Application Selection and

Cross-Reference Guide

Commercial Thermostats

GET CONTROL. GET HONEYWELL.

WEBSTAT®CONTROLLER T7350 T7351F COMMERCIAL VISIONPRO 8000®COMMERCIALPRO®7000 MULTIPRO™7000 ZONEPRO®FAN COIL LINE VOLT PNEUMATIC

For more than a century, Honeywell has been on the

leading edge of product development for energy-efficient

HVAC and building automation products. Contractors and

building owners count on Honeywell commercial thermostats

for the latest technology, ease-of-use and energy savings.

Support

Commercial Thermostats Hotline

1-763-954-6464

Web Site

customer.honeywell.com

New Product Information

customer.honeywell.com/buildings

Contractor PRO™Program

www.contractorpro.com

Technical and Sales Literature

customer.honeywell.com

For more information, please contact your local Honeywell

authorized distributor or Honeywell sales representative.

The Innovative Leader

WebStat® Controller

Web Accessible Thermostats

• Honeywell’sWebStat®system is composed of the

world-class T7350H Lo n Wo r k s ®communicating

thermostats combined with a single WebStat

controller which enables your network of T7350H

thermostats to be configured and monitored

from any computer with internet access from

anywhere in the world.

Features

• Configure/commission/monitorthrough

the same easy-to-use Web-based interface

• Freejobestimatingandsubmittaltoolsthatprovide

everything from wiring diagrams to guide specs

• Datatrendingforuseintroubleshooting

• Customizablefloorplanlayouts

OS Number Description Application

W7350A1000 WebStat®Controller with Lo n Wo r k s ®

Loncard and Power Supply Web-Based Network Controller

T7350H1009

Communicating Commercial

Programmable Thermostat

T735H1009: 3 Heat/3 Cool or 2 Heat/4 Cool

Conventional or 3 Heat/2 Cool Heat Pump

T7350H1017: Two 4-20 mA Outputs

for Modulating Applications

T7350H1017

WebStat®Features and Benefits Summary

Low Installed

Cost

Low Operating

& Service Cost Ease of Use Advanced

Comfort

Embedded Software • •

Integrated Graphic, Config

and Commissioning Tool •••

Wizard Programming Tool •••

Device Self Discovery •

Field Wiring & Sensor Avg. Diagrams • •

Thin Client Web Remote Monitoring ••••

Trending, Troubleshooting • •

Floor Plan Locator •

Remote Programming ••••

Multi-User Access View • •

User Privilege Setup •••

Advanced Dehumidification •

Special Event, Holiday Scheduling •(E)

Override Controls •(E)

Thermostat Assignment •(E)

Advanced Remote Sensing •

E=Energy Savings

T7350H

Communicating Thermostat

• CommunicationviaLo n Wo r k s ®Network

– Remote access for diagnostics

• Integratedhumiditysensor

– Several strategies for dehumidifying

• 365-DaySchedule

– Schedule holidays throughout the year

to save energy

• Remotesensing

– Indoor, outdoor, humidity, occupancy and

discharge air sensors available for added flexibility

 –OutdoorAirandDischargeAirTemperatureLockout

• Controlsupto3H/3Cor2H/4Cconventional

 systemsor3H/2Cheatpumps(T7350H1009)

– Flexibility allows the same thermostat to be

used on every RTU in the system

• Hastwo4-20modulatingoutputsforcontrolling

 heatingandcoolingvalves(T7350H1017)

– Allows thermostat to be used in hydronic

heating or cooling applications

– Control of staged and modulating hybrid systems

OS Number Description Application

T7350H1009

Communicating Commercial

Programmable Thermostat

T735H1009: 3 Heat/3 Cool or 2 Heat/4 Cool

Conventional or 3 Heat/2 Cool Heat Pump

T7350H1017: Two 4-20 mA Outputs

for Modulating Applications

T7350H1017

Replacements Sensor

Capabilities

Honeywell

White-Rodgers

Invensys/

Robertshaw

Carrier/Totaline

TCS/Basys

Controls

Communicating

T7350H1009

All T7300s

with Q7300H

Subbases

Equivalent

Offering

Equivalent

Offering

Equivalent

Offering

SZ1022,

SZ1024,

SZ1031,

SZ1033,

SZ1035,

SZ1009

T7771A1005,

TR21,

TR21-A

(averaging),

TR22,

TR23,

TR24,

C7772A1012

(flushmount),

C7770A1006

(returnairduct),

C7041P2004

(buttonsensor)

T7350H1017 No Previous

Offering

Equivalent

Offering

Equivalent

Offering

Equivalent

Offering

SZ1017a,

SZ1053

Compatible With These Honeywell Systems

LCBS

LonSpec™/LonStation™XL15B W7760B2001

WEBsAX™

T7350 Wizard

WebStat®

W7350A1000

T7350M

Modulating and Staged Thermostat

• Integratedhumiditysensor

– Several strategies for dehumidifying

• 365-DaySchedule

– Schedule holidays throughout the year to

save energy

• Remotesensing

– Indoor, outdoor, humidity, occupancy

and discharge air sensors available for

added flexibility

 –OutdoorAirandDischargeAirTemperatureLockout.

• Hastwo4-20modulatingoutputsforcontrolling

heating and cooling valves

– Allows thermostat to be used in hydronic

heating or cooling applications

• Controlofstagedandmodulatinghybridsystems

• PIDloop

 – FirstthermostatwithconfigurablePIDloop

OS Number Description Application

T7350M1008 Modulating Commercial

Programmable Thermostat

– Two 4-20 mA Outputs for Modulating Applications

– Two Relays for Staged Control

–AdvancedDehumidification

Replacements Sensor

Compatibility

Honeywell

White-Rodgers

Invensys/

Robertshaw

Carrier/Totaline

TBS/Basys Controls

Modulating

T7350M1008 No Previous

Offering

Equivalent

Offering

Equivalent

Offering

Equivalent

Offering

SZ1017a,

SZ1053

T7771A1005,

TR21,

TR21-A

(averaging),

TR22,

TR23,

TR24,

C7772A1012

(flushmount),

C7770A1006

(returnairduct),

C7041P2004

(buttonsensor)

T7350A,B,D

Standalone Staged Thermostat

• Integratedhumiditysensor(T7350D)

– Several strategies for dehumidifying

• 365-DaySchedule

– Schedule holidays throughout the year

to save energy

• Remotesensing(T7350B,D)

– Indoor, outdoor, humidity, occupancy and discharge

air sensors available for added flexibility

 –OutdoorAirandDischargeAirTemperatureLockout

• Controlsconventionalorheatpumpsystems

• Flexibilityallowsthesamethermostattobe

used on every top roof unit in the system

• PIDloop

 – FirstthermostatwithconfigurablePIDloop

OS Number Description Application

T7350A1004

T7350 Commercial

Programmable Thermostat

T7350A1004: 1 Heat/2 Cool and 2 Heat/1 Cool

Conventional, 2 Heat/1 Cool Heat Pump

T7350B1002 T7350B1002: 3 Heat/2 Cool and 2 Heat/3 Cool

Conventional, 3 Heat/2 Cool Heat Pump

T7350D1008

T7350D1008:3Heat/3Cooland2Heat/4Cool

Conventional, or 3 Heat/2 Cool Heat Pump with

 2AuxiliaryStages,AdvancedDehumidification

and Occupancy Option

Replacements Sensor

Compatibility

Honeywell

White-Rodgers

Invensys/

Robertshaw

Carrier/Totaline

TCS/basys Controls

Conventional/Heat Pump

T7350A1004

All T7300s

with

Q7300A2008

Subbase

1-F90-371,

1-F97-371,

1-F96-344,

1-F90-374,

1-F97-374

9700i, 9701i SZ1009

T7350B1002

All T7300s

with Q7300A

and Q3700C

Subbases

All

White-Rodgers

Thermostats

9700i Series,

300 Series

All Carrier/

Totaline

Thermostats

Sz1022,

SZ1024,

SZ1031,

SZ1033,

SZ1009

T7771A1005,

TR21,

TR21-A

(averaging),

TR22,

TR23,

TR24,

C7772A1012

(flushmount),

C7770A1006

(returnairduct),

C7041P2004

(buttonsensor)

T7350D1008

All T7300s

with

Non-Q7300H

Subbases

All

White-Rodgers

Thermostats

All Invensys/

Robertshaw

Thermostats

All Carrier/

Totaline

Thermostats

SZ1022,

SZ1024,

SZ1031,

SZ1033,

SZ1035,

SZ1009

T7351F

Standalone Staged Thermostat

• Keypadprogramming

– All configuration is done through the keypad

• Integratedhumiditysensor

– Several strategies for dehumidifying

• 365-DaySchedule

– Schedule holidays throughout the year

to save energy

• Remotesensing

– Indoor, outdoor, humidity, occupancy and discharge

air sensors available for added flexibility

 –OutdoorAirandDischargeAirTemperatureLockout

• Controlsconventionalorheatpumpsystems

• Flexibilityallowsthesamethermostattobe

used on every top roof unit in the system

OS Number Description Application

T7351F2010 T7351 Commercial

Programmable Thermostat

3 Heat/3 Cool and 2 Heat/4 Cool Conventional, or

3 Heat/2 Cool Heat Pump with 2 Auxiliary Stages,

AdvancedDehumidificationandOccupancyOption

Replacements Sensor

Compatibility

Honeywell

White-Rodgers

Invensys/

Robertshaw

Carrier/Totaline

TCS/basys Controls

Conventional/Heat Pump

T7351F2010

All T7300s

with

Non-Q7300H

Subbases

All

White-Rodgers

Thermostats

All Invensys/

Robertshaw

Thermostats

All Carrier/

Totaline

Thermostats

SZ1022,

SZ1024,

SZ1031,

SZ1033,

SZ1035,

SZ1009

T7771A1005,

TR21,

TR21-A

(averaging),

TR22,

TR23,

TR24,

C7772A1012

(flushmount),

C7770A1006

(returnairduct),

C7041P2004

(buttonsensor)

Schools

• Upto10holidayscanbescheduledintotheHoliday

Scheduler, which can be programmed to handle multiple

days per holiday event, can program closed days

during the summer or spring break and can be

 programmedforspecificcalendarevents.(AllModels)

• Dehumidificationfeaturescanbeusedtocontrol

dew points in buildings and can be deployed where

moisture is an issue, such as around school pools or

 inhumidlocations.(T7350D,M,HandT7351F)

• TemporaryOverridecanbeconfiguredfrom1to8hours

to allow override from unoccupied schedule to an

occupied schedule as well as for classrooms that are

onlyusedforpartsoftheweekorjustoccasionallyused.

 (AllModels)

• PIDAlgorithmisthebestcontrolalgorithmavailable

that can heat and cool large spaces, such as

gymnasiums or auditoriums, quickly and accurately.

 ThePIDAlgorithmisspecificallytunedforoversized

equipment and has a short sensor time constant that

 canreactquicklytodemandchanges.(AllT7350Models)

Banks

• Easy-to-useHolidayScheduler.(T7350B,D,M,H

andT7351F)

• T7350Palm®Software comes pre-configured with

all bank holidays for easy programming into the

 thermostat.(AllT7350Models)

Healthcare and Gym Facilities

• Solidsolutionforrooftopunitsonfacilitiesthatdemand

very accurate temperature and enthalpy control.

 ThePIDAlgorithmwillmaintainthemostaccurate

 temperaturecontrolinthefacility.(AllT7350Models)

• Dehumidificationfeaturesareidealforcontrolling

high-moistureareas.(T7350D,M,HandT7351F)

Restaurant/Food Service

• PIDCommercialAlgorithmprovidesthebest

comfort control to react to the constantly changing

food service and restaurant environments, reacting

quickly to changing load demands via fast-sensing

timeconstants.(AllT7350Models)

• RemoteSensingconfigurationoptionsallowtheuseof

commercial20Kohmand10Kohmsensorstocreate

 a20Kohmaveragingnetwork,agoodsolutionforfood

service locations that have high load demands.

 (T7350B,D,M,HandT7351F)

• Economizerfunctionallowsrestaurantstomeet

ventilation requirements and is also important to

balance the air intake of the restaurant. Restaurants that

are not properly balanced do not achieve good comfort

controlastheydrawinunconditionedair.(AllModels)

Churches/Public Worship

• PIDAlgorithmisthebestcontrolalgorithmavailablethat

can heat and cool large spaces, such as sanctuaries

andfellowshiprooms,quicklyandaccurately.ThePID

Algorithm is specifically tuned for oversized equipment

and has a short sensor time constant that can react

quicklytodemandchanges.(AllT7350Models)

• T7350WallModules,includingtheT7771,TR22,TR23

andTR24modelsallowforsetpoint-onlyadjustmentwith

range stops, temporary override control or a combination

of both to provide the end-users with flexibility to provide

optimalcomfortduringoccupiedevents.(T7350B,D,M,H

andT7351F)

Retail

• CustomizableRecoveryRampfeatureguarantees

the exact temperature specified when the store opens,

ensuringcustomerandstaffcomfort.(AllModels)

• Easy-to-useHolidayScheduler.(AllModels)

• Forenergymanagement,theT7350DemandLimit

BumpandDemandLimitControlcanbeprogrammedwith

communicating versions of the T7350 to provide energy

savings when rooftop units can be staggered to control

energycostsduringpeakperiods.(T7350H)

T7350/T7351F Applications

Office Building Zones

• TheT7350isoneoftheonlyHoneywellthermostatsthat

integrate with occupancy sensors for office zones

that are normally unoccupied or partially occupied.

(T7350D,M,HandT7351F)

• T7350WallModules,includingtheT7771,TR22,TR23

andTR24modelsallowforsetpoint-onlyadjustmentwith

range stops, temporary override control or a combination

of both to provide the end-users with flexibility to provide

optimalcomfortduringoccupiedevents.(T7350B,D,

M,HandT7351F)

• CustomizableRecoveryRampfeatureguaranteesthe

exact temperature specified when the office opens.

(AllModels)

Heat Pumps

• OutdoorAirSensorautomaticallyturnsoffheatpump

equipment in cold climates. The T7350 is the only

Honeywell thermostat that uses both an outdoor air

sensor and indoor sensors/wall modules for heat pump

controlapplications.(T7350B,D,HandT7351F)

Equipment Protection

• DischargeAirSensordetectsabnormallyhighorlowdis-

charge air temperatures and shuts down equipment

 iflimitsareexceeded.(T7350B,D,M,HandT7351F)

Modulating Control —

Discharge Air Control

• BytuningthePIDloop,optimalcontrolcanbeachieved.

20Kohmductsensorscanbeusedinthewallmoduleter-

minals for temperature sensing. The modulating output will

controlthedamperposition.(T7350M,H)

Modulating Control –

Hydronic Boilers and Pumps

• Combinemodulatingcontrolandon/offrelaycontrol.

The modulating output can control modulating actuator

valves during the heating season and up to 2-stage

 conventionalcoolingduringthecoolingseason.(T7350M,H)

• Idealforsplitsystemsthathaveseparateheatingand

cooling equipment and need both a modulating output

and a conventional output. The fan relay can be config-

uredforeitherconventional(plenumswitchcontrolsfan)

orelectric(thermostatenergizedfanoncallforheat)

applications.(T7350M,H)

• Varioushydroniccontrolapplicationsarepossible,

including unit ventilators, fan coils or any other modulat-

ing system. The modulating outputs support both direct

andreverseactingsignals.(T7350M,H)

Communicating Control

• UsingtheHoneywellCommandDisplayS7760A,the

Honeywell LonStation™front-end or the Honeywell XL15B

Web Building Manager, a single user interface can be

accessedtoperformthefollowingfunctions:(T7350H)

– Group Scheduling

– Group Override/Setback

 – Trending(notsupportedwithcommanddisplay)

 – Alarming(notsupportedwithcommanddisplay)

 – DemandLimitControl(XL15Bonly)

– LonSpec™Configuration PC Tool

 – Web-BasedControl(XL15Bonly)

 – Dial-UpControl(LonStationonly)

Web-Based Interface

• UsingHoneywell’sWebStat®Controllerinconjunction

with the T7350H communicating thermostats allows for

a single user interface to be used during system setup,

commissioning, monitoring and troubleshooting. With the

WebStat Controller, the following functions are enabled:

– Group Scheduling

– Group Override-Setback

– Trending

– Alarming

– Custom Graphics

and Floorplans

OS Number Benefit

T7350A1004 Energy Savings, Comfort, Fresh Air

T7350B1002 Energy Savings, Comfort, Fresh Air

T7350D1008 Energy Savings, Comfort, Fresh Air,

Dehumidification

T7351F2010 Energy Savings, Comfort, Fresh Air,

Dehumidification

T7350M1008 Energy Savings, Comfort, Fresh Air,

Dehumidification,Modulating

T7350H1009 Energy Savings, Comfort, Fresh Air,

Dehumidification,Communicating

T7350H1017 Energy Savings, Comfort, Fresh Air,

Dehumidification,Modulating,Communicating

Commercial

VisionPRO®8000

Programmable Touchscreen Thermostat

• Touchscreenuserinterface

– The sleek design, menu-driven programming

and large touchscreen display are all here

• Savesenergy

– Effortless programming helps your customers

save up to 33% off their energy bill1

• Meetscommercialbuildingcodes

– Pre-occupancy Purge, Economizer Output and

Override Limits meet all fresh air and override

limitation requirements

– Qualifies for utility rebates2

– Title 24/IECC/ASHRAE codes

• Multiplelockoutlevels

– Save energy and money by preventing

unauthorized setting changes

• Compatiblewithauxiliarycommercialdevices

– Commercial sensors

– Economizers

• Commercialcomfort

– Commercial Algorithm, configurable recovery ramps

and temporary override button allow users to control

at setpoint and guarantee a comfortable environment

1If used as directed. Savings may vary depending on geographic

region and usage.

2Where applicable.

OS Number Description Application

TB8220U1003 Commercial VisionPRO®8000

Programmable Thermostat

– 2 Heat/2 Cool Conventional

– 3 Heat/2 Cool Heat Pump

Replacements Sensor

Compatibility

Honeywell

White-Rodgers

Invensys/

Robertshaw

Carrier/Totaline

Commercial

VisionPRO®8000

TB8220U1003

T7300 with

Q7300A2016,

Q7300A2008,

Q7300C2004

and

Q7300C2012

Subbase

IF90 Series,

IF80 Series

9800 Series,

9700i Series,

300 Series

P374-2100,

P374-2200,

P374-2300,

33S250-01,

33CS220-01,

33CS071-01,

33CSSP2-WC,

33CSSN2-WC

TR21,

TR21-A

(averaging),

C7772A1012

(flushmount),

C7770A1006

(returnair

duct),

C7041P2004

(buttonsensor)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Honeywell Thermostat

Honeywell

Honeywell RET93E Series Manuel utilisateur

Honeywell

Honeywell MAGICSTAT 3355 Manuel utilisateur

Honeywell

Honeywell RTH8500 Series Manuel utilisateur

Honeywell

Honeywell RET97B5D Manuel utilisateur

Honeywell

Honeywell Lyric Enrollment Manuel utilisateur

Honeywell

Honeywell Chronotherm IV Manuel utilisateur

Honeywell

Honeywell 2080WL Manuel d'utilisation

Honeywell

Honeywell RTH7000 Manuel utilisateur

Honeywell

Honeywell TL8100 Manuel utilisateur

Honeywell

Honeywell TL7135A Manuel utilisateur

Honeywell

Honeywell VisionPRO TH8000 Series Manuel utilisateur

Honeywell

Honeywell T451A Instructions d'installation et d'utilisation

Honeywell

Honeywell INNCOM e7 Manuel utilisateur

Honeywell

Honeywell T4098A Manuel d'utilisation

Honeywell

Honeywell T8611M7065 Manuel utilisateur

Honeywell

Honeywell RTH230B - 5-2 Day Programmable Thermostat Manuel utilisateur

Honeywell

Honeywell T6811 Manuel utilisateur

Honeywell

Honeywell Lyric Round TH8732WFH-5002/U Manuel utilisateur

Honeywell

Honeywell RTH3100C Manuel utilisateur

Honeywell

Honeywell FocusPRO TH6320WF02 Manuel utilisateur

Honeywell

Honeywell LP916A-C Manuel utilisateur

Honeywell

Honeywell Braukmann T104F Manuel utilisateur

Honeywell

Honeywell RTH8500 Series Manuel utilisateur

Honeywell

Honeywell ST772 Manuel utilisateur

Manuels Thermostat populaires d'autres marques

EWELLY

EWELLY EW-181 Manuel utilisateur

Prolon

Prolon T1100 Instructions d'installation

Computherm

Computherm Q20 Manuel utilisateur

Heatmiser

Heatmiser neoStat Manuel utilisateur

Aube Technologies

Aube Technologies TH111GFCI-NP 240 VCA Manuel utilisateur

Mars

Mars HEAT CONTROLLER IR Wireless Thermostat Manuel utilisateur

Saswell

Saswell SAS920XWHB-7-S-RF Mode d’emploi

Aircalo

Aircalo TFP1-ET85P2 Manuel utilisateur

Carrier

Carrier DEBONAIR 33CS Manuel utilisateur

Lennox

Lennox iHarmony Zone Thermostat Instructions de montage

Gemtech

Gemtech GT7000 Mode d’emploi

Rollei

Rollei Smartes 45000 Manuel utilisateur

Sinope

Sinope TH1300RF Manuel utilisateur

NuTone

NuTone NTBZ48 Instructions d'utilisation d'origine

Stelpro

Stelpro MAESTRO ASMT402AD Manuel utilisateur

Aube Technologies

Aube Technologies TH305 Manuel utilisateur

Powtier Controls

Powtier Controls 505MST Manuel utilisateur

Kanmor

Kanmor Zone Control 369e Manuel utilisateur
