Hored PS3016 Manuel utilisateur
User manual
PS3016
16 Port Layer 2 PoE Switch
1
Installation manual introduction
The Product installation manual mainly describes PS3016SPoE switch
hardware features, installation methods, and precautions during the
installation
This manual includes the following chapters:
Chapter 1: Product Introduction. Briefly describes the basic
features, Detailed hardware & software specifications of the switch
and the appearance details.
Chapter 2: Product Installation. Guide the switch hardware
installation methods and precautions.
Chapter 3: Hardware Connections. Guide the connection between
switches and other devices and precautions.
Chapter 4: Packaging and product usage suggestions.
2
Chapter 1: Product Introduction
1.1 Products description
PS3016S is managed PoE switch for security transmission and
WIFI coverage, meet the need of PoE power supply for WIFI AP,
IP-camera, WIFI bridge, IP phones and other types of equipment.
New generation of high-performance hardware and software
platforms are used, providing flexible, cost-effective full Gigabit
access and uplink ports, complete security mechanisms, improved
ACL / QoS strategy and rich VLAN capabilities. It is easy to
manage and maintain, meet the users' requirements for network
equipment easy to manage, high security and low cost.
Supporting Apollo Cloud One-stop Management Platform,
realizing status checking and management monitoring functions,
suitable for campus, Hotel and enterprise park network access,
convergence, core multi-application scenarios
3
1.2 Product Features
Full Gigabit Port
16 1000Mbps RJ45 ports (support PoE power supply) with 2
Gigabit SFP ports, Data transmission is not jammed.
Realtek chip, the performance is more stable and powerful
Realtek high-performance chip can greatly improve network
data processing rate
Convenient operation
·AI VLAN mode: Separating 1-8 ports from each other, can
effectively restrain network storm and improve network
performance.
·AI Extend mode: Designed for monitoring application
scenarios, 1-8 ports support 250 meters long distance power
supply.
·AI PoE mode：automatically check, reboot the device while
find it fake dead
·AI QoS mode：video data first, more fluent transmission
Support Apollo Cloud Platform One-stop Management
Support cloud platform for resource visualization management
of switches and downloaded PD devices, make operation and
4
maintenance management easy
1.3 product specification
Hardware Specifications
Chipset
RealtekHigh Performance Chipset
Flash
16MB
RAM
128M DDR
Port
16 10/100/1000Mbps RJ45 ports
210/100/1000Mbps RJ45ports
2 Gigabit SFP ports
1 Console port
PoE
16 10/100Mbps RJ45 port support
PoE+
Max 150W
Single port max 46W
LEDs
18 Link/Act LEDs
16 POE LEDs
1 Power LED
1 SYS LED
Performance
Forwarding mode: store and forward
Switch Volume (Full-duplex) ：7.2Gbps
Packet forwarding rate：5.36Mpps
8K MAC address table
lightning protection
±6KV
ESD
No barrier: ±6KV Air：±8KV
5
Input
100-240V/50-60Hz
Dimension
（L×W×H）
440mm×180mm×44mm
Software Specifications
Network standard
IEEE 802.3: Ethernet Media Access Control
(MAC) protocol
IEEE 802.3i:10BASE-T Ethernet
IEEE 802.3u:100BASE-TX fast Ethernet
IEEE 802.3ab:1000BASE-T gigabit Ethernet
IEEE 802.3z:1000BASE-X gigabit Ethernet
（fiber）
IEEE 802.3ad: comply link aggregation
standard
IEEE 802.3x: flow control
IEEE 802.1p: About the traffic priority of
the second layer of Qos / Cos protocol
(multicast filtering)
IEEE 802.1q:VLAN Bridge operation
IEEE 802.1d:STP spanning tree
IEEE 802.1s:MSTP spanning tree
IEEE 802.1w:RSTP spanning tree
IEEE 802.3af
IEEE 802.3at
Shortcut function
One key VLAN
One key Exnted(1-8 port 250meters PoE
distance)
6
One key QoS (Video priority)
One key AI power supply
DHCP
DHCP Snooping
VLAN
Support 4K VLAN
Support 802.1Q VLAN、Port VLAN、Voice
VLAN
MAC address table
Comply the IEEE 802.1d standard
Support MAC address learning and aging
automatically
Support static, dynamic, filter address table
Safety
Password protection
Support based on the port number, IP
address, MAC address restrictions on user
access
Support HTTPS、SSL V3、TLS V1、SSH
V1/V2
Based on user rating management and
password protection
Support IP-MAC-PORT
Support ARP protection, IP sources
protection, DoS protection
Support DHCP Snooping、DHCP attack
protection
7
Support 802.1X AAA
Support port security, port isolation
Support CPU protection
PoE
Support setting the PoE port priority
Support viewing POE Chip Status
Support setting PoE power supply period
Support setting port power
Access control (ACL)
Support L2(Layer 2)～L4(Layer 4) packet
filtering function
Support port mirroring, port redirection,
flow rate limit, QoS re-marking
QoS
Support 8 port queue
Support port priority, 802.1p priority, DSCP
priority
Support SP、RR、WRR、WFQ Priority
scheduling algorithm
Support automatically identify, manage
and acquire of connected equipment
information
Multicast
Support IGMP v1/v2 Snooping
Support static multicast
Support multicast VLAN
Support multicast filtering, message statistics,
unknown multicast discarding
8
Spanning Tree
Support STP(IEEE 802.1d)，RSTP(IEEE
802.1w) and MSTP(IEEE 802.1s) protocol
Support loop protection, BPDU protection
Storm suppression
Support for multicast suppression
Support broadcast suppression
Support for unknown unicast suppression
Link aggregation
Support static aggregation
Support dynamic aggregation
Support IP, MAC, hybrid load balancing
mode
Supports up to 32 aggregation groups
IPv6
Support IPv6 Ping、IPv6 Tracert、IPv6 Telnet
Support IPv6 SSH 、IPv6 SSL
Management and
maintenance
Support WEB management（HTTP、
HTTPS、SSL V3）
Support CLI（Telnet、SSH V1/V2，local
serial port）
Support SNMP V1/V2/V3
Support LLDP、RMON
Support SNMP
Support ARP Protection, IP Source
9
protection、DoS protection
Support CPU monitor、memory
monitoring
Support system log
Support Ping, Tracert detect cable testing
1.4 Appearance
Front Panel
Including indicators, RJ45 port, DIP switch, RST button, SFP port,
CONSOLE port, as shown below
indicator
PS3016S The indicator working status is shown as the
following table
PS3016S The indicator working status is shown as the
