Configuring Graphics Memory

for HP Business PC dx6050

Abstract.............................................................................................................................................. 2

Introduction......................................................................................................................................... 2

Graphics Memory Allocation ................................................................................................................ 3

Graphics Driver................................................................................................................................... 3

Main Memory Configuration................................................................................................................. 4

Memory Speed.................................................................................................................................... 4

Summary ............................................................................................................................................ 5

Appendix ........................................................................................................................................... 6

Example 1....................................................................................................................................... 6

Example 2....................................................................................................................................... 7

Example 3....................................................................................................................................... 8

Abstract

By incorporating processors, chipset and integrated graphics from AMD and NVIDIA, the HP Business

PC dx6050 delivers proven technologies at an extremely competitive price.

The NVIDIA GeForce4 MX graphics integrated into the HP Business PC dx6050 can deliver a new

level of high-performance graphics to the mainstream PC user. With its powerful nView multi-display

architecture, Lightspeed Memory Architecture II and Accuview Antialiasing engine, the GeForce4 MX

series delivers feature-rich, leading-edge graphics technology, performance and flexibility.

Because the integrated graphics receive an allocation of DDR main memory, graphics performance

can be tied directly to main memory performance. The graphics memory allocation is hidden from the

operating system and cannot be used for other purposes.

The HP Business PC dx6050 supports single-channel and dual-channel main memory configurations.

Performance tests carried out by HP indicate that a dual-channel memory configuration can lead to

significant performance gains.

This white paper outlines main memory configuration issues and the performance testing, and offers

recommendations for optimizing the memory configuration.

Introduction

The HP Business PC dx6050 is an AMD-based business desktop from HP, further broadening the

range of HP business desktops available to the customer.

By incorporating processors, chip set and integrated graphics from industry leaders AMD and

NVIDIA, the HP Business PC dx6050 delivers the latest, proven technologies at an extremely

competitive price. The powerful HP Business PC dx6050 offers excellent value to small to medium

businesses and the public sector.

Key HP Business PC dx6050 features include:

•Up to 2 GB of dual-channel DDR main memory

•The latest NVIDIA nForce2 GT chipset

•Integrated NVIDIA GeForce4 MX graphics with up to 64 MB of DDR memory automatically

allocated to graphics

•Award-winning AMD Athlon 1XP processors

•Dual-monitor support with two standard VGA monitor connections

Simple, yet powerful and reliable, the HP Business PC dx6050 is an excellent investment for today’s

business customers.

1For example, PC World magazine named AMD Athlon the Computer Product of the Year (June 3, 2002) for delivering today’s most compelling

blend of value and performance.

Graphics Memory Allocation

Up to 64MB 2of graphics memory–part of the main memory space–is available to the NVIDIA

GeForce4 MX graphics integrated into the HP Business PC dx6050. Graphics performance depends,

in part, on the characteristics of that memory–allocation, configuration and speed.

The graphics memory allocation is made at boot time. The graphics memory allocation is hidden from

the operating system and cannot be used for other purposes. By default, the Auto feature of the F10

set-up utility selects an appropriate graphics memory allocation based on the amount of main memory

available.

Table 1 shows the amount of memory allocated by the Auto feature.

Table 1. Auto graphics memory allocation

Main memory Graphics memory allocation

Less than 256 MB 16 MB

256 MB 32 MB

384 MB or more 64 MB

Alternatively, the end-user can manually specify an allocation of up to 128 MB.

Note:

If the end-user specifies a graphics memory allocation that exceeds

available main memory, the BIOS defaults to the Auto setting.

HP recommends using the Auto feature.

Graphics Driver

Not only is graphics memory size important, so is location. With the HP graphics driver installed,

graphics memory is allocated at the top of main memory space. If any other driver is used, graphics

memory may be allocated elsewhere, potentially impacting the performance of the entire system. See

the Appendix for more information.

2Up to128 MB if allocated manually

Main Memory Configuration

Graphics performance depends, in part, on memory configuration.

Main memory offers the end-user a number of configuration options, as shown in Table 2.

Table 2. Auto graphics memory allocation

Characteristic Description

Support PC2100, PC2700

DIMM slots Two

Channels Single (one DIMM deployed), dual (two DIMMs deployed)

As shown in Table 2, the system board of the HP Business PC dx6050 includes two DIMM slots, each

delivering an independent, 64-bit-wide memory channel. Configuring these channels appropriately

can impact graphics performance.

•Single channel–With one DIMM slot populated, the memory bus is 64-bits wide. Memory

bandwidth is significantly less than that of the processor’s front-side bus; the processor often wastes

valuable CPU cycles waiting for access to memory.

•Dual channel–With both DIMM slots populated, the memory bus becomes128-bits wide, doubling

memory bandwidth. Memory performance can improve significantly.

Note

Performance tests carried out by HP on a HP Business PC dx6050 show the

following performance gains for dual-channel over single-channel memory:

SYSmark test suites, 5.6%–7.6%; Winstone test suites, 0.4%–2.9%; Mad

Onion 3DMark, as much as 65%.

These test results only serve as a reference to demonstrate differences that

may exist between memory configurations.

The results may vary with system configuration and driver versions.

Memory Speed

Graphics performance depends, in part, on memory speed.

For convenience, the HP Business PC dx6050 supports two DDR memory standards:

•PC2100–266 MHz

•PC2700–333 MHz

However, actual memory speed is constrained 3by the speed of the processor’s front-side bus.

For some Athlon XP processors the front-side bus speed is 266 MHz–no performance advantage is

gained by using faster PC2700 memory with these processors. However, other processors, such as

the XP2800+ and XP3000+, have front-side buses that operate at 333 MHz and can take advantage

of the higher performance of PC2700 memory.

3To maximize system performance, the BIOS sets actual memory speed to not exceed the speed of the front-side bus.

The HP Business PC dx6050 will not support future Athlon XP processors with front-side buses that

operate at a 400 MHz.

HP offers the following recommendations for maximizing performance:

•Dual-channel–While it is possible to configure single-channel main memory, HP recommends the

dual-channel configuration, which doubles memory bandwidth.

•Matching DIMMs–When configuring dual-channel memory, HP strongly recommends using DIMMs

that are matched in size and speed.

•If DIMM speeds are mismatched, memory runs at the speed of the slower DIMM.

•If the DIMMs are different sizes, then part of the memory configuration is dual-channel and part is

single-channel.

Note

See the Appendix for more information on the impact of using mismatched

DIMMs.

•Memory size–Depending on configuration, memory performance can differ between desktops with

the same total memory size. For example, a desktop with two 128MB DIMMs may out-perform a

system with a single 256MB DIMM (because the dual-channel configuration doubles memory

bandwidth). Again, HP recommends the dual-channel configuration.

•Graphics driver–HP recommends using the graphics driver supplied with the HP Business PC

dx6050. Using an alternative driver may impact system performance (as shown in the Appendix).

Summary

The NVIDIA GeForce4 MX graphics integrated into the HP Business PC dx6050 automatically receive

an allocation of up to 64 MB of DDR main memory.

The HP Business PC dx6050 supports single-channel and dual-channel configurations. Performance

tests carried out by HP indicate that a dual-channel memory configuration can achieve significant

performance gains. Some care is required when configuring memory; mismatched DIMMs or the use

of an alternative graphics driver can degrade graphics or system performance.

Simple, yet powerful and reliable, the HP Business PC dx6050 is an excellent investment for today’s

small to medium business customers.

Appendix

This Appendix offers graphical representations of two issues that may impact performance:

•Mismatched (differently-sized) DIMMs are deployed

•An alternative graphics driver is used

Note

In this context, a graphics driver supplied with the system or downloaded

from the HP website is an HP driver; any other graphics driver is an

alternative driver.

Example 1

In this example (shown in Figure 1), the end-user is deploying matched DIMMs. The graphics driver

can be HP-or an alternative.

Figure 1: Dual-channel memory with matched DIMMS.

The BIOS maps the entire memory space to be 128 bits wide.

The BIOS maps the specified graphics memory allocation to the top of the memory space.

Since memory is 128 bits wide, graphics performance is optimal.

Note

If the end-user deploys an add-in AGP graphics card, the integrated

graphics are automatically disabled; the graphics memory allocation

becomes available to other applications.

If the end-user deploys a PCI graphics card, the integrated graphics are

likewise disabled and the graphics memory allocation becomes available

to other applications. However, if desired, the end-user can re-enable the

integrated graphics (using the F10 set-up utility) to create a multi-monitor

configuration using one or both integrated VGA ports and the PCI card’s

VGA port. With integrated graphics re-enabled, the BIOS maps the

specified graphics memory allocation to the top of the memory space.

Example 2

In this example (shown in Figure 2), the end-user is deploying mismatched DIMMs. There is an HP

graphics driver.

Figure 2: Dual-channel memory with mismatched DIMMS, HP graphics driver.

The BIOS maps upper memory to be 64 bits wide, lower memory to be 128 bits wide.

The BIOS maps the specified graphics memory allocation to the top of the memory space (the larger

DIMM).

Since upper memory is 64 bits wide, graphics performance is sub-optimal.

Example 3

In this example (shown in Figure 3), the end-user is deploying mismatched DIMMs. There is an

alternative graphics driver.

Note

An alternative graphics driver may behave differently than an HP driver if

memory is mismatched, as in this example.

Figure 3: Dual-channel memory with mismatched DIMMS, alternative graphics driver.

The BIOS maps upper memory to be 64 bits wide, lower memory to be 128 bits wide.

The BIOS maps the specified graphics memory allocation to the top of the memory space (part of the

larger DIMM). The allocation is 64 bits wide.

An alternative driver may automatically re-map the graphics allocation to the faster 128-bit memory

space to optimize graphics performance. However, the space originally allocated by the BIOS for

integrated graphics is still hidden from the operating system and cannot be used, reducing the amount

of memory available for other applications.

In addition, boot time may increase substantially as data from upper memory are copied to the 128-

bit space.

contained herein is subject to change without notice. The only warranties for

HP products and services are set forth in the express warranty statements

accompanying such products and services. Nothing herein should be construed

as constituting an additional warranty. HP shall not be liable for technical or

editorial errors or omissions contained herein.

371658-001, 06/2004

Autres manuels pour Compaq dx6050 MT

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HP Ordinateur de bureau

HP Compaq Presario Manuel

HP -380467-003 - COMPAQ PRESARIO C300 C500 C700 F500 F700 LAPTOP... Manuel d'utilisation

HP EX470 - MediaSmart Server - 512 MB RAM Comment utiliser

HP m9250f - Pavilion - Elite Comment utiliser

HP ZX2000 Fiche technique

HP Pavilion p7-1200 Manuel d'utilisation et d'entretien

HP Visualize J5000 Manuel utilisateur

HP Pavilion 754 Instructions d'installation

HP Kayak XA Manuel utilisateur

HP Pavilion t490 Instructions d'installation

HP Pavilion t122 Manuel utilisateur

HP ProDesk 400 G3 MT Instructions d'installation

HP Compaq dx2810 Microtower Instructions d'utilisation

HP S5220F - Pavilion Slimline - Desktop PC Manuel utilisateur

HP BV704AA#ABA Manuel utilisateur

HP 2133 Mini-Note PC Instructions de montage

HP Media Center m400 - Desktop PC Manuel d'instructions

HP Vectra XA 6/xxx Manuel de la liste des pièces

HP Vectra XE310 Manuel du produit

HP TouchSmart IQ530 Manuel d'instructions

HP Elite Slice Manuel d'utilisation et d'entretien

HP Compaq Presario Instructions d'installation

HP Pavilion Slimline s7500 - Desktop PC Fiche technique

HP TouchSmart 600-1200 - Desktop PC Fiche technique

Manuels Ordinateur de bureau populaires d'autres marques

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur

Everex

Everex eXplora Manuel utilisateur

Lenovo

Lenovo ThinkCentre M75e Manuel utilisateur

Dell

Dell Alienware Area-51 R4 Manuel utilisateur
