Hoshizaki DCM-270BAH Manuel utilisateur

Hoshizaki

©HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com

DIMENSIONS

WxDxH

DCM-270BAH

4/08

Item # 13116

SANITARY CUBELET ICE MACHINE/DISPENSER

Warranty

Valid in United tates, Canada, Puerto Rico, & U. .Territories. Contact factory for warranty in

other countries.

Two Year - Parts & Labor on entire machine.

Five Year - Parts on: hermetic compressor, air-cooled fin and tube type condenser.

DCM-270BAH

Item #

Project:

Qty:

Hoshizaki reserves the right to change specifications without notice.

DCM-270BAH

169/16 x 241/8 x 3111/16*

*with 4" legs

*AutoCad available on KCL

DCM-270BAH

•CleanCycle12® - Every 12 hours, unit perfor s 15 inute purge to rid itself of i purities

•Durable stainless steel exterior

•Up to 282 lbs. of ice production per 24 hours

•Easy to chew, cubelet ice

•Self contained design reducing opportunities for cross conta ination

•Dispenses ice and water

•Re ovable air filter

•Stainless steel internal auger

•R-404A Refrigerant

SD-270 Stand

•Heavy duty stand for floor odel ice aker/dispenser

•Corrosion resistant stainless steel exterior

•Easy cleaning with attractive appearance

•Locking door

DCM-270BAH

Air-Cooled

hown on an optional

SD-270 Stand

DCM-270

SD-270

161/2 x 24 x 353/16

SD-270

optional

stand

Hoshizaki

DIMENSIONS

WxDxH

DCM-270BAH

169/16 x 241/8 x 3111/16*

*with 4" legs

SD-270

161/2 x 24 x 353/16

©HOSHIZAKI AMERICA, INC.

DCM-270BAH

SANITARY CUBELET ICE MACHINE/DISPENSER

UTILITY CONSUMPTION

AIR-COOLED

Model Number

70˚

50˚ 70˚

282

90˚

80˚

90˚

KWH per

100 LBS.

DCM-270BAH

A r Temp˚ F.

Water Temp˚ F.

SPECIFICATIONS

Model Number Condenser Amperage Sh pp ng

We ght

8.5 165 lbs.

DCM-270BAH

7.6 12.0

248

219

271

238

259

228

201

Air-Cooled

215

90/70 70/50

5.5 12.0

O P E R AT I N G L I M I T S

• Ambient Temp Range 45 - 100˚F

• Water Temp Range 45 - 90˚F

• Water Pressure 10 - 113psig

• Voltage Range 104 - 127V

ELECTRICAL&PLUMBING/DCM-270BAH

• 115V/60/1

• 15 amp cord connection

• 1/2" FPT Water Inlet

• 3/4" MPT Drain

SE R I C E

• Panels easily removed and all components

accessible for service.

• Removable/cleanable air filter.

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com Printed in U.S.A.

• Air-cooled

• Optional stand with locking door

GAL per

100 LBS.

90/70 70/50

Flaked Ice compacted into Cubelets by Extrudin

Head Cutter and stored in an Insulated Bin with

Continuous A itation durin Dispensin and Direct

Dispensin Au er

Bin

Cutter

Extruding

Head

Evaporator

Refrigerant tubing

Freezing Cylinder

Stainless Steel Auger

Insulation

Gear Motor

Gear Train

Evaporator

N/A 95 lbs.

SD-270 N/A DCM-270

2711/16

3111/16

81/2

Ice making

lamp

Air Flow

Ice/ ater

dispenser

nozzle

4” Black legs

3/4 MPT Drain 1/2 FPT

water supply

9’ 16 A G

power cord

Removable

cleanable

air filter

For best performance

allow 6” clearance

for air circulation

121/4

169/16 241/8

20 13

4” Legs

9 lb. Capacity Built-in Bin

SD-270

35-3/16"

(894 mm)

29-3/16"

(741.4 mm)

6" Adj.

Le s

16-1/2"

(419.1 mm)

24"

(614 mm)
