HP Sb21 Manuel utilisateur

English • version 13.05.02

owner’s manual

hp digital projectors

xb31 & sb21

owner’s manual for the

hp digital projector xb31 and sb21

safety

Personal Safety ............................................ 4

Protecting Your Projector ............................... 4

introduction

Projector Features......................................... 5

Package Contents......................................... 6

Projector Overview ...................................... 7

Control Panel.......................................... 8

Back Panel Features ................................ 8

Remote Control With Mouse &

Laser Pointer........................................... 9

installation

Connecting the hp digital

projector xb31 to a computer ...................... 10

Connecting the hp digital

projector xb31 to other signal sources .......... 11

Connecting the hp digital

projector sb21 to a computer....................... 12

Connecting the hp digital

projector sb21 to other signal sources .......... 13

operation

Turning the projector ON and OFF............... 14

Turning the projector ON....................... 14

Turning the projector OFF ...................... 14

Adjusting the projected image ..................... 16

Adjusting the display angle .................... 16

Adjusting the hp xb31 zoom and focus ... 18

Projection image size (diagonal)............. 18

Adjusting the hp sb21 focus ................... 19

Projected image size (diagonal).............. 19

user controls

Control panel & remote control .................... 20

Control Panel........................................ 20

On-Screen Display Menus ........................... 21

How to operate..................................... 21

“Language” Menu................................. 22

“All Images” Menu................................ 23

“Audio” Menu ...................................... 24

“Computer Image” Menu ....................... 25

“Management” Menu............................ 26

“Video Image” Menu............................. 27

Remote control ........................................... 28

appendices

Troubleshooting ......................................... 30

Changing the lamp module ......................... 32

hp xb31 specifications................................ 34

hp xb31 compatibility modes ...................... 35

hp sb21 specifications ................................ 36

hp sb21 compatibility modes....................... 37

Regulatory information................................ 38

Warranty & Support ................................... 39

table of

contents

Personal Safety

CAUTION! PREVENT EYE INJURY. Do not look into the projector’s lens when the

lamp is on. Do not point the remote control’s laser light at your own,

or anyone else’s, eyes.

CAUTION! AVOID BURN HAZARD. The lamp gets hot during normal operation.

Allow it to cool down for 30 minutes before changing lamp!

CAUTION! CUT HAZARD. If the bulb is broken, use caution while removing the

bulb assembly to avoid injury.

CAUTION! PREVENT ELECTRICAL SHOCK. Do not expose to rain or moisture. Do

not open or disassemble projector, except as instructed by this

manual.

WARNING! MERCURY HAZARD. This projector’s bulb contains a small amount of

mercury. If the lamp breaks, adequately ventilate the area where the

breakage occurred. The projector bulb may require special handling

and disposal at end-of-life.

Protecting Your Projector

Do:

•Connect projector’s cables before turning the projector ON.

•Allow the projector to complete its cooling cycle after turning the Power OFF (refer

to page 14).

CAUTION: Unplugging the projector while the fan is running reduces lamp life.

•Turn off and unplug the projector before cleaning.

•Use a soft, dry cloth to clean the projector’s housing.

•Use camera-lens cleaning materials and procedures to clean the lens.

•Disconnect the power plug from AC outlet if the projector isn’t being used for an

extended period of time.

•Allow the projector to cool-down for at least 30 minutes before changing the lamp.

Follow instructions provided with replacement lamp or in this manual.

•Lamp failure may produce a loud popping sound. This is normal and should not

cause concern. The projector will not turn back on until the lamp module has been

replaced.

•Reset the “Lamp Hour” monitor from the On Screen Display “Management” menu

tab after replacing the lamp module (refer to page 26).

•Refer to page 39 for warranty and support information.

Don’t:

•Unplug the projector while the fan is running.

•Block the projector’s ventilation openings.

•Use abrasive cleaners, waxes, or solvents for your cleaning.

•Clean the lens with detergent.

•Use in very hot, cold, or humid environments.

•Use or store in dusty or dirty conditions.

•Use in a strong magnetic field.

•Place the projector in direct sunlight.

safety

b31 sb21

Projector Features

The hp digital projector xb31 is an XGA single chip 0.7” DLPTM projector with

these outstanding features:

• True XGA, 1024 x 768 addressable pixels

• 1500 comparable lumens

• Approximately 3.5 lbs (1.6 kg) compact design

• Single chip DLPTM technology

• SXGA compression and VGA, SVGA re-sizing

• 156 watts (W) user-replaceable P-VIP lamp module

• NTSC3.58/NTSC4.43/PAL/PAL-M/PAL-N/SECAM and HDTV compatible

• Full function remote with mouse control and laser pointer

• High-tech VESA M1-DA connection for digital and analog video connectivity

• High definition TV (HDTV) compatibility

• User-friendly multilingual On Screen Display (OSD) menu

• Advanced electronic keystone correction

• User-friendly control panel

• Built-in 2 watt audio speaker

• Carrying case and cables included (refer to page 6)

The hp digital projector sb21 is an SVGA single chip 0.55” DLPTM projector with

these outstanding features:

• True SVGA, 800 x 600 addressable pixels

• 1000 comparable lumens

• Approximately 2.2 lbs (1 kg) compact design

• Single chip DLPTM technology

• XGA compression and VGA re-sizing

• 132 watts (W) user-replaceable P-VIP lamp module

• NTSC3.58/NTSC4.43/PAL/PAL-M/PAL-N/SECAM and HDTV compatible

• Full function remote with mouse control and laser pointer

• High-tech VESA M1-DA connection for digital and analog video connectivity

• High definition TV (HDTV) compatibility

• User-friendly multilingual On Screen Display (OSD) menu

• Advanced electronic keystone correction

• User-friendly control panel

• Carrying case and cables included (refer to page 6)

introduction

b31 sb21

Package Contents

The hp digital projectors come with the following items. Please check to make

sure your unit is complete. If anything is missing contact your dealer

immediately.

Projector with lens cap Projector with lens cap Carrying Case

Composite Video Cable 2.5 mm Mini Phone Jack for

Composite Video Cable

Power Cord

S-video Cable USB Mini-B 5-pin to

S-video Input Cable

Mi-A to VGA

and USB Cable

Battery x2

Audio Cable Remote Control with Mouse

Function and Laser Pointer

Owner’s Manual on

Compact Disc (CD ROM)

Quick Start Card

Warranty/Support

Information Data Sheet

introduction

b31 sb21

Projector Overview

1. Control Panel 6. Remote Control Receivers (front & back)

2. Power Connector 7. Elevation Button

3. I/O Connection Ports 8. Elevation Foot

4. Zoom Ring 9. Lens Cap

5. Focus Ring

1. Control Panel 5. Remote Control Receivers (front & back)

2. Power Connector 6. Elevation Button

3. I/O Connection Ports 7. Elevation Foot

4. Focus Ring 8. Lens Cap

sb21

b31

introduction

Control Panel

1. Power (ON/OFF) Button

2. Lamp Warning Indicator Light

3. Temperature Warning

Indicator Light

4. Source Button

5. Menu (ON/OFF) Button

6. Auto Image Button

7. Four Directional Select Buttons

Back Panel Features

1. KensingtonTM Lock Hole 4. S-Video Input

2. Composite Video Input

3. Audio Input

5. VESA M1-DA Analog RGB / Digital / HDTV /

Component Video / USB Mouse Input

1. KensingtonTM Lock Hole 4. Power Connector

2. Composite Video Input

3. S-Video Input

5. VESA M1-DA Analog RGB / Digital / HDTV /

Component Video / USB Mouse Input

b31 sb21

introduction

12 3 4 5

b31

sb21

Remote Control With Mouse & Laser Pointer

b31 sb21

introduction

Multi-Directional Selector

Right Mouse Button

Hide Image

Page Down

Keystone Correction

Zoom In / Zoom Out

Transmit

Indicator Light

Projector Power

Page Up

Laser Pointer

Volume ( + / - )

Source

Freeze

Left Mouse Button

CAUTION!

PREVENT EYE INJURY.

Do not point the remote

control’s laserlight at

anyone’s eyes.

NOTE: Connect the USB

cable when using

the remote control

mouse features.

Connecting the hp digital projector xb31 to a

computer

Connect the power cord to the

projector and a power outlet.

Connect the black end of the

video cable to the projector.

Connect the blue end of the video

cable to the PC; optionally, to

have the remote control function

as a mouse, connect the USB

connector to the PC.

Start the projector; after a 30-

second warm-up it will search for

a video signal.

If no video signal is found, you

may need to set up the PC to

send a video signal out the video

port.

installation

b31

CAUTION!

Unplugging the projector while

the fan is running may reduce

lamp life.

NOTE: For best performance,

configure the display

mode of your computer’s

graphic card to

1024×768 resolution.

Ensure the timing of the

display mode is

compatible with the

projector. Refer to the

“hp xb31 compatibility

modes” section on

page 35.

Autres manuels pour sb21

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HP Projecteur

HP xp8010 series Manuel utilisateur

HP ep9010 Manuel utilisateur

HP mp3220 Series Manuel utilisateur

HP Ep7110 - Home Cinema Digital Projector SVGA... Manuel utilisateur

HP vp6121 Manuel utilisateur

HP xp8010 series Manuel utilisateur

HP vp6200 - Digital Projector Manuel utilisateur

HP Vp6110 - Digital Projector SVGA DLP Manuel

HP mp2210 Manuel utilisateur

HP AX325AA Instructions d'utilisation

HP WT431AA#ABA Manuel utilisateur

HP mp3220 Series Manuel utilisateur

HP xp8020 Manuel utilisateur

HP vp6310 Series Manuel utilisateur

HP mp3130 Manuel utilisateur

HP vp6100 series Manuel utilisateur

HP L1548A–ABA Manuel utilisateur

HP mp2220 Series Manuel utilisateur

HP xp8000 - Digital Projector Manuel utilisateur

HP mp2210 Manuel utilisateur

HP xp7010/xp7030 Manuel utilisateur

HP ep9010 - Instant Cinema Digital Projector Manuel utilisateur

HP MP100 Manuel utilisateur

HP xp8010 series Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

HP sb21 Manuel utilisateur

Manuels Projecteur populaires d'autres marques
