HP 3PAR StoreServ 7000 Manuel utilisateur

HP 3PAR StoreServ 7000 Storage extends the innovative HP 3PAR StoreServ product line to the midrange with industry leading

performance and features at the price you need. Spend less time managing storage, get more features for less money, and do it all

without sacrificing performance or future scalability. HP 3PAR StoreServ 7000 Storage provides high performance and guarantees to

double your virtual machine density. With hardware assisted thin storage it is the only platform that guarantees a 50% reduction in

capacity requirements. HP 3PAR StoreServ is also the first product family with a common architecture that meets SMB needs and spans

to the largest global enterprise giving you access to the same features as the world's largest service providers. You can start small and

grow without painful upgrades down the road.

HP 3PAR StoreServ 7000 is storage made effortless.

HP 3PAR StoreServ 7200 Storage HP 3PAR StoreServ 7400 Storage

Summary

3PAR StoreServ 7200 3PAR StoreServ 7400

Number of Controller Nodes

2 or 4

HP 3PAR Gen4 ASICs

2 or 4

Processors

2 four-core 1.8 GHz

2 - 4 six-core 1.8 GHz

Cache

24 GB

32 - 64 GB

Maximum Host Ports

12 ports 24 ports

Fibre Channel Host Ports

4 - 12 ports 4 - 24 ports

10Gb/s iSCSI Host Ports

0 - 4 ports 0 - 8 ports

Maximum Initiators Supported

512

512 or 1024

2U Controller Enclosure SAS Drive Capacity

24 24

Number of Disk Drives

- 144 drives

- 480 drives

Number of Solid State Drives

- 120

- 240

Raw Capacity (approx.)

1.2 - 250 TB

1.2 - 864 TB

QuickSpecs

HP 3PAR StoreServ 7000 Storage

Overview

DA - 14433 North America — Version 6 — February 19, 2013

Page 1

Capacity Details

3PAR StoreServ 7200 3PAR StoreServ 7400

RAID Levels

RAID 0, 1, 5, 6 RAID 0, 1, 5, 6

RAID 5 Data to Parity Ratios

2:1 - 8:1 2:1 - 8:1

RAID 6 Data to Parity Ratios

4:2, 6:2, 8:2, 10:2, 14:2 4:2, 6:2, 8:2, 10:2, 14:2

Drive Capacities (approximate GB

)

(RAID levels, parity ratios, and drive capacities all mixable

within the same Storage System)

100 SSD

, 200 SSD

300 SAS, 450 SAS, 900 SAS, 2000

,3000 NL

100 SSD

, 200 SSD

300 SAS, 450 SAS, 900 SAS, 2000

,3000 NL

Number of Add-on Drive Enclosures

(Each Drive Enclosure holds up to 24 drives in 2U for small

form factor drives and 4U for large form factor drives)

0 - 5 enclosures

0 - 18 enclosures

The minimum drive quantity is permitted as long as the total raw capacity is at least 1.2 TB.

Maximum raw capacity currently supported with any and all drive types.

For storage capacity, 1 GB = 1,000,000,000 bytes and 1 TB = 1,000 GB.

SSDs are Solid State Drives.

NL drives are 7200 RPM Enterprise SAS drives.

Ports are FCoE ready. FCoE support will be available in a later release.

NOTE:

Specifications are subject to change without notice.

Host OS Support

Citrix® XenServer® | HP-UX® | IBM® AIX®

Microsoft® Windows® Server, including Microsoft® Hyper-V™

Oracle® Linux® (UEK and RHEL compatible kernels) | Oracle® Solaris

Red Hat® Enterprise Linux® | Red Hat® Enterprise Virtualization

SUSE® Linux Enterprise | VMware vSphere™

For the latest information on supported operating systems refer to Single Point of Connectivity Knowledge for HP Storage Products

(SPOCK):

http://www.hp.com/storage/spock

QuickSpecs

HP 3PAR StoreServ 7000 Storage

Overview

DA - 14433 North America — Version 6 — February 19, 2013

Page 2

Efficient

Get thin and stay thin - Thin technologies unique to the HP 3PAR StoreServ family can reduce capacity

requirements by 50%. Purchase only what you need, as you need it so you can focus resources on growing

your business, not maintaining your storage. Additionally, the HP 3PAR ASIC with Thin Built In features an

efficient, silicon-based zero-detection mechanism. This unique hardware capability gives HP 3PAR

StoreServ Storage the power to remove allocated but unused space without impacting performance.

Data center virtualization - Increase virtualization return on investment. Double virtual machine density on

your physical servers, spend up to 90 percent less time managing your storage, and support your

virtualization deployment with 50 percent less storage capacity. HP 3PAR StoreServ is built from the

ground up to deliver performance that exceeds the demands of virtualized data centers along with

transformative levels of simplicity, agility, and efficiency.

Service levels - With policy-based autonomic sub-LUN tiering, you can balance the cost of capacity and the

cost of performance and put the right data on the right storage tier at the right time.

Do more with less - With HP 3PAR StoreServ Storage you can purchase up to 75 percent less capacity-

meaning less equipment to house, fewer disks to power and cool, less hardware to retire after it has

reached its end of life, and a reduced carbon footprint.

Autonomic

It's like breathing-you don't even have to think about it. Simplify, automate, and expedite storage

management by handling storage provisioning, tiering, and change management autonomically-

intelligently, at a sub-system level, and without administrator intervention.

SmartStart Software - software designed to get you off to a quick start with your new HP 3PAR StoreServ

7000 system.

Common architecture - Access the same features as the world's largest service providers with a common

architecture that meets SMB needs and spans to the largest global enterprise.

Resilient

Secure multi-tenancy - Consolidate with confidence. Achieve higher service levels for more users and

applications with less infrastructure. HP 3PAR StoreServ Storage is designed to support massive

consolidation by supporting mixed workloads and secure administrative segregation of users, hosts, and

application data. Deliver higher performance levels, greater availability, and next-generation functionality

to multiple user groups and applications from a single storage system.

Scalable - HP 3PAR StoreServ 7000 provides affordable entry pricing and unique, non-disruptive scalability

to four nodes.

High Availability - Featuring the same mesh-active architecture as all HP 3PAR StoreServ products, HP

3PAR StoreServ 7000 offers the highest levels of data availability and protection for the midrange.

Intelligent data striping across all available enclosures provides HA Cage, the ability to maintain

availability even when a whole drive enclosure fails. HP 3PAR Persistent Cache in four node configurations

eliminates performance impacts that result from unplanned component failures, making it a must-have

for maintaining service levels in the virtual data center-a feature that you can't get from any other

midrange storage platform.

Storage federation - Meet the needs of today's data center with the ability to move data and workloads

between arrays without impact to applications, users, or services. Simply and non-disruptively shift data

between any model HP 3PAR StoreServ system without additional management layers or appliances.

QuickSpecs

HP 3PAR StoreServ 7000 Storage

Features

DA - 14433 North America — Version 6 — February 19, 2013

Page 3

Storage federation on HP 3PAR StoreServ Storage can also help you improve availability in clustered

VMware environments.

Mixed workload - Mixed workload support serves transactional and throughput-intensive workloads from

a single device. The purpose-built HP 3PAR ASIC delivers mixed workload support to alleviate performance

concerns and cut traditional array costs. Transaction- and throughput-intensive workloads run on the

same storage resources without contention, thereby cutting array purchases in half.

QuickSpecs

HP 3PAR StoreServ 7000 Storage

Features

DA - 14433 North America — Version 6 — February 19, 2013

Page 4

Warranty

3 Year, On-site Warranty Service. 7x24 4-hour remote response with next business day on-site response

HP 3PAR StoreServ 7000 drive (SSD, SAS performance and Nearline) warranty is 3 years, parts only.

HP warrants only that the Software media will be free of physical defects for a period of ninety (90) days

from delivery.

For more information about HP's Global Limited Warranty and Technical Support, visit:

http://www.hp.com/products/storageworks/warranty

Service and Support

Technology Services for increased uptime, productivity and ROI

Trust HP storage technology experts for every level of service and support. Our integrated portfolio of

services for storage help customers reduce costs, optimize data, streamline storage management, and

improve backup and recovery. Capitalizing on HP Storage Systems' capabilities requires a service partner

who understands your increasingly complex environment. Team with the people who know HP

infrastructure hardware and software best-the experienced professionals at HP Services.

Protect your business beyond warranty

Warranty protects against manufacturer defects, however warranty uplifts, such as HP Care Pack Services

protect the business-by reducing downtime risks and providing operational consistency for mission-

critical and standard business computing.

What HP Storage Technology Services can do for you

HP Storage Technology Services can help you design, deploy, test, integrate, support, and manage IT and

infrastructure solutions. HP storage lifecycle support services offers a full spectrum of customer care-

from technology support to complex migrations to complete managed services.

Choose the right level of support, deployment and integration services

HP support recommendations are designed to help you enhance technology operations and lower risk-and

make it easier for you to seek the right balance between affordability and service-level commitments.

Depending on your individual support needs, choose from three levels of care that cover the entire

lifecycle to better address your needs-Optimized Care, Standard Care, and Basic Care. If none of our

support recommendations meet your needs, we can tailor a service solution for your unique support

requirements. Only HP brings together deep expertise, proactive and business critical support and a strong

partner network-together with, a full set of infrastructure services designed to power a Converged

Infrastructure

Optimized Care

- delivers

best performance and

stability through

deployment and proactive

management practices

HP Critical Service -

This service delivers 24x7 monitoring of your environment, making it the right choice

when uninterrupted uptime is essential. We implement improvement projects to mitigate risks and reduce

incidents to maximize uptime. If outages do occur, they will be addressed immediately through access to

our dedicated critical support escalation resources, with a six-hour call-to-repair commitment from our

mission-critical call center.

Additional Option:

10 Proactive Select credits per year per array

- HP Proactive Select is a flexible way to purchase services

to fit your particular environment or situation. Working with an HP Account Support Manager, you select a

package of services in the form of services credits that include proactive services spanning many

technologies and processes, such as on-site firmware upgrades, health checks, assessments, and

education. You tailor the service delivery to improve time to production, optimize performance, or build in

QuickSpecs

HP 3PAR StoreServ 7000 Storage

Service and Support, HP Care Pack, and Warranty Information

DA - 14433 North America — Version 6 — February 19, 2013

Page 5

continuous improvements.

Standard Care

- maintains

high level of uptime, along

with expert help to cut the

cost and complexity of

implementation and

support

HP Proactive Care 24x7

- for a higher return on your storage investment, Proactive Care delivers hardware

and software support services designed specifically for your technology; rapid access to Advanced

Solution Center Specialists plus, Firmware/Software management and best practice advice. Customers can

optimize the return on their IT investment and realize the advantage of running their business critical

applications on virtualized infrastructure. Plus, HP Proactive Select 20 credits per year, select from an

extensive menu of consultancy and technical services, such as onsite firmware upgrades, health checks,

assessments, and education.

Additional Option:

HP Proactive Care Personalized Support

- The HP Proactive Care Personalized Support option allows for

an increased personalization of the Proactive Care support experience through the assignment of an

Account Service Manager (ASM) who provides IT best practice advice to help address IT issues and projects.

The ASM will develop an annual support plan, provide four days of operational and technical advice, and

conduct semi-annual support reviews to ensure the Proactive Care service deliverables address the

customer's priorities. This option is only available for Proactive Care customers and may be purchased

once per environment.

HP Personalized Support Additional Day

- Customers who require more time than is provided by the

Personalized Support option can elect to purchase additional days through the Personalized Support

Additional Day option. The time may be used to provide extra support reviews and/or more operational &

technical advice.

Basic Care

- Minimum

recommended support

HP Proactive Care 24x7 -

for a higher return on your storage investment, Proactive Care delivers hardware

and software support services designed specifically for your technology; rapid access to Advanced

Solution Center Specialists plus, Firmware/Software management and best practice advice. Customers can

optimize the return on their IT investment and realize the advantage of running their business critical

applications on virtualized infrastructure. Plus, 10 credits per year, select from an extensive menu of

consultancy and technical services, such as onsite firmware upgrades, health checks, assessments, and

education.

Additional Option:

HP Proactive Care Personalized Support -

The HP Proactive Care Personalized Support option allows for

an increased personalization of the Proactive Care support experience through the assignment of an

Account Service Manager (ASM) who provides IT best practice advice to help address IT issues and projects.

The ASM will develop an annual support plan, provide four days of operational and technical advice, and

conduct semi-annual support reviews to ensure the Proactive Care service deliverables address the

customer's IT priorities. This option is only available for Proactive Care customers and may be purchased

once per environment.

HP Personalized Support Additional Day

- Customers who require more time than is provided by the

Personalized Support option can elect to purchase additional days through the Personalized Support

Additional Day option. The time may be used to provide extra support reviews and/or more operational &

technical advice.

Implementation

Installation:

Whichever level of care you select, consider our Installation and Startup Services for a smooth

implementation.

QuickSpecs

HP 3PAR StoreServ 7000 Storage

Service and Support, HP Care Pack, and Warranty Information

DA - 14433 North America — Version 6 — February 19, 2013

Page 6

HP 3PAR StoreServ 7000 Storage Installation and Startup Service

- For smooth startup, this service

provides you with deployment of your HP 3PAR StoreServ 7000 Storage, ensuring proper installation into

your storage environment and helping you realize the maximum benefit from your storage investment.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-2568ENW.pdf

Related Services

HP Storage Data Migration Service-

HP expertise and tools help you migrate data across your data center

or around the globe. Take the burden of migration off your shoulders and put it in the capable hands of

expert HP storage migration consultants. Our proven approach helps orchestrate the complete data

migration and consolidation process while maintaining consistent data availability during the transfer

process.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-0774ENW.pdf

HP Enhanced Implementation Service for SANs -

HP delivers complete design and implementation

services for Fibre Channel, FCoE, FCIP, SAS, and iSCSI storage area network (SAN) connectivity

components. This service includes three levels of support based on the type of environment, ranging from

simple to more complex. A trained service specialist guides the implementation of the storage switches in

the SAN environment according to HP quality standards.

http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-8527EN.pdf

HP Data Replication Solution Service for 3PAR Virtual Copy-

HP Data Replication Solution Service for HP

3PAR Virtual Copy Software helps create, manage and configure local replication data mirroring and

snapshot capabilities of 3PAR storage systems. This service enables snapshots and mirroring to facilitate

data restores, minimize downtime for backups, perform application testing, support data mining use with

decision-support tools.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-0217ENW.pdf

HP Data Replication Solution Service for 3PAR Remote Copy

- HP Data Replication Solution Service for

3PAR Remote Copy Software configures real-time data mirroring between local and remote 3PAR storage

systems to safeguard critical business information. Provides scalable deployment of HP Remote Copy

Software real-time data mirroring between a local and a remote 3PAR storage system.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-8627ENW.pdf

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA0-9431ENW.pdf

HP 3PAR 7000 Replication Software Suite Installation and Startup Service

- Provides implementation

of the HP 3PAR 7000 Replication Software Suite product. Replication Suite includes 3PAR Remote Copy,

3PAR Virtual Copy, and 3PAR Peer Persistence. The service is designed to help get HP 3PAR 7000

Replication Software Suite up and running quickly and to provide a demonstration of the product's key

features using sample or test data only.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-2570ENW.pdf

HP 3PAR Peer Persistence Software Installation and Startup Service

- Provides implementation of the

HP 3PAR Peer Persistence Software product. The service is designed to help get HP 3PAR Peer Persistence

up and running quickly and to provide a demonstration of the product's key features using sample or test

data only.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-2772ENW.pdf

HP 3PAR Adaptive Optimization Policy Implementation Service -

HP 3PAR Adaptive Optimization Policy

Implementation Service provides analysis, recommendations, and implementation of HP 3PAR Adaptive

Optimization policies to enable storage tiering using data collected from the HP 3PAR Storage system over

time. With the assistance of a designated IT storage administrator, a service specialist works with the

QuickSpecs

HP 3PAR StoreServ 7000 Storage

Service and Support, HP Care Pack, and Warranty Information

DA - 14433 North America — Version 6 — February 19, 2013

Page 7

customer to implement Adaptive Optimization policies on the HP 3PAR Storage system to help deliver

service level optimization for virtual and cloud data centers while reducing cost, increasing agility and

minimizing risk.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENW.pdf

HP Storage Virtual Volume Design and Implementation Service

- When redeploying an HP StorageWorks

Disk Array, the HP Virtual Volume Design and Implementation Service provides the necessary activities

required to design and implement a new virtual volume configuration.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3764ENN.pdf

HP Thin Volume Conversion Service

- Provides evaluation and execution of conversion from standard to

thin provisioned virtual volumes for HP 3PAR Storage. A service specialist advises the customer on HP thin

provisioning best practices, provides evaluation of potential disk capacity savings if target virtual volumes

are converted, and plans and implements thin conversion processing. The service leverages 3PAR thin

provisioning capabilities to help optimize storage capacity, reduce cost, increase agility and maintain

performance.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENW.pdf

HP Performance Analysis Service for HP Disk Arrays

- The service provides data collection, detailed I/O

analysis and enhancement recommendations for HP 3PAR StoreServ Storage disk arrays, HP EVA P6000

Storage disk arrays and HP XP P9000 Storage disk arrays. HP Performance Analysis Service for HP Storage

Disk Arrays provides a single engagement concerning the performance of a single HP 3PAR StoreServ

Storage disk array, HP EVA P6000 Storage disk array and HP XP P9000 Storage disk array

http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6668EN.pdf

HP 3PAR Health Check Service-

The HP 3PAR Health Check service is delivered as a single engagement,

providing data collection, analysis, report creation, and a briefing session concerning the performance of a

single HP 3PAR StoreServ Storage System. This health check service is best for HP 3PAR StoreServ Storage

Systems that have been installed and are in normal production mode. It can also be used to establish a

baseline for future reference to improve the effective use of your storage system.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-3225ENW.pdf

HP 3PAR Storage Assessment Service-

The HP 3PAR Assessment Service is delivered remotely for a

single HP 3PAR StoreServ Storage System and does not include performance analysis, testing, or

modeling. The service requires that remote monitoring be enabled on the HP 3PAR StoreServ Storage

System being assessed. The assessment findings are compared to HP best practices and a summary

report is provided that includes recommendations intended to improve availability and ongoing

management of your HP 3PAR StoreServ Storage System.

http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA3-2346ENW.pdf

HP 3PAR Storage Rebalance Service

- The HP 3PAR Rebalance Service helps balance data across your HP

3PAR StoreServ Storage to take advantage of the capabilities of the array architecture. The service

provides analysis, planning, and implementation of data movement and/or physical movement of drive

magazines within the array.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-0280ENW.pdf

HP EVA to 3PAR Acceleration Service

- The HP EVA to 3PAR Acceleration Service can help guide you or

even execute data migration activities on your behalf that can not only optimize, but provide OPEX and

CAPEX savings as a result of your journey from EVA to 3PAR. This service provides customers with an

alternative DIY ("do-it-yourself") data migration option with guidance from TS Storage migration

specialists. With the help of migration experts, this service allows customers to execute an EVA to 3PAR

data migration at their own pace and lowered cost.

QuickSpecs

HP 3PAR StoreServ 7000 Storage

Service and Support, HP Care Pack, and Warranty Information

DA - 14433 North America — Version 6 — February 19, 2013

Page 8

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-4234ENW.pdf

HP 3PAR Adaptive Optimization I&S

-For Adaptive Optimization, design, creation, and implementation of

Adaptive Optimization policies; policy design, creation, and implementation can be accommodated using

the HP 3PAR Adaptive Optimization Policy Implementation Service, which is available via HP Proactive

Select.

The Service has further been described in the HP 3PAR 7000 Software Installation and Startup Service

Datasheet:

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-2569ENW.pdf

HP 3PAR Dynamic Optimization I&S -

For Dynamic Optimization, implementation by HP of tasks required

to balance the HP 3PAR storage system; the service provides the Customer with a product overview,

advice, and suggested strategies for use of Dynamic Optimization, and extended/ongoing analysis and/or

implementation of Dynamic Optimization strategies can be accommodated at additional cost

The Service has further been described in the HP 3PAR 7000 Software Installation and Startup Service

Datasheet:

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-2569ENW.pdf

For more information

www.hp.com/services/storage

To learn more on HP Storage Services, please contact your HP sales representative or HP Authorized

Channel Partner

HP Care Pack Services are sold by HP and HP Authorized Service Partners

Services for customers purchasing from HP or an enterprise reseller are quoted using HP order

configuration tools.

Customers purchasing from a commercial reseller can find HP Care Pack Services at:

www.hp.com/go/lookuptool

QuickSpecs

HP 3PAR StoreServ 7000 Storage

Service and Support, HP Care Pack, and Warranty Information

DA - 14433 North America — Version 6 — February 19, 2013

Page 9

Step 1 - Choose a Base configuration

HP 3PAR StoreServ 7000 configurations start with the selection of the Base. The Base includes controller nodes, bays for small form

factor drives, and PCIe slots for host adapter cards. SAN Kits are also considered base configurations. The SAN Kits simplify ordering

for SAN configurations with the array and extend the switch warranty to 3-years by including switches with an HP 3PAR StoreServ

7000 Storage Base.

HP 3PAR StoreServ 7000 Base Configurations

HP 3PAR StoreServ 7200 2-node Storage Base

QR482A

HP 3PAR StoreServ 7400 2-node Storage Base

QR483A

HP 3PAR StoreServ 7400 4-node Storage Base

QR485A

HP 3PAR StoreServ 7200 8Gb H-Series Base System SAN Kit

QR488A

HP 3PAR StoreServ 7200 16Gb Virtualization Base System SAN Kit

QR489A

HP 3PAR StoreServ 7400 16Gb Virtualization Base System SAN Kit

QR510A

A minimum of one (1) configuration base must be ordered.

The HP 3PAR StoreServ 7200 base configuration includes (2) controller nodes, 24

GB of cache, (24) small form factor drive bays, (4) built-in 8 Gb/sec FC ports, (4)

8Gb shortwave FC SFP, (2) PCIe adapter slots for host adapter cards - one slot

per node, (4) 2m SAS cables, (1) mounting rail kit, and power cords.

The HP 3PAR StoreServ 7400 2-node base configuration includes (2) controller

nodes, 32 GB of cache, (24) small form factor drive bays, (4) built-in 8 Gb/sec FC

ports, (4) 8Gb shortwave FC SFP, (2) PCIe adapter slots for host adapter cards -

one slot per node, (4) 2m SAS cables, (2) 1U rack filler panels to reserve 2U of

rack space above the 2-node Storage Base for a future upgrade to a 4-node

configuration, (1) mounting rail kit, and power cords.

The HP 3PAR StoreServ 7400 4-node base configuration includes (4) controller

nodes, 64 GB of cache, (48) small form factor drive bays, (8) built-in 8 Gb/sec FC

ports, (8) 8Gb shortwave FC SFP, (4) PCIe adapter slots for host adapter cards -

one slot per node, (8) 2m SAS cables, (4) node link cables, (2) mounting rail kits,

and power cords.

The HP 3PAR StoreServ 7200 8Gb H-Series Base System SAN Kit includes the

QR482A HP 3PAR StoreServ 7200 2-node Storage Base, (2) BK780B HP SN6000

Stackable 8 Gb/s 8 Active Port Single Power Supply FC Switches and (4) TA821A

4-port FC Switch Upgrade LTUs. Each switch comes with serial cable, mounting

rail kits, power cords, and SAN Connection Manager software entitlement. Also

included is a 3 year warranty for the switches.

NOTE:

Requires optical transceivers and switch cabling which must be supplied

separately.

The HP 3PAR StoreServ 7200 16Gb Virtualization Base System SAN Kit includes

the HP 3PAR StoreServ 7200 2-node Storage Base and (2) QK753B HP SN6000B

16 Gb/s 48-port/24-port Active FC Switches - dual power. Each switch comes

with rack mount kit (including rails, mounting hardware, and plenum), RJ-45

serial cable with adaptor for RJ-45 to DB9, power cords, and SAN Network

Advisor DVD. Also included is a 3 year warranty for the switches.

NOTE:

Requires optical transceivers and switch cabling which must be supplied

separately.

The HP 3PAR StoreServ 7400 16Gb Virtualization Base System SAN Kit includes

QuickSpecs

HP 3PAR StoreServ 7000 Storage

Configuration

DA - 14433 North America — Version 6 — February 19, 2013

Page 10

Autres manuels pour 3PAR StoreServ 7000

Table des matières

Autres manuels HP Serveur de stockage réseau

HP ProLiant ML350 G5 Manuel utilisateur

HP StorageWorks P4000 Series Guide de référence rapide

HP NetStorage 6000 Manuel utilisateur

HP J3278B - SureStore CD-ROM Server/Tower 7 NAS... Mode d’emploi

HP AK373A - StorageWorks All-in-One Storage System 1200r 5.4TB SAS Model NAS... Comment utiliser

HP StorageWorks NAS e7000 v2 Manuel utilisateur

HP 201723-B21 - HP StorageWorks Modular SAN Array 1000 Hard... Manuel utilisateur

HP J3278B - SureStore CD-ROM Server/Tower 7 NAS... Manuel utilisateur

HP DL100 - ProLiant G2 320GB File Print... Mode d’emploi

HP ProLiant DL38 Manuel utilisateur

HP AK373A - StorageWorks All-in-One Storage System 1200r 5.4TB SAS Model NAS... Comment utiliser

HP ProLiant ML110 G1 Manuel utilisateur

HP J3278B - SureStore CD-ROM Server/Tower 7 NAS... Manuel utilisateur

HP ProLiant DL100 G2 DPSS Mode d’emploi

HP J3278B - SureStore CD-ROM Server/Tower 7 NAS... Manuel utilisateur

HP AK373A - StorageWorks All-in-One Storage System 1200r 5.4TB SAS Model NAS... Comment utiliser

HP J3278B - SureStore CD-ROM Server/Tower 7 NAS... Instructions d'installation et d'utilisation

HP ML350 - ProLiant - G2 Manuel utilisateur

HP J3278B - SureStore CD-ROM Server/Tower 7 NAS... Manuel utilisateur

HP StorageWorks XP10000 - Disk Array Manuel utilisateur

HP NAS 4000s Mode d’emploi

HP ProLiant DL100 G2 DPSS Manuel utilisateur

HP X300 Data Vault Guide d'installation

HP ProLiant ML310 Generation 5p Manuel utilisateur

Manuels Serveur de stockage réseau populaires d'autres marques

Seagate

Seagate U10 ST320423A Manuel utilisateur

Synology

Synology RackStation RS816 Manuel

D-Link

D-Link ShareCenter Pro DNS-1200-05 Manuel utilisateur

Avid Technology

Avid Technology VideoRAID ST Guide de sécurité

Western Digital

Western Digital My Cloud Home Duo Manuel utilisateur

PrimeArray

PrimeArray 4xxx Manuel utilisateur

Buffalo

Buffalo TeraStation WSS WSH5010N6 Manuel utilisateur

Planex

Planex MZK-NAS01SG Manuel utilisateur

Intel

Intel SS4000-E - Entry Storage System NAS Server Manuel utilisateur

Synology

Synology RS2212+ Manuel utilisateur

Allnet

Allnet ALL69000 Manuel utilisateur

Adaptec

Adaptec 5325301580 Manuel utilisateur

Motorola

Motorola EXORdisk II Manuel utilisateur

Sony

Sony XDAAI1PK Manuel utilisateur

Cisco

Cisco Linksys NAS200 Instructions d'utilisation d'origine

Sans Digital

Sans Digital MR4UT6G Manuel utilisateur

AIC

AIC FB128-LX Manuel utilisateur

Dell

Dell PowerVault NX3500 Instructions d'utilisation
