HP ProLiant Storage Server

installation instructions

These instructions are intended for professionals who

install and configure HP ProLiant Storage Servers. Ex-

perience with Microsoft® administrative procedures

and system and storage configurations is helpful, but

not required.

L.P.

First edition: November 2008

The information in this document is subject to change without notice.

Printed in Puerto Rico

www.hp.com

*5697-7749*

Supported storage servers

These installation instructions apply to the following HP ProLiant Storage

Server models:

•ML110 G5 Storage Server

•DL160 G5 Storage Server

•DL185 G5 Storage Server

•DL380 G5 Storage Server

IMPORTANT:

If your storage server is an HP ProLiant DL380 G5 High

Availability Storage Server, see the

HP ProLiant DL380 G5 High

Availability Storage Server installation instructions

for detailed

clustering instructions.

Go to http://www.hp.com/support/manuals, click Disk Storage

Systems, and select HP ProLiant DL380 G5 High Availability

Storage Server.

Supporting documentation

The following documentation provides additional information about using

your HP ProLiant Storage Server. To obtain this documentation, go to

http://www.hp.com/support/manuals, click Disk Storage Systems, and

select your HP ProLiant Storage Server model.

•HP ProLiant Storage Server user guide

•HP StorageWorks All-in-One Storage Manager user guide

•HP Rack Rail Kit installation instructions

•HP ProLiant DL380 G5 High Availability Storage Server installation

instructions

•HP ProLiant Server troubleshooting guide

Determine a network access method

Before installing the storage server hardware, decide which access

method will be used to connect to the storage server.

•Direct attach — Connect a monitor, keyboard, and mouse directly

to the storage server. This access method is mandatory if your network

does not have a Dynamic Host Configuration Protocol (DHCP) server.

•Remote browser — Access the storage server through a client running

Internet Explorer 5.5 or later. ActiveX controls must be enabled on

the remote client and the serial number or IP address of the storage

server is required.

•Remote desktop — Access the storage server through a client running

Remote Desktop Connection. The serial number or IP address of the

storage server is required.

•Remote management — Access the storage server using either the

Integrated Lights-Out 2 or Lights-Out 100 remote management

method.

For detailed instructions on using each of these access methods, see the

HP ProLiant Storage Server user guide.

Page 1

Install the storage server hardware and

power on

1. If installing the storage server in a rack, install the rail kit or

tower-to-rack conversion kit by following the HP Rack Rail Kit

installation instructions. Go to http://www.hp.com/support/

manuals, click Disk Storage Systems, and select your storage

product.

2. If connecting to the storage server using the direct attach method,

connect the following cables to the back panel of the storage server

in the following sequence: keyboard, mouse, network cable, monitor

cable, and power cable.

NOTE:

The keyboard, mouse, and monitor are not provided

with the storage server.

3. If connecting to the storage server using the remote browser, remote

desktop, or remote management method, connect only the network

cable and power cable.

4. Power on the system by pushing the power button on the front panel

(remove the bezel if needed).

The storage server starts and displays an HP ProLiant Storage Server

installation screen. The installation process takes approximately

10–15 minutes and requires no user interaction. When the

installation process is complete, the system prompt appears.

5. At the system prompt, enter the default user name administrator

and password hpinvent.

After logging in for the first time, the Welcome screen of the Rapid

Startup Wizard opens.

Set up the storage server with the Rapid

Startup Wizard

The Rapid Startup Wizard guides you through setting up your storage

server with basic configuration information. Before configuring any other

storage settings, complete the Rapid Startup Wizard.

1. On the Rapid Startup Wizard Welcome screen, click Next.

2. On each screen of the wizard, complete the requested information.

The final screen of the Rapid Startup Wizard is a summary page

that displays the configuration settings. If you need to make changes,

you can go back to any previous wizard screen by clicking the Back

button.

3. Click Finish after completing the configuration changes.

If prompted, restart the storage server after applying the changes.

Manage your storage

After installing and setting up your HP ProLiant Storage Server, you can

begin managing your storage using the HP StorageWorks All-in-One

Storage Manager (ASM). HP ASM comes preinstalled on the following

HP ProLiant Storage Server models:

•ML110 G5 Storage Server*

•DL160 G5 Storage Server

•DL185 G5 Storage Server

•DL380 G5 Storage Server*

* HP ASM is not supported on the ML110 G5 320GB SATA and DL380

G5 SAN Gateway models.

To maximize HP ASM's functionality on HP ProLiant Storage Servers,

install the following software. To obtain these software programs, go to

http://www.hp.com/go/simplestorage.

•Microsoft iSCSI Software Target — required for hosting application

storage (Exchange and SQL Server) and iSCSI-based User-Defined

application storage

•Data Protector Express — required for creating backups to tape,

other disks, or other types of storage media

•HP StorageWorks Storage Mirroring — required for replication

(required on replication source and all replication targets)

Before scheduling data migration of SQL, Exchange, or User-defined

data using HP ASM, you must first install Microsoft iSCSI Software Target

on your storage server in addition to installing the HP All-in-One Storage

Manager Agent on remote application servers that store the data to be

migrated.

For more information about using the HP All-in-One Storage Manager,

see the HP StorageWorks All-in-One Storage Manager user guide. Go

to http://www.hp.com/support/manuals, click Disk Storage Systems,

and select your storage product.

Page 2
