HIGH RESOLUTION VFAI LENS DAY/NIGHT

INDOOR MINIDOME CAMERA

Honeywell’s HD3HRSX high resolution indoor fixed minidome camera delivers

superb image quality in almost any lighting and is easy to install.

The HD3HRSX incorporates the latest Digital Signal Processing (DSP) and Digital

Noise Reduction (DNR) technology to produce extremely sharp, clear images

regardless of lighting levels. DNR removes noise artifacts from the image, improving

motion detection performance and enabling longer DVR recording times. Offering

600 TV lines of horizontal resolution with a minimum illumination of 0.05 lux, the

HD3HRSX captures the smallest details with outstanding accuracy.

Installation is fast and easy. The housing pieces snap together so there are no

screws to remove and the camera converts easily to a surface or flush mount for

direct installation to a ceiling, wall, or 2S electrical box. With the built-in “push and

turn” brackets no additional mounting hardware is required for flush mounting on

a ceiling or wall. The HD3HRSX comes with a 2.8–12 mm (F1.4) varifocal auto iris

(VFAI) lens for a wide range of viewing angles and a 3D axis gimbal provides 360°

of pan, 70° of tilt, and 360° of horizontal rotation for precise camera positioning.

A second video output and on-board OSD controller are provided for on-site

adjustments.

Market Opportunities

Superb picture quality, true colour reproduction, and enhanced low-light

performance makes the Honeywell HD3HRSX minidome camera the ideal solution

for a wide range of indoor surveillance applications, including banks, ATMs,

reception areas, atriums, commercial or government facilities, schools, casinos,

retail stores or hospitals.

Features

• 1/3"InterlineTransferCCD

• Highresolution:600TVL

• 2.8–12mm(F1.4)VFAIlens

• Day/nightfunction

• 3Ddigitalnoisereduction

• 3Daxisgimbal

• Secondvideooutputand

on-screen display for easy setup

• Dualvoltage:12VDCor24VAC

power input

• Surface,flush,andpendantmount

options available

HD3HRSX

Surface Mount

Flush Mount

SPECIFICATIONS

Operational

Video Standard PAL

Image Sensor 1/3"InterlineTransferCCD

Number of Pixels (H×V) 795 × 596 (PAL)

Minimum Illumination 0.05 lux @ F1.4, 50 IRE

Horizontal Resolution 600 TVL

Video Output (Aux) 1.0 Vp-p @ 75 ohms

Sync System Internal

S/N Ratio 50 dB or more (AGC off)

Auto Gain Control Low/Mid/High/Highest

Automatic Electronic

Shutter

1/60 to 1/100,000 s (NTSC)

1/50 to 1/100,000 s (PAL)

Sense-Up ×2 to ×1024

Lens Type 2.8–12 mm VFAI, DC drive, F1.4

Gamma 0.45

Day/Night Auto/Colour/BW

3D DNR Off/Low/Mid/High/Smart

Motion Detection 4 programmable zones

Privacy Mask 8 programmable zones

White Balance AWC/ATW/Manual/Push Lock

Highlight Masking On/Off

Backlight Compensation On/Off

Electrical

Input Voltage 12 V DC/24 V AC

Input Range 11–16 V DC, 17–28 V AC

Power Consumption 2.2 W (max)

Mechanical

Dimensions

(W × H) 120 × 97.6 mm

Weight 0.3 kg

Construction Housing:ABS

Bubble:Polycarbonate

Connectors

Mainvideo:BNC(coax)

Auxvideo:2-pinconnector

Powerinput:2.1mmplug

Environmental

Temperature Operating:–10°Cto50°C

Storage:-20°Cto60°C

Relative Humidity 0% to 90% non-condensing

Regulatory

Emissions FCC, Part 15, Class A

EN 55022

Immunity EN 50130-4

Safety EN 60065

UL/CSA 60065

Recommended Accessories

Housing Mount

HD3-MK1 Pendant/Wall Mount Kit

120 mm

97.6 mm

85 mm

94.6 mm

32.5 mm

Ordering

HD3HRSX HighResolution,Day/Night,IndoorMinidomeCamera,1/3"CCD,600TVL,2.8–12mmVFAI,12VDC/24VAC,PAL

For additional information,

please visit www.honeywell.com/security/uk

Honeywell Security Group

Aston Fields Road

Whitehouse Industrial Estate

Runcorn

Cheshire

WA7 3DL

Tel:08448000235

www.honeywell.com

HD3HRSX

HVS-HD3HRSX-01-UK(0213)DS-E

February 2013
