Medium-Profile

Desktop Vectras HP Vectra VA 6/xxx PC Series 14-1

14

14

HP Vectra VA 6/xxx PC Series

Models and Accessories

1. For Windows NT 3.51 WS, the operating system is supplied on CD-ROM. For Windows NT

4.0 WS and Windows 95, the operating system is preloaded.

Product

Number

Flexible

Drive A:

Hard

Drive C:

Video

Controller

Std.

RAM

Multi-

media

Network OS1

Vectra VA 6/xxx PC

HP Vectra VA 6/180 PC (CPL: 08/96 )

D4201A 1.44 MB None Integrated

Cirrus 5446

(1 MB

video

memory

fitted,

upgradable

to 2 MB)

16 MB None None None

D4202N 1.2 GB

IDE

8 ✕IDE

CD-ROM

(D4381A)

NT

3.51

WS

D4202W Win 95

D4211N 1.6 GB

IDE

NT 4.0

WS

D4211W Win 95

D4212N 10 BT NT 4.0

WS

D4203N 2.5 GB

IDE

None NT

3.51

WS

D4213N NT 4.0

WS

HP Vectra VA 6/200 PC (CPL: 08/96 )

D4204N 1.44 MB 1.2 GB

IDE

Integrated

Cirrus 5446

on system

board,

(maximum

2 MB video

memory

already

fitted)

32 MB 8 ✕IDE

CD-ROM

(D4381A)

None NT

3.51

WS

D4204S OS/2

D4204W Win 95

D4214N 1.6 GB

IDE

NT 4.0

WS

D4214W 2.5 GB

IDE

Win 95

D4205N NT

3.51

WS

D4215N NT 4.0

WS

D4216N 10 BT

HP Vectra VA 6/xxx PC Series

14-2 HP Vectra VA 6/xxx PC Series Medium-Profile

Desktop Vectras

14

Supported Accessories

8-MB kit (2 ✕4-MB) 32-bit EDO, 60 ns main memory modules D3646B

16-MB kit (2 ✕8-MB) 32-bit EDO, 60 ns main memory modules D3647B

32-MB kit (2 ✕16-MB) 32-bit EDO, 60 ns main memory modules D3648B

64-MB kit (2 ✕32-MB) 32-bit EDO, 60 ns main memory modules D4543A

1 MB, 50 ns video memory upgrade kit D4219A

Documentation

HP Vectra VA User’s Guide Manual Kit D4200A

Input Devices

HP mouse C3751B

HP keyboard for Windows® 95 C4735A

Video Displays

All current HP Displays (see the HP Vectra Accessory Service Handbook)

Mass Storage

1.2-GB IDE hard disk D2785A

Flexible disk 3.5-inch 1.44-MB (1-inch high) D2035B

IDE 8✕CD-ROM drive D4381A

Multimedia sound accessory kit (8✕CD-ROM drive, Plug-and-Play ISA audio

board, headphones)

D4179A

3.5-inch side mounting rails (packs of 5 pairs) D3566A

5.25-inch side mounting rails (packs of 5 pairs) D2880A

HP Vectra VA 6/xxx PC Series

Medium-Profile

Desktop Vectras HP Vectra VA 6/xxx PC Series 14-3

14

System Board, BIOS, and Memory

Main Memory:

16 MB or 32 MB,

depending on model, fitted

as standard.

Install pairs of identical

modules in each bank, up

to a maximum of 192 MB.

System Board Switches Processor:

Zero Insertion Force (ZIF)

socket allows upgrades

using overdrive

processors.

HP Vectra VA 6/xxx PC Series

14-4 HP Vectra VA 6/xxx PC Series Medium-Profile

Desktop Vectras

14

System Board Switches

BIOS History

The latest BIOS, the flasher utility program, and the BIOS history can each be

obtained from the World Wide Web:

http://www.hp.com/go/VectraSupport.

Main Memory

The PC has three banks on the system board for installing main memory; banks

A, B and C. Each bank consists of two sockets. The PC is supplied with 16 or

32 MB of main memory (composed of two memory modules installed in any

bank). The PC uses 60-ns EDO DRAM.

Memory modules must be installed in identical pairs, so that each bank with

memory installed contains two memory modules of the same size and type

(both EDO, or both FPM).

Main memory can be installed up to a maximum of 192 MB.

Switch Function Default

1-5 - Processor frequency, see the table below -

6Open Normal operation Open

Closed Clear the configuration data (in CMOS memory)

7Open Normal operation Open

Closed Clears all passwords

8

Open Disables keyboard power-on

Closed

Closed Enables the PC to be turned on from the space bar on the

keyboard

9Open Normal operation Open

Closed Clears the Product Identification (VA)

10 Open Pentium Pro 3.3 V Open

Closed Pentium Pro 3.5 V

Processor

Frequency

Switch

12345

150 MHz Closed Open Open Open Closed

166 MHz Open Open Open Open Closed

180 MHz Closed Open Open Closed Open

200 MHz Open Open Open Closed Open

233 MHz Open Open Open Closed Closed

266 MHz Open Open Closed Open Open

HP Vectra VA 6/xxx PC Series

Medium-Profile

Desktop Vectras HP Vectra VA 6/xxx PC Series 14-5

14

Video Memory

Vectra 6/180 PCs are supplied with 1 MB of video memory. An additional 1 MB

of video memory (D4219A) can be installed in the video memory sockets (to

make a total of 2 MB).

Replacing the Processor Chip

Ethernet 10 BaseT Network Connections

The Ethernet 10 BaseT network board is installed underneath the internal, hard

disk drive, rear-shelf. It is plugged into the PCI accessory slot that is situated on

the right-hand side of the double-sided backplane board.

The board has an RJ-45 UTP network connector. This emerges through a

dedicated I/O panel at the back of the computer, below the cover lock assembly.

To install a BNC coax connection, a coax adapter (D3979A) is required as

described in the HP Vectra Accessories Service Handbook. The I/O panel has a

hole in it, for this BNC coax adapter accessory, which is covered by a metal plug

when the adapter is not installed.

If any thermal interface material, such as aluminium

foil or silicone, is supplied with the heat-sink or the

processor chip, place it carefully on the top of the

processor before installing the heat-sink.

I/O panel

Coax adapter

Ethernet 10 BaseT network board

Internal network cable

HP Vectra VA 6/xxx PC Series

14-6 HP Vectra VA 6/xxx PC Series Medium-Profile

Desktop Vectras

14

Part Numbers

HP Vectra VA 6/xxx PC Series

Medium-Profile

Desktop Vectras HP Vectra VA 6/xxx PC Series 14-7

14

1. For optional disk drive information, see the Accessory Service Handbook.

2. Where “xx” is the code for your national keyboard (see the Accessory Service Handbook).

Parts List for HP Vectra VA 6/xxx PC

Item Description Repl.

Part Number

Exchange

Part Number

1 Box assembly:

a Cover lock assembly

b Serial number label

c I/O panel blank

d Filler panel 1.75 inch

e Filler panel 3.5 inch

f Bumper foot

5064-0215

5062-5590

5182-0030

45935-00004

5042-1155

5063-7067

02225-00010

—

2 Rear bezel connector label 5042-1828 —

3 VA DT logo 5042-1483 —

4IDE hard disk drive (standard) 1

1.2 GB — D2930-69001

1.6 GB — D4621-69001

2.5 GB — D2784-69001

5 IDE hard disk cable 5182-1862 —

6 Rail kit (1 ×3.5 inch, 1 ×5.25 inch) 5063-7922 —

7 Flexible disk drive D2035-60152 —

8 Flexible disk drive cable 5182-1037 —

9IDE 8✕CD-ROM drive — D4381-69001

10 IDE CD-ROM cable 5182-1856 —

11 Power supply 5063-7943 —

12 System board See PC’s system board parts list

13 Status panel 5063-7956 —

14 Backplane board 5063-9092 —

15 Ethernet 10 BaseT PCI network board 5063-8790 —

Coax network adapter D3979-63001 —

16 Internal network cable 5183-0758 —

17 Mouse C3751-60201 —

Keyboard C4735-601xx2—

HP Vectra VA 6/xxx PC Series

14-8 HP Vectra VA 6/xxx PC Series Medium-Profile

Desktop Vectras

14

1. Electronic file only.

System Board Parts List for HP Vectra VA 6/xxx PC

Description Repl.

Part Number

Exchange

Part Number

System board:

Vectra VA 6/xxx system board — D4201-69002

Processors:

Intel Pentium Pro (P6) 180 MHz 5063-8755 or 5064-1804 —

Intel Pentium Pro (P6) 200 MHz 5063-8756 or 5064-1805 —

Thermal interface material 6040-0939 —

Heatsink and clip 1205-1170 —

Main memory modules:

2 ✕4-MB main memory 60-ns EDO RAM D3646-63001 —

2 ✕8-MB main memory 60-ns EDO RAM D3647-63001 —

2 ✕16-MB main memory 60-ns EDO RAM D3648-63001 —

2 ✕32-MB main memory 60-ns EDO RAM D4543-63001 —

1 MB Video Memory (D4219A) Upgrade

Kit:

512 KB video memory module 50-ns 1818-6527 —

Batteries:

3 V system board battery (type CR2032) 1420-0356 —

Software for HP Vectra VA 6/xxx PC

NT, OS/2 and Windows 95 drivers:

HP Vectra VA and XA Drivers CD-ROM

5011-3831

DOS and Windows 3.x drivers:

available from HP BBS or WWW

—

Manuals and Documentation for HP Vectra VA 6/xxx PC

User’s Guide (Setting up the PC and Troubleshooting) D4200A

HP Help (Using the PC and Technical information) online 1

Familiarization Guide D4200-90901

Technical Reference Manual: hardware and BIOS No number 1
