Product Overview and Features

After reading this chapter, you will be able to describe the features specific

to the Vectra VL 5/xx series 4 Desktop PC and the Vectra VL 5/xx MT

series 4 Mini-Tower PC.

1 Product Overview and Features

Vectra Products Comparison

The following table compares the new HP Vectra VL 5/xx series 4 Desktop

and Mini-Tower PC with the HP Vectra VL 5/xx series 3 PC.

Component HP Vectra VL 5/xx series 3 PC

(D339xA and D34xxA series)

HP Vectra VL 5/xx series 4

Desktop PC

(D366xA, D367xA, D368xA and

D369xA series)

HP Vectra VL 5/xx MT series 4

Mini-Tower PC

(D380xA series)

Microprocessor 5/75: PentiumTM 75 MHz

5/90: PentiumTM 90 MHz

5/100: PentiumTM 100 MHz

5/120: PentiumTM 120 MHz

5/90: PentiumTM 90 MHz

5/100: PentiumTM 100 MHz

5/120: PentiumTM 120 MHz

5/133: PentiumTM 133 MHz

Math coprocessor On the microprocessor

Main Memory

Standard

Maximum

Sockets

32-bit (70 ns)

8 MB (a pair of 4 MB modules)

or 16 MB (a pair of 8 MB modules)

192 MB

Six

32-bit EDO (60 ns)

8 MB (a pair of 4 MB modules)

or 16 MB (a pair of 8 MB modules)

128 MB

Six

Level 1 cache memory 8 KB for code, plus 8 KB for data (both caches on the microprocessor)

Level 2 cache memory 256 KB asynchronous cache

(Integrated on system board)

256 KB synchronous pipeline burst cache (Socketed on system board)

Video Controller Integrated 64-bit Ultra VGA on PCI

bus (Cirrus Logic 5434)

Integrated 64-bit Ultra VGA on PCI bus (S3 Trio 765 64V+) or

Matrox MGA Millennium video card on PCI bus

Video Memory

Upgrade

1 MB (expandable to 2 MB)

One module (use D3404A)

1 MB (expandable to 2 MB) for S3 Trio 765 64V+, or

2 MB (expandable to 8 MB) for Matrox models.

Two 512K chips (use D3500A) for S3 Trio 765 64V+, or

2 MB upgrade card (use D3557A) for Matrox models.

Disk Controller Fast IDE controller on PCI local bus

(Integrated on system board)

Master IDE controller on PCI local bus

(Integrated in system board chipset)

Hard Disks Fast IDE 420 MB (D2918A)

Fast IDE 840 MB (D2919A)

Fast IDE 540 MB

Fast IDE 1 GB

Fast IDE 1 GB (D2919A)

1 Product Overview and Features

Vectra Products Comparison

1. 5V supply only, no 3.3V supply.

Mass storage shelves One front access 3.5-inch shelf

One front access 5.25-inch shelf

Two internal 3.5-inch shelves for hard

disks

One front access 3.5-inch shelf

One front access 5.25-inch shelf

One front access 5.25-inch/3.5-inch

(1-inch high) shelf

One internal 3.5-inch shelf

One front access 3.5-inch shelf

Three front access 5.25-inch shelves

Two internal 5.25-inch shelves

Integrated ports 1 parallel port (bi-directional, ECP/EPP capable)

2 serial ports (UART 16650)

Keyboard connector

Mouse connector

Video connector Integrated on system board Integrated on system board for S3 Trio 765 64V+, or

on video adapter card for Matrox models.

Accessory slots One 32-bit PCI

One 32-bit PCI / full-length 16-bit ISA

Combination

One full-length 16-bit ISA

One half-length 16-bit ISA

One 32-bit PCI1

One 32-bit PCI1/ full-length 16-bit ISA

Combination

One full-length 16-bit ISA

One half-length 16-bit ISA

Two 32-bit PCI1

One 32-bit PCI1/ half-length 16-bit

ISA Combination

Three full-length 16-bit ISA

Network Interface None

Power supply 100 W

(full range 90-264 VAC)

100 W

(full range 90-264 VAC)

200 W

(100-127 VAC and 176-264 VAC)

Manual switching between 115V and

230V

Security Power-on password

Mechanical cover lock

Disk and port disabling.

Power-on password

Mechanical cover lock

Disk and port disabling

Power-on keyboard lock

Space bar power-on enabling/

disabling

Boot on CD-ROM, FDD & HDD

enabling/disabling

Write on FDD enabling/disabling

Security bracket.

Power-on password

Mechanical cover lock

Disk and port disabling

Power-on keyboard lock

Space bar power-on enabling/

disabling

Boot on CD-ROM, FDD & HDD

enabling/disabling

Write on FDD enabling/disabling.

Passwords User Password and Administrator Password

Component HP Vectra VL 5/xx series 3 PC

(D339xA and D34xxA series)

HP Vectra VL 5/xx series 4

Desktop PC

(D366xA, D367xA, D368xA and

D369xA series)

HP Vectra VL 5/xx MT series 4

Mini-Tower PC

(D380xA series)

1 Product Overview and Features

Vectra Products Comparison

1. Some models have a dual pre-loading configuration of Windows 95 and Windows 3.11 on the hard disk. Certain VL 5/xx series 4 models will have

OS/2 3.0 pre-loaded.

2. HP’s new style BIOS co-developed with Phoenix Technologies.

Component HP Vectra VL 5/xx series 3 PC

(D339xA and D34xxA series)

HP Vectra VL 5/xx series 4

Desktop PC

(D366xA, D367xA, D368xA and

D369xA series)

HP Vectra VL 5/xx MT series 4

Mini-Tower PC

(D380xA series)

Pre-loaded software MS-DOS 6.22, Windows for Workgroups13.11, Dashboard, HP User Tools, Drivers

BIOS ROM HP BIOS, Flash EEPROM HP/Phoenix2BIOS, Flash EEPROM

System ROM localization English only

Vectra VL 5/xx series 4 Desktop

Vectra VL 5/xx MT series 4 Mini-Tower

1 Product Overview and Features

Product Features

Overview The HP Vectra VL 5/xx series 4 is a PENTIUM (P54) processor,

ISA/PCI-based PC. It comes in two different packages, a mid-profile

desktop box and a mini-tower box.

❒The mid-profile desktop box has three front-access drive shelves and one

rear shelf. It is easily opened using two front tabs.

❒The mini-tower has four front-access drive shelves, two rear shelves, and

a high-capacity power supply. It is easily opened using two side latches.

The system consists of a system board and a backplane.

❒The desktop’s backplane has two ISA slots, one PCI slot, and one

combination ISA/PCI slot for accessory boards.

❒The mini-tower’s backplane has three ISA slots, two PCI slots, and one

combination ISA/PCI slot for accessory boards.

The system boards are the same for the desktop and the mini-tower.

New Features •A completely upgradable Pentium-based system board (using

system board switches and voltage regulator module).

• A new keyboard supporting Windows 95 special key functions.

• Vectra Ergonomic Power Solution (VEPS): space bar power-on

(under any operating system), push-button status panel, and

software shutdown from Windows 95.

• A mini-tower available for extra expandability.

• Certain multimedia models feature the high performance Matrox

MGA Millennium PCI video adapter card.

•HP’s new style BIOS.

1 Product Overview and Features

Product Features

System Board The main features of the system board are:

❒A system board that can mount PENTIUM processors (with

accompanying Voltage Regulation Module) at several different clock

speeds (90 MHz, 100 MHz, 120 MHz and 133 MHz, as well as 150 MHz and

166 MHz when they become available).

❒A new type of main memory module called EDO (Extended Data Output)

for faster memory access times (60 ns).

❒256KB of synchronous pipeline burst level 2 cache.

❒A 64-bit host bus for PENTIUM processor, cache and main memory.

❒A 32-bit Peripheral Component Interconnection (PCI) local bus for

accessing the video controller and IDE controller.

❒An Industry-Standard Architecture (ISA) bus for ISA-compatible

controllers (for devices such as flexible disk drives, serial ports,

parallel port, and audio card in multimedia models).

❒A security system that provides protection against unauthorized use of

the PC.

❒A flash BIOS updating facility.

1 Product Overview and Features

Product Features

Desktop Models The following desktop models will be available:

The 133 MHz models will be available at product launch. The 90 MHz,

100 MHz and 120 MHz models are planned for release one month later.

1. OS/2 bundle, planned for release early 1996.

2. Multimedia models include 4× CD-ROM and Creative Labs Vibra 16S audio card.

Standard

Desktop Models

Hard Disk

Drive (MB)

Product

number

RAM

(MB)

Sync

Cache

(KB)

Video

RAM

(MB)

Video

controller

VL 5/90 series 4

540

1000

D3660A

D3661A

D3662A

D3662S1

D3664A

256

S3 Trio 765

64V+

VL 5/100 series 4

540

1000

D3670A

D3671A

D3672A

256

S3 Trio 765

64V+

VL 5/120 series 4

540

1000

D3680A

D3681A

D3682A

256

S3 Trio 765

64V+

VL 5/133 series 4

1000

D3690A

D3692A

D3692S1

256

S3 Trio 765

64V+

Multimedia

Desktop Models2

VL 5/90 series 4 1000 D3663A 16 256 1 S3 Trio 765

64V+

VL 5/133 series 4 1000 D3693A 16 256 2 Matrox MGA

Millennium card

1 Product Overview and Features

Product Features

Mini-tower Models The following mini-tower models will be available at product launch:

Microprocessor The Pentium microprocessors used in the HP Vectra VL 5/xx series 4 use

internal clock multiplication, similar to that used by the 486 DX2 processor.

The microprocessor’s internal clock is a multiple of the system clock. The

Pentium 90 MHz and 100 MHz processor multiply the 60 MHz and 66 MHz

system clock by a factor of 1.5. The Pentium 120 MHz and 133 MHz

processors double the 60 MHz and 66 MHz system clocks. To set the

appropriate switches for each processor speed, refer to the Pentium

Processor table in the section System Board Switches in chapter 2.

The system board of the HP Vectra VL 5/xx series 4 has a Voltage Regulator

Module (VRM) which supplies the Pentium processor with the correct

voltage. The VRM allows the processor to be upgraded without replacing the

system board.

The 90 MHz, 100 MHz and 133 MHz processors need a passive shortening

block VRM (providing VCC voltage), while the 120 MHz processor needs an

active VRM (providing VRE voltage). The appropriate VRM is provided with

each processor upgrade kit.

Standard

Mini-Tower Models

Hard Disk

Drive (MB)

Product

number

RAM

(MB)

Sync

Cache

(KB)

Video

RAM

(MB)

Video

controller

VL 5/90 MT series 4 0

1000

D3801A

D3802A

256

S3 Trio 765

64V+

VL 5/100 MT series 4 0

1000

D3803A

D3804A

256

S3 Trio 765

64V+

VL 5/120 MT series 4 0 D3805A 8 256 1 S3 Trio 765

64V+

VL 5/133 MT series 4 0 D3807A 8 256 1 S3 Trio 765

64V+

Multimedia

Mini-Tower Models

VL 5/90 MT series 4 1000 D3806A 16 256 2 Matrox MGA

Millennium card

VL 5/133 MT series 4 1000 D3808A 16 256 2

Autres manuels pour Vectra VL5 4

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HP Ordinateur de bureau

HP Pavilion x360 14 Series Manuel

HP A1210n - Pavilion - 512 MB RAM Manuel utilisateur

HP Pavilion a700 - Desktop PC Instructions d'installation

HP Pro 3080 - Microtower PC Instructions d'installation

HP Intel EtherExpress PRO 10+ ISA Manuel utilisateur

HP 260 G3 Desktop Mini Business Instructions de montage

HP Pavilion 743 Manuel utilisateur

HP Kayak XW U3-W3 Mode d'emploi

HP EX470 - MediaSmart Server - 512 MB RAM Comment utiliser

HP Presario SR1200 - Desktop PC Manuel utilisateur

HP Compaq dx2700 Microtower and Small Form... Guide d'installation

HP HP 3588A Manuel utilisateur

HP Z420 Series Manuel utilisateur

HP Vectra XA 6/xxx Comment utiliser

HP ProOne 490 G3 Instructions d'installation

HP 8100 - Elite Convertible Minitower PC Manuel d'utilisation et d'entretien

HP Compaq 8200 Elite Series Instructions d'utilisation

HP TouchSmart ENVY 23-d055 Manuel utilisateur

HP Pavilion a210 Manuel utilisateur

HP 205 G3 AiO Manuel

HP 200 G1 ST Manuel

HP Pavilion p7-1200 Manuel d'utilisation et d'entretien

HP ProOne 600 Manuel d'utilisation et d'entretien

HP Pavilion t700 - Desktop PC Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur

Everex

Everex eXplora Manuel utilisateur

Lenovo

Lenovo ThinkCentre M75e Manuel utilisateur

Dell

Dell Alienware Area-51 R4 Manuel utilisateur
