HP ProBook 455 Instructions d'utilisation

WLAN antennas (select models only)

11.

Power light

Webcam light

12.

Digital media slot

Webcam

13.

Audio-out (headphone) jacks

Internal microphone

14.

Audio-in (microphone) jack

Internal microphone

15.

USB port

Right TouchPad button

16.

HDMI port

Left TouchPad button

17.

RJ-45 (Ethernet)

Touchpad with scroll zone

18.

External monitor port

TouchPad on/off button

19.

Power button

10.

Hard drive light

QuickSpecs

HP 455 Notebook PC

Overview

DA - 14301 Worldwide — Version 6 — August 15, 2013

Page 1

Optical drive

AC adaptor light

Optical drive light

Power connector

Optical drive eject button

Security cable slot

USB ports

Battery bay

Hard drive bay compartment

Vents

Wireless compartment, and memory module compartment,

keyboard screw, and optical drive bay.

Battery release latch

QuickSpecs

HP 455 Notebook PC

Overview

DA - 14301 Worldwide — Version 6 — August 15, 2013

Page 2

At A Glance

Windows 8 versions, Windows 7 versions, SUSE Linux, FreeDOS 2.0*

VISION Technology with AMD Mobility Radeon™ HD

Durable, sophisticated design with smooth surfaced charcoal color.

Full-sized keyboard with action keys enabling functions directly

HDMI port for connecting to high-resolution displays

Integrated HD or VGA webcam, integrated microphone

Integrated 802.11 b/g/n wireless LAN module**

Bluetooth™ 2.1 or Bluetooth™ 4.0 + High Speed (HS)**

14.0" diagonal LED-backlit HD anti-glare display

* Operating system options vary by country.

** Select models only (BT4.0 HS supports under Windows 7 OS only; BT2.1 supports under Linux)

QuickSpecs

HP 455 Notebook PC

Overview

DA - 14301 Worldwide — Version 6 — August 15, 2013

Page 3

OPERATING SYSTEM

Preinstalled

Windows 8 64*

Windows 8 Pro 64*

Windows 7 Professional 64**

Windows 7 Home Premium 64**

Windows 7 Home Basic 64**

Windows 7 Starter 32**

SUSE Linux Enterprise Desktop 11

FreeDOS 2.0

* Not all features are available in all editions of Windows 8. Systems may require upgraded and/or separately purchased

hardware, drivers and/or software to take full advantage of Windows 8 functionality. See

http://www.microsoft.com

for details.

** Not all features are available in all editions of Windows 7. This system may require upgraded and/or separately purchased

hardware to take full advantage of Windows 7 functionality.

See

http://www.microsoft.com/windows/windows-7/

for details.

PROCESSOR

AMD

AMD Dual Core E2-1800 APU with Radeon™ HD 7340 Graphics (1.7 GHz, 1 MB L2 cache, 2 cores)*

AMD Dual Core E1-1200 APU with Radeon™ HD 7310 Graphics (1.4 GHz, 1 MB L2 cache, 2 cores)*

AMD Dual Core E300 APU with Radeon™ HD 6310 Graphics (1.3 GHz, 1 MB L2 cache, 2 cores)

* This system requires a separately purchased 64-bit operating system and 64-bit software products to take advantage of the 64-

bit processing capabilities of AMD technology. Multi-core processing with AMD technology is designed to improve performance of

this system. Given the wide range of SW applications available, performance will vary. AMD's numbering is not a measurement of

clock speed.

CHIPSET

AMD A68M

GRAPHICS

AMD Radeon™ HD 6310 (AMD Dual Core E300 APU)

AMD Radeon™ HD 7310M Graphics (AMD Dual Core E1-1200 APU)

AMD Radeon™ HD 7340M Graphics (AMD Dual Core E2-1800 APU)

QuickSpecs

HP 455 Notebook PC

Features

DA - 14301 Worldwide — Version 6 — August 15, 2013

Page 4

DISPLAY

Internal

14.0" diagonal LED-backlit HD anti-glare (1366 x 768)

External

Up to 32-bit per pixel color depth

VGA

Port supports resolutions up to 2014 x 1536 external resolution @ 60 Hz

HDMI

1.3 port supports up to 1080p, 1920 x1080 at 60Hz and 1920 x1200 @ 60Hz DVI Mode

NOTE:

Resolutions are dependent upon monitor capability, and resolution and color depth settings.

STORAGE AND DRIVES

Primary Storage Bay

Hard Drives

320/500/640/750 GB 5400 rpm SMART SATA II

DriveGuard

The hard drive is mounted directly to the notebook frame, reducing the transmission of shock to the hard drive.

NOTE:

For hard drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 16 GB (for Windows 7) and 36 GB (for Windows

8) of system disk is reserved for the system recovery software.

OPTICAL DRIVES

Fixed Optical Drive

DVD+/-RW SuperMulti DL Drive

Weight saver

MEMORY

Standard

DDR3 SDRAM (1600 MHz)* or DDR3/3L SDRAM (1600 MHz)

Two SODIMM slots supporting single channel 2048 MB and 4096 MB SODIMMs

Standard memory up to 6144 MB

Maximum

Upgradeable to 8192 MB with optional 2048/4096 MB SODIMMs in slots 1 and 2

NOTE:

Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to

ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. With Windows Starter 32-

bit operating systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may

not be available due to system resource requirements.

QuickSpecs

HP 455 Notebook PC

Features

DA - 14301 Worldwide — Version 6 — August 15, 2013

Page 5

NETWORKING/COMMUNICATIONS

Wireless

Integrated 802.11b/g/n 1x1 wireless LAN module

Ralink 802.11 b/g/n (1x1) wireless LAN module (Windows 8 only)

Ralink 802.11 b/g/n (1x1) + Bluetooth™ 4.0 combo (Windows 8 only)

Bluetooth™ 2.1 or Bluetooth™ 4.0 + High Speed (HS)

Communications

Realtek Ethernet (10/100/1000 NIC)

* Bluetooth 4.0 is supported in Windows 7 OS only, BT2.1 is supported in Linux

NOTE:

In countries where 802.11n is not allowed, this capability is not enabled.

AUDIO/MULTIMEDIA

Audio

Integrated Altec Lansing Stereo Speakers

Integrated microphone

High Definition Audio support

Webcam

Integrated VGA webcam

Integrated HD Webcam

Supports videoconferencing and still image capture

Improved quality for video streaming and still image capture (1280x720 resolution)

Up to 30 frames/sec

Fixed focus lens

KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS

Keyboard

The 100% compatible keyboard features a, industry standard, full-pitch key layout with features such as the isolated inverted-T

cursor control keys, editing keys, both left and right control and alt keys, and 12 function keys. International key layouts are

available. Other features include hotkeys for instant access to, brightness, etc. 19-mm x 19-mm key pitch (center-to-center

spacing), 2.2-mm stroke, comfort-dished keycaps, and bright key legends for improved visibility in low light conditions.

Pointing Devices

Touchpad with 2-piece pick button with left and right click functions

Buttons and Function Keys

Multi-touch gestures supported

On/off button

QuickSpecs

HP 455 Notebook PC

Features

DA - 14301 Worldwide — Version 6 — August 15, 2013

Page 6

SOFTWARE AND SECURITY

Preinstalled Software with Windows Operating System

HP Recovery Manager (Windows 7 only)

HP Support Assistant*

HP Wireless Hotspot* (Windows 8 only, web download)

HP Connection Manager* (Windows 7 only)

Cyberlink Power DVD **

Cyberlink YouCam DE***

Symantec Norton™ Internet Security 2012 (60-day trial)

Getting Started with Win8 (Windows 8 only)

Additional Software

Buy Office

CompuTrace® Anti-Theft Absolute® Software* (must be purchased separately)

Security

Security Lock slot (lock must be purchased separately)

NOTE:

The Computrace agent is shipped turned off, and must be activated by customers when they purchase a subscription.

Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside

the U.S.

For more information on HP security solutions refer to:

http://www.hp.com/go/security

Custom Integration Services provides tailor-made, turnkey solutions for Business Ready PCs.

* Not available in all regions.

** Available on select models and not available in all regions.

*** Available on select models.

POWER

Power Supply

External 65W AC adapter

Primary Battery

HP 6-cell (47 WHr) Li-Ion battery

Battery life up to 6 hours

System Standby Time

Up to 1 week

*Battery life will vary depending on the product model, configuration, loaded applications, features, use, wireless functionality

and power management settings. The maximum capacity of the battery will naturally decrease with time and usage. See

MobileMark07 battery benchmark

http://www.bapco.com/products/mobilemark2007

for additional details.

NOTE:

Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. The HP Fast Charge is only for 6

cell/47 WHr battery pack.

Power Conservation

Hibernation

Standby

ACPI compliance

* Only Windows 7 and Linux will feature power conservation.

QuickSpecs

HP 455 Notebook PC

Features

DA - 14301 Worldwide — Version 6 — August 15, 2013

Page 7

ENVIRONMENTAL

US Energy Star

IT ECO Declaration

EPEAT – Silver where HP registers commercial notebook products. See

http://www.epeat.net

for registration status in your

country.

NOTE:

This product has received or is in the process of being certified to the following approvals and may be labeled with one or

more of these marks.

WEIGHTS & DIMENSIONS

Weight

Starting at 4.85 lb (2.0 kg)

Dimensions

(w x d x h)

13.46 x 9.09 x 1.40 in

34.2 x 23.1 x 3.55 cm

NOTE:

Height varies depending upon where on the notebook the measurement is made. Weight varies by configuration and

components. Weight includes 6-cell battery, hard drive,

1 GB memory, and optical drive. Weight varies by configuration and components.

PORTS/SLOTS

Ports

VGA – One

HDMI – One

Stereo microphone in – One

Stereo headpone/line out – One

Power Connector – One

RJ-45 (Ethernet) – One

USB 2.0 – Three

Digital Media Slots

Supports SD (Secure Digital), and MultiMediaCard

Supports mini versions with adapter

SERVICE AND SUPPORT

HP Services offers limited 1 year warranty options depending on country;

1 year limited warranty on primary battery. On-site service and warranty upgrades are also available. HP Care Pack Services

extend service contracts beyond the standard warranties. To choose the right level of service for your HP product, use the HP Care

Pack Services Lookup Tool at:

http://www.hp.com/go/lookuptool

. Additional HP Care Pack Services information by product is

available at:

http://www.hp.com/hps/carepack

NOTE:

Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.

http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp

QuickSpecs

HP 455 Notebook PC

Features

DA - 14301 Worldwide — Version 6 — August 15, 2013

Page 8

SYSTEM UNIT

Dimensions

(w x d x h)

13.46 x 9.09 x 1.40 in

34.2 x 23.1 x 3.55 cm

Weight

Starting at 4.85 lb (2.0 kg)

NOTE:

Height varies depending upon where on the notebook the measurement is made. Weight varies by configuration and

components. Weight includes 6-cell battery, hard drive, 1 GB memory, and optical drive. Weight varies by configuration and

components.

Stand-Alone Power

Requirements

(AC Power)

Nominal Operating

Voltage

18.5/19.5V

Average Operating Power

Integrated graphics: 12.55 W

AMD E-series platform

Max Operating Power

< 65 W

Temperature

Operating

32° to 95° F (0° to 35° C) (not writing optical)

41° to 95° F (5° to 35° C) (writing optical)

Non-operating

-4° to 140° F (-20° to 60° C)

Relative Humidity

Operating

10% to 90%, non-condensing

Non-operating

5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature

Shock

Operating

40 G, 2 ms, half-sine

Non-operating

200 G, 2 ms, half-sine

Random Vibration

Operating

0.75 grms

Non-operating

1.50 grms

Altitude

(unpressurized)

Operating

-50 to 10,000 ft (-15.24 to 3,048 m)

Non-operating

-50 to 40,000 ft (-15.24 to 12,192 m)

Planned Industry

Standard

Certifications

Yes

CSA

Yes

FCC Compliance

Yes

ENERGY STAR®

Select models

EPEAT

Registered Silver in United States

ICES

Yes

Australia /

NZ A-Tick Compliance

Yes

CCC

Yes

Japan VCCI Compliance

Yes

BSMI

Yes

CE Marking Compliance

Yes

BNCI or BELUS

Yes

CIT

Yes

GOST

Yes

QuickSpecs

HP 455 Notebook PC

Technical Specifications

DA - 14301 Worldwide — Version 6 — August 15, 2013

Page 9

Saudi Arabian Compliance

(ICCP)

Yes

SABS

Yes

UKRSERTCOMPUTER

Yes

* Configurations of the HP 455 that are ENERGY STAR qualified are identified as HP 455 ENERGY STAR on HP websites and on

www.energystar.gov

** EPEAT registration varies by country. See

www.epeat.net

for registration status by country.

EPEAT status listed above applies to U.S.

For accessibility information on HP products, please visit:

http://www.hp.com/accessibility

DISPLAY

14.0" LED HD

BrightView

(1366 x 768)

Active Area

(w x h)

12.16 x 6.85 in (30.9 x17.4 cm)

Diagonal Size

14.0 in (35.6cm)

Surface Treatment

BrightView (glossy)

Contrast Ratio

500:1 (min)

Refresh Rate

60 Hz

Brightness

200 nit (typical)

Pixel Resolution

Pitch

0.252 mm

Format

1366 x 768

Configuration

RGB Stripe

Backlight

LED

PPI

112 ppi

Viewing Angle

±40° Horizontal, +10°/-30° Vertical (minimum)

40/40/30/10 (Left/Right/Down/Up) (minimum)

STORAGE AND DRIVES

Internal Storage

QuickSpecs

HP 455 Notebook PC

Technical Specifications

DA - 14301 Worldwide — Version 6 — August 15, 2013

Page 10

Autres manuels pour ProBook 455

Table des matières

Autres manuels HP Ordinateur portable

HP Pavilion DV1010 Instructions de montage

HP ProBook 6570b Manuel utilisateur

HP Dv7-2040us - Pavilion Entertainment - Core 2 Quad... Manuel utilisateur

HP EliteBook 850 G6 Manuel

HP Mini 210-1040 Manuel utilisateur

HP Compaq Presario Manuel

HP 2530p - EliteBook - Core 2 Duo 2.13 GHz Manuel utilisateur

HP ENVY x2 Detachable PC Instructions de montage

HP Pavilion dv2-1200 - Entertainment Notebook... Manuel utilisateur

HP Omen X Instructions d'installation

HP Compaq Presario Manuel utilisateur

HP Compaq Presario Manuel

HP OMEN Manuel

HP OmniBook VT6200 Manuel technique

HP ENVY 17 Manuel

HP Pavilion HDX9200 Manuel utilisateur

HP ProBook 6545b - Notebook PC Instructions d'installation

HP Dv2210us - Pavilion Entertainment - Turion 64 X2 1.6... Manuel utilisateur

HP 6720t - mobile thin client Manuel utilisateur

HP 2730p - EliteBook - Core 2 Duo 1.86 GHz Manuel utilisateur

HP Pavilion g6-2200 Manuel

HP ENVY x360 Manuel

HP Pavilion 11 x360 PC Manuel

HP 17-ab200na Manuel utilisateur

Manuels Ordinateur portable populaires d'autres marques

Velocity

Velocity NoteMagix M10 Manuel utilisateur

Dell

Dell Alienware 17 R2 Manuel utilisateur

Toshiba

Toshiba A105-S2236 Manuel utilisateur

Winbook

Winbook LM Manuel utilisateur

Dell

Dell Inspiron 1464 Manuel utilisateur

Dell

Dell Inspiron 15R 5537 Manuel utilisateur

Dell

Dell Latitude ATG D620 Manuel utilisateur

Sony

Sony VAIO PCG-FX270 Manuel utilisateur

Dell

Dell Latitude 7310 Manuel utilisateur

Dell

Dell Precision GU806 Manuel utilisateur

Sony

Sony VAIO PCG-R505JLK Manuel utilisateur

Lenovo

Lenovo THINKPAD X32 Manuel utilisateur

Toshiba

Toshiba mini NB300 Manuel utilisateur

Lenovo

Lenovo ThinkPad X201 Tablet Manuel

Lenovo

Lenovo THINKPAD X31 Manuel

Sony

Sony VGN-T240P VAIO Manuel utilisateur

Compaq

Compaq Armada E700 Series Manuel utilisateur

Fujitsu

Fujitsu Lifebook A6230 Manuel utilisateur
