HP Ultrium 232e Manuel utilisateur

getting started guide

hp StorageWorks

Ultrium tape drive

external model

Ultrium 232e, 448e

1 2

External drives - contents

Pre-Installation

Before you start page 3

Backup software and drivers page 5

Usage models page 7

Using the CD-ROM page 9

Installing the tape drive

Step 1: Check the SCSI connection page 11

Step 2: Check the drive’s SCSI ID page 13

Step 3: Connect the SCSI cable page 15

Step 4: Connect the power cable page 17

Step 5: Verify installation page 19

Using the tape drive

Your HP StorageWorks Ultrium tape drive page 21

Use the correct media page 23

Using HP OBDR page 27

Diagnostic tools page 30

Optimizing performance page 32

Troubleshooting page 34

Understanding the LEDs page 39

Problems with cartridges page 42

Other sources of information page 44

February 2005

Part Number: DW017-90905

Hewlett-Packard Company makes no warranty of any kind with regard to this material,

including, but not limited to, the implied warranties of merchantability and fitness for a

particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the furnishing, performance, or use

of this material.

This document contains proprietary information, which is protected by copyright. No part of

this document may be photocopied, reproduced, or translated to another language without

the prior written consent of Hewlett-Packard. The information contained in this document is

subject to change without notice.

Linear Tape-Open, LTO, LTO Logo, Ultrium and Ultrium Logo are trademarks of Certance, HP

and IBM in the US, other countries or both.

Patented under one or more of U.S. Patents Nos. 5,003,307; 5,016,009; 5,463,390;

5,506,580; held by Hi/fn, Inc.

Microsoft®, MS-DOS®, MS Windows®, Windows®and Windows NT®are U.S.

registered trademarks of Microsoft Corporation.

UNIX®is a registered trademark of The Open Group.

Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions

contained herein. The information is provided ”as is” without warranty of any kind and is

subject to change without notice. The warranties for Hewlett-Packard Company products are

set forth in the express limited warranty statements for such products. Nothing herein should

be construed as constituting an additional warranty.

Printed in the U.K.

Product Details

Write your tape drive details here so you can find them easily if you need them. The model name is on the

front of the drive and the product and serial numbers are on a label on the bottom of the drive.

Model (type of drive):

Model (number):

Serial (number):

Date purchased/installed:

SCSI ID:

Before you start

HP StorageWorks Ultrium tape drives are high-performance Ultra 160 SCSI half-height

devices with a maximum burst transfer speed of 160 MB/second. They are designed to

operate on a low voltage differential SCSI bus (LVDS). They should be connected to a VHD

SCSI connection on your storage server. For a detailed product specification, please refer to

our World Wide Web site (www.hp.com).

Before starting to install your tape drive, you should consider the following:

Which operating systems are supported?

HP StorageWorks Ultrium drives can be connected to servers running under Windows®,

NetWare, HP-UX, Tru64, Linux and several other industry-standard operating systems. Refer to

the “HP StorageWorks Tape Software Compatibility” topic on our World Wide Web site

(www.hp.com/go/connect) for more information about the operating systems and

versions that are supported.

How do I connect the drive to my server?

Check the usage models on page 6. This shows how the HP StorageWorks Ultrium tape drive

can be used in different system architectures.

Your tape drive is supplied with a 68-pin, wide, VHD-to-HD SCSI cable to attach to the host

server.

You will need a properly installed and configured SCSI host bus adapter (HBA) or a built-in

SCSI controller on your server with a spare LVD SCSI port with a 68-pin, very high density

(VHD), wide SCSI connector.

For optimum performance your tape drive should only be connected to a SCSI bus that can

transfer data at a rate that supports the tape drive’s maximum burst transfer speed, see

Table 2, “supported SCSI bus types,” on page 11, and it should be the only device on the

SCSI bus. Do not attach the drive to the same SCSI bus as your disk drive or RAID controller

(unless you are connecting to a ProLiant server with a Smart Array 6i RAID controller).

How can I check the SCSI bus?

We strongly recommend that you use HP Library & Tape Tools to check your server’s current

SCSI configuration (see)“Step 2: Check the drive’s SCSI ID” on page 13. This will provide

information about the SCSI bus and the SCSI IDs in use.

HP Library & Tape Tools is the recommended diagnostic and support tool for your HP tape

storage product. It is available on the CD shipped with your product or as a free download

from the HP web site and is supported on nearly all major operating systems.

See www.hp.com/support/tapetools for compatibility information, updates and the

latest version of the tool.

Do I need additional items for installation?

• If the tape drive is not the only or last device on the SCSI bus, you must terminate the bus

with a multimode terminator. If the tape drive is the only or last device on the bus, then the

tape drive enclosure provides active termination and you do not need to purchase a

separate terminator.

• If you do not have a VHD, wide SCSI connector on your server, you will need to purchase

and install a VHD-to-HD adapter or use an HD-to-HD cable instead of the supplied cable.

• If you do not have a spare, suitably rated SCSI connector on your server, you must install a

new HBA (also known as a SCSI card). The SCSI bus rating should match or be higher than

the SCSI rating of your tape drive. See Table 2, “supported SCSI bus types,” on page 11

for recommended HBAs. For specific details relevant to your server model please refer to

www.hp.com/go/connect. You will need to purchase and install the new HBA into an

unused, 64-bit PCI expansion slot within your server before installing your tape drive. (The

kit can also be installed in a 32-bit PCI expansion slot, but this may limit performance.)

Refer to our World Wide Web site for recommended products, configurations and ordering

information: www.hp.com/go/connect or www.hp.com/support/ultrium.

Backup software and drivers

Backup software

For optimum performance it is important to use a backup application that is appropriate for

your system’s configuration. In a direct attach configuration, where the tape drive is attached

to a standalone server, you can use backup software that is designed for a single-server

environment. In network configurations you will need backup software that supports enterprise

environments. HP, Veritas, Yosemite, Legato and Computer Associates all provide suitable

products. Further details about these and other products that may be appropriate can be

found on our connectivity web site.

1Go to our connectivity web site: www.hp.com/go/connect.

2Select software compatibility.

3Select your combination of operating system and tape drive model in the table. A list of

supported backup applications is displayed. This will also tell you whether your configuration

is compatible with HP One-Button Disaster Recovery, HP OBDR. (All HP StorageWorks Ultrium

tape drives support HP OBDR. However, you can only use this feature, if your system

configuration and backup application also support it. See “Using HP OBDR” on page 27.)

4Make sure you have a backup application that supports your HP StorageWorks Ultrium tape

drive and download any upgrades or patches, if required.

Drivers

Windows users

The driver available from Microsoft update is acceptable, but the HP driver (available on the

CD-ROM or the web) provides better support for all the features of your new tape drive.

After you connect the tape drive, insert the HP StorageWorks Tape CD-ROM and follow the

link to download the HP driver from our web site: www.hp.com/support, see “Step 5:

Verify installation” on page 19. Refer to the accompanying README file for specific

installation instructions for Windows 2000, Windows XP and Windows Server 2003 drivers.

Note: We recommend that you install drivers from the web link on the CD-ROM rather than

the Windows Hardware Installation Wizard, because you can also use HP Library & Tape

Tools software on the CD-ROM to verify that your installation is correct (see “Step 5: Verify

installation” on page 19). If you do not have internet access, you can also install drivers

directly from the HP StorageWorks Tape CD-ROM, but these may not be the latest versions

available.

UNIX users

The recommended backup applications use the operating system’s standard, built-in device

drivers. To upgrade drivers we recommend that you patch to the latest version of the operating

system, following the instructions in the patch documentation. You will also find information

about configuring device files in the UNIX Configuration Guides on the CD-ROM.

Figure 1: usage models

tape

drive (B)

Direct attach - SCSI Network attach - SCSI

storage server (A)

RAID disk subsystem

recommended, see

page 7

Usage models

The tape drive (B) can be used in a standalone or network environment. It should always be

directly attached to a VHD SCSI connector on the storage server (A), as shown in Figure 1.

Recommended models

The following table shows the recommended usage models and “Optimizing performance”

on page 32 provides further information about factors that can affect performance.

table 1: recommended usage models

A RAID disk subsystem is recommended, especially for Ultrium 448 drives. A single disk,

particularly a fast disk such as a 15K RPM drive, will also be sufficient, but be aware of other

factors that can affect performance—such as, compressibility of data, disk fragmentation and

the number of files. You can use our free performance assessment tools, which are available

standalone or integrated into HP Library & Tape Tools, to check tape performance and test

whether your disk subsystem can supply data at the optimum transfer rate. You can also use

these tools to calibrate your restore performance and maximal tape performance with more

compressible data.

Other models

The tape drive may work with other usage models, such as network attach storage (NAS) and

storage area networks (SAN), but HP does not currently provide technical support for

installing and using standalone Ultrium tape drives with these architectures. Similarly,

connection to fibre channel may be possible, if you purchase and install a fibre channel/SCSI

bridge, but it is not currently a supported option.

Please check www.hp.com/go/connect for the latest supported configurations.

Direct Attach,

single storage server

Across the Network,

single storage server, multiple clients

Ultrium 448 Recommended Recommended

anything less than Gigabit Ethernet

may limit performance

Ultrium 232 Recommended Recommended

anything less than 100 Base-T

Ethernet may limit performance

install your

product

buy media

online

troubleshoot

with L&TT

learn about your

product

Figure 2: the

HP StorageWorks Tape

CD-ROM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HP Stockage

HP StorageWorks 4000/6000/8000 - Enterprise Virtual... Mode d’emploi

HP Ultrium 215 Instructions d'utilisation

HP Surestore 64 - Director Switch Manuel utilisateur

HP 3000 - 37XE System Mode d’emploi

HP STORAGEWORKS ALL-IN-ONE STORAGE SYSTEM Manuel utilisateur

HP Storevirtual 4000 Guide de référence rapide

HP StorageWorks P4000 Series Manuel utilisateur

HP StorageWorks 2000fc - G2 Modular Smart Array Mode d’emploi

HP StorageWorks D2700 Manuel utilisateur

HP LaserJet P2050 Series Manuel utilisateur

HP Portable Hard Drive Manuel utilisateur

HP StorageWorks Ultrium 1760 Manuel utilisateur

HP Model 744 - VME Workstation Guide de référence

HP StorageWorks 2/128 - SAN Director Switch Mode d’emploi

HP StorageWorks DLT VS 40/80 GB Manuel utilisateur

HP StoreEver ESL G3 Manuel utilisateur

HP SCSI Ultra320 Guide d'installation

HP StorageWorks XP48 - Disk Array Manuel utilisateur

HP StorageWorks 8B - FC Entry Switch Manuel utilisateur

HP P6080-63001 - Maxtor DiamondMax Plus 40 GB Hard... Manuel utilisateur

HP Surestore XP256 - Disk Array Manuel utilisateur

HP D2D Manuel de l'opérateur

HP VS160 - StorageWorks DLT Tape Drive Mode d'emploi

HP 12Gb SAS SSDs Instructions d'utilisation

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur

Dell

Dell PowerVault MD3600f Series Manuel utilisateur

CFI

CFI TERA STOR SATA RAID IV Manuel utilisateur
