HP Pro 3520 Series Instructions d'utilisation

Dual Microphone Array

Stereo Speakers

Webcam

20" Diagonal Widescreen LCD HD Anti-glare Display

Webcam LED

QuickSpecs

HP Pro All-in-One 3520 Business PC

Overview

DA - 14525 Worldwide — Version 2 — March 8, 2013

Page 1

Power Button

6-in-1 Media Card Reader

Optical Disk Drive

USB 3.0 Ports

Hard Disk Drive LED Indicator

Microphone Port

Media Card Reader LED Indicator

Headphone Port

QuickSpecs

HP Pro All-in-One 3520 Business PC

Overview

DA - 14525 Worldwide — Version 2 — March 8, 2013

Page 2

Security Lock Slot

RJ45 Ethernet Port

Adjustable Tilt Stand

USB 2.0 Ports

Power Connector LED Indicator

Audio Line Out

Power Connector

At A Glance

Windows® 8 Professional 64-bit and Windows® 8 64-bit

20" 16:9 WLED 1600x900 NonGlare 250nit

Integrated All-in-One form factor

Adjustable tilt stand

Intel H61 chipset supporting Intel 2nd and 3rd generation processors featuring Intel HD Graphics

Integrated Realtek RTL8171FH-CG Gigabit Ethernet Controller; Optional wireless connectivity

Integrated low-light webcam with dual microphone array

Integrated audio card and stereo speakers

Up to 8GB of DDR3 SDRAM supported

Up to 2 TB hard drive

HP Slim-Tray SuperMulti SATA 8X Drive

6-in-1 Media Card Reader

USB Keyboard and Mouse - wireless option

ENERGY STAR® (for Windows OS only)

EPEAT Silver certification*

BFR/CFR/PVC-free**

QuickSpecs

HP Pro All-in-One 3520 Business PC

Overview

DA - 14525 Worldwide — Version 2 — March 8, 2013

Page 3

Protected by HP Services. Terms and conditions vary by country. Certain restrictions and exclusions apply.

* Where HP registers commercial desktop products. See

http://www.epeat.net

for registration status in your country.

** Meeting the industry definition of 'BFR/PVC-free' per the iNEMI Position Statement on "Low Halogen" Electronics. Plastic parts

incorporated into the chassis generally contain < 1000 ppm (0.1%) of bromine or chlorine. Printed circuit board and substrate

laminates generally contain < 1500 ppm (0.15%) of total bromine and chlorine. Service parts after purchase may not be BFR/PVC-free.

External accessories, including power supplies, power cords, and peripherals may not be BFR/PVC-free.

QuickSpecs

HP Pro All-in-One 3520 Business PC

Overview

DA - 14525 Worldwide — Version 2 — March 8, 2013

Page 4

CHIPSET

Intel® H61

PROCESSOR

Intel® Core™ i3 Processors

Intel® Core™ i3-3240

3.40 GHz base frequency, 3 MB cache, 2 cores, 4 threads

Intel® HD Graphics 2500

Intel® Core™ i3-3225

3.30 GHz base frequency, 3 MB cache, 2 cores, 4 threads

Intel® HD Graphics 4000

Intel® Core™ i3-3220

3.30 GHz base frequency, 3 MB cache, 2 cores, 4 threads

Intel® HD Graphics 2500

Intel® Core™ i3-3210

3.20 GHz base frequency, 3 MB cache, 2 cores, 4 threads

Intel® HD Graphics 2500

Intel® Core™ i3-2130

3.40 GHz base frequency, 3 MB cache, 2 cores, 4 threads

Intel® HD Graphics 2000

Intel® Core™ i3-2120

3.30 GHz base frequency, 3 MB cache, 2 cores, 4 threads

Intel® HD Graphics 2000

Intel® Pentium® Processors

Intel® Pentium® G2130

3.20 GHz base frequency, 3 MB cache, 2 cores, 2 threads

Intel® HD Graphics

Intel® Pentium® G2120

3.10 GHz base frequency, 3 MB cache, 2 cores, 2 threads

Intel® HD Graphics

Intel® Pentium® G2020

2.90 GHz base frequency, 3 MB cache, 2 cores, 2 threads

Intel® HD Graphics

Intel® Pentium® G645

2.90 GHz base frequency, 3 MB cache, 2 cores, 2 threads

Intel® HD Graphics

Intel® Pentium® G640

2.80 GHz base frequency, 3 MB cache, 2 cores, 2 threads

Intel® HD Graphics

Intel® Celeron® Processors

QuickSpecs

HP Pro All-in-One 3520 Business PC

Standard Features

DA - 14525 Worldwide — Version 2 — March 8, 2013

Page 5

Intel® Celeron® G1620

2.70 GHz base frequency, 2 MB cache, 2 cores, 2 threads

Intel® HD Graphics

Intel® Celeron® G1610

2.60 GHz base frequency, 2 MB cache, 2 cores, 2 threads

Intel® HD Graphics

Intel® Celeron® G550

2.60 GHz base frequency, 3 MB cache, 2 cores, 2 threads

Intel® HD Graphics

Intel® Celeron® G540

2.50 GHz base frequency, 3 MB cache, 2 cores, 2 threads

Intel® HD Graphics

NETWORKING/COMMUNICATIONS

Integrated Realtek RTL8171FH-CG Gigabit Ethernet Controller; with Wake on LAN

HP WLAN 802.11 b/g/n 1x1 - WiFi

GRAPHICS

Intel HD Graphics (integrated; varies by processor)

DISPLAY

20" diagonal TN widescreen WLED backlit, Non-Glare LCD

Type

TN (Twisted Nematic) LED Backlit LCD

Viewable image area

(horizontal & vertical)

442.8(H) x 249.075(V) [mm]

Screen opening (H x V)

446.8(H)×253.2(V) [mm]

Resolution

1600 × 900

Aspect ratio

16:9

Contrast ratio (typical)

1000:1

Brightness (typical)

250 nits (cd/m

)

Viewing angle (typical)

85/85/80/80 (L/R/U/D)

Pixel pitch

0.27675(H) x 0.27675(W) [mm]

Backlight lamp life (to half brightness)

30,000 hours minimum

Color support

Over 16 million colors (through FRM)

Color gamut (typical)

72%

Anti-glare

Yes

Default color temperature

Warm (6500K)

NOTE:

All performance specifications represent the typical specifications provided by

HP's component manufacturers; actual performance may vary either higher or lower.

QuickSpecs

HP Pro All-in-One 3520 Business PC

Standard Features

DA - 14525 Worldwide — Version 2 — March 8, 2013

Page 6

AUDIO/MULTIMEDIA

Realtek ALC269 codec

Integrated business class 2.0 speakers (2W x 2)

Stereo headphone jack

Microphone in

Stereo line out

Integrated 1MP, 720p HD low-light Webcam with 2 Microphone Array

STORAGE DRIVES

2TB 7200 RPM SATA 6G Hard Drive

1TB 7200 RPM SATA 6G Hard Drive

500GB 7200 RPM SATA 6G Hard Drive

MEDIA DEVICES

HP 6-in-1 Media Card Reader

Slim 8X SuperMulti DVDRW SATA ODD

KEYBOARDS AND POINTING DEVICES

HP USB Keyboard

HP USB Optical Mouse

HP Wireless Keyboard & Mouse with USB dongle

MEMORY

2GB DDR3-1600 SODIMM (1x2GB) RAM

4GB DDR3-1600 SODIMM (1x4GB) RAM

6GB DDR3-1600 SODIMM (1x4GB+1x2GB) RAM

8GB DDR3-1600 SODIMM (2x4GB) RAM

SECURITY

Security lock slot

Norton Internet Security

QuickSpecs

HP Pro All-in-One 3520 Business PC

Standard Features

DA - 14525 Worldwide — Version 2 — March 8, 2013

Page 7

PORTS

Side I/O Ports

Two (2) USB 3.0 ports

One (1) microphone in

One (1) headphone out

One (1) 6 in 1 Card reader

Rear I/O Ports

Four (4) USB 2.0 ports

One (1) RJ45 network connection

One (1) Stereo audio line out

One (1) DC in power

BAYS

One (1) 3.5" HDD

One (1) 5.25" slimtray ODD

SLOTS

1 PCIe Mini-Card (WLAN)

POWER SUPPLY

External 87% efficient 120watt power adapter: 19V/4.7A

SERVICE AND SUPPORT

On-site Warranty

Note 1:

One-year (1-1-1) limited warranty delivers one year of on-site, next business-day

Note 2:

service for parts

and labor and includes free telephone support

Note 3:

24 x 7. One-year onsite and labor are not available in all countries. To choose

the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at:

http://www.hp.com/go/lookuptool

Additional HP Care Pack Services information by product is available at:

http://www.hp.com/hps/carepack

NOTE 1

: Terms and conditions may vary by country. Certain restrictions and exclusions apply.

NOTE 2

: On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and

is not available in certain countries. Response times are based on commercially reasonable best effort and may vary by country.

NOTE 3

: Technical telephone support applies only to HP-configured Compaq and third-party HP-qualified hardware and software.

Toll-free calling and 24 x 7 support may not be available in some countries.

OPERATING SYSTEMS

Preinstalled

Windows® 8 Professional 64-bit

Windows® 8 64-bit

FreeDOS

For all Preinstalled operating systems HP provides Microsoft WHQL certified (where applicable) drivers on www.hp.com at the time of

product announcement.

QuickSpecs

HP Pro All-in-One 3520 Business PC

Standard Features

DA - 14525 Worldwide — Version 2 — March 8, 2013

Page 8

SOFTWARE

Preinstalled (varies by country)

(Buy Office)

Browser and Toolbars

Internet Explorer 10

Norton Toolbar

Security and Protection

HP Client Security

Productivity

Buy Office

Optical Disc Drive Playback and TV Tuners

CyberLink PowerDVD

Avermedia TV app

Hauppauge TV app

Windows® Live™

Movie Maker

Writer

Photo Gallery

Windows 8 applications

Mail

Calendar

People

SkyDrive

Photos

Messaging

Photos and Videos

CyberLink YouCam

CyberLink Media Suite

CyberLink Power2Go

CyberLink Label Print

A/V Integration

HP Connected Remote

Audio Post Processing

Beats Audio™

QuickSpecs

HP Pro All-in-One 3520 Business PC

Standard Features

DA - 14525 Worldwide — Version 2 — March 8, 2013

Page 9

Games

HP Games by WildTangent

Communication

Broadband connection utility

HP MyRoom

Utilities and Support

HP Online User Guide

HP Recovery Manager

HP Support Assistant

HP MyDisplay

HP ePrint (driver)

QuickSpecs

HP Pro All-in-One 3520 Business PC

Standard Features

DA - 14525 Worldwide — Version 2 — March 8, 2013

Page 10
