HP Compaq t1010 Manuel utilisateur

User’s Guide

Compaq Evo Thin Client T20 and

Compaq T1010 Windows Based

Te r m i n a l s

Document Part Number: 250090-001

June 2001

250090-001 Thin Clients Book.book Page i Tuesday, July 17, 2001 9:52 AM

Compaq, the Compaq logo, Armada, Deskpro Registered in U. S. Patent and

Trademark Office. Evo is a trademark of Compaq Information Technologies

Group, L.P. in the United States and other countries.

ICA is a registered trademark and MetaFrame is a trademark of Citrix

Systems, Inc.

Microsoft, MS-DOS, Windows, Windows CE, Windows NT, and Windows

Terminal Server are trademarks of Microsoft Corporation in the United States

and other countries.

All other product names mentioned herein may be trademarks of their respective

companies.

Compaq shall not be liable for technical or editorial errors or omissions

contained herein. The information in this document is provided “as is” without

warranty of any kind and is subject to change without notice. The warranties for

Compaq products are set forth in the express limited warranty statements

accompanying such products. Nothing herein should be construed as

constituting an additional warranty.

Compaq service tool software, including associated documentation, is the

property of and contains confidential technology of Compaq Computer

Corporation. Service customer is hereby licensed to use the software only for

activities directly relating to the delivery of, and only during the term of, the

applicable services delivered by Compaq or its authorized service provider.

Customer may not modify or reverse engineer, remove, or transfer the software

or make the software or any resultant diagnosis or system management data

available to other parties without Compaq’s or its authorized service provider’s

consent. Upon termination of the services, customer will, at Compaq’s or its

service provider’s option, destroy or return the software and associated

documentation in its possession.

ÄCAUTION: Text set off in this manner indicates that failure to follow

directions could result in damage to equipment or loss of

information.

ÅWARNING: Text set off in this manner indicates that failure to follow

directions could result in bodily harm or loss of life.

Printed in the U.S.A.

User’s Guide

First Edition (June 2001)

Document Part Number: 250090-001
