HP IPAQ rz1700 series Instructions d'utilisation

Charge/Notification LED indicator

5-Way Navigation Touch Pad

QVGA Colour Display

Messaging Button

Calendar Button

Today Screen Button

Contacts Button

Stylus

QuickSpecs

HP iPAQ rz1700 series Pocket PC

Overview

DA - 11969 Canada — Version 6 — August 23, 2005

Page 1

3.5 mm Stereo Headphone Jack

Microphone

SD Slot (SDIO)

Infrared Beam

Stylus

Power Button

At A Glance

Dazzling Transflective QVGA TFT colour display, Landscape and Portrait modes

Microsoft® Windows Mobile™ 2003 Second Edition software for Pocket PC

Stay productive with Pocket versions of familiar applications like Microsoft® Outlook®, Word and Excel

Integrated SD expansion slot (SDIO)

Rechargeable Lithium-lon battery

View Photos with HP Image Zone software

Entertainment while on the go with ability to view photos, play games, and music

QuickSpecs

HP iPAQ rz1700 series Pocket PC

Overview

DA - 11969 Canada — Version 6 — August 23, 2005

Page 2

Models

HP iPAQ rz1710 Pocket PC – 32 MB Flash ROM/32 MB SDRAM

FA289A#ABA – Canada – English

FA289A#ABC – French (Keyboard layout is AZERTY)

Processor

203 MHz Samsung S3C2410 processor

Memory

User Available Memory

Up to 25 MB user available memory including 10 MB iPAQ File Store on model

HP iPAQ rz1710

Display

Type

Transflective type QVGA TFT

Modes

Portrait and Landscape

Number of Colours

64K colour (65,536 colours) 16-bit

Touch Screen

Yes

Resolution

(W x H)

240 x 320

Viewable Image Size

3.5 in (89 mm)

Hardware Buttons/

Reset Buttons

One power button, one reset button, four shortcut software programmable application buttons, one 5-

way navigation button

Stylus

One

Audio

Microphone, speaker, one 3.5 mm headphone jack, MP3 stereo through audio jack

Indicators

Charge/Notification LED

Charge and Notify indicators

Blinking amber LED – charging

Solid amber LED – full charge

Blinking green – event notification

Notification

Sound and message on the display

Cradle Interfaces

Connector

1 – 22 pin

QuickSpecs

HP iPAQ rz1700 series Pocket PC

Standard Features

DA - 11969 Canada — Version 6 — August 23, 2005

Page 3

Other interfaces

IrDA

– Supported (Standard IR)

USB

– Supported via sync cable

Serial

– Supported

Sync/Data Connector

– Full RS 232 support

SD Slot

Support 4-bit SDIO and 4-bit SD/Multimedia Card type memory standard

Power Supply

Battery

Internal Rechargeable 1000 mAh Lithium-lon battery.

Estimated usage time of fully charged battery is up to 7 hours. Charging time

up to 4 hours.

Optional extended Lithium-lon batteries are available for purchase at

http://www.hp.ca/go/ipaqaccessories

or from any authorized HP reseller.

AC Power

AC Input: 100~240 Vac, 50/60 Hz, AC Input current: 0.2 Aac max

Output Voltage: 5Vdc (typical), Output Current: 2A (typical)

NOTE:

Battery run time varies based on the usage pattern of an individual user and the configuration of

the handheld. Use of backlight will significantly decrease battery run time.

AC Adapter

Dimensions

(H x W xD)

3 x 1.9 x 1.8 in (76 x 48 x 44 mm - including prongs), (may vary by model)

Cord Length

(approx.)

6 ft (1.83 m)

Power Supply Ratings

Voltage Range

100 to 240 V Switching

Input Current

0.3 Aac

Input Frequency

50 to 60 Hz

Output Voltage

5 VDC

Output Current

2 Amp

System Unit

Dimensions

(H x W x D)

4.48 x 2.75 x .53 in (114 x 70 x 13.4 mm)

Weight

4.23 oz (120 g)

Operating Temperature

32° to 104° F (0° to 40° C)

Storage Temperature

-4° to 140° F (-20° to 60° C)

Operating Humidity

90% RH

Regulatory Marks

Electrical

FCC Class B, Canadian ICES-003 Class B, CE

Safety

UL or CSA, NRTL C-UL, NOM

Design Features

4 programmable application launch buttons – defaults Calendar, Contacts, Messaging and Today buttons.

Push and hold application buttons to launch additional programs: Windows Media Player, HP Image Zone,

Record; Landscape/Portrait toggle

QuickSpecs

HP iPAQ rz1700 series Pocket PC

Standard Features

DA - 11969 Canada — Version 6 — August 23, 2005

Page 4

Operating System

Microsoft® Windows Mobile™ 2003 Second Edition software for Pocket PC – Professional for model HP

iPAQ rz1710

Pocket versions of Microsoft software are included (Outlook, Word, Excel and Internet Explorer for Pocket

PC)

Operating System

Applications

Contacts, Tasks, Voice Recorder, Notes, Pocket Word (with Spellchecker), Pocket Excel, Pocket Internet

Explorer, Pocket MSN, Windows Media Player 9 (MP3, audio and video streaming), Calculator, Solitaire,

Jawbreaker, Messaging (with Spell Checker for email), File Explorer, Infrared Beaming, VPN support (PPTP)

Clock, Align Screen, Memory, Volume control. Premium version also includes Microsoft Reader (eBooks),

and VPN support (L2TP IPSEC).

Additional Software and

links

Outlook 2002, Microsoft ActiveSync 3.7.1 (Desktop device synchronization), Links to Microsoft websites

for additional downloadable applications (some programs may require purchase of additional desktop

software to utilize Pocket PC versions)

In-the box

HP iPAQ rz1710 Pocket PC unit, AC adapter, USB sync cable, Stylus, "How do I" guide, HP iPAQ Pocket PC

Companion CD and Documentation kit

Service and Support

1-year parts and labour in all regions. 90 days technical support for software in most regions. Additional

offers may vary by region.

HP Exclusive Applications

iPAQ File Store: non-volatile storage in flash ROM

Experience HP iPAQ: flash demo to show key features in HP iPAQ

HP Image Zone for Pocket PC: application to view and create slide shows

HP Task Switch: switch between programs or close open programs

HP Profiles: set up setting profiles for meeting, outdoor, and other situations

Utilities: Self Test, Audio, Power Status, Key Lock

QuickSpecs

HP iPAQ rz1700 series Pocket PC

Standard Features

DA - 11969 Canada — Version 6 — August 23, 2005

Page 5

Companion CD from HP

APPLICATIONS

Full Versions

Trial Versions

Adobe Reader

Active Sync

Outlook 2002 Desktop

Windows Media Player

Desktop

Illium Dockware

Audible Player

List Pro

WorldMate

Clear View Player

Pocket Slides

CD LINKS

Full Versions

Trial Versions

Handango

Flash Player for Pocket PC

Microsoft Games

AvantGo Trial

Software Choice (EMEA)

Sprite Backup

Vindigo

Additional Documentation

Safety and Comfort Guide on PDF, and User Guide on PDF, How Do I Guide on PDF

NOTE:

Programs could vary based on model. Some programs are accessed through CD links to download

web sites.

QuickSpecs

HP iPAQ rz1700 series Pocket PC

Standard Features

DA - 11969 Canada — Version 6 — August 23, 2005

Page 6

NOTE:

Optional accessories are available at additional costs, see

http://www.hp.ca/go/ipaqaccessories

your authorized HP reseller for details.

Memory Card

128 MB SD Memory Card

FA135A#AC3

256 MB SD Memory Card

FA136A#AC3

512 MB SD Memory Card

FA184A#AC3

1 GB SD Memory Card

FA283A#AC3

Power

Auto Adapter

FA125A#AC3

Charger Adapter

FA133A#AC3

AC Adapters

FA130A#ABA

Synchronization

USB Desktop Cradle/Charger

FA260A#AC3

AutoSync Cable (USB and Serial)

FA122A#AC3

Other

Stylus Three-pack

FA261A#AC3

Foldable Keyboard – English only

FA118A#ABA

Thumb Keyboard (available August 2004) – English only

FA302A#AC3

Performance

SDIO Camera (Photosmart Mobile Camera)

FA185A#ABA

Cases

Leather Belt Case

FA160A#AC3

Nylon Slimline Case

FA161A#AC3

Leather Flip Case

FA349A#AC3

HP Care Pack Services

Next Day Exchange, 3 years

U4998E

Pick up and Return, 2 years

U5862E

Pick up and Return, HW Support, CPU Only, 3 years

U5001E

Pick up and Return, HW Support, CPU Only, 1 year

U8308E

NOTE

: For additional information on HP Care Pack Services, please see

http://www.hp.ca/hps/carepack/

QuickSpecs

HP iPAQ rz1700 series Pocket PC

Options

DA - 11969 Canada — Version 6 — August 23, 2005

Page 7

HP iPAQ Pocket PC is a Microsoft® Windows® Powered Pocket PC

For more information on HP iPAQ Pocket PC, visit our website at

http://www.hp.ca/iPAQ

The information in this document is subject to change without notice.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and

services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial

errors or omissions contained herein. Microsoft, Windows, the Windows Logo and ActiveSync are registered trademarks or trademarks

of Microsoft Corporation in the United States and/or other countries. Intel is a registered trademark of Intel Corporation in the U.S.

and/or other countries.

QuickSpecs

HP iPAQ rz1700 series Pocket PC

Options

DA - 11969 Canada — Version 6 — August 23, 2005

Page 8
