calling Support .......................................3-6

A Specifications

Switch Specifications ........................................... A-1

Physical ................................................... A-1

Electrical ................................................. A-1

Environmental ............................................. A-2

Acoustics ................................................. A-2

Safety .................................................... A-2

Cabling and Technology Information Specifications ................. A-3

Twisted-Pair Cable/Connector Pin-Outs ........................... A-4

Straight-through Twisted-Pair Cable for

10 Mbps or 100 Mbps Network Connections .................... A-6

Cable Diagram ......................................... A-6

Pin Assignments ........................................ A-6

Crossover Twisted-Pair Cable for

10 Mbps or 100 Mbps Network Connection ..................... A-7

Cable Diagram ......................................... A-7

Pin Assignments ........................................ A-7

Straight-Through Twisted-Pair Cable for

1000 Mbps Network Connections ............................. A-8

Cable Diagram ......................................... A-8

Pin Assignments ........................................ A-8

B EMC Regulatory Statements

Regulatory Statements .......................................... B-1

Index

1-1

Introducing the Switch

The HP 1405-5, 1405-5G, 1405-8, and 1405-8G Switches are multiport

unmanaged switches that can be used to build high-performance switched

workgroup networks. These switches are store-and-forward devices that offer

low latency for high-speed networking.

Throughout this manual, these switches will be referred to as the 1405-5

Switch, 1405-5G Switch, 1405-8 Switch, and 1405-8G Switch.

■The 1405-5 Switch has 5 auto-sensing 10/100Base-TX RJ-45 ports.

■The 1405-5G Switch has 5 auto-sensing 10/100/1000Base-T RJ-45 ports.

■The 1405-8 Switch has 8 auto-sensing 10/100Base-TX RJ-45 ports.

■The 1405-8G Switch has 8 auto-sensing 10/100/1000Base-T RJ-45 ports.

These switches can be directly connected to computers, printers, and servers

to provide dedicated bandwidth to those devices, and you can build a switched

network infrastructure by connecting the switch to other switches or routers.

54321

87654321

HP 1405-5 Switch (J9791A)

HP 1405-5G Switch (J9792A)

HP 1405-8 Switch (J9793A)

HP 1405-8G Switch (J9794A)

1-2

Introducing the Switch

Front of the Switch

321

HP 1405-5 Switch (J9791A)

HP 1405-5G Switch (J9792A)

Power LED

Link/Activity LEDs

8765

321

HP 1405-8 Switch (J9793A)

HP 1405-8G Switch (J9794A)

Power LED

Link/Activity LEDs

1-3

Introducing the Switch

Front of the Switch

Network Ports

The network ports support “Auto-MDIX” feature, which means that you can

use either straight-through or crossover twisted-pair cables to connect any

network devices to the switch.

■5 or 8 auto-sensing 10/100Base-TX ports.

■5 or 8 auto-sensing 10/100/1000Base-T ports (for 1405-5G and 1405-8G

only).

LEDs

The front panels of the switches provide status LEDs for system monitoring.

Table 1-1 details the functions of the LED indicators.

Table 1-1. Switch Status LEDs

Switch LEDs State Meaning

HP Power LED

(white)

On The switch is properly receiving power.

Off No power connection. The switch is NOT receiving power.

Port LEDs

Link/Act

(blue)

On The port is enabled and receiving a link indication from the connected device.

Off One of these condition exists:

• no active network cable is connected to the port

• the port is not receiving link beat or sufficient light

Flashing1Indicates that there is network activity on the port.

1The flashing behavior is an on/off cycle once every 0.083 seconds approximately.

1-4

Introducing the Switch

Back of the Switch

Power Connector

The switches do not have a power switch. They are powered on when the

external AC/DC power adapter is connected to the switch and to a power

source. The external AC/DC power adapter supplies 12 volts DC to the switch

and automatically adjusts to any AC voltage between 100-240 volts and either

50 or 60 Hz. No voltage range settings are required.

54321

87654321

RJ-45 ports DC power connector

HP 1405-5 Switch (J9791A)

HP 1405-5G Switch (J9792A)

HP 1405-8 Switch (J9793A)

HP 1405-8G Switch (J9794A)

RJ-45 ports DC power connector
