HP MR Gen10 Plus Manuel utilisateur

HPE MR Gen10 Plus Controller User GuideHPE MR Gen10 Plus Controller User Guide

Part Number: 30-9E6EB4E3-002

Published: April 2022

Edition: 2

HPE MR Gen10 Plus Controller User GuideHPE MR Gen10 Plus Controller User Guide

AbstractAbstract

This document includes feature, installation, and configuration information about Hewlett Packard Enterprise MR Gen10 Plus controller and

is for the person who installs, administers, and troubleshoots servers and storage systems. Hewlett Packard Enterprise assumes you are

qualified in the servicing of computer equipment and trained in recognizing hazards in products with hazardous energy levels.

Part Number: 30-9E6EB4E3-002

Published: April 2022

Edition: 2

NoticesNotices

The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and

services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as

constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained

herein.

Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use, or copying. Consistent with FAR

12.211 and 12.212, Commercial Computer Software, Computer Software Documentation, and Technical Data for Commercial Items are

licensed to the U.S. Government under vendor's standard commercial license.

Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard Enterprise has no control over and is

not responsible for information outside the Hewlett Packard Enterprise website.

AcknowledgmentsAcknowledgments

Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other

countries.

MegaRAID is the registered trademark of Broadcom, Inc.

Linux is the registered trademark of Linus Torvalds in the U.S. and other countries.

® ®

™

Table of contentsTable of contents
HPE MR Gen10 Plus Controller
1 200 series
2 400 series
Features
1 Controller supported features
1.1 Operating environments
1.2 RAID technologies
1.3 Transformation
1.4 Drive technology
1.5 Security
1.6 Reliability
1.7 IO performance mode
2 RAID technologies
2.1 Selecting the right RAID type for your IT infrastructure
2.1.1 Selecting RAID for fault tolerance
2.1.2 Selecting RAID for write performance
2.1.3 Selecting RAID for usable capacity
2.1.4 Selecting RAID for the storage solution
2.2 Mixed mode (RAID and JBOD)
2.3 Striping
2.3.1 RAID 0
2.4 Mirroring
2.4.1 RAID 1 and RAID 1+0 (RAID 10)
2.4.2 Read load balancing
2.5 Parity
2.5.1 RAID 5
2.5.2 RAID 50
2.5.3 RAID 6
2.5.4 RAID 60
2.5.5 Parity groups
2.5.6 Initialize
2.5.6.1 Fast initialization
2.5.6.2 Full initialization
2.5.6.3 No initialization
2.5.7 Regenerative writes
2.5.8 Backed-out writes
2.5.9 Full-stripe writes
2.6 Spare drives
2.6.1 Dedicated spare
2.6.2 Global spare
2.7 Drive rebuild
2.8 Foreign configuration import

3 Transformation
3.1 Array transformations
3.1.1 Expand array
3.1.2 Replace Drive
3.2 Logical drive transformations
3.2.1 Transportable controller
3.2.2 Expand Logical Drive
3.2.3 Migrate RAID level
4 Drive technology
4.1 Hot-plug drive LED
4.2 Consistency check
4.3 Dynamic sector repair
4.4 Online drive firmware update
4.5 Predictive drive failure
4.6 Patrol read
5 Security
5.1 Drive erase
5.1.1 Simple
5.1.2 Normal
5.1.3 Thorough
5.2 Sanitize
5.3 Self-Encrypting Drive
6 Reliability
6.1 Cache Error Checking and Correction (ECC)
6.2 Thermal monitoring
7 Performance
7.1 Manage SAS storage link speed
7.2 Manage PCIe Storage Interface
7.3 FastPath
7.4 Cache
7.4.1 Read policy
7.4.2 Write policy
7.4.3 I/O policy
7.4.4 Drive caching
7.4.5 Strip size selection
Installation
1 Installing in a configured server
2 Installing in an unconfigured server
2.1 Installing the operating system with the controller driver
3 Configuring boot controller options
3.1 Selecting a boot mode
3.2 Changing the Legacy BIOS boot order
4 Connecting storage devices
4.1 Connecting internal storage

5 Cable part numbers
Configuration
1 Array and controller configuration
1.1 MR Storage Administrator
1.2 StorCLI
1.3 UEFI System Utilities
1.3.1 Using UEFI System Utilities
2 Configuration in UEFI System Utilities
2.1 Viewing controller information and performing common actions
2.2 Configuration management
2.2.1 Creating a logical drive
2.2.1.1 Selecting drives to include in a logical drive
2.2.2 Creating a profile-based logical drive
2.2.3 Importing secured foreign drive
2.2.4 Viewing array properties
2.2.5 Viewing global spare drives
2.2.6 Making a JBOD
2.2.7 Making an Unconfigured Good drive
2.2.8 Clearing a configuration
2.3 Controller management
2.3.1 Managing the controller
2.3.2 Advanced controller management
2.3.2.1 Clearing controller events
2.3.2.2 Saving controller events
2.3.2.3 Saving a serial log
2.3.2.4 Enabling Drive Security
2.3.2.5 Disabling Drive Security
2.3.2.6 Changing Drive Security settings
2.3.2.7 Changing Drive Security Key Management Mode
2.3.2.8 Managing link speed
2.3.2.9 Managing advanced SW options
2.3.2.10 Scheduling a consistency check
2.3.2.11 Setting factory defaults
2.4 Configuring advanced controller properties
2.4.1 Configuring cache and memory settings
2.4.2 Configuring Patrol Read settings
2.4.3 Configuring Spare settings
2.4.4 Configuring Task Rates
2.5 Logical drive management
2.5.1 Viewing and configuring properties of a logical drive
2.5.2 Deleting a logical drive
2.5.3 Initializing a logical drive
2.5.4 Locating a physical drive associated with a logical drive
2.5.5 Erasing a logical drive

2.6 Drive management
2.6.1 Viewing drive properties
2.6.2 Locating a drive
2.6.3 Initializing a drive
2.6.3.1 Placing a drive offline
2.6.4 Erasing a drive
2.6.5 Making a JBOD
2.6.6 Making an Unconfigured Good drive
2.6.7 Making a bootable drive
2.6.8 Assigning a global spare drive
2.6.9 Unassigning a global spare drive
2.6.10 Sanitizing an Unconfigured Good drive
Maintenance
1 System maintenance tools
1.1 Updating software and firmware
1.2 Diagnostic tools
1.2.1 Troubleshooting resources
Models
1 HPE MR Gen10 Plus Controller
Energy pack options
1 HPE Smart Storage Battery
2 HPE Smart Storage Hybrid Capacitor
3 Energy pack specifications
Specifications
1 Memory and storage capacity conventions
2 RAID conventions
3 Controller specifications
Websites
Support and other resources
1 Accessing Hewlett Packard Enterprise Support
2 Accessing updates
3 Remote support
4 Customer self repair
5 Warranty information
6 Regulatory information
7 Documentation feedback

HPE MR Gen10 Plus ControllerHPE MR Gen10 Plus Controller

The HPE MR Gen10 Plus Controller is a family of tri-mode controllers ideal for maximizing performance while supporting advanced

RAID levels. This controller operates in Mixed Mode, which combines RAID and JBOD operations simultaneously.

This controller provides:

16 lanes across 2 x8 internal SlimSAS (SFF-8654) ports

16 Gbs NVMe, 12 Gbs SAS, 6 Gbs SATA

Mixed mode RAID and JBOD functionality simultaneously

UEFI and Legacy Boot modes

Support for Self-Encrypting Drive (SED)

Eight lane PCIe Gen4 host interface

Management tools:

MR Storage Administrator

IMPORTANT:IMPORTANT:

This controller is managed through the MR Storage Administrator. It cannot be managed using Smart Storage

Administrator or Intelligent Provisioning, or HPE OneView. MR controllers can be monitored by HPE OneView.

HPE StorCLI

UEFI Storage Configuration Utility

Redfish RESTful API

Figure 1: Figure 1: HPE MR Gen10 Plus ControllerHPE MR Gen10 Plus Controller naming framework naming framework

HPE MR Gen10 Plus Controller 7

200 series200 series

HPE MR216i-a Gen10 Plus Controller and HPE MR216i-p Gen10 Plus Controller are ideal for all virtualized environments where HBA /

Pass-through mode is applicable offering high-bandwidth and up to 3M IOPs (IO per Second) of 4KiB random read performance.

RAID levels — 0, 1, 10

Supported Supported HPE Gen10 PlusHPE Gen10 Plus servers servers HPE MR216i-a Gen10 PlusHPE MR216i-a Gen10 Plus HPE MR216i-p Gen10 PlusHPE MR216i-p Gen10 Plus

ProLiant DL325 Gen10 Plus v2

ProLiant DL345 Gen10 Plus

ProLiant DL360 Gen10 Plus

ProLiant DL365 Gen10 Plus

ProLiant DL380 Gen10 Plus

ProLiant DL385 Gen10 Plus v2

ProLiant DL20 Gen10 Plus

200 series 8

400 series400 series

HPE MR416i-a Gen10 Plus Controller and HPE MR416i-p Gen10 Plus Controller are ideal for all data center environments where RAID is

applicable offering reduced rebuild times, high-bandwidth, and up to 4.86GBs of RAID 5 sequential write performance.

RAID levels — 0, 1, 10, 5, 6, 50, 60

4 GB x72 flash-backed write cache.

Supported Supported HPE Gen10 PlusHPE Gen10 Plus servers servers HPE MR416i-a Gen10 PlusHPE MR416i-a Gen10 Plus HPE MR416i-p Gen10 PlusHPE MR416i-p Gen10 Plus

ProLiant DL325 Gen10 Plus v2

ProLiant DL345 Gen10 Plus

ProLiant DL360 Gen10 Plus

ProLiant DL365 Gen10 Plus

ProLiant DL380 Gen10 Plus

ProLiant DL385 Gen10 Plus v2

ProLiant DL20 Gen10 Plus

400 series 9

FeaturesFeatures

Features 10
