OPERATION MANUAL
HY-BUGGY
KART
1
HELMETS SAVE LIVES!
Always wear a properly fitted helmet that complies with CPSC or CE safety standards when you
ride.
Correct Fit:
Make sure your helmet
covers your forehead.
Incorrect Fit:
Forehead is exposed and
vulnerable to serious injury.
2
This manual provides you the information you need for the safe operation and maintenance of your Hover-1
Kart. Please read it thoroughly before riding your Hover-1 Kart.
INTRODUCTION
WARNING
Make sure you read this complete manual before riding
your Hover-1 Kart. Even if you are an experienced rider, it
is important that you read this manual to ensure your
safety. Failure to read the manual or follow its guidelines
could lead to serious injury or death.
Please visit
www.hover-1.com/troubleshoot
to request replacements for
missing or defective parts
3
HOVER-1 KART DIAGRAM
SPECIFICATIONS
1. Seat
2. Handlebars
3. Handlebar Mounts
4. Hook and Loop Strap
5. Seat Frame
6. Lockers
7. Front Frame
8. Foot Rests
9. Front Wheel
10. Flag
11. Flag Tube
Compatibility: Most 6.5” hoverboards
Max Supported Weight: Refer to your hoverboard’s manual
Wheel Size: 4” swivel caster wheel
Seat Material: Polypropylene
1
2
3
11
10
4
5
6
78
9
2
3
4
6
8
4
(1) Wrench
(2) Hex Keys
(2) Lockers
(2) 8 X 38 Screws
(4) M6 X 16 Screws
(2) 8 mm Nuts
(4) 6 mm Nuts
(4) Metal Washers
(1) Flag Set
(1) Flag Tube
PARTS LIST
(1) Seat
(1) Seat Frame
(1) Front Frame
(1) Right Handlebar
(1) Left Handlebar
(2) Hook and Loop Straps
(4) Spare Foam Pads
(4) Spare Hook and
Loop Straps
5
ASSEMBLING YOUR HOVER-1 KART
Remove all Hover-1 Kart contents from the box. Ensure all contents from the “PARTS LIST” section are accounted for.
1. Check the foam pads located underneath the handlebar mounts to ensure they are securely attached.
After riding for a while, they may wear down and fall o. You can replace the foam pads with the included
spare foam pads if needed. If the pads are secured, proceed to step 2. Otherwise, remove the adhesive
backing of the spare foam pads and stick them under the handlebar mounts.
6
2. Insert the left and right handlebar mounts into the seat frame as shown below. Align the holes of the handlebar
mounts with the holes in the seat frame. Align the hole of the ag tube with the hole in the seat frame on either
side. This will be where the ag is inserted later. Insert the 8 X 38 screws into the seat frame holes and attach the 8
mm nuts to the end of the screws by twisting them on clockwise. Hold the 8 mm nuts in place with the wrench and
turn the screws clockwise with the smaller hex key to tighten the screws. Make sure both screws are tightly secured.
3. Insert the front frame into the seat frame. Adjust the front frame to your preferred length. Remove the black bolt
and the rst white washer from the end of each locker. Fully insert the screwed section of one locker into the seat
frame holes. Add the white washer and black bolt back onto the locker once it is fully inserted and twist them on
clockwise until they are tightly secured. Close the locker clamp tightly. Repeat these steps on the other side of the
seat frame with the other locker.
Seat Frame
Flag Tube
7
4. Align the holes of the seat with the highlighted holes of the seat frame as show below. Insert the 4 silver washers
into the seat holes, then insert the M6 X16 screws. Attach the 6 mm nuts to the bottom of each screw, under the
seat frame. Twist the nuts on clockwise. Hold the 6 mm nuts still with the wrench while turning the screws clockwise
with the larger hex key to tighten the screws. Make sure all 4 screws are tightly secured.
5. Your Hover-1 Kart is now assembled and should look like the image below.
8
ATTACHING THE HOVER-1 KART TO YOUR HOVERBOARD
Carefully follow the instructions on the following pages to attach the Hover-1 Kart to your hoverboard. Read
this entire manual before riding your Hover-1 Kart.
Your Hover-1 Kart should be completely assembled prior to attaching it to your hoverboard. Please refer to the
“ASSEMBLING YOUR HOVER-1 KART” section of the manual for assembly instructions.
1. Place the handlebar mounts onto the foot pads of your hoverboard. Ensure the mounts are centered on
the foot pads of your hoverboard as much as possible.
9
2. Secure your Hover-1 Buggy to your hoverboard using 2 of the included hook and loop straps. With the
fastener side facing away from your hoverboard, thread the straps through the outside hole of each
handlebar mount.
3. Wrap the straps underneath the hoverboard and pull them through to the other side. Insert the straps into
the rear hole of the handlebar mounts. Fasten the front and rear sides of the straps. Make sure they are tightly
secured to the hoverboard.
