Honeywell HD3CHS Manuel utilisateur

Document 800-05321 – Rev B – 05/10

User Guide

3 Inch Dome Camera

NTSC / PAL

HD3CHS HD3CHSX

Revisions

Issue Date Revisions

A 03/10 New document.

B 05/10 Change ‘Senes-Up’ to ‘Sens-Up’ on page 17.

Document 800-05321 Rev B 3

05/10

Warnings

Installation and servicing should be performed only by qualified and

experienced technicians to conform to all local codes and to maintain your

warranty.

WARNING! The Use of CSA Certified/UL Listed Class 2 power

adapters is required to ensure compliance with

electrical safety standards.

WARNING! To reduce the risk of fire or electrical shock, do not

expose the product to rain or moisture.

WEEE (Waste Electrical and Electronic Equipment). Correct disposal of

this product (applicable in the European Union and other European

countries with separate collection systems). This product should be

disposed of, at the end of its useful life, as per applicable local laws,

regulations, and procedures.

Explanation of Graphical Symbols

RISK OF ELECTRIC

SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE THE COVER.

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL

THIS SYMBOL INDICATES THAT

DANGEROUS VOLTAGE

CONSTITUTING A RISK OF

ELECTRIC SHOCK IS PRESENT

WITHIN THE UNIT.

THIS SYMBOL INDICATES THAT

IMPORTANT OPERATING AND

MAINTENANCE INSTRUCTIONS

ACCOMPANY THIS UNIT.

CAUTION

FCC Compliance Statement

Information to the User: This equipment has been tested and found to

comply with the limits for a Class A digital device. Pursuant to Part 15 of the

FCC Rules, these limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely

to cause harmful interference in which case the user will be required to

correct the interference at his own expense.

Caution Changes or modifications not expressly approved by the

party responsible for compliance could void the user’s

authority to operate the equipment.

This Class A digital apparatus complies with Canadian ICES-003.

Manufacturer’s Declaration of Conformance

The manufacturer declares that the equipment supplied with this guide is

compliant with the essential protection requirements of the EMC directive

2004/108/EC and the Low Voltage Directive LVD 2006/95/EC, conforming

to the requirements of standards EN 55022 for emissions.

Document 800-05321 Rev B 5

05/10

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Unpack Everything . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Cautions and Operating Notes . . . . . . . . . . . . . . . . . . . . . . . 7

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Disassembling the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connecting the Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Mounting the Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Configuring the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Camera Setup Functions . . . . . . . . . . . . . . . . . . . . . . . 12

Adjusting the Camera Position. . . . . . . . . . . . . . . . . . . . . . . 13

On-Screen Display (OSD) Menu Structure . . . . . . . . . . 15

Main Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Setting the Lens and Brightness Level . . . . . . . . . . . . . 16

Optimizing the Lens Setup . . . . . . . . . . . . . . . . . . . . . . 16

Setting the White Balance . . . . . . . . . . . . . . . . . . . . . . . 18

OSD Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Completing the Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Attaching and Securing the Dome Cover . . . . . . . . . . . . . . 25

Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Product Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Accessory Mounting Application . . . . . . . . . . . . . . . . . 27

Warranty and Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Document 800-05321 Rev B 7

05/10

Introduction

The HD3CHS Series CCTV Camera is ideal for indoor installations in

commercial and residential environments.

Before You Begin

Please read this guide carefully before you install the HD3CHS Series 3

Inch Dome Camera. Keep this guide for future reference.

Unpack Everything

Check that the items received match those listed on the order form and

packing slip. The HD3CHS Series 3 Inch Dome Camera packing box

should include, in addition to this Install Guide:

If any parts are missing or damaged, contact the dealer you purchased the

camera from or call Honeywell Customer Service.

• One fully assembled camera • One hardware kit containing

mounting screws

• One 2nd video monitor output

cable

• One mounting template

• Two Honeywell labels •

Cautions and Operating Notes

Power Supply This dome camera can operate on 24 VAC or 12 VDC.

Operating Conditions

Avoid viewing very bright objects (example, light fixtures) for extended

periods.

Avoid operating or storing the unit in the following locations:

• Extremely humid, dusty, hot/cold environments (where the operating

temperature is outside the recommended range of 14°F to 122°F

[-10°C to +50°C])

• Close to sources of powerful radio or TV transmitters

• Close to fluorescent lamps or objects reflecting light

• Under unstable light sources (may cause flickering)

Document 800-05321 Rev B 9

05/10

Installation

The HD3CHS Series is a fully-integrated enclosure with camera and lens.

Figure 1 Camera Parts

Legend

aVideo output connector

b24 VAC/12 VDC power input

connector (red+, black-)

1Side notch used for surface run

power/video connector

2Camera base

3Camera housing lock

4Camera housing

5Bubble

6Zoom lever

7Focus lever

Note See Figure 4 for an explanation of the camera board settings.

Disassembling the Camera

1. Gently turn the camera housing (#5 on Figure 2) counter-clockwise to

unlock and pull free of the camera base. Note the two line markers.

2. Remove the inner liner (#4) by gently pulling it free of the two notches

(#3) in the camera housing (#5). Set the housing, bubble (#6) and

liner aside.

Figure 2 Camera Disassembly

Legend

1Camera base (including gimbal)

2Line markers

3Tilt adjustment bracket and

thumbnuts, Notches (x2)

4Inner liner

5Camera housing

6Bubble
