HP OmniBook Docking System

User’s Guide

1-2

Notice

This manual and any examples contained herein are provided “as is”and are

subject to change without notice. Hewlett-Packard Company makes no warranty

of any kind with regard to this manual, including, but not limited to, the

implied warranties of merchantability and fitness for a particular purpose.

Hewlett-Packard Co. shall not be liable for any errors or for incidental or

consequential damages in connection with the furnishing, performance, or use of

this manual or the examples herein.

Consumer transactions in Australia and the United Kingdom: The above disclaimers

and limitations shall not apply to Consumer transactions in Australia and the United

Kingdom and shall not affect the statutory rights of Consumers.

adaptation, or translation of this manual is prohibited without prior written

permission of Hewlett-Packard Company, except as allowed under the copyright

laws.

The programs that control this product are copyrighted and all rights are reserved.

Reproduction, adaptation, or translation of those programs without prior written

permission of Hewlett-Packard Co. is also prohibited.

Portions of the programs that control this product may also be copyrighted by

Microsoft Corporation, SystemSoft Corp., and Chips and Technologies, Inc. See the

individual programs for additional copyright notices.

Microsoft, DriveSpace, MS, MS-DOS, and Windows are registered trademarks or

trademarks of Microsoft Corporation in the United States and/or other countries

(U.S. patent numbers 4955066 and 4974159). SystemSoft is a registered trademark

and CardWizard, CardLite, and CardID are trademarks of SystemSoft Corporation.

For warranty and regulatory information, see the Support and Service booklet.

Hewlett-Packard Company

Mobile Computing Division

1000 N.E. Circle Blvd.

Corvallis, OR 97330, U.S.A.

Edition History

Edition 1 .......................................... October 1996

This manual is printed on recycled paper.

1-3

Contents

Using the Docking System ................................. 1-5

Understanding the Basics ................................ 1-8

To set up the docking system ............................ 1-8

To dock the OmniBook ................................ 1-10

To undock the OmniBook .............................. 1-11

To set a docking password.............................. 1-12

To manually undock the OmniBook ....................... 1-13

To attach a security cable .............................. 1-14

To understand docking status lights ....................... 1-15

Making Connections .................................... 1-16

To connect an external keyboard ......................... 1-17

To connect a PS/2 mouse .............................. 1-17

To connect a serial mouse .............................. 1-18

To switch back to the internal pointing device ................ 1-19

To connect an external display .......................... 1-19

To enable the built-in and external displays simultaneously....... 1-20

To connect a parallel device ............................ 1-20

To connect a serial device .............................. 1-21

To connect your audio equipment ........................ 1-21

To connect SCSI devices ............................... 1-22

To install an expansion card ............................ 1-23

To remove a device from the undocked configuration .......... 1-25

Troubleshooting......................................... 1-27

Solving Problems ...................................... 1-29

Specifications and Regulatory Information .................... 1-33

Regulatory Information .................................. 1-35

U.S.A. ............................................ 1-35

Canada ........................................... 1-36

Japan ............................................ 1-36

Europe ........................................... 1-37

1-5

Using the Docking System

1-6

Getting Started

With the OmniBook Docking System, you can significantly increase the capabilities

of your OmniBook. By making one connection—plugging your OmniBook into the

docking system—you can get convenient access to these types of connections:

♦ Printer.

♦ Modem or other serial device.

♦ External SCSI peripherals, such as a CD-ROM drive or disk drive.

♦ Network access cards.

♦ External keyboard and external mouse.

♦ External display.

♦ Audio connections.

♦ Power.

1-7

How to Use This manual

The procedures in this manual differ slightly depending on the operating system

you’ve installed—Windows 95 or Windows for Workgroups. Read each step

carefully to see if it applies to your operating system.

What About Other Operating Systems?

If you’ve installed another operating system on the OmniBook—Windows NT or OS/2 for example—

follow the general procedures under Windows for Workgroups. Instead of exiting Windows (when so

instructed), exit the operating system you are using.

About Your OmniBook Manuals

Your OmniBook provides these additional manuals:

• The online OmniBook User’s Guide introduces the OmniBook and shows you

how to operate and maintain your OmniBook. It also contains troubleshooting

information.

• The Introducing Microsoft Windows 95 manual, shipped with your OmniBook,

contains information about using the standard features of Windows 95.

Using the Docking System

Understanding the Basics

1-8

Understanding the Basics

This section shows you how to get your docking system and OmniBook up and

running quickly, including how to

♦ Set up the docking system.

♦ Dock and undock the OmniBook.

♦ Manually undock.

♦ Attach a security cable to the docking system.

♦ Set a docking password.

♦ Understand the docking status lights.

To set up the docking system

1. Optional: To adjust the typing angle of keyboard, you can connect the tilt legs

to the docking system. Gently press inward on the tilt feet and snap on at one of

the three height settings shown below.

Squeeze and slide to one

of three height settings.

Using the Docking System

Understanding the Basics

1-9

2. Plug the power cord into the ac adapter, then into a grounded ac outlet. Plug

ac adapter connector into the port on the back of the docking system.

CAUTION

Use only an HP F1140A ac adapter (the type shipped with the Docking

System)

—

do not use an ac adapter from the OmniBook or another product.

Using an improper adapter could damage the OmniBook and will make your

warranty invalid.

3. Place the cable cover on the docking system.

Using the Docking System

Understanding the Basics

1-10

To dock the OmniBook

1. Collapse the OmniBook tilt feet. The OmniBook will not align correctly with the

docking port if the tilt feet are extended.

2. Unplug the OmniBook’s ac adapter and cables, then close the cable door.

3. Open the OmniBook’s docking port door and slide the door under the port.

Tilt foot
