The HP ProLiant DL180 G6 is a low cost high capacity storage optimized 2-way server that delivers on a history of design excellence

and 2U density for a variety of rack deployments and applications.

Front View:

Rear View:

Access panel

Redundant Power Supply Bay (Optional)

Front LED Indicators

Power Supply Cable Socket

Power on/off

Low Profile Card Slot

Optional DVD-RW or DVD-ROM drive

PCI Expansion Card Slot

Front USB Ports (2)

PCI Expansion Card Slot

Non-Hot Plug Non Redundant fans (4 fans)

UID LED Button

Air Baffle

(Optional) LO100i 10/100 Mbps LAN port for IPMI

management (RJ-45)

PCI Cage

System Board

LAN Port

10.

2 Rear USB 2.0 Ports

11.

VGA Port

12.

Serial Port

What's New

Support for HP 3TB 3G SATA 7.2K 3.5in MidlLine Hard Drive

QuickSpecs

HP ProLiant DL180 Generation 6 (G6)

Overview

DA - 13248 Worldwide — Version 53 — September 24, 2012

Page 1

NOTE:

For the Standard Features shipped in the Factory Integrated Models, please see the "Configuration Information - Factory

Integrated Models" section.

Processor

One of the following

depending on Model

Intel® Xeon® X5660 (2.80GHz/6-core/12MB/95W, DDR3-1333, HT, Turbo 2/2/2/2/3/3) Processor

NOTE:

Available through Configure To Order only. See Factory Integration Models section for more details.

Intel® Xeon® X5650 (2.66GHz/6-core/12MB/95W, DDR3-1333, HT, Turbo 2/2/2/2/3/3) Processor

Intel® Xeon® E5649 (2.53GHz/6-core/12MB/80W, DDR3-1333, HT, Turbo 1/1/1/1/2/2) Processor

NOTE:

Available through Configure To Order only. See Factory Integration Models section for more details.

Intel® Xeon® E5645 (2.40GHz/6-core/12MB/80W, DDR3-1333, HT, Turbo 1/1/1/1/2/2) Processor

Intel® Xeon® L5640 (2.26GHz/6-core/12MB/60W, DDR3-1333, HT, Turbo 2/2/3/3/4/4) Processor

NOTE:

Available through Configure To Order only. See Factory Integration Models section for more details.

Quad -Core Processors

Intel® Xeon® X5672 (3.20GHz/4-core/12MB/95W, DDR3-1333, HT, Turbo NA/NA/2/2/3/3) Processor

Intel® Xeon® E5620 (2.40GHz/4-core/12MB/80W, DDR3-1066, HT, Turbo 1/1/2/2) Processor

Intel® Xeon® E5606 (2.13GHz/4-core/8MB/80W, DDR3-1066) Processor

Intel® Xeon® E5603 (1.60GHz/4-core/4MB/80W, DDR3-1066) Processor

NOTE:

Available through Configure To Order only. See Factory Integration Models section for more details.

Intel® Xeon® L5630 (2.13GHz/4-core/12MB/40W, DDR3-1066, HT, Turbo 1/1/2/2/) Processor

Intel® Xeon® E5540 (2.53GHz/4-core/8MB/80W, DDR3-1066, HT, Turbo 1/1/2/2) Processor

Intel® Xeon® E5520 (2.26GHz/4-core/8MB/60W, DDR3-1066, HT, Turbo 1/1/2/2) Processor

NOTE:

HT indicates that the processor model supports Intel® Hyper-Threading Technology.

NOTE:

Turbo indicates the maximum potential frequency increment when using Intel® Turbo Boost

Technology, with 4, 3, 2, and 1 cores active.

NOTE:

DDR3 speed is the maximum memory speed of the processor. Actual memory speed may depend on

the quantity and type of DIMMs installed.

NOTE:

For the Intel 5000 Series, the letter preceding the model number indicates the

performance/wattage of the processor. "X" denotes High Performance/Wattage; "E" denotes Enterprise

Performance/Wattage (Mainstream); and "L" denotes Lower Wattage.

Cache Memory

One of the following

depending on Model

12 MB Level 3 cache (L5630,E5620,X5650)

Chipset

Intel® 5520 Chipset

NOTE:

For more information regarding Intel chipsets, please see the following URL:

http://www.intel.com/products/server/chipsets/

Upgradeability

Upgradeable to two processors

QuickSpecs

HP ProLiant DL180 Generation 6 (G6)

Standard Features

DA - 13248 Worldwide — Version 53 — September 24, 2012

Page 2

Memory Protection

Advanced memory protection

Mirroring Mode

Lockstep Mode

Memory

Type

DDR3 Registered (RDIMM) or Unbuffered (UDIMM)

DIMM slots

Total 12 DIMM slots

Standard (Entry Models)

4GB (1 x 4GB)

Standard (Base Models)

8GB (2 x 4GB)

Standard (Performance

Models)

16GB (4 x 4GB)

Maximum (RDIMM)

192GB (12 x 16GB)

Maximum (UDIMM)

48GB (12 x 4GB)

NOTE:

Half DIMM slots are available when one processor is installed.

NOTE:

Depending on the memory configuration and processor model, the memory speed may run at

1333MHz, 1066MHz, or 800MHz. Please see the Online Memory Configuration Tool at:

www.hp.com/go/ddr3memory-configurator

Network Controller

HP NC362i Integrated Dual Port Gigabit Server Adapter

Expansion Slots

Slot Number

Bus Speed

Bus Number

Device

Number

Hot Plug

(Y/N)

Notes

x16 PCI-Express

6 0

Low Profile

x8 PCI-Express

5 0

Full Length

Full Height

x8 PCI-Express

4 0

Full Length

Full Height

x4 PCI-Express

3 0

Full Length

Full Height

PCI-X

***

Dynamic

Full Length

Full Height

PCI-X

***

Dynamic

Full Length

Full Height

NOTE:

All slots can accept universal keyed PCI cards.

NOTE:

Only PCI-X support is available in slot 4, supporting PCI-X cards. PCI legacy cards are not supported.

* Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number.

** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID by

bus (starting with the lowest bus).

*** PCI-X bus speed will be 100MHz in maximum and support two PCI-X/100MHz cards.

**** Slot 2 contains bus 4 and bus 5 because BIOS configures this x16 PCI-express.

NOTE:

Slot to two x8 PCI-express slot for production riser, this is valid only on Option1: 2 PCIe2x8 full-

length/full-height PCI-Express slots (Optional) or Option 4: 2 PCIe2x8 and 1 PCIex8 (4) full-length/full-

height slots (Optional).

QuickSpecs

HP ProLiant DL180 Generation 6 (G6)

Standard Features

DA - 13248 Worldwide — Version 53 — September 24, 2012

Page 3

Storage Controller

One of the following

depending on Model

4HDD Models

HP Smart Array B110i SATA RAID

NOTE:

To enable RAID on Embedded SATA, use the HP Smart Array B110i SATA

RAID Controller, To enable use of the B110i, enter the ROM based setup

utility(RBSU). The option for enabling RAID can be found in the Advanced

section of the RBSU.

NOTE:

Embedded SATA controller support transfer rate up to 3Gb/s

NOTE:

A diskette drive or virtual FDD using LO100 Advanced Pack is needed to

install storage controller drivers during a Windows operating system

installation from a CD.

NOTE:

HP Smart Array B110i does not support greater than 2TB hard drive.

8HDD Models

HP Smart Array P410/256MB Controller (RAID 0/1/1+0/5/5+0)

NOTE:

Support transfer rate up to 6Gb/s SAS or 3Gb/s SATA

12HDD Models

HP Smart Array P212/256MB Controller (RAID 0/1/1+0/5/5+0)

NOTE:

Available upgrades: P410 with FBWC, 256MB with BBWC, 512MB with

FBWC, Battery kit upgrade (for the 256MB cache), and Smart Array Advanced

Pack (SAAP).

NOTE:

Support transfer rate up to 3Gb/s SAS or 3Gb/s SATA

25HDD Models

HP Smart Array P410/256MB Controller (RAID 0/1/1+0/5/5+0)

NOTE:

Available upgrades: P410, 512MB with FBWC, Battery kit upgrade (for

the 256MB cache), and Smart Array Advanced Pack (SAAP).

NOTE:

Support transfer rate up to 6Gb/s SAS or 3Gb/s SATA

NOTE:

A minimum of 256 MB cache, battery kit, and Smart Array Advanced Pack License Key upgrade (P/N:

516471-B21) is required to enable RAID 6, 6+0

NOTE:

To achieve highest possible stated transfer rate please make sure the firmware on the drive bays

(backplanes) and HP Smart Array controller up to date. Latest firmware are available to download from HP

support web site.

NOTE:

All Hard drive bay options except 4LFF require HP Smart Array P410 or P212 controller. NOTE: Full

Height/ Full Length Riser Option is not available when the Rear 2LFF drive bays is selected for the system.

Internal Storage Devices

Diskette Drives

Via USB only

Optical Drives

One of the following

depending on Model

Optional HP Slim SATA DVD-ROM Optical Drive

Optional HP Slim SATA DVD RW Optical Drive

NOTE:

Support in 4, 8, and 12 drive models. Optical drives can only be installed

in 12 drive model and 25SFF drive bay system with rear option kit (P/N

515826-B21).

Drive Bays

One of the following

depending on Model

Up to 14 Hot Plug SAS/SATA 3.5" drives

Up to 25 Hot Plug SAS/SATA 2.5" drives

NOTE:

4 Drive Models are Non-Hot Pluggable. Smart Array Controller must be

added for Hot Plug drive capability. 4 Drive Models can be upgraded with the

addition of a Smart Array Controller and a SAS/SATA Multi-lane cable

(496013-B21).

NOTE:

The addition of a Smart Array Controller requires the addition of a

SAS/SATA Multi-lane cable (P/N 496013-B21).

QuickSpecs

HP ProLiant DL180 Generation 6 (G6)

Standard Features

DA - 13248 Worldwide — Version 53 — September 24, 2012

Page 4

Maximum Internal

Storage

One of the following

depending on Model

Hot Plug 3.5" SATA

42.0TB (14 x 3TB)

Hot Plug 3.5" SAS

42.0TB (14 x 3TB)

Hot Plug 2.5" SATA

25.0TB (25 x 1.0TB)

Hot Plug 2.5" SATA SSD

10.0TB (25 x 400GB)

Hot Plug 3.5" SATA SSD

5.6TB (14 x 400GB)

Hot Plug 2.5" SAS

25.0TB (25 x 1.0TB)

Hot Plug 2.5" SAS SSD

20.0TB (25 x 800GB)

Interfaces

Network RJ-45 (Ethernet)

2 10/100/1000 NIC ports (plus 1 dedicated for the HP ProLiant Lights Out 100i

Remote Management)

Serial

Graphics

USB

5 total ports: (2) front, (2) rear, (1) optional internal

NOTE:

In order to connect a USB device internally, the internal USB Cable G6

Kit must be used (P/N 536769-B21).

Industry Standard

Compliance

ACPI V2.0 Compliant

PCI 2.2 Compliant

PXE Support

WOL Support

Microsoft® Logo certifications

IPMI 2.0 Compliant

Server Power Cords

One 6' Highline (IEC-IEC) power cord ships standard

NOTE:

HP ProLiant DL servers no longer ship standard with NEMA power cords (P/N 163719-002) that

allow connection to 110V US wall outlets in a home or office. ProLiant DL servers are primarily connected

to PDU's in data center racks so they now ship standard with a PDU power cord (416151-B21). If a user

wishes to power a ProLiant DL server using a 110V receptacle (NEMA-15), the NEMA power cord must be

ordered separately.

If customers require a local power cord, they can check the power cord matrix for the appropriate cord.

Please see the following power cord matrix:

http://www.hp.com/go/powercordmatrix

NOTE:

Rack models ship standard with an IEC cable.

Localized cables included with geographic specific models in other world regions.

QuickSpecs

HP ProLiant DL180 Generation 6 (G6)

Standard Features

DA - 13248 Worldwide — Version 53 — September 24, 2012

Page 5

Common Slot Power

Supply

HP has a new design for ProLiant power. The new Common Slot Power Supply bay. This design provides

the customer with commonality in power supplies across multiple platforms to save on the cost of spares

and allows HP to offer multiple power solutions to fit the customers' needs. Many HP ProLiant Servers

come with Common Slot, High Efficiency and Right-Size Power Supplies. Common Slot (CS) designates

commonality of the power supply across multiple ProLiant servers. HP's new Common Slot power supplies

are designed for highest efficiency to provide power efficiency without degrading performance of the

ProLiant. Power Supplies will have efficiency ratings up to 92%. There are three Right Size power options

available, depending on the configuration of your server. To make sure you select the correct power

supply to meet your configuration, we suggest that you use the HP Power Advisor to decide the "Right-

Size" for your configuration. All HP Common Slot power sources are UL, CE Mark Compliant, Hot Plug and

Redundant.

It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for

your needs. HP offers Power Supply Options:

460Watts, Common Slot, 92% Efficiency

750Watts, Common Slot, 92% Efficiency

460Watts, Common Slot, 94% Efficiency

750Watts, Common Slot, 94% Efficiency

1200Watts, Common Slot, -48V DC Power Supply

HP's ProLiant Common Slot Power supplies (460W & 750W) meet multiple Energy Efficiency Initiatives.

Climate Savers Computing Initiative GOLD, ECOS Consulting 80PLUS GOLD and plans on offering models

that meet the Energy Star for Server requirements when they are published.

HP's ProLiant Common Slot Power supplies (1200W) meet multiple Energy Efficiency Initiatives. Climate

Savers Computing Initiative Bronze, ECOS Consulting 80PLUS Bronze Power Supply requirements.

Redundant Power: Optional (1+ 1 or n+n redundant) power supplies can be purchased through power

supply option kits.

System Fans

4 system fans ship standard; Non-hot plug, Non-redundant

NOTE:

Redundant fan kit (P/N 516009-B21) available for purchase.

Operating Systems and

Virtualization Software

Support for ProLiant

Servers

Microsoft Windows Server

Microsoft Windows Server Hyper-V

Red Hat Enterprise Linux (RHEL)

SUSE Linux Enterprise Server (SLES)

VMware ESX Server

Citrix Essentials for XenServer (Retail)

NOTE:

For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization

Software and latest listing of software drivers available for your server, including how to purchase from

HP, please visit our OS Support Site at:

http://www.hp.com/go/ossupport

Graphics

32MB shared supporting all display resolutions up to 1600x1200 16bpp@75Hz

NOTE:

8MB is dedicated to video memory.

QuickSpecs

HP ProLiant DL180 Generation 6 (G6)

Standard Features

DA - 13248 Worldwide — Version 53 — September 24, 2012

Page 6

Form Factor

Rack (2U), (3.5 in/8.89 cm)

Embedded Manageability

HP Lights-Out 100

(LO100) Advanced

HP LO100 with Optional LO100 Advanced Licenses for Virtual KVM and Virtual

Media.

Features:

Embedded IPMI standard reporting

System event log access

Remote Serial console (serial redirection)

Browser, Telnet access

SMASH-CLP compliant

IPMI 2.0 compliant

Secure Socket Layer Encryption

Secure Shell Encryption

Virtual media (Floppy, CD, USB 2.0) with Advanced License

Virtual KVM with Advanced License

NOTE:

For more information, see:

http://www.hp.com/go/lo100

Core Server Management

ProLiant 100 Series G6

Core Management

Software

HP provides management solutions that are designed to simplify a server's

installation, configuration, and maintenance throughout the entire server

lifecycle. This provides the customers with higher levels of operational

efficiency and highly reliable systems.

While ProLiant 100 series G6 servers do not support the Insight Foundation

Suite for ProLiant, they support a key subset of this important suite software

tools and utilities which are very suitable for this class of server: SIM, SMH,

agents, providers, and a SmartStart 'like' deployment CD called Easy Set-up

which greatly simplifies server set-up. Additionally the DL100 and SL100 G6

models support the SmartStart Scripting Toolkit (SSSTK), an automated

scalable deployment utility.

Information on core management supported on ProLiant 100 series G6 servers

can be found at these URLS:

Core Management:

www.hp.com/go/coremanagement

HP ProLiant 100 series Easy Set-up CDs:

www.hp.com/servers/easysetup

HP Systems Insight

Manager

HP Systems Insight Manager (HP SIM) provides a unified, secure and

extensible standards-based environment to centrally manage servers,

storage and other infrastructure devices, (both HP and non-HP) across

multiple operating system platforms.

Insight Management

Agents

HP Insight Management Agents and Insight Management Providers are

available for HP Systems Insight Manager (SIM) Integration.

ProLiant 100-series G6 servers can use the same SNMP based Insight

Management Agents supported by other ProLiant servers. As a result,

administrators can use HP Systems Insight Manager (SIM) 5.3 and

QuickSpecs

HP ProLiant DL180 Generation 6 (G6)

Standard Features

DA - 13248 Worldwide — Version 53 — September 24, 2012

Page 7

greater to manage ProLiant 100-series G6 servers. Administrators can

also use any other SNMP- based management tool. These agents are

obtained as part of the ProLiant 100-series model-specific "Easy Set-

up" CDs, or through:

www.hp.com/servers/easysetup

The following capabilities are enabled on the 100-series G6 servers by

the SNMP agents:

Health monitoring capabilities, including monitoring for drives, fans,

network, power supplies, and temperature

Alerting capabilities, including basic alert notification for Smart Array

drive pre-failure only

Performance monitoring capabilities providing information on

processor, memory, disk free space, network utilization

NOTE:

For additional information, please see:

http://www.hp.com/go/insight

Easy Set-up CD

Easy Set-up CDs are available on all 100-series G6 servers and are also

available as an ISO image web download. HP ProLiant Easy Set-up CDs provide

easy, step-by-step, single and multi-server server utilities for the ProLiant

100-series G6 servers to streamline server setup for 100-series G6 servers.

The user experience is consistent with SmartStart and offers the following

capabilities:

Boot environment and GUI

Assisted Installation: Windows 2003 Server and Windows 2008 Server

drivers

Manual installation: Windows 2003 Server, Windows 2008 Server, and

Linux drivers (specific OS support varies by server. Refer to each

server's QuickSpecs for supported versions)

HP Insight Diagnostics

AutoRun

Array Configuration Utility (ACU) has been combined with Array

Diagnostics Utility (ADU) to offer both configuration of array controllers

and storage devices and testing of array controller hardware

SmartStart Scripting Toolkit (SSSTK) and Smart Components for

software and drivers for DL100 and SL100 servers

NOTE:

OS and SW available for Manual Installation are listed on each server's

QuickSpecs.

SmartStart Scripting

Toolkit (SSSTK)

The SmartStart Scripting Toolkit is a server deployment product that delivers

an unattended automated installation for high-volume server deployments.

The SmartStart Scripting Toolkit includes a set of utilities for configuring and

deploying servers in a customized, predictable, and unattended manner.

These utilities enable you to duplicate the configuration of a source server on

target servers with minimum user interaction.

The Toolkit is designed for IT experts with experience in scripting operating

system installations and configuring ProLiant server hardware.

NOTE:

For additional information, please see:

http://h18004.www1.hp.com/products/servers/management/toolkit/

index.html

QuickSpecs

HP ProLiant DL180 Generation 6 (G6)

Standard Features

DA - 13248 Worldwide — Version 53 — September 24, 2012

Page 8

Subscriber's Choice

Subscriber's Choice Driver and Support Alerts/Notifications is a web-based

email subscription service that provides software and driver change

notifications for ProLiant products. Sign up at:

http://www.hp.com/go/subscriberschoice

and customize your profile to receive various new alerts as they become

available, on a weekly or monthly basis.

ROMPaq, software and

latest drivers

The latest software, drivers, and firmware fully optimized and tested for your

ProLiant server and options; downloaded from Software and Drivers

download pages website at:

http://www.hp.com/go/support

and from

www.hp.com/servers/easysetup

. Contains the following:

HP Insight Management Agents for Systems Insight Manager (SIM)

Integration

HP Systems Management Homepage

Array Configuration Utility (ACU)

Array Diagnostics Utility (ADU)

HP Insight Diagnostics

Security

Power-on password

Setup password

Diskette boot control

Secure Sockets Layer (SSL)

Secure Shell (SSH)

Warranty

This product is covered by a global limited warranty and supported by HP Services and a worldwide

network of HP Authorized Channel Partners. Hardware diagnostic support and parts replacement is

available for three years from date of purchase. Support for software and initial setup is available for 90

days from date of purchase. Enhancements to warranty services are available through HP Care Pack

services or customized service agreements. Hard drives have either a one year or three year warranty;

refer to the specific hard drive QuickSpecs for details.

NOTE:

Server Warranty includes 3-Years Next Business Day Parts replacement, 0-Years Labor, 0-Years

Onsite support. Additional information regarding worldwide limited warranty and technical support is

available at:

http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html

QuickSpecs

HP ProLiant DL180 Generation 6 (G6)

Standard Features

DA - 13248 Worldwide — Version 53 — September 24, 2012

Page 9

HP Insight Control

management software

HP Insight Control for

Linux

HP Insight Control for Linux, as a product option, delivers essential

infrastructure management that can help save time and money by making it

easy to deploy, monitor, remote control, and optimize your IT infrastructure

through a single, simple management console. The Insight Control for Linux

installs and license software modules that are integrated into HP System

Insight Manager.

The HP Insight Control for Linux (IC-Linux) serves environments requiring a

Linux-based management consoles. See

www.hp.com/go/ic-linux

HP Insight Control include one year of 24 x 7 HP Software Technical Support

and Update Service ensuring rapid access to HP support staff and proactive

delivery of software updates. For more information about this service, please

visit:

http://www.hp.com/services/insight

Insight Control server

deployment

HP Insight Control server deployment is a deployment solution for HP ProLiant

and Integrity servers hosted on a Windows CMS. It automates the process of

deploying and provisioning server software, enabling companies to quickly

and easily adapt to changing business demands. Insight Control server

deployment includes software optimizations for HP servers, including the HP

scripting toolkits, configuration jobs for leading industry-standard operating

systems, sample unattended files, and HP server support packs that include

software drivers, management agents, and important documentation.

Deploying servers can be accomplished either through imaging or through

scripting.

Insight Control server deployment is hosted on a Windows server and is

intended for heterogeneous environments deploying Windows, Linux, VMware

ESX and Microsoft Hyper-V systems.

Insight Control server deployment includes one year of 24 x 7 HP Software

Technical Support and Update Service ensuring rapid access to HP support

staff and proactive delivery of software updates. For more information about

this service, please visit:

http://www.hp.com/services/insight

QuickSpecs

HP ProLiant DL180 Generation 6 (G6)

Optional Features

DA - 13248 Worldwide — Version 53 — September 24, 2012

Page 10

Autres manuels pour ProLiant DL180 G

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HP Serveur de stockage réseau

HP AK373A - StorageWorks All-in-One Storage System 1200r 5.4TB SAS Model NAS... Comment utiliser

HP DL380 - ProLiant G4 9 TB Data Protection Storage Server... Manuel utilisateur

HP NAS 4000s Mode d’emploi

HP StorageWorks XP10000 - Disk Array Manuel utilisateur

HP Proliant DL580 Manuel utilisateur

HP ProLiant 300 Series Mode d’emploi

HP DL100 - ProLiant G2 320GB File Print... Mode d’emploi

HP MediaSmart EX495 Comment utiliser

HP ProLiant ML350 G5 Mode d’emploi

HP J3278B - SureStore CD-ROM Server/Tower 7 NAS... Manuel utilisateur

HP ProLiant ML110 G1 Manuel utilisateur

HP NetStorage 6000 Guide de démarrage rapide

HP J3278B - SureStore CD-ROM Server/Tower 7 NAS... Manuel utilisateur

HP ProLiant DL380 G4 DPSS Manuel utilisateur

HP NetStorage 6000 Manuel d'utilisation et d'entretien

HP ProLiant ML110 G1 Manuel utilisateur

HP J3278B - SureStore CD-ROM Server/Tower 7 NAS... Instructions d'installation et d'utilisation

HP ML350 - ProLiant - G2 Manuel utilisateur

HP 201723-B21 - HP StorageWorks Modular SAN Array 1000 Hard... Manuel utilisateur

HP ML110 - ProLiant G5 2TB Storage Server NAS Comment utiliser

HP ProLiant DL38 Manuel utilisateur

HP ProLiant DL100 G2 DPSS Mode d’emploi

HP ProLiant DL100 G2 DPSS Manuel utilisateur

HP ProLiant ML110 G5 Manuel utilisateur

Manuels Serveur de stockage réseau populaires d'autres marques

Seagate

Seagate U10 ST320423A Manuel utilisateur

Synology

Synology RackStation RS816 Manuel

D-Link

D-Link ShareCenter Pro DNS-1200-05 Manuel utilisateur

Avid Technology

Avid Technology VideoRAID ST Guide de sécurité

Western Digital

Western Digital My Cloud Home Duo Manuel utilisateur

PrimeArray

PrimeArray 4xxx Manuel utilisateur

Buffalo

Buffalo TeraStation WSS WSH5010N6 Manuel utilisateur

Planex

Planex MZK-NAS01SG Manuel utilisateur

Intel

Intel SS4000-E - Entry Storage System NAS Server Manuel utilisateur

Synology

Synology RS2212+ Manuel utilisateur

Allnet

Allnet ALL69000 Manuel utilisateur

Adaptec

Adaptec 5325301580 Manuel utilisateur

Motorola

Motorola EXORdisk II Manuel utilisateur

Sony

Sony XDAAI1PK Manuel utilisateur

Cisco

Cisco Linksys NAS200 Instructions d'utilisation d'origine

Sans Digital

Sans Digital MR4UT6G Manuel utilisateur

AIC

AIC FB128-LX Manuel utilisateur

Dell

Dell PowerVault NX3500 Instructions d'utilisation
