Hoshizaki KM-515MAH Manuel utilisateur

Hoshizaki

©HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com

C BER DIMENSIONS

WxDxH

KM-515M_H

5/08

Item # 13217

SLIM-LINE MOD LAR CRESCENT C BER

Warranty

Valid in United States, Canada, uerto Rico, & U.S.Territories. Contact factory for warranty in

other countries.

Three Year - arts & Labor on entire machine.

Five Year - arts & Labor on: Evaporator.

Five Year - arts on: Compressor, air-cooled condenser coil.

KM-515M_H

Item #

Project:

Qty:

Hoshizaki reserves the right to change specifications without notice.

KM-515M_H

22 x 273/8 x 305/16

*AutoCad available on KCL

•Up to 501 lbs. of ice production per 24 hours

•Durable stainless steel exterior

•Individual crescent cube

•Protected by HoshiGuard Antimicrobial Agent

•CycleSaver®Design

•EverChec ®alert system

•Stainless steel evaporator

•Mount two units side-by-side, in only 44" of floor space, for 1,002 lbs. per 24 hours

•Removable air filters (Air-cooled models only)

•Complies with California Energy Commission guidelines (CEC)

•R-404A Refrigerant

KM-515MAH

Air-Cooled

Shown on an optional

B-300

KM-515MWH

Water-Cooled

KM-515MRH

Remote Air-Cooled

B-500

B-700

B-900

B-800

B-300

Also availabl on Larg Bins:

B-1150SS

B-1300SS

B-1500SS

B-1650SS

* The KM-515MRH is ENERGY STAR certified.

Hoshizaki

DIMENSIONS

WxDxH

©HOSHIZAKI AMERICA, INC.

KM-515M_H

SLIM-LINE MOD LAR CRESCENT C BER

TILITY CONS MPTION

AIR-COOLED

Model Number

70˚

50˚ 70˚

501

90˚

80˚

90˚

Ice Production

Per Cycle

KWH per

100 LBS.

Potable

Water

Gal. per

100 lbs.

Lbs. Cubes

KM-515MWH

Air Temp˚ F.

Water Temp˚ F.

SPECIFICATIONS

Model Number Condenser Amperage Min. Circuit

Ampacity Shipping

Weight

9.6 20 175 lbs.

Water-Cooled

KM-515MWH

6.0 22.8

486

482

456

447

416

396

10.2 480

435

90/70

Condenser

Water

Gal. per

100 lbs.

N/A

O P E R AT I N G L I M I T S

• Ambient Temp Range 45 - 100˚F

• Water Temp Range 45 - 90˚F

• Water ressure 10 - 113psig

• Voltage Range 104 - 127V

O P E R AT I N G L I M I T S / R C - 5 F

• Ambient Temp Range -20˚F - +122˚F

• Voltage Range 104 - 127V

ELECTRICAL&PL MBING/KM-515M_H

• 115V/60/1

• 20 Amp Max Fuse/HACRBreaker Size

• 1/2” F T water inlet

• 3/4” F T water drain

SERVICE

• anels easily removed and all components

accessible for service.

• Removable/cleanable air filters.

(Air-cooled models only)

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com Printed in .S.A.

KM-515M_H

22 x 273/8 x 305/16

WATER-COOLED

70˚

50˚ 70˚

500

90˚

80˚

90˚

Air Temp˚ F.

Water Temp˚ F.

494

493

483

465

445

441

475

KM-515MAH

4.8 21.5

10.3 480 115

11.7 20 175 lbs.

Air-Cooled

KM-515MAH

STORAGE BINS

Model Number Application Capacity ARI-Rated Capacity

B-500 500 lbs. 360 lbs.

B-700 700 lbs. 550 lbs.

B-800 800 lbs. 600 lbs.

B-900 900 lbs. 660 lbs.

B-1150 1150 lbs. N/A

B-1300 1275 lbs. N/A

B-1500 1490 lbs. N/A

B-300 300 lbs. 260 lbs.

FRONT VIEW SIDE VIEW ICE DROP ZONE

AIR-COOLED NIT WATER-COOLED NIT

REMOTE AIR-COOLED

70˚

50˚ 70˚

491

90˚

80˚

90˚

Air Temp˚ F.

Water Temp˚ F.

482

480

465

443

417

408

452

KM-515MRH 5.8 20.8

10.3 480 N/A

11.3 20 175 lbs.

Remote

Air-Cooled

KM-515MRH

REMOTE AIR-COOLED NIT

17 1/8

32 13/16

URC-5F

Air Flow

Liquid Refrigerant

Line

Discharge Line

Electrical

Conduit

Access

Pre-Charged Tubing Kits

(Sold Separately)

20’ R404-2046-2

35’ R404-3546-2

RC-5F Remote Condenser (Sold Separately)

For Use with KM-515MRH

Voltage supply for the RC Remote

Condenser is supplied from the Ice Maker.

No additional circuit is required.

• Air-cooled

• Water-cooled

• Remote Air-cooled

21/2

13/4

18 1/8

B-1650 1605 lbs. N/A
