HP d3000 Manuel utilisateur
d3000
Digital Camera
Appareil photonumérique
Digitalkamera
macchina fotografica digitale
Cámara digital
Ψηφιακή Κάμερα
Câmera Digital
Quick Start Guide
Guide de démarrage rapide
Schnelleinstieg
Guida veloce
Guía rápida
Γρήγορος Οδηγός Εκκίνησης
Guia de Início Rápido
For the full version of the d3000 product user manual go to : www.hp.com/support
Per la versione completa del manuale d’uso del modello d3000 consultare il sito : www.hp.com/support
Pour obtenir une notice d'utlisation complete du d3000 allez sur le lien suivant : www.hp.com/support
Das vollständige Handbuch der d3000 Kameraist unter : www.hp.com/support zu finden
Para descargarse la versión completa del manual de instrucciones del modelo d3000,
puede acceder al siguiente enlace: www.hp.com/support
Για την πλήρη έκδοση του εγχειριδίου χρήσης του προϊόντος d3000 πηγαίνετε στο : www.hp.com/support
Para a versão completa do manual do usuário do produto d3000 ir para: www.hp.com/support
CONTENT
PORTUGUÊS
Ελληνικά
d3000 Quick Start Guide
ENGLISH
Camera Views
Front View Back View
1. Self-timer LED/
AF Assist Lamp
2. Microphones
3. Lens
4. LCD display
5. LED indicator
6. Video Record button
7. Playback button
8. OK button/4-way
navigation control
9. Function/Delete
button
10. Menu button
Top View
11. Flash enclosure
12. Zoom toggle
13. Shutter button
14. ON/OFF
(Power button)
15. Mode dial
Bottom View
16. Battery/Memory
card compartment
17. Tripod screw hole
Right View
18. Strap ring
Left View
19. Strap ring
20. Speaker
21. USB AV/Out
Step 1. Inserting the Battery
1. Unlock and open the battery/memory card compartment (feature no. 16 on page 2) on the bottom
of the camera as shown below. To unlock the door slide the release slider (step 1) towards the back
of the camera. At the same time slide the door (step 2) to the right.
2. Insert four AA batteries into the cavities with
the alternating battery orientation exactly as
shown in the figure to the right. Note:
inside each battery cavity there is a small
decal that depicts proper battery orientation.
3. Close the battery/memory card compartment
door and slide it back to its closed position.
The slider will click into its locked position.
Step 2. Inserting an SD/SDHC/SDXC Memory Card
1. Unlock and open the Battery/memory card
compartment at the bottom of the camera as
described in the previous section.
2. Insert an SD, SDHC, or SDXC card into the
memory card slot with the contact pins facing
the back side of the camera as shown.
3. Push the memory card into the memory slot
until it clicks into place.
4. Close and lock the Battery/memory card
compartment door as described in the
previous section.
NOTE: To remove the memory card: Gently push the card until it pops out. Pull the card out and lock the battery cover.
Step 3. Setting the Language, Date, and Time
1. Turn on the power by pressing Power button. (feature no. 14 on page 1)
2. Use 4-way navigation controller (feature no. 8 on page 1) to move and change the settings.
3. Press OK button to finish. (also feature no. 8 on page 1)
Step 4. Taking Pictures
1. Power on the camera by pressing the Power button.
2. Compose your image in the LCD display monitor.
3. Use the Zoom toggle (feature no. 12 on page 1) to
zoom in, or out, to frame your subject.
4. Press the Shutter button (feature no. 13 on page 1)
halfway down to start adjustment to the auto focus and
the exposure. Once the framing bracket turns green,
press the Shutter button down fully to take the Photo.
When using the flash strobe, note that the flash door does not pop-up automatically.
Please open the Flash manually. Lift using the tabs on the Flash cover. (feature no. 11
on page 1)
Step 5. Recording Video
1. Power on the Camera.
2. Press the Video Record button to start recording
(feature no. 6 on page 1). The green LED (feature no. 5 on
page 1) will blink as an indication that you are recording.
3. Use the Zoom toggle (feature no. 12 on page 1) to zoom in
and zoom out as desired.
4. To pause recording momentarily, press the located
on the top of the navigation controller (feature no. 8 on page
1).
5. To resume recording, press again.
6. To stop recording altogether, press the again.
Step 6. Viewing photos, videos and audio
clips
1. Press the Playback button on the camera. (feature
no. 7 on page 1)
2. The LCD screen displays an image. Press the left and right
quadrants of the navigation controller (feature no. 8 on page
1; the macro and flash symbols) to view the previous or next
image, or video.
3. Press the OK button (also feature no. 8 on page 1) to play a
video clip.
Step 7. Using the Setup Menu
1. Power on the Camera.
2. Press the Menu button (feature no. 10 on page 1)
to open the Record/Playback Menu.
3. Press the left and right quadrants of the navigation
controller (feature no. 8 on page 1; the macro and flash
symbols) to change the menu tab to Setup menu.
4. Press upper and lower quadrants of the navigation controller
to move up and down through the menu selections. Use
the right quadrant (flash symbol) to expand menus that
have sub features.
5. Press the OK button (also feature no. 8 on page 1) to save
and apply settings.
Guide de démarrage
FRANÇAIS
Vues de l’appareil photo
Vue de face Vue de dos
1. Diode du déclencheur
à retardement/
lumière de soutien AF
2. Microphone
3. Objectif
4. Écran LCD
5. Témoin diode
6. Bouton Vidéo
7. Bouton Lecture
8. Bouton OK/contrôle
de navigation à
quadruple
commande
9. Bouton
Fonction/Supprimer
10. Bouton Menu
Vue supérieure
11. Flash
12. Levier de zoom
13. Déclencheur
14. ON/OFF (Bouton
d’alimentation)
15. Molette de mode
Vue inférieure
16. Compartiment de la
batterie/carte
mémoire
17. Trou de vis du
trépied
Vue droite
18. Anneau de la
courroie
Vue gauche
19. Anneau de la
courroie
20. Haut-parleur
21. USB Sortie/AV
Étape 1. Insérer la batterie
1. Déverrouillez et ouvrez le compartiment de la batterie/carte mémoire dessous l’appareil photo.
2. Insérez la batterie dans le compartiment avec
la borne dirigée vers l’intérieur de l’appareil
photo.
3. Fermez et verrouillez le compartiment de la
batterie/carte mémoire.
Étape 2. Insérer une carte mémoire SD/SDHC/SDXC
1. Déverrouillez et ouvrez le compartiment de la
batterie/carte mémoire dessous l’appareil
photo.
2. Insérez la carte SD/SDHC/SDXC dans
l’emplacement de la carte mémoire avec la
partie métallique dirigée vers l’arrière de
l’appareil photo.
3. Poussez la carte SD/SDHC/SDXC dans
l’emplacement de la carte mémoire jusqu’à ce
qu’elle s’enclenche en place.
4. Fermez et verrouillez le compartiment de la
batterie/carte mémoire.
REMARQUE : Pour retirer la carte SD/SDHC/SDXC : Poussez doucement la carte jusqu’à ce qu’elle s’éjecte. Retirez la carte et verrouillez le
couvercle de la batterie.
